Title: SUSTAINABILITY


1
  • SUSTAINABILITY
  • February 13, 2009

2
  • R.F. Rick Shangraw, Jr., PhD
  • Vice President of Research and Economic Affairs
  • Arizona State University

3
Lubricants to Biofuels Chemical Feedstocks
fromPhotosynthetic Bacteria
  • Contact Information Neal Woodbury
  • Nwoodbury_at_asu.edu
  • Team Leaders Wim Vermaas, Bruce Rittman, Deirdre
    Meldrum, Roy Curtiss

4
A Variety of Useful Chemical Feedstocks Can Be
Made Using Photosynthetic Microbes
  • Lipids
  • Biodiesel (or green diesel)
  • Jet fuel
  • Lubricants
  • Surfactants (detergents)
  • Cooking oils
  • Isoprene
  • Hydrogen
  • Polyhydroxybutarate
  • Bioplastics
  • Carbohydrates
  • Food additives
  • Bioplastics
  • Proteins
  • Animal feed
  • Food additives
  • Carotenoids
  • Other specialty chemicals

But what to focus on?
5
  • Biolubricants The low hanging fruit
  • 37.4 MM tons used annually
  • Relatively high margin compared to liquid fuels
  • Relatively low production level can allow
    market entry
  • More channels to the marketplace
  • Benign regulatory path compared to food oils
  • Relatively un-crowded area in the renewable
    space

6
The Key PlayerThe cyanobacterium, Synechocystis
sp. PCC 6803
7
Why Bacteria Instead of Plants?
vs.
8
Comparison of Solar Energy Conversion In Plants,
Microalgae and Si-based PV
Data derived from http//www.hort.purdue.edu/newcr
op/duke_energy/dukeindex.html and http//www.green
fuelonline.com/gf_files/performance20Summary20Re
port.pdf
9
Advantages of Photosynthetic Bacteria vs. Plants
  • superior energy conversion yield
  • independent of arable land
  • low water usage
  • facile genetic engineering
  • CO2 from power plants can be used
  • wide range of possible products/high purity
  • rapid growth (short generation time)
  • no limitation on seasonal growth
  • efficient recycling of nutrients

10
TID Project Phasing
Phase 1 (yrs 1-2)
Benchtop Photobioreactors
Phase 2 (yrs 3-5)
Notional Location to Depict Size
Phase 3 (yrs 5)
Commercial scale deployment
Rooftop Photobioreactors
11
Next Steps
  • Our business plan exploits investments made
    (gt5M) in
  • this technology to date.
  • Presently at a 4,000 liter scale bioreactor
  • Market entry requires 3 logs greater scale.
  • We need to raise 25 to 30 million for a three
  • year project that will demonstrate ability to
    scale.
  • Continuing improvements to the bacteria will
  • increase yields and lower costs.

12
Technology for Production of the Natural Pigment
and Antioxidant - Astaxanthin
Present at ASU Technology Forum by Qiang Hu
Milton Sommerfeld Laboratory for Algae Research
and Biotechnology Arizona State
University February 13, 2009
13
Astaxanthin
  • Naturally occurring carotenoid pigment
  • Powerful biological antioxidant
  • Anti-Inflammatory and stress-releasing agent
  • UV light protection
  • US FDA approved as a food coloring
  • Food dye within the European Commission

14
Astaxanthin Market Opportunities
15
Astaxanthin Problems
  • High production costs
  • - Photobioreactors
  • - Processing
  • - Product stability
  • Low bioavailability
  • - 8 30
  • - short shelf-life
  • High sale price
  • - 6,000 10,000/kg

Algatech
Parry Nutraceuticals
16
Astaxanthin Solutions
  • Improved algal strains
  • Highly efficient photobioreactors
  • Optimized production protocol
  • Reduced Cost
  • capital gt60
  • operational gt30
  • Improved bioavailability
  • 60 90
  • longer shelf-life
  • Lower sale price
  • gt 2000/kg

17
Competitive Advantages
18
Business Model
  • First market segment will be animal feed sector,
    then nutraceutical and cosmetics, followed by
    pharmaceutical sector
  • Establish strategic alliances with major
    customers, thereby
  • providing them with bulk quantities of
    Haematococcus biomass
  • and/or pure astaxanthin
  • Funding/investment sources SBIR, SFAz, equity
    financing, venture capital investment, individual
    investors, etc.
  • Joint-venture with strategic partners

