Linear and Logistic Regression

1
Linear and Logistic Regression
2
Where Are We Going Today?

• An Linear regressions example
• Data how to obtain manipulate it
• Cleaning the data - Splus
• Analysis
• Issues
• Interpretation
• How to present the results meaningfully
• Application
• Description forecasting/prediction
• Traps for the unwary
• Logistic regression
• Conclusions

3
An example?

• Insurance company claims satisfaction

4
Background

• Top secret company - insurance
• Claims satisfaction
• 546 persons asked to rate aspects of service and
  then overall satisfaction/likelihood to recommend
  5 point scale
• We recommend 10 point scale - as more natural to
  respondents (1-10)
• Major storm in a teacup

5
Questionnaire explanatory variables

• Thinking firstly about the service you received
  from (top secret). I am going to read you some
  statements about this service and as I read you
  each statement, please give your opinion using a
  five-point scale where 1 is extremely
  dissatisfied and 5 extremely satisfied
• (read, rotate (start at x). write in (one digit)
  per statement)
• How satisfied or dissatisfied are you with.
• ... everything being kept straightforward
• ... being kept in touch while the claim was being
  processed
• ... the general manner and attitude of the staff
  you dealt with
• ... your claim being dealt with promptly
• ... being treated fairly

6
Questionnaire dependent variables

• 4a Using the same five-point scale as previously
  where 1 is extremely dissatisfied and 5
  extremely satisfied, how satisfied or
  dissatisfied were you with the overall service
  you received from (Top secret) ?
• write in (one digit)
•
• 4b And, using a five-point scale where 1 is
  extremely unlikely and 5 extremely likely, how
  likely or unlikely are you to recommend (Top
  secret) insurance to others?
• write in (one digit)

7
Data

• Get DP to create an Excel file with all the data
• Make your self familiar with Excel formats
• Clean data
• Then start analysing the data
• Use data to describe each aspect of service
• the time taken to get an appointment with the
  loss adjustor
• the convenience of meeting with the loss
  adjustor
• the general manner and attitude of the loss
  adjustor you dealt with
• being kept in touch while your claim was
  processed...
• the time taken for repairs to be completed

8
Data
9
Some Code for cleaning / inspecting

• cleaning the data
• Regress.eg,-1Regress.eg,-16_NA
• sum(is.na(Regress.eg))
• 1 49
• mn_apply(Regress.eg,2,mean,na.rmT)
• for (i in 2ncol(Regress.eg))
• id_is.na(Regress.eg,i)
• Regress.egid,i_mni
• let's look at this with a bit of jitter
• Regress.eg2_Regress.eg2
• matrix(rnorm(nrow(Regress.eg2)ncol(Regress.eg2),0
  ,.1),ncolncol(Regress.eg2))
• Regress.eg2_Regress.eg2,-1

10
Matrix plot (with jitter)
11
More Code

• lets analyse this data
• apply(Regress.eg,2,mean)
• cor(Regress.eg2)
• Regress.eg.coeff_NULL
• for (i in 26)
• Regress.eg.coeff_c(Regress.eg.coeff,
  lm(Regress.eg,7Regress.eg,i)coeff2)
• Regress.eg.mlr.coeff_lm(formula Satisfaction
  Straightforward
• kept.in.touch manner.attitude prompt
  fairly, data
• Regress.eg, na.action na.exclude)coeff

12
Output Code

• gt Regress.eg.mlr.coeff
• (Intercept) Straightforward kept.in.touch
• -0.08951399 0.3802814 0.1624232
• manner.attitude prompt fairly
• 0.08986848 0.2199223 0.1567801
• gt cbind(apply(Regress.eg, 2, mean)26,
  cor(Regress.eg)
• 26, 7, Regress.eg.coeff, Regress.eg.mlr.coeff
• -1)
•
  Regress.eg.coeff
• Straightforward 4.329650 0.7982008
  0.8010022
• kept.in.touch 4.394834 0.7280380
  0.7185019
• manner.attitude 4.021359 0.6524997
  0.5399704
• prompt 4.544280 0.6774585
  0.8653943
• fairly 4.417440 0.7017079
  0.6902109
• Straightforward 0.38031150
• kept.in.touch 0.16243157

13
Some issues

• 5 point scale so definitely not normal
• Note that the data is very left skew
• Regression/correlation assumptions may not hold,
  except
• CLT may kick in (546 obsns)
• Not probably the best - but still useful
• Challenge can anyone transform y (satisfaction)
  so it looks vaguely normal
• If so how do we interpret these results?
• Any other solutions?

14
Questions

• With respect to overall satisfaction
• What are the relationships, if any ?
• Which are the most important?
• What can I tell management?
• Can I predict future scores?

15
Modelling is the answerSo what is modelling?
16
Essence of Modelling

• Relationships
• Understanding causation
• Understanding the past
• Predicting the future

A correlation does not imply Causation
17
A relationship

• See Excel spreadsheet

18
Interpretation

• Correlation/R2/Straight line equation
• For one aspect of service (variable) at a time
  correlation measures strength of straight line
  relationship
• between -1 and 1
• 0 no straight line relationship (slr)
• NB may not imply no relationship, just not slr!!
• -1 perfect -ve slr, 1 perfect -ve slr
• R2 corr. squared .7982012 .6371
• 100 R2 VARIATION EXPLAINED BY SLR

19
Interpretation...

• Correlation/R2 measure strength of slr
• not the actual relationship
• Regression equation measures size of slr
  relationship
• Satis 0.8561
• 0.801x (straight forward score)
• e.g. if respondent gives a 3 we predict
• satis .8561 0.801x ( 3 ) 3.3
• Can use this to predict and set targets for KPIs
  or key performance indicators

