CS444A: Software for Critical Systems

1
CS444ASoftware for Critical Systems
2
Staff

• Prof. David L. Dill
• Prof. Armando Fox

3
Topic

• The engineering of software for applications
  where failure is unacceptable
• . . . for some value of failure and
  unacceptable.
• Costs of failure exceed value of the software

4
Critical software is growing in importance

• Computers are getting exponentially smaller,
  cheaper, faster, and better connected.
• Communications are improving at least as fast.
• Increased use of critical software is
  irresistable
• Automation of tasks that were previous manual or
  infeasible.
• Sophisticated control replacing simple control.
• Replacing mechanical, analog, digital hardware.

5
Software is growing

• Software will replace mechanical, analog, and
  digital hardware
• Cheaper to copy.
• Easier to manufacture.
• Easier to upgrade.
• Provides more functionality.
• Software will replace manual processes
• Cheaper and more reliable than human workers
• Relieves them of tedious tasks
• Faster and more predictable

6
Complexity is increasing

• COTS is coming to software
• Large projects increasingly use commercial
  off-the-shelf components
• Commodity hardware, OSs, tools, other building
  blocks
• Example Mars Pathfinder
• This is good and bad
• COTS reduces development cost development time
• Sophisticated building blocks allow creation of
  more complex systems
• But they are often brittle intra-component and
  inter-component failure modes are poorly
  understood
• Composition of pieces that were designed
  separately sometimes leads to unexpected failure
  modes

7
Software will be used in safety-critical
applications

• All of the above reasons (esp. cost)
• Software can make systems safer
• TCAS - Aircraft collision avoidance system
• Software can enhance system performance
• Fly-by-wire
• antilock braking
• Software can perform life-saving functions
• Computer-controlled pacemakers

8
Software will be used in safety-critical
applications

• All of the above reasons (esp. cost)
• Software can make systems safer
• TCAS - Aircraft collision avoidance system
• Software can enhance system performance
• Fly-by-wire
• antilock braking
• Software can perform life-saving functions
• Computer-controlled pacemakers

9
Subtopics

• Successful engineering of software encompasses
  many different issues
• Relationship of software to the larger system
• Software development processes
• Software design
• Algorithms
• Programming practices

10
Goal Best Of Both Worlds

• Traditional safety-engineering perspective
• Formal verification, requirements specification,
  related formal methods
• Traditional hazard/fault analysis
• Fault tolerance
• Systems perspective
• Design techniques and programming practices
• As much folklore as formal
• Especially recent experience in Internet-scale
  mission-critical systems

11
Formal Methodology Outline

• Safety engineering of systems
• Hazard identification
• Hazard avoidance
• Standards
• Requirements specification and tools
• Specification for reactive systems
• Model checking
• Logical specification (Z, VDM?)
• Theorem proving
• Fault tolerance
• Fault models
• Fault tolerant protocols
• Etc.

12
The Case for the Systems Perspective

• Many visible success stories
• The Internet
• Mars Pathfinder
• Gargantuan-scale 24x7 mission critical systems
  Wal-Mart financial exchanges, Visa, CIRRUS
  banking network
• Some spectacular failures
• Therac-25 (today)
• System design combines engineering judgment and
  folklore with formal methodology

13
The Role of the Internet

• The distributed system from hell
• Evolved over gt25 years, lots of legacy code
  layers
• Widely distributed, both geographically and
  administratively
• Transient failure (hardware software) is a way
  of life
• Yet, it mostly works...What great ideas can we
  steal?
• The Internet is a good testbed for new approaches
  to reliability
• Internet scale implies large size, exponential
  growth, and 24x7 operational requirements
• People dont die (usually) when systems go down
• Strong financial incentive spurs industrial
  deployment -)

14
Systems Track Outline

• Conceptual vocabulary, research landscape
• Fault isolation, fault containment, orthogonal
  guard mechanisms
• Transactions, replication, consistency
• State maintenance
• Availability vs. consistency tradeoffs, harvest
  and yield
• Application-level vs. OS-level mechanisms
• Systems case studies

15
Goals

• Identify recurrent design philosophies that work
  well
• Taxonomize the folklore in software systems
  design
• Identify fertile crossover areas to the formal
  world

16
Example Software failures in the Therac-25
17
Motivation

• The "Therac-25" is a classic case study in
  engineering failure -- like Tacoma Narrows
  bridge, Challenger disaster, etc.
• Illustrates many problems and issues of software
  safety.
• Shows how not to do it.
• Related to assignment.

18
The Machine

• The Therac-25 is a linear accelerator used for
  radiation therapy (e.g. cancer treatment).
• Safety issues
• overdose Patient is injured or dies from
  radiation burns.
• underdose Serious disease is not treated
  properly, patient may be injured or die because
  of this.
• Therac-25 much more dependent on software for
  safety than its predecessors (Therac-20,
  Therac-6)
• "Hardware interlocks" replaced by software.

19
Technical details

• Multi-mode machine protons, electrons, X-rays.
• X-rays generated when electron beam collides with
  target.
• - This is inefficient, so electron beam
  must be very powerful.
• Different modes require turntable to be properly
  positioned with targets, spreaders, etc. between
  beam and patient.

20
Accidents

• Machine reliably treated thousands of patients,
  but occasionally weird things would happen.
• There were at least 6 accidents.
• Kennestone 1985
• Patient treated for breast cancer is
  unexpectedly burned.
• Est. 15K-20K rad dose (500 rad to whole body
  50 fatal).
• Patient lost breast, shoulder and arm
  paralyzed.
• Patient sued, settled out of court.
• FDA not informed until much later.

21
Another accident

• Tyler 1986
• Patient to be treated with electron beam.
• Operator said to treat with X-ray, then
  corrected.
• Patient felt "electric shock.
• Operator saw "malfunction 54" and under-dose
  reading, so said "proceed" to zap patient
  again.
• Patient overdosed a second time (in arm) as he
  was trying to escape.
• Patient died horribly of radiation overdose 5
  months later.

22
Software issues

• No locks on shared variables (race conditions).
• Control flow bug some newly entered data can be
  ignored.
• Timing sensitivity in user interface.
• Wrap-around on counters.

23
User interface issues

• Malfunction 54 (patient might have received
  overdose or under-dose).
• No indication about patient safety with error
  messages.
• Proceed button continues after error message
• - one patient overdosed twice.

24
System issues

• Inadequate mechanical checks on turntable
• - 3 microswitches for position sensing.
• - 1-bit error in encoding makes position
  inaccurate.
• - potentiometer installed later to sense
  position.
• No independent hardware to suppress beam.
• Dosage measurement devices (ion chambers) report
  inaccurate results for very high doses.
• Therac-20 had same bugs, but no accidents because
  of independent protective systems.

25
Management issues

• Software complacency
• - software errors not modelled in fault
  trees.
• - users told no possibility of overdose.
• Absurdly low probabilities assigned to SW
  failure.
• Guesswork in analyzing observed failures
• - blamed microswitches on turntable.
• - no actual failures found in microswitches.
• - problem was probably software.
• Inadequate software processes
• - unclear safety analyses.
• - no audit trails.
• - inadequate testing.

26
Regulatory and legal issues

• FDA, Canadian regulators not heavily involved
• - no software regulation in med. devices (at
  that time).
• - not notified of incidents (no requirement to
  do so).
• - inadequate investigation of early incidents.
• When FDA got involved, the machine got fixed.
• (speculation) Out of court settlements impeded.
  dissemination of information about hazards.

27
A more Armando-like example?
