The sensory system

1
The sensory system

• Vth year 2002/2003

2
The sensory system

• Spinothalamic system (tractus spinothalamicus)
  exteroceptive sensation) pain
• temperature
• light touch
• Dorsal column pathway ( lemniscus medialis)
  conscious proprioception joint position
• vibration
• deep pressure
• two point discrimination
• graphaesthesia, stereoaesthesia

• Dorsal and ventral spinocerebellar pathway
  unconscious proprioception

3
Spinothalamic system

• Pain perception
• C fibers thin, unmyelinated
• A delta thinly myelinated
• Temperature
• A delta thinly myelinated

4
Dorsal column pathway/lemniscus medialis
5
Spinal cord pathways - somatotopia
6
Segmental innervation (dermatomes)Peripheral
innervation
7
Sensory disturbances

• Positive symptoms
• Pain
• Hyperalgesia when threshold to pain appears
  lowered
• Hyperpathia pain threshold elevated, but once
  reached, the painful stimulus is
  excessively felt
• Hyperaesthesia
• Paraesthesiapins and needles sensation,burning
  feeling
• Dysaesthesia/allodynia when touching is painful
• Neuralgia
• Causalgia spontaneous burning sensation in the
  distribution of the injured nerve with
  increased sensitivity to painful stimuli
  (efferent sympathetic fibers link up to
  afferent somatic fibers ?)
• Phantom limb pain

8
Sensory disturbances

• negative symptoms
• Hypaesthesia decreased sensation
• Anaesthesia loss of feeling

9
Examination of the sensory system 1.

• Special standpoints
• Subjective examination
• Requires good cooperation on the patients side.
• Allows accurate localisation of the pathology.
• Preliminary diagnosis is needed. Examine
  according to the expected damage !
• Most often we compare different parts of the
  body.
• Do not tell the patient what should be felt !
• The patient should not see the examined part of
  the body !
• Subjective sensory disturbance ( pain,
  paraesthesia ) is not necessarily accompanied by
  objective sensory disturbance (hypaesthesia,
  anaesthesia )

10
Examination of the sensory system 2.

• Pain pin prick, tooth picks
• Light touch use a wisp of cotton wool !
• Temperature use a cold (5-10 0C) or a hot (40-45
  0C object (test tubes) ! Depends on the
  duration of the stimulus, size of the
  surface of contact.
• Examine the patient with his/her eyes closed !
• Instruct the patient to reply
• Tell me if you feel the stimulus ! Name the
  area stimulated ! State the nature of the
  stimulus ! What do you feel?
• Is it equal on both sides? What is the
  difference ?
• Map out the extent of abnormality !
• Move from the abnormal to the normal area (Tell
  me if sensation changes!)
• Pin must be discarded after single use

11
Examination of the sensory system 3.

• Joint position / motion
• - Hold the sides of the patients finger !
• - Move it up and down at random !
• - Ask to specify the direction of movement !
• - Normal individual is able to detect movement
  of 1 2 0 at the interphalangeal joints
• - If these senses are lost in the digits examine
  joints further up (wrist, elbow) !
• - Note the promptness or the hesitation of the
  response !
• - Disturbance of deep sensation are accompanied
  by abnormal movements ( pseudoathetosis, ataxia )
  especially with closed eyes.

12
Examination of the sensory system 4.

• Vibration
• - Place a vibrating tuning fork on a bony
  prominence ( ankle, knee, processus spinosus,
  processus styloideus radii et ulnae, elbow,
  clavicula)
• - lt 128 c/s
• - Ask the patient to indicate when the vibration
  ceases !
• - If impaired, move more proximally and repeat !
• - Vibration sense does not necessarily change
  parallel with joint position sense.
• - Patients may use different words for the
  description of the vibration (shaking,
  tingling, itching)

13
Examination of the sensory system 5.

• Two point discrimination
• -The ability to discriminate two blunt points
  when applied simultaneously.
• -3-5 mm on the finger, 4-7 cm on the trunk
• Sensory inattention (perceptual rivalry)
• -The ability to detect sensory stimuli applied
  simultaneously on both limbs.
• -Subdominant parietal lobe, associative areas
• Stereoaesthesia
• - An object is placed in the patients hand.
• - Ask patient to describe its size, shape,
  surface, material !
• - Stereoanaesthesiadisturbance of the sensory
  afferent tracts.

14
Examination of the sensory system 6.

• Astereognosis
• -Inability to identify an object by palpation
• -The primary sense data being intact
• -Lesion of the opposite hemisphere,
  postcentral gyrus
• Tactile agnosia
• -The patient is unable to recognize an object
  by touch in both
• hands
• -Disorder of perception of symbols.
• -Lesion of the dominant parietal lobe,
  associative areas
• Graphaesthesia
• - The ability to recognize numbers of letters
  traced out
• on the palm.

15
Examination of the sensory system

• Nerve conduction studies
• sensory antidrom neurography
• median nerve, ulnar nerve
• Somatosensory evoked potentials (SEP)
• median nerve, tibial nerve

16
Sensory syndromes 1.

• Peripheral nerve
• according to the distribution area of the
  affected nerve
• Polyneuropathy
• glove stocking distribution,
• more pronaunced distaly, more on the lower
  extremities
• Dorsal root ganglia or radicular laesions
• segmental, localised to dermatomes

17
Sensory syndromes 2.

• Spinal cord
• -complete cord lesion
• -hemisection of spinal cord Brown Sequard
  syndrome
• -central cord lesion (Syringomyelia, dissociated
  sensory loss
• loss of pain and temperature, preservation
  of proprioception)
• -posterior tract lesion (funicular myelosis
  loss of
• proprioception, ataxia)
• -conus laesion (sensory loss of sacral area,
  saddle
• anaesthesia)
• Brain stem Wallenberg syndrome
• Thalamus Dejerine Roussy syndrome
  (contralateral hemihypaesthesia, ataxia, pain)
• Sensory cortex contralateral hemihypaesthesia

18
Sensory syndromes spinal ganglion
19
Sensory syndromes funicular myelosis
20
Sensory syndromes
21
Sensory syndromes
22
Sensory syndromes
23
Sensory syndromes
24
Sensory syndromes visceral pain
