Computational Limitations Associated with Large
DNA Datasets for Comparative Community Profiling
D. Papamichail 1,2, C. Lesaulnier 1,3, S.
McCorkle 1, S. Skiena 2, B. Ollivier 3, D. van
der Lelie 1 1Brookhaven National Laboratory,
Upton, NY, USA. 2Stony Brook University, Stony
Brook, NY, USA. 3Institut de Recherche pour le
Developpement, Marseille, FRANCE.
Results
Abstract
Using the value of the highest scoring alignment
for each sequence, and setting the Boolean value
for correct (1) or incorrect (0) classification
for the genus, family, order, class or phylum, we
created a confidence estimate for each blast
alignment score. Since many of these scores do
not have corresponding ratings, regression curves
were used to approximate their values.
Recent years have shown great advances in
high-throughput experimental methods in molecular
biology. Our capacity to now rapidly and cost
effectively sequence DNA in very large volumes
has greatly advanced our ability to study
microbial communities. While useful, these
generated datasets present many computational
challenges. High-throughput biological datasets
are now becoming very large, often very noisy and
contain many missing points. In addition, many of
these data sources measures only one gene (or
type of activity) in the cell. Principled
computational methods are required in order to
make full use of each of these datasets, to
better define their constituents and to combine
them to infer not only genetic but eventually
functional interaction networks.
Why did the RDP classifier not convince us? A
large number of our 16S sequences classified in
the same genus had edit distances accounting for
gt20 the total sequence length, sometimes
reaching distances of up to 50. Many of these
occurred between sequences classified with low
confidence estimates (lt50), creating uncertainty
for a large number of classification groupings
and gave the first clue that many of the
sequences we were trying to classify were distant
from all the vetted sequences available. We also
noticed that some sequences with gt97 edit
distance similarity to any member of another
group were found classified in different taxa,
with a couple of occurrences even in the phylum
level. Such closely related sequence group
schisms were found even in sequences groups
within 99 edit distance similarity to each
other.
We use polynomial regression of the 4th degree,
smoothed by addition of extra points,
representing high confidence estimates at very
high scores and zero confidence estimates at very
low scores. The unsmoothed regression curves and
the classification score confidence estimates are
shown in (Figures 2-7). The confidence estimate
now of each score is calculated from the value of
the polynomial for this score.
Full Alignment against vetted sequences. Global
alignment of our sequences with the 5574 RDP-II
vetted sequences was then carried out using the
Needleman-Wunsch algorithm for global alignment,
with the (match, mismatch, ins/del) values set to
(0, 1, 1) and no other gap penalties (Levenshtein
edit distance). This algorithm with O(n2)
complexity, is simple enough in its
implementation to be relatively fast for small
fragments, such as 16S rRNA sequences. These
results were still troubling as the great
majority of the sampled 16S rRNA sequences had an
edit distance ranging from 150 to 300 (90 to 80
similarity) to the closest match in the vetted
sequences.
Figures 9 12 represent alternate methods for
profiling community composition and change for
both Prokaryotes (Figures 9 and 11) and
Eukaryotes (Figures 10 and 12).
How does the classification accuracy change when
the threshold of what we consider acceptable
changes? Two serious challenges were encountered
in identifying unknown rRNA sequences from our
sampling experiment (i) The sequence similarity
is not always congruent to the taxonomical
categorization of the sequences. (ii) The
limitation of reference points (number of vetted
sequences) and biases in the number of
represented groups (i.e. pathogens) are not
reflective of the diversity found in
nature. With reference to the first challenge,
organisms having similar properties and falling
into specific groups may still contain sequence
fragments closely resemble those of organisms in
other groups. It is worth mentioning that 62 of
the sequences aligned better with a sequence
outside of their genus than with some sequence in
their assigned genus. The second challenge is
somewhat alleviated by the fact that we are
searching for significant changes in populations,
which allows us to extrapolate ratios either by
eliminating low score classifications or by
combining classifier results.
Table 1 Statistical analysis of population
importance and distribution
Rather than using RDP phylogenetic grouping, the
Chao1 non-parametric estimator was used to
determine phylotype richness 4, 5 and calculated
on groups clustered according to specific
Levenshtein edit distance values.
