Osler Institute Pathology Board Review: Electron Microscopy

1
Osler Institute Pathology Board Review
Electron Microscopy
EM of Tumors and Tumor-like Entities
2

• Neoplasms
• Oncocytoma
• Salivary gland
• Parotid
• Kidney

3

• Neoplasms
• Oncocytoma
• Pleomorphic mitochondria
• Lamelliform (plate like) mitochondrial cristae
• Dense bodies in mitochondria

4

• Neoplasms
• Plasmacytoma
• Nuclei
• Marginated heterochromatin
• Prominent profiles of rough endoplasmic reticulum
• Immunoglobulin inclusions in RER and nucleus

5

• Neoplasms
• Renal Cell Carcinoma
• (conventional type)
• Long microvilli
• Glycogen
• Lipid droplets

6

• Neoplasms
• Renal Cell Carcinoma
• Chromophobe Type
• Microvesicles
• Hales colloidal iron positive
• Papillary (chromophil) Type
• Abundant mitochondria

7

• Neoplasms
• Seminoma
• Wandering, ropy, nucleolus
• Finely dispersed heterochromatin
• Inconspicuous organelles
• Intercellular junctions

8

• Neoplasms
• Squamous cell carcinoma
• Desmosomes
• Tonofilament bundles

9
Small Round Cell Tumors
10

• Neoplasms
• Small Round Cell Tumors
• Ewings Sarcoma
• Dispersed heterochromatin
• Small nucleolus

11

• Neoplasms
• Small Round Cell Tumors
• Ewings Sarcoma
• Large pools of glycogen

12

• Neoplasms
• Small Round Cell Tumors
• Rhabdomyosarcoma
• Actin-myosin filaments with Z-band
• Primitive sarcomeres

13

• Neoplasms
• Small Round Cell Tumors
• Rhabdomyosarcoma
• Ribosome-filament complexes
• Small primitive junctions
• External lamina

14

• Neoplasms
• Small Round Cell Tumors
• Neuroblastoma
• Cell processes
• Secretory granules
• Microtubules
• Neurofilaments

15

• Neoplasms
• Small Round Cell Tumors
• Lymphoma (Follicular Center Cell)
• No cell junctions
