Nailing
MEDIN, a.s. Czech Republic www.medin.cz
2
TRAUMATOLOGY Nailing
Implants Elastic nails Hacketal and Ender
nails Reconstrution Nails short, long
Intramedullary Nails tibia, femur, humerus
Retrograde Nails Operation Sets Reaming set
Set for Reconstruction Nails Set for
Intramedullary Nails Set for Humerus Nails
Set for Retrograde Nails
3
TRAUMATOLOGY Nailing
Elastic nails (titanium) Usage - are used
for elastic stabile intramedullary osteosynthesis
which is indicated for treatment of
dia- and metaphysis fractures at children.
There is a cartilage in these parts of long
bone in children age whose spreading
causes the bone protraction.
Fracture types transverse fractures short
oblique or transverse fractures with
wedge-shaped fragment long oblique fractures
with the possibility of cortical base more
splinter or biofocal fractures spiral
fractures pathologic diaphysial fractures at
juvenile bone cysts
Fracture localisation diaphysis of femur and
crus distal metaphysis of femur femur
subtrochanteral crus distal metaphysic
humerus diaphysis and subcapital diaphysis of
radius and ulna radius neck Special
indication humerus and antebrachium by adults
polytrauma and craniocerebral lesion
4
TRAUMATOLOGY Nailing
Hacketal and Ender Nails Usage Ender nails
fractures fixation of femur neck or femur are
featherly introduced into a
condyle of femur or into a large trochanter
Hackethal nails fractures fixation of humerus or
tibia are introduced through trepanation
opening in corticalis into a medullary cavity
through reponated fracture and are featherly
placed into spongiosis

• Ender Nails
• diameter 4.5 mm
• length 250 500 mm
• including of instruments
• for its introduction

• Hackethal Nails
• diameter 3.0, 3.5, .,5 mm
• length 200 400 mm
• including of instruments
• for its introduction

5
TRAUMATOLOGY Nailing
Implants for Nailing Usage - implants for
nailing systems - material stainless steel,
titanium Cortical bone screws, self-taping
Locking Screws Screws Plates Adjusting
screws Compression screws
Stoppers Detail list of recommended sets of
implants for each nailing system you can find in
our catalogue.
6
TRAUMATOLOGY Nailing

• Reaming set
• Usage
• pre-drilling of cavity for nail
• Characteristics
• contents medullary flexible cutters, drill,
  introducing wire and
• handle

Note Set could be completed by some suplementary
instruments eg. introducer, holding forceps, hand
chuck etc. detail list you can find in our
catalogue.
7
TRAUMATOLOGY Nailing
Intramedullary Nails Usage - implants enable
the fixation of simultaneous fractures of
shaft and neck of femur Characteristics -
options tibial diameters 8.0, 9.0, 10.0,
11.0, 12.0 mm length 240 420 mm
femoral diamaters 10.0, 11.0, 12.0, 13.0,
14.0, 15.0 mm length 320 500
mm - materials stainless steel, titanium
8
TRAUMATOLOGY Nailing
Retrograde Nails (titanium) Usage - used for
fixation of femoral fractures Characteristics -
diamater 10.5 12.5 mm - length 200
250 300 350 mm
9
TRAUMATOLOGY Nailing
Set for Intramedullary Nails Tibia, Femur,
Retro
1 Aiming Device 2 Impactor 3-5
Sleeves 6 Mallet 7 Trocar 8 Screw of aiming
device 9 Screwdriver 10 Wrench 11 - 12
Drills 13 Depth gauge 14 Perforator 15 - 16
K-wires
Note Set could be completed by some suplementary
instruments eg. surgical mallet, futher
perforators, taps, flexibel wrenches,
screwdrivers, hand chuck, protectors etc.
detail list you can find in our catalogue.
10
TRAUMATOLOGY Nailing
Reconstruction Nails Usage - implants enable
the fixation of fragmantation fracture of
peritrochanterical, intertrochanterical and
subtrochanterical fracture and its
combination with neck fracture Remark trochante
r bone protrusions on the upper part of femoral
bone subtrochanteric fracture below trochanter
(femoral bone) intertrochanteric fracture
between trochanters peritrochanteric fracture
around trochanters Characteristics - options
long - left, right diameters 10, 11,
12, 13, 15 mm length 320 500 mm
short full, cannulated diameters
11, 13 mm length 200 225 mm
angle 130 135 - material stainless steel,
titanium
11
TRAUMATOLOGY Nailing
Set for Reconstruction Nails

• 1 Guide wire
• 2 Aiming device
• 3 Impactor
• 4-8 Sleeve
• 9 Drill
• T-Wrench
• Mallet
• 12 Depth Gauge
• 13 Screwdriver
• - 15 Trocars
• 16 Extraction bar
• 17 Bolt
• Wrench
• Measuring gauge
• - 21 Drills

Note Set could be completed by some suplementary
instruments eg. surgical mallet, futher
perforators, taps, flexibel wrenches,
screwdrivers, hand chuck, protectors etc.
detail list you can find in our catalogue.
12
TRAUMATOLOGY Nailing
Humeral Nails Usage - implants enable
osteosynthesis of humeral bone. It can be
introduced in retrograde or antigrade
way. Also it enables good fixation of short
distal or proximal fragments. Remark antigrad
e forward retrograde backward (opposite
direction than usually) proximal/distal eg.
proximal part of hand is shoulder and distal part
is hand with fingers Characteristics -
options diameters 7, 8, 9 mm
length 190 310 mm - material stainless
steel, titanium
13
TRAUMATOLOGY Nailing
Set for Humeral Nails

• 1 Aiming Device H
• 2 Screw of AD
• 3 Impactor
• 4-5 Sleeve
• 6 Distal aiming device
• 7 Introduc.axis of mallet
• Weigh
• Gauge
• 10 Awl
• 11 Drill 2,7
• 12 Bone cutter
• 13 Wrench
• 14 Universal mallet
• 15 - 19 Humeral cutter
• Extract.axis of mallet
• - 22 Screwdriver 2,5 3,5

14
TRAUMATOLOGY - Nailing