Exit Strategy
  • IPO in 2014
  • Possible M A
  • JV with strategic partner/s

19
IP Status
  • Patents filed
  • Wall-less Haematococcus mutant and
    uses
  • (PCT filed March 31, 2006)
  • Photobioreactor and uses therefore
  • (PCT filed on February 20, 2007)
  • Trademark and trade secret protection

20
Pro Forma Financials
NPV 16 - 17 M (i 40)
21
Interim Management Team
  • CEO Qiang Hu, Ph.D.
  • Professor of Applied Biological Sciences at
    ASU
  • 20 years of experience in algae research
  • Extensive RD experience in algal
    biotechnology
  • Expert in photobioreactor system design and
    algal mass culture
  • Author/co-author of over 40 research papers
  • Co-inventor of 11 patents
  • Technology transfer resulted in 2.6M upfront
    license fees to ASU
  • CSO Milton Sommerfeld, Ph.D.
  • Professor of Applied Biological Sciences at
    ASU
  • 40 years of experience in algae research and
    biotechnology
  • Expert in algal physiology and mass culture
  • Author/co-author of more than 260 publications
  • Co-inventor of 10 patents
  • Technology transfer resulted in 2.6M upfront
    license fees to ASU
  • Marketing and Sales?
  • -
  • -

22
Electrolyte solvent additives for high-voltage
Lithium-Ion Batteries
Austen Angell Regents Professor Dept. of
Chemistry Biochemistry
23
Overview of the Battery Market
  • Sales in the Lithium Battery market were 7B in
    2007 (1.10B Primary, 5.9B secondary)
  • Unit shipments of Secondary lithium-ion
    batteries predicted to grow from 1.76 billion to
    nearly 3.99 billion units in 2013
  • (Source Frost Sullivan, 2008)
  • Automotive markets emerging (A123, Johnson
    Controls/Saft Advanced Power Solutions)
  • Global Battery Market Past Performance
  • Hybrid Vehicle Sales

Source http//www.electricdrive.org/index.php?tg
articlestopics7
Source Market Avenue, 2007
24
Applications
  • Automotive batteries
  • - must be rechargeable and preferably deliver
    high voltages, e.g. greater than 4.5 VDC, to
    provide adequate power to the motor
  • Smaller, thinner rechargeable batteries with the
    same runtime as existing technologies.
  • Portable devices such as laptops and mobile
    phones.
  • Other energy storage devices.
  • Defense and Aerospace applications in low
    temperature environments.

Source Batteryuniversity.com, 2006
25
Li-ion Advantages
  • High energy density (Wh/kg) Results in slim
    3mm (low profile) designs.

Source Batteryuniversity.com, 2006
Source National Institute of Standards and
Technology, 2005.
  • Higher voltages than Ni-MH etc single cell
    replaces multiple.
  • No memory effect
  • Low self-discharge

26
Technology Solution Overview
  • ASUs sulfone additives create lithium ion
    battery electrolytes with higher ionic
    conductivity.
  • Fluorinated and non-fluorinated sulfones are
    added to tetraalkylammonium based ionic liquid to
    form alkyl sulfone.
  • Lithium salt is dissolved in alkyl sulfone to
    form the electrolyte.
  • Vinylene carbonate (VC) is used to promote solid
    electrolyte interface (SEI) formation.
  • Propylsulfone (PS) is added to lower the
    viscosity of the solution.

27
Performance
  • Wide electrochemical windows gt 5V for high
    voltage applications.
  • Low melting points lt 2C
  • High cyclability

State-of-the-art
Our system
1M LiTFSI in MEMS
Cut-off voltage for S-o-Art cell
28
Advantages
  • Lower melting point (lt 2 C vs. 35 C for
    existing technologies)
  • can use a single solvent in applications over a
    broader temperature range
  • Equal to state-of-the-art cyclability -
    critically important property
  • long service life, high reliability, lower long
    term costs.
  • Lower viscosities, higher conductivities, in
    prospect (fluorination)
  • A cell with a lower viscosity solution will
    recover to its previous energy capacity after
    being subjected to high current discharges.
  • The promise of higher energy density.
  • Based on wide electrochemical potential. (Toyota
    aims at 5V hybrid).
  • Higher Oxidation Resistance!!!
  • Li-ion battery fires have been attributed to
    electrical shorting
  • ASU battery materials (fluorinated) are also
    used as component of fire extinguishers!
  • Outstanding proposal reviews from DOE

29
Patent Status
  • IP Protection US/international patents pending
  • Inventors Austen Angell and colleagues
  • Contact Bill Loux (bloux_at_azte.com), PH
    480.884.1992
  • Phil Dowd (pdowd_at_azte.com), PH 480.884.1982
