NASA Developed AIDC Products
Fred Schramm Engineering Directorate NASA
Marshall Space Flight Center
Department of Defense UID IPT June 3, 2005
2
NASA Thanks Those Who Protect Our Freedom
3
Direct Part Marking
4
DoD..NASA... Work Together
A History of Collaboration
Direct Part Marking Project
1984 laser etching studies by the USAF (Jane
Channell) with NASA 1984-1988 Air Force
provided consulting services for Shuttle
DPM 2001 DoD, NASA and others developed the DPM
Standard 6002 and Handbook 6003 2002 2005 DoD
and USCG work with NASA and licenseesNCMS
marking development and pilot studies 2005- UID
initiative explores common ground
5
NASA Direct Part Marking Project
1986 Challenger Return to Flight Configuration
Mgt Improvement 2001 Result.NASA Standard and
Handbook
NASAs Primary Emphasis
.Item-Level Traceability
.Track the Piece
Left 10x10 matrix symbol on the head of a
straight pin
Below 10x10 matrix symbol on the side of a
turbine blade
Know the Pedigree .Know who made it
.Know who marked it
.Know who stands behind it
6
International Space Station Materials Experiment
7
NASA Direct Part Marking Project
NASA Direct Part Marking Standard 6002 and
Handbook 6003 Currently in final review for
Revision B
http//standards.nasa.gov Free Download.Public
Site
8
Read Through Paint
9
May 2005 Welcome to The CTMA Connector, a monthly
newsletter designed to provide news and ideas
about the Commercial Technologies for Maintenance
Activities (CTMA) program. The CTMA program is a
joint Department of Defense/National Center for
Manufacturing Sciences (DoD/NCMS) effort
promoting collaborative technology development
between industry and the DoD maintenance and
repair facilities. This newsletter highlights
ongoing projects, serves as a forum for promoting
new project ideas, and provides other news of
interest to the program.


Direct Part Marking (DPM) For High Strength Metals and Painted Over Articles Problem DPM of high strength metals painted over articles is difficult. The overhaul cycles of the high strength steel components typically require shot blast  or a grit blast process that only a fused on data symbol can survive. Other parts requiring Direct Part Marking requires the data symbol to get covered with paint to protect the part from corrosion.   The problem is to find a non-invasive method that allows for the rapid fusion of a DPM to high strength metal substrates.  Another related problem is to find a way to apply direct part marks to paint over articles allowing the data symbol to be read through the paint Solution Find a non-invasive method that allows for the rapid fusion of a DPM to high strength metal substrates. NCMS Contact Steve Hale, steveh_at_ncms.org, 734-995-2195 May 2005
10
Magnetic Handheld Reader A portable magnetic
scanner about the size of a hair dryer Decodable
images (right) through 15 mils of copy paper or
paint (6 layers) Licensee RVSI
NASA Read-Through-Paint Products
Commercially available Licenses available
11
NASA Read-Through-Paint Products
Magnetic Marks on Coast Guard Plane Door
Mark Survived 8 Months of Duty
Mark Decoded
Mark Easily Imaged
12
NASA Read-Through-Paint Products
Ultrasonic Handheld Reader A portable
ultrasonic scanner about the size of a hair
dryer Decodable images (right) through 15 mils
of copy paper or paint (6 layers)
Commercially available Licenses available
13
Autofocus
Angular and Distance Reads
14
Autofocus Distance Scanner
No contrast mark on smooth aluminum
NASA Optical Scanner For Visible Marks
Shiny screwdriver
Licenses available
15
Stretch Codes
16
Unusual Applications
http//directmeasure.com/
17
NanoCodes
18
Nanocodes
X-ray Fluorescence. A New Way To
Find.............Unapproved Parts
19
Nanocodes
Standard XRF Detection Range Titanium, Nickel,
Steel alloys General analyses for heavier
elements
Licensee KeyMaster Technologies
20
Nanocodes
X-Ray Fluorescent Spectral Data Output
gt

• X-ray fluorescent analysis
• detects elements present
• Software converts to ASCII
• and code of choice
• Can be matched with printed
• codes in other places

gt
gt
Conversion
gt
21
Nanocodes
If you had to put a bar code inside a
softball, then read it through the cover how
would you do it?
Let XRF Put the Bar Codes Inside!!!
22
Nanocodes
New Vacuum XRF Extended Detection Range

Sodium and Heavier.. Of Interest are Aluminum
and Magnesium for Alloys.. Silicon for
Contamination and Electronic Applications Sodium
, Sulfur and Calcium for Chemical Applications
23
Nanocodes Using X-ray Fluorescence
How would you bar code a carpet fiber ???
24
(No Transcript)
25
Direct Mark RFID
Vacuum Arc Vapor Deposition Spray-on Circuits
26
(No Transcript)
27
Spray-on Circuits/Sensors
Vacuum Arc Vapor Deposition Spray-on Circuits
Apply materials for ultra-thin memory devices
(nanometer to microns thick) Circuits (use
patterns for a circuit mask) Radio frequency
tags are first application
Single layer circuits applied in the field with
hand-held (near futurebetter masks)
Multi-layer circuits applied under controlled
conditions with positioning tooling (requires
development and culture shift from subtractive to
additive circuit making)
28
Spray-on Circuits/Sensors
Spray-on Circuits/Sensors Business
Information OEM Partner VATI to Build VAVD
Equipment. Licensee for Spray-on Circuits to
Develop Product Intaka Dinesh Vadhia, CEO 400
East Remington Drive, Sunnyvale, CA 94087
650-996-4927 dineshbvadhia_at_hotmail.co
m Patent Status Patent 6,866,752 issued March
15, 2005 License Opportunity Available
Contact Sammy Nabors at Marshall Space Flight
Center Sammy.nabors_at_nasa.gov or 256-544-5226
29
U I D Technologies
30
Automatic Identification Fully Integrated (tempora
ry to permanent to intrinsic marks for routine to
the most secure product ID and validation
matching)
RFID
Direct Mark
Magnetic
Visible
Ultrasonic
XRF
Five Levels of Auto ID Work Together Transparent
to IT System
31
