Software Reliability

1
Software Reliability

• Reliability What is it?

2
Software Reliability

• Informally--
• The reliability of a software system is a measure
  of how well users think it meets their needs.

3
Software Reliability

• Formally--
• Reliability is the probability of failure-free
  operation for a specified time in a specified
  environment for a specified purpose.
• Adapted fromhttp//www.ece.cmu.edu/koopman/des_s
  99/sw_reliability/

4
Software Reliability

• Is not a direct reflection of time, even though
  it is expressed as a probability.
• Software does not become old and break down or
  wear out with use.
• Software will not change over time unless
  intentionally changed or upgraded.
• Adapted fromhttp//www.ece.cmu.edu/koopman/des_s
  99/sw_reliability/

5
Software Reliability

• Software Reliability is a primary factor in
  software quality.
• Software quality also involves functionality,
  usability, performance, serviceability,
  capability, installability, maintainability, and
  documentation.
• Software Reliability is hard to achieve, because
  of the inherent complexity of software.
• Adapted fromhttp//www.ece.cmu.edu/koopman/des_s
  99/sw_reliability/

6
Software Failures

• Software Failures may be due to
• Errors, ambiguities, oversights or
  misinterpretation of the specification that the
  software is supposed to satisfy.
• Carelessness or incompetence in writing code,
  inadequate testing, incorrect or unexpected usage
  of the software or other unforeseen problems.
• Adapted fromhttp//www.ece.cmu.edu/koopman/des_s
  99/sw_reliability/

7
Software vs. Hardware Reliability

• Dont follow the same rules
• Hardware faults are mostly physical faults
• Software faults are design faults
• Design Faults are
• Harder to visualize, classify, detect, and
  correct.
• Related to fuzzy human factors and the design
  process itself in which we don't have a solid
  understanding.
• While hardware may also suffer from design
  faults, these faults do not dominate.
• Adapted fromhttp//www.ece.cmu.edu/koopman/des_s
  99/sw_reliability/

8
Software vs. Hardware Reliability

• Problems that software experience that make it
  different from hardware
• Failure cause Software defects are mainly design
  defects.
• Wear-out Software does not have energy related
  wear-out phase. Errors can occur without warning.
• Repairable system concept Periodic restarts can
  help fix software problems.
• Time dependency and life cycle Software
  reliability is not a function of operational
  time.
• Environmental factors Do not affect Software
  reliability, except it might affect program
  inputs.
• http//www.ece.cmu.edu/koopman/des_s99/sw_reliabi
  lity/

9
Software vs. Hardware Reliability

• Reliability prediction Software reliability can
  not be predicted from any physical basis, since
  it depends completely on human factors in design.
• Redundancy Can not improve Software reliability
  if identical software components are used.
• Interfaces Software interfaces are conceptual
  not visual.
• Failure rate motivators Usually not predictable
  from analyses of separate statements.
• Built with standard components Well-understood
  and extensively-tested standard parts will help
  improve maintainability and reliability.
• Code reuse has been around for some time, but to
  a very limited extent.
• There are no standard parts for software, except
  to a limited degree.
• http//www.ece.cmu.edu/koopman/des_s99/sw_reliabi
  lity/

10
Hardware Reliabilityhttp//www.ece.cmu.edu/koopm
an/des_s99/sw_reliability/
11
Software Reliability http//www.ece.cmu.edu/koopm
an/des_s99/sw_reliability/
12
Software Reliability

• Reliability is a direct reflection of users'
  expectations.
• Software reliability is a function of the number
  of failures experienced by a particular user with
  a particular piece of software.

13
Software Reliability

• Reliability is related to the probability of an
  error occurring in operational use.
• Removing software problems from parts of the
  system that are rarely used does little to
  increase perceived reliability.

14
Software Reliability

• Why would a program with known faults be
  perceived as reliable by users?

15
Software Reliability When is a fault not a
fault?

• Users may never enter "faulty" input so program
  failures never occur.
• Users may never user a portion of the program
  that has faults.
• Experienced users often "work around" software
  faults which are known to cause failures.
• What the users experience is all they know.

16
Software Reliability

• If the customer does not perceive a problem
• Should we repair the faults in these sections of
  code?

17
Software Reliability

• The reliability is difficult to quantify.
• Reliability depends on the pattern of usage of
  that particular system.

18
Software Reliability

• Some claim that the use of formal methods for
  system development leads to more reliable
  systems.

19
Software Reliability

• Experience shows that formal specification and
  proofs do not guarantee that the software will be
  reliable in practical use.
• Why?

20
Why do formal specifications and proofs not
guarantee reliability?

• The specification may not reflect the real
  requirements of system users.
• Formal program proofs may contain errors because
  they are large and complex reflecting large and
  complex programs.
• The system may not be used as anticipated.

21
Software Reliability

• It is NOT possible to certify that a system is
  100 reliable.
• The time involved in doing so would be equal to
  the lifetime of the system.

22
Software Reliability

• As reliability requirements increase, system
  costs usually rise exponentially.
• Reliable system are often less efficient.
• Why?

23
How can Reliable system be less efficient?

• We MUST include extra, often redundant, code to
  perform the necessary checking for exceptional
  conditions.

24
But -- Reliability should always take precedence
over efficiency because

• Computers are now cheap and fast.
• Unreliable software is liable to be discarded
  (????) by users
• System failure costs may be enormous
• Unreliable system are difficult to improve.
• Inefficiency is predictable.
• Unreliable systems may cause information loss.

25
Software Reliability

• Users often complain that systems are unreliable.

• This may be due to poor software engineering
• -- BUT --
• The most common cause of perceived unreliability
  is incomplete specifications.

26
The most common cause of perceived unreliability
is incomplete specifications

• What does that mean?

27
Unreliability incomplete specifications

• The system performs as specified but the
  specifications do not set out how the software
  should behave in exceptional situations (or even
  not so exceptional situations).

28
Building in reliability

• Most large systems are composed of several
  sub-systems which often have different
  reliability requirements.
• Reliability requirements of each sub-system must
  be assessed separately rather than impose the
  maximum reliability requirement on all
  sub-systems.

29
Failure class Description Transient Occurs only
with certain inputs Permanent Occurs with all
inputs Recoverable System can recover without
operator intervention Unrecoverable Operato
r intervention is needed to
recover Non-corrupting Failure does not
corrupt system state or data Corrupting Fail
ure corrupts system state or data
30
Software Validation

• Software managers must decide how much effort
  should be devoted to system testing.
• Customers expect their software to operate
  without failures.

31
Reliability strategies

• (1) Fault avoidance
• (2) Fault tolerance
• (3) Fault detection

32
Reliability strategies Fault avoidance

• The design and implementation process should be
  organized around the goal of producing fault-free
  systems!

33
Reliability strategies Fault tolerance

• The product is designed with the expectation that
  some faults will persist past the testing stage.
  Facilities are provided in the software to allow
  operation to continue when these faults cause
  system failures -- recovery procedures.

34
Reliability strategies Fault detection

• The goal is to detect faults BEFORE the software
  is put into operation.

35
Software Reliability

• A small number of faults may be acceptable.
• However--
• When software is safety-critical the program MUST
  be designed so that residual faults do not cause
  catastrophic failure.