How did we adjust the parameters? To maximize
classification accuracy using BLAST 3, the
(match, mismatch, gap_start, gap_extend)
parameters were adjusted to minimize the
misclassifications within the RDP-II vetted
sequences. A genus level leave-one-out test for
each of the 5574 vetted sequences with nine
different parameter sets was implemented to find
the one set that best separates the scores of
closely related species to distant ones. Only
highly conserved regions that match exceptionally
well were aligned. The score for each blast
alignment was constructed by summing up the
individual scores of the locally aligned pieces,
normalized against the length of the sequences
being compared. The two tests to measure
misclassifications and calibrate local alignment
parameter space, were (i) The number of rRNA
sequences that score better against a sequence
from another genus than against all of the
sequences in their genus. (ii) The number of
ribosomal sequences that score better against a
sequence from another genus than at least one
sequence from their genus. After examining the
different parameter sets constructed, we decided
on the values (1, 5, 3, 2.5 corresponding to
match, mismatch, gap_open, and gap_extend
respectively) where match is positive and
considered a reward, and mismatch, gap_open and
gap_extend are negative and considered penalties.
This set of parameters minimized the number of
misclassified vetted sequences from 274 to 229
out of a total of 5574. The constructed blast
classifier is now classifying an unknown sequence
against the set of vetted sequences available and
selecting the highest scoring sum of locally
aligned pieces and the resulting score is then
used to create a confidence estimate.
Conclusion
Figure 1 Currently available technology
Objectives
The effectiveness of clustering depends on the
definition of distance and how well groups can be
formed. As the number of elements increases, the
number of clusterings also increases
exponentially, giving rise to a wide range of
choices for our solution, which, although may
score equally well, can have significant
differences, especially at the higher taxonomic
levels. The computation time needed is very high
when dealing with more than one thousand
elements, as it is with the numerous manual
adjustments to the multiple alignments which are
commonly used for calculating distances. It is
difficult for biologists to classically deal with
such large data sets, and the need exists to
develop tools to overcome the computational
limitations in accurately identifying taxonomical
relationships and reconstructing phylogenetic
histories for the purpose in this case of better
extrapolating ecological roles.
Our model was based on two Prokaryotic and
Archaeal 16S and Eukaryotic 18S rRNA gene
libraries comprising 6000 and 2000 clones
respectively. These were constructed from Poplar
rhizosphere extracted DNA under ambient and
elevated atmospheric CO2. The aim of this study
was to profile as accurately as possible the
microbial community composition with the
optimization of currently existing bioinformatics
tools. This further enabled molecular ecologists
a more accurate determination of population
changes under elevated CO2 and extrapolate the
reasons for which we observe changes.
Introduction
References
Many tools already exist for the identification
and classification of rRNA genes. To date the
most widely used is the ribosomal database
project Naïve Bayesian classifier. The clustering
and classification of 16S sequences using this
tool is based upon 5600 vetted sequences
outlined in 1. Eukaryotic 18S rRNA sequences
have been taxonomically outlined in 2, but no
vetted sequence dataset exists and one had to be
compiled.
1 Garrity, G., Bell, J. A., and Lilburn, T. G.
2004. Taxonomic outline of the prokaryotic
genera. Bergey's manual of systematic
bacteriology, 2nd ed., release 5.0.
Springer-Verlag, New York, N.Y. Online. DOI
10.1007/bergeysoutline200405 http//141.150.157.80
/bergeysoutline/. 2 Kirk, P. M., Cannon, P. F.,
David, J. C., and Stalpers, J. A. 2001. Ainsworth
and Bisby's dictionary of the fungi, 9th ed. CAB
International, Wallingford, United Kingdom.
Online at http//www.speciesfungorum.org/Names/fu
ndic.asp. 3 Altschul, S. F., Madden, T. L. et al
(1997). "Gapped BLAST and PSI-BLAST a new
generation of protein database search programs."
Nucleic Acids Res 25(17) 3389-402. 4 Chao, A.
1984. Nonparametric estimation of the number of
classes in a population. Scandinavian Journal of
Statistics, 11, 265-270. 5 Chao, A. 1987.
Estimating the population size for
capture-recapture data with unequal catchability.
Biometrics, 43, 783-791.
