Intuitive Surgical

1
da Vinci Robotic Surgery System
Leading the treatment of prostate cancer Galway
Clinic
2
What is the prostate?

• Male sexual gland
• Adds nutrients and fluids for sperm
• This fluid is added to sperm during ejaculation
• Urethra (urine channel) runs through the middle
  of the prostate

3
Prostate Cancer
4
What is prostate cancer?

• Abnormal cells growing out of control
• Spreads and invades local tissues
• Prostate Cancer
• Begins with a small tumor in the gland
• First spreads to the local lymph nodes
• Then spreads to the bony skeleton and other areas
  of the body

5
Prostate Cancer Facts

• Prostate cancer
• 543 prostate cancer deaths in Ireland in 2002
• Leading type of cancer in men
• 2nd most common cancer killer of men
• Estimated 15,000 men living with prostate cancer
• Projected increase of 270 over the next 12 years
• Note 400 Road Deaths in Ireland in 2005

6
Early Detection

• Early Detection
• Best prognosis is early detection
• Recent data on lower mortality rates of prostate
  cancer
• Affords patients many options for treatment

7
Early Detection

• Digital Rectal exam (DRE)
• Prostate Specific Antigen blood test (PSA)
• Any abnormality in the PSA or DRE will require
• Biopsy of the prostate
• Ultrasound guided
• Usually performed in the office
• Short procedure

8
Biopsy results

• Prostate cancer graded on appearance of cancer
  cells
• Gleason grading system
• Gleason grade ranges from 1 (least aggressive) to
  5 (most aggressive)
• Gleason score (2-10)
• Most common cell grade (first) added to second
  most common cell grade
• i.e Gleason 7 (34)

9
Staging of Prostate Cancer

• PSA
• Digital Rectal Exam
• Trans Rectal Ultrasound
• Gleason Score
• Bone Scan
• /- CT scan or MRI
• Biopsy and TNM staging system
• Tumor, Nodes, Metastases

10
Prostate Cancer T1 disease

• Cannot be felt
• T1a cancer found in 5 TURP specimen
• T1b - cancer found in 5 TURP specimen
• T1c cancer found as a result of PSA elevation
  only

11
Prostate Cancer T2

• Can be felt during DRE (digital rectal exam)
• T2a felt on one side of prostate
• T2b felt on both sides of prostate

12
Prostate Cancer T3

• Has spread beyond the prostate
• T3a extra capsular extension
• T3b tumor invades seminal vesicle(s)

13
Prostate Cancer T4

• Cancer has invaded local organs
• Bladder invasion
• Invasion into surrounding pelvic side wall
• May cause pain in joints and back

14
Treatment Options

• Dependent upon
• Stage of disease
• Patients age and health
• Patients personal preference

15
Treatment Options

• Radiotherapy
• Brachytherapy
• Surgery
• Open Radical Prostatectomy
• Laparoscopic Radical Prostatectomy
• Robotic Assisted Radical Prostatectomy

16
Goals of Radical Prostatectomy

• Remove the prostate and cancer
• High cure rates for localized disease
• Preserve urinary function
• Preserve erectile function
• Analyze the prostate after surgery to assess risk
  of recurrence of cancer

17
Laparoscopic Surgery

• Minimally invasive surgery
• Ability to operate through small keyhole
  incisions
• Camera and instruments fit through the keyhole
  incisions
• Better visualization than open surgery

18
Conventional Laparoscopic Surgery Drawbacks

• 2D flat image video
• Rigid instruments - chopsticks
• Instruments controlled at a distance - fulcrum
  effect
• Decreases your surgeons precision, dexterity and
  control
• Higher surgeon fatigue
• Makes complex operations more difficult

19
How can we overcome these drawbacks?

• Provide a high resolution 3D color image
• Interpose a computer between the surgeons hand
  and the instrument tip
• Increase the surgeons dexterity for the
  difficult aspects of the procedure
• Sparing the nerves to preserve erectile function
• Preserving continence
• Preserving quality of life
• Robotic Assisted Surgery System

20
Main Intellectual Drivers of Robotic Surgery

• Department of Defence
• NASA
• MIT
• Stanford University

21
History of Robotic Prostatectomy

• 1980s master slave remote operating developed by
  NASA and US military
• Patents held by 3 competing companies
• 1999 merger with Intuitive Surgical,CA
• USA sole ownership
• Device is Da Vinci Robotic Surgical System
• 2001 FDA approval for use on humans

22
(No Transcript)
23
What is the da Vinci Robotic Surgical System?

• Powered by state-of-the-art robotic technology
• Surgeon is in control and operates at the console
• Assistant surgeon is next to the patient

24
Vision System

• Surgeon is immersed in 3-Dimensional image of the
  surgical field

25
The Surgeon Directs The Instruments

• The surgeons hands are placed in special devices
  called masters that direct the precise instrument
  movements
• Instruments move like a human wrist unlike
  traditional laparoscopic instruments
• Instruments are small and are able to fit through
  keyhole incisions

26
(No Transcript)
27
Advantages to the Surgeon

• Access
• ROM- 8 degrees
• 3D binocular vision
• X10 magnification
• Pneumoperitoneum
• Tremor filter
• Ergonomically intuitive
• Benefits of MIS

28
(No Transcript)
29
(No Transcript)
30
(No Transcript)
31
(No Transcript)
32
Advantages to the patient

• Minimally invasive keyhole surgery
• Less blood loss
• Shorter hospital stay
• Decreased postoperative pain
• Less scarring
• Faster return to normal activity
• Earlier return to urinary continence
• Earlier and improved rates of erection
• Better cosmesis

33
Comparison of Open Surgery and Robotic- Assisted
Procedure

• Open Procedure
• Long Incisions
• Hospital Stay of 5-7 days
• Blood Loss 900ml
• Catheter removal 14 to 21 days
• Robotic-Assisted Procedure
• 5 or 6 small keyhole incisions
• Hospital stay of 2-3 days
• Blood Loss 153 ml
• Catheter days 5 to 7 days

34
Robotic-Assisted Surgery Access
Open Surgical Incision Robot Assisted
Prostatectomy Incision
35
Worldwide applications of Da Vinci Robotic
Surgical System
36
da Vinci Surgical System U.S. Installed Base
1999 2006
37
da Vinci European Installed Base 1999 2006
38
UK Experience

• Imperial College
• Six centres including Cambridge University
• Averaging 3.8 procedures per week

39
Galway Clinic, Ireland

• Consultant Urologists Drs. David Bouchier Hayes
  and Paddy OMalley have proven track record in
  performing this surgery in leading Australian
  centre of excellence.
• Da Vinci Robot purchased by Galway Clinic in July
  2007
• Capital costs of 2.7 million provided by
  investors and members of the board of Galway
  Clinic
• VIVAS, VHI QUINN all cover this procedure.
• First robotic assisted prostatectomy in
  Irelandwas performed in November 07.

40
Other Roles for Robot Assisted Surgery

• Cardiac Surgery
• Mitral Valve Repair
• Single Vessel Bypass Graft
• Anti-Obesity Surgery
• Thoracic Surgery
• Partial lung removal for cancer
