Viralbased Gene Therapy of Tumours

1
Viral-based Gene Therapy of Tumours

• Andy, Andy, Kim, Liya, Quin Raf
• Dr. Radek Erban Dr. Kerry Fisher

2

• What our problem was and why
  we wanted to model it?
• How Tumours Work
• Modelling Virus Kinetics
• Experimental Data
• Predictions from our Model
• Diffusion of the Virus
• Conclusion Further Work

3
Modelling of Viral-based Gene Therapy of Tumours

• Many medical conditions have faulty, mutant
  genes, as an underlying cause
• Tumours dont stay in one place, but spread
  around the body making operating difficult
• Reintroducing healthygenes is difficult

4
Modelling of Viral-based Gene Therapy of Tumours

• Viruses can be used to carry healthy genes
• Oxfords Gene Therapy group aim to administer
  viruses via the blood stream
• Find and destroy all tumours in the body
• Ideal treatmentfor later stagesof cancer

5
Modelling of Viral-based Gene Therapy of Tumours

• Problems
• The Liver removes virus particles quickly
• Tumours take in the virus slowly
• Solutions
• Modify the virus
• Modify liver clearance efficiency

6
Adenovirus
7
(No Transcript)
8
Experiments

• Gene therapy group Clinical Pharmacology
• Test subjects Mice (Mus Musculus)
• Two types of tumour
• Different levels of Clodronate administered
• Tumours removed
• Tested for virus particles

9
Zero-order and first-order kinetics
Zero-order kinetics
Rate of removal of virus in the blood is
independent of the amount of virus particles
present.
First-order kinetics
Rate of removal of virus is proportional to the
amount of virus particles.
10
How realistic is the model?
LIVER
BLOOD
TUMOUR

• First-order kinetics is not enough
• Multi-compartment model
• Virus particles absorbed by liver and tumour
• Liver can be saturated with virus particles

11
Developed model with saturation
12
Dosing schedule

• Solve analytically using first-order kinetics
• V Kexp(-rt)

• New dose is to be given at time td where
• Td log(C0/K) / r

13
Exploratory Data Analysis
LoVo blood counts (24h)
HT29 blood counts (24h)
24h tumour counts
14
The Blood Counts
15
The Blood Counts
16
The Tumour Counts
17
Diffusion of Virus

• If the virus gets into capillaries, does it get
  into the tumour?
• How fast do virus particles diffuse?

18
Random Walk Model

• Simulation with 500 virus particles
• Estimated diffusion coefficient D 0.93397
  µm2/s
• Diameter of a virus particle a 90 nm (90?10-9
  m)
• Diameter of a capillary d 8 µm (8?10-6 m)

19
Deterministic Model
Concentration of Particles in a Capillary
20
Comparing the two models
1'000 particles
100'000 particles
0
0
4µm
4µm
-4µm
-4µm
Distribution of particles in the cross-section of
a capillary
21
Summary

• ODE model of virus concentration.
• Data analysis to find parameters.

• Diffusion model for virus in blood stream.

22
Extensions

• Virus diffusion model
• Allow for non-homogeneous tissue
• Model blood flow in capillaries
• Replicant competent virus
• Virus capable of multiplying within a tumour
• Which grows fastest, the tumour or the virus?

23
Conclusion

• Viral based gene therapy is an exciting
  development in the battle against cancer.
• Research is still required.
• Mathematicians can help!

24
Acknowledgements

• Dr Radek Erban
• Dr Kerry Fisher