20
Multiple linear regression

• SLR except more than one input
• ie more than one input
• Correlation not applicable
• R2 same interpretation
• eg 72 versus 64 for just Straightforward only
  as an input
• Can predict in same way - more inputs
• satis -0.08951399
• 0.3802814 x Straightforward
• 0.1624232 x kept in touch
• 0.08986848 x manner/attitude
• 0.2199223 x prompt
• 0.1567801 x fairly

21
Traps for young players

• All models are wrong, some are just more useful
  than others
• Dont always assume it is a slr
• Multiple regression may not help you much more
• problems of multicollinearity ( MC) -redundancy
  of variables
• Correlation does not imply causality
• Predicting away from region you have analysed
  will probably be crapola!!
• Anyone thought of a solution(s) yet?

22
Output Code

• gt Regress.eg.mlr.coeff
• (Intercept) Straightforward kept.in.touch
• -0.08951399 0.3802814 0.1624232
• manner.attitude prompt fairly
• 0.08986848 0.2199223 0.1567801
• gt cbind(apply(Regress.eg, 2, mean)26,
  cor(Regress.eg)
• 26, 7, Regress.eg.coeff, Regress.eg.mlr.coeff
• -1)
•
  Regress.eg.coeff
• Straightforward 4.329650 0.7982008
  0.8010022
• kept.in.touch 4.394834 0.7280380
  0.7185019
• manner.attitude 4.021359 0.6524997
  0.5399704
• prompt 4.544280 0.6774585
  0.8653943
• fairly 4.417440 0.7017079
  0.6902109
• Straightforward 0.38031150
• kept.in.touch 0.16243157

23
More code

• gt summary(lm(formula Satisfaction
  Straightforward
• kept.in.touch manner.attitude prompt
• fairly, data Regress.eg, na.action
• na.exclude))
• Call lm(formula Satisfaction Straightforward

• kept.in.touch manner.attitude prompt
• fairly, data Regress.eg, na.action
• na.exclude)
• Residuals
• Min 1Q Median 3Q Max
• -3.687 -0.08301 0.04314 0.133 1.924
• Coefficients
• Value Std. Error t value
  Pr(gtt)
• (Intercept) -0.0895 0.1369 -0.6540
  0.5134
• Straightforward 0.3803 0.0404 9.4127
  0.0000
• kept.in.touch 0.1624 0.0370 4.3937
  0.0000
• manner.attitude 0.0899 0.0270 3.3274
  0.0009

24
So what do we conclude?

• Note in this case all the MLR estimates are ve
• Not always the case because of MC
• Using the KISS approach SLR is still useful
• but note that not much difference between these
  values
• So stretch out differences by looking at
• Index slr coeff. x corr. Coeff

25
Presention of results

• Invented the Importance Index
• individual regressions
• avoids problems that can occur with
  multi-collinearity
• adjusted by correlation
• allows for level of explanation
• produce performance by importance matrix

26
Presention of results
Strengths
Concern
Maintain or divert
Secondary drivers
27
Interpretation of plot

• Four quadrants
• Strengths high performance /high importance
  keep up the good work
• Maintain high performance/low importance
  dont let down your guard, maintain where
  possible
• Secondary drivers low performance / low
  importance - keep an eye on but not too
  important
• Concern low value/high importance this
  should be the priority area of improvement

28
Logistic Regression
29
Logistic regression

• Suppose we wish look at the proportion of people
  who give a top box score for the satisfaction
• Here we have a variable that is binary. Let 0a
  1-4 score and 1 top box or 5
• Natural regression is now logistic as we have
  binary response
• We are now in the wonderful world of generalised
  linear models

30
Logistic regression

• With Linear regression our mean structure linear
  depends on the explanatory variables
• mXTb
• With logistic regression we have a non-linear
  response
• mexp(XTb)/(1 exp(XTb))
• Note that this is a good way of getting around
  the left skew ness of the data

31
Lets analyse this data again

• Logistic regression code
• Regress.eg.logistic.coeff_glm(formula
  1(Satisfaction5) Straightforward
• kept.in.touch manner.attitude prompt
  fairly, data
• Regress.eg, na.action na.exclude,familybino
  mial)coeff

32
Lets analyse this data again

• gt cbind(Regress.eg.coeff, Regress.eg.mlr.coeff-1
  ,
• Regress.eg.logistic.coeff-1)
• Straightforward 0.8010022 0.38028138
  1.1928456
• kept.in.touch 0.7185019 0.16242318
  0.6297301
• manner.attitude 0.5399704 0.08986848
  0.4143086
• prompt 0.8653943 0.21992225
  1.0494582
• fairly 0.6902109 0.15678007
  1.0760604
• Note that fairly comes up as being more
  important - ie this is more high associated
  with top box figures.

33
More details

• summary(glm(formula 1 (Satisfaction 5)
• Straightforward kept.in.touch
• manner.attitude prompt fairly, data
• Regress.eg, na.action na.exclude, family
• binomial))
• Deviance Residuals
• Min 1Q Median 3Q
  Max
• -2.252605 -0.3172882 0.4059497 0.4059497
  2.825783
• Coefficients
• Value Std. Error t value

• (Intercept) -19.3572967 1.7395651 -11.127665
• Straightforward 1.1928456 0.2674028 4.460857
• kept.in.touch 0.6297301 0.2404842 2.618593
• manner.attitude 0.4143086 0.1567237 2.643560
• prompt 1.0494582 0.2813209 3.730467
• fairly 1.0760604 0.2524477 4.262509

34
