Modern Medical Manufacturing Plants

1
OEM CATALOGUE
2
Overview
Since 1988,Modern Medical Equipment MFG. LTD. has
been engaged in the OEM manufacturing in the
medical industry, providing its customers With
the highest level of quality and service . Today
, Modern Medical maintains itself as a
well-rounded, diversified company in serving the
industry. We response actively to the
requirements of the industry by offering them
advanced capabilities in tooling, injection
molding , assembly and clean room Manufacturing
with unparalleled customer satisfaction.
Fully integrated With the CAD/CAM system,
advanced equipment and highly Skilled workforce ,
Modern Medical able to build and assemble high
quality Medical devices at a very competitive
cost-even at huge volume and with Complicate
design . Our manufacturing capabilities are
complemented by Design and development ,packaging
,sterilization ,quality control And more.
We capable of producing a comprehensive range of
products for Minimal Invasive Surgery , Closure
Device , Respiratory Specialty, Arthroscopy, OBG
,Dermatology ,Cardiology , as well as specialized
items for electro-surgery. With continually
strive for excellence, Modern Medical keep on
embracing Innovative approaches to manufacturing
in order to provide even better services to its
OEM customers.
3
Design and Engineering
Modern Medical with its engineering centers
specialize in design, research and develop
medical devices, solutions, private labels, and
other medical products that meet customers'
requirements and cater for market needs. We
support all phases of product development and
manufacturing, from RD, through clinical trials.
Our dedicated engineering team, with the aids of
sophisticated CAD systems, such as Pro-E, Solid
Works, AutoCAD, we are confident that the final
product exceed customer cost, quality, delivery,
service expectations.
Prototyping
In the early development stage, before that
particular product is made, a prototype is surely
helpful for the study of the product
characteristics from esthetic, technical,
functional aspects, materials used and etc.We
employ advanced technology in rapid prototyping,
stereo lithography, helps reduce preparation time
significantly, as well as cost on materials,
tooling and production.
4
Powder Coating
Powder coating is an advanced, environmental
friendly technique of applying insulation Layer
to metal parts by means of electrostatic. Powder
Coating is electro-statically charged and sprayed
on to the parts. The powder contains no solvents,
thus it will not be causing air pollution and
over-spray will be reused and maintaining a high
material usage. The powder liquefies and adheres
to the metal surface, once the part was cured it
has finish with no runs or drips. It can adapt to
very unique contour Shape of metal instruments
Injection Molding
Modern Medical equip with more than 20 horizontal
vertical molding machines ranging from 50 - 250
ton, and we are actively expanding our molding
capacity by investing in the state of the art
equipments to cater for large volume and rapid
turnaround order. With through understanding of
various polymer's characteristics and its
applications, we are capable of manufacturing
high quality plastic parts by stable processes.
We have extensive experience in molding a wide
range of polymers for different applications,
such as ABS, PC, PP, HDPE, LDPE for disposable
and PEEK, PPSU, PP Fiber, ULTEN for reusable
products.
5
MIM CIM Technology
Taking both the advantages of plastic injection
molding technology and the wide range powder
metallurgy materials, Modern Medical is capable
for large scale production of small and highly
complex components with a board spectrum of
materials. We achieve it by applying the
advanced technology - Metal Injection Molding
(MIM) Technology and Ceramics Injection Molding
(CIM) Technology. With minimal number of
secondary operations, labor cost and production
lead time reduced significantly compare with
using conventional manufacturing processes. Near
net shaped components could be made by the
technology with the final density of the molded
parts are above 98.
Applications do not limit to the manufacturing of
complex components of medical device, it is also
applicable for making medical implants. Wide
range of materials are available for Metal
Injection Molding, e.g. Stainless steel 316,
Stainless steel 420, Titanium, Nickel Iron and
even metal alloys such as Alumina and
Zirconia. Ceramics such as Aluminimum Oxide,
Zirconium Oxide and even more are available for
Ceramics Injection Molding.
6
10K Class Clean Room Assembly Facilities
Modern Medical has 10K Class clean room and
skilled workforce for performing mechanical
assembly and second operations. We keep
constantly monitoring of the temperature,
pressure, humidity, particles and bio-burden
level of the clean rooms to ensure these
facilities are under well control.This
department performs a variety of services
including general machining, sonic welding,
sewing, mechanical assembly, packaging and more.
Our assembly management team constantly reviews
production process with emphasis on quality and
productivity.
Sterilization
Modern Medical offers gamma radiation and EO gas
sterilization capacity. We develop sterilization
protocol for specific product. All facilities
operated under ISO13488 standard with EN550/EN552
certified. Our high quality traceability control
provides a reliable sterilized product at world
class standard.
7
Regulatory
To provide a world class medical devices support,
our factory is certified ISO 90012000 (quality
management standard), ISO 134851996 (medical
device-specific standard) and GMP system. We
own several regulatory licenses to simply the
regulatory issue to sell worldwide. We have a
regulatory team to assist our client to applied
various kinds of regulatory and license around
the world. Our solid experience in application
of
510k for USA market CE mark for Europe
market CMDCAS for Canada Market MHLW for
Japan Market SDA for China Market
8
Metal Stamping
The high-speed presses and well trained
technicians at Modern Medical are ready to
produce precision metal stampings of any shape
with different kind of material such as copper
alloys, aluminum, stainless steel and etc. We are
capable of joining of metal stampings with other
components right in the press offering high
precision and cost advantages of automated
assembly. Moreover, secondary operations are
available for your selection, they include de
burring, tapping, heat treating, plating, etc.
Wire Forming
We have a particular expertise in wire-forming,
with many years of experience in manufacturing
components, with a wide range of applications on
various instruments. We are capable of bending
most metals, most commonly including mild steel,
carbon spring steel, stainless steel (and all
other non-ferrous metals). Also, we facilitate to
cope with your precise requirements on you
customized design of wire form or spring.
9
Our Experience

• Electrosurgical Instrument, including.....
• Electrosurgical Pencil
• Electrodes
• LLETZ Electrodes
• Ground Pad
• Bipolar Forceps
• Monopolar and Bipolar Cables
• Adaptors
• Suction Coagulator

• OBGY Products, including......
• LLETZ Electrode
• Speculum
• Propap
• Pessaries
• Catheter
• Dilators

• Respiratory Accessories, including......
• CPAP Accessories
• Nebulizer
• Filter Mask
• Special Facial Mask
• Tubing
• Connector

• Others, including......
• Sensor Pad
• Medical Lights

• Closure Devices, including......
• Skin Stapler and Remover
• Wound Dressing
• Wound

• Cardio Instrument, including......
• Suction Wand
• Emboli Filter
• Aortic Punch
• Aortic Knife
