The University of Pittsburgh Cancer Institute caBIG Architecture

1
The University of Pittsburgh Cancer
InstitutecaBIG Architecture

• Establishing a framework for
• Creating Products
• Understanding Process
• Producing Value

2
Architectural Goals

• Create a framework for building systems that are
  widely accessible, modular, interoperable,
  supportable, locally extensible and future-proof
• Create data storage and communication strategies
  that are hardware- and software-agnostic
• Support standardization and "convergent
  evolution" of software tools as they are shared
  and tested by domain workgroups
• Cancer Biomedical Informatics Grid
• Convergent Architecture Biomedical Informatics
  Grid

3
Overview of UPMC/UPCI Architecture
UPMC
UPCI
Clinical Users Fat clients, browsers
Clinical and Research Users
Cerner CIS
Presentation
Browser, Java applets
Oracle, Java API, AIX
Message Router HL7
HL7 2.x
HTTP, RMI, SSL
HL7 2.x
Ancillaries
Middleware
iPlanet, Oracle (PL/SQL), Java, Oracle Forms,
Cold Fusion, W2K
Various, Legacy
MARS
C, Python, AIX
JDBC, Oracle drv
Oracle 9i
Proprietary UPMC, AIX
Sun Solaris
CRIS
Research Users File Transfer
4
Overview of UPMC/UPCI Architecture
UPMC
UPCI
Clinical Users Fat clients, browsers
Clinical and Research Users
Cerner CIS
Presentation
Browser, Java applets
Oracle, Java API, AIX
Message Router HL7
HL7 2.x
HTTP, RMI, SSL
HL7 2.x
Ancillaries
Middleware
iPlanet, Oracle (PL/SQL), Java, Oracle Forms,
Cold Fusion, W2K
Various, Legacy
MARS
C, Python, AIX
JDBC, Oracle drv
Oracle 9i
Proprietary UPMC, AIX
Sun Solaris
Proxy Server
CRIS
Firewall
VPN
5
OPI Clinical Systems Application Architecture
Client Tier
UPMC Internal Network PCs (W2K)
Web Browsers
Oracle Forms
2nd-Tier
Web Servers WIN2K OS Iplanet 6.0 Cold Fusion
1upmc-pci2 intranet.upci.edu
Crystal Reports
3rd-Tier
Application Servers WIN2K OS
1upmc-opi-cry01 Crystal Enterprise Server
1upmc-pci1 Java DBServer J2EE environment
Database Servers Solaris 2.8 Oracle 9.2.0.1
Back-end
Redo Log Replication
Opiunx01 UPCI Database Production
Opiunx04 UPCI Database Standby
6
Key caBIG Projects at UPCI

• Mature
• Clinical Trials Management Application
• Tissue Banking System and Organ-Specific
  Databases
• Currently in development
• SPIN distributed virtual database
• SPIN free text concept extraction

7
Clinical Trial Management Application

• Currently deployed at UPCI (since 2000)
• Supports a range of users including
• Nurse Coordinators
• Data Managers
• Clinical Trial Specialists
• Clinicians
• Administrators
• Researchers
• Pharmaceutical representatives
• Houses over 250 active protocols representing
  in-house, Co-op, NCI and pharmaceutical-sponsored
  trials
• Contains clinical data for approximately 16,000
  patients

8
CTMA Architecture

• Multi-tiered Java implementation
• Java/Swing client applet (pure Java)
• Uses RMI to communicate via SSLava to the middle
  tier
• Authentication via by iPlanets LDAP server and
  Oracle
• Data access server (DAS) written in Java (Win2K)
• Mediates between RMI client calls and middleware
  objects or database routines
• Runs on a Windows NT machine designated as
  intranet host
• Communicates with an Oracle database using JDBC
  and the Oracle Type 4 Thin SQL driver, with
  Oracle's RC4_56 encryption algorithms
• Administrative reports via Crystal Reports
  Enterprise Server
• Database
• Oracle 9i database on SUN Solaris

9
Tissue Banking Systemand Organ-Specific Databases

• Inventory, specimen management organ-specific
  views of aggregate data
• Consent tracking (universal consent, deceased
  patients)
• Sample inventory including sample
  features/quality, bar coding, storage and access
  tracking
• Manual sample annotation using local data elements

• Organ-specific views provided by form-based
  applications (Oracle Forms)
• Aggregation and summary based on local data
  elements
• On-the-fly HIPAA de-identification through local
  proprietary tools
• In production at UPMC and 15 collaborating
  institutions.

10
Tissue Banking Architecture

• Multi-tiered implementation
• Client display implemented using Oracle Forms
• Middleware layer using Oracle Apache Services
• Data processing and aggregation partially in Java
• Data extraction and processing in PL/SQL
• Database
• Oracle 9i database on SUN Solaris
• Includes primary data and metadata that defines
  rules for grouping data into specimens, cases,
  patients, organs, diseases and aggregates of
  patients

11
SPINShared Pathology Informatics Network

1. Distributed virtual database using a peer-to-peer
   network with query/response communications based
   on web services

Local databases at participating institutions
SOAP
JBoss/servlet middleware MySQL back end
Query
Response
Pitt Regenstrief Harvard UCLA
In development at Harvard
12
SPINShared Pathology Informatics Network

• 2. Free text UMLS-based concept extraction from
  pathology reports, in development at Pitt
• De-identification based on local tools
• Processing pipeline includes report section
  "chunker," tokenizer, and concept tagger
  including negated concepts, written in Java
• Incorporates Gate, an open source Java framework
  for language engineering
• Output as XML-structured report with identified
  subsections (including diagnoses) and embedded
  code elements
• Modular, will communicate through Java API or web
  services (automated data extraction from MARS)

13
Key Issues/Lessons

• Get software into the hands of users/testers as
  rapidly as possible.
• Our first generation tools are functional but
  need to evolve to fully support the ultimate
  caBIG architecture.
• Iteratively modifying functional tools at
  implementation sites will be challenging.
• Changes that impact the clinical workflow will be
  disruptive.
• Developers tend to gravitate to familiar tools.
  In medical settings, these have not typically
  included open source.
• Focus when possible on language-agnostic open
  messaging standards for communication rather than
  language-specific APIs (consistent with caBIO
  technical guidelines).

14
UPCI's Role in Realizing the Architecture

• Because the UPCI is involved in several
  workgroups, it may offer a helpful environment
  for communication between domain and the
  cross-cutting workgroups
• Direct communication from the AWG to the project
  technical staff and direct access to feedback
  from the projects
• Coordination between the Architecture and the
  CDE/Vocabulary cross-cutting workgroups.
• Generate integrated feedback to the AWG as
  policies and recommendations develop.
• Initial implementation and testing of
  architectural recommendations in several
  production settings

15
Mechanisms for Providing Guidance

• Bi-directional communication between AWG and the
  domain WGs
• Position statements and guidelines from AWG
• Critiques on guidelines from domain WG
• Documentation from ongoing projects, including
  early docs such as information models and UML
  diagrams
• Critique of project plans/designs
• Process and schedule for documenting development
  (planning and implementation) important
• Communication mechanisms
• Online asynchronous discussion, conference calls
  sparingly
• Online documents and critiques accessible to all
  WG
• Periodic meetings of AWG, possibly open source
  "sprint" style over several days
• Concurrent meetings or representation at domain
  WG meetings and CDE/Vocab WG
• Explicit connection with other standards
  organizations (HL7)?

16
Development Plan
Standards-Centered Framework
17
Development Plan
Standards-Centered Framework Effectively
Communicated
