Title: The Plate Tectonics


1
The Plate Tectonics
Revolution
A paradigm shift in the Earth Sciences
2
  • Topics
  • Wegeners Theory of continental drift
  • Seafloor spreading the Vine-Matthews-Morley
    hypothesis
  • The plate-tectonics revolution
  • What is a plate? How many are there?
  • J. Tuzo Wilson and his cycles
  • Triple junctions

3
  • Promoted continental drift with publication of
    The Origin of Continents and Oceans in 1915
  • Alternative to land bridges as theory to explain
    similar fossils on different continents

Alfred Wegener (1880-1930)
4
  • Supporting evidence Appalachian mountains match
    Scottish Highlands similar rocks in South Africa
    and Brazil
  • Coined term Pangea (Greek, meaning all the
    Earth)

Alfred Wegener
Scottish Highlands
Appalachians (eastern N.A.)
5
In 1962, U.S. Navy marine geologist Harry Hess
proposed that ocean crust is much younger than
continental crust, and forms by seafloor
spreading
Harry Hess
6
  • Magnetic surveys revealed a distinctive striped
    pattern in the oceans

Raff, A. D. and R. G. Mason. 1961. Magnetic
survey off the west coast of North America, 40º
N. latitude to 52º N. latitude. Geological
Society of America Bulletin 721267-1270.
7
In the meantime, scientists in U.S.A. and
Australia discovered that the Earths magnetic
field has reversed many times
8
The Vine-Matthews Hypothesis
  • Magnetic Stripes Seafloor Spreading Magnetic
    Field Reversals
  • Basalt extruded at mid-ocean ridges is
    magnetized in the direction of the Earths
    magnetic field

Vine, F. J. and D. H. Matthews. 1963. Magnetic
anomalies over oceanic ridges. Nature
199947-949.
9
  • but did they discover this first?
  • several months before Vines and Matthews, Larry
    Morley (Geological Survey of Canada) had
    submitted a paper to Nature with the same
    conclusion
  • His paper was rejected as too speculative
  • Revisionist history
  • Vines-Matthews hypothesis is now known as the

Larry Morley
10
(No Transcript)
11
The new global tectonics of the 1970s Earths
ultimate recycling program
  • New oceanic lithosphere is created at mid-ocean
    ridges
  • Oceanic lithosphere is destroyed at deep-sea
    trenches (subduction zones)
  • This process largely explains the global
    distribution of earthquakes and volcanoes

12
What is the lithosphere?
  • Outer part of the Earth, 100-200 km thick
  • Includes the crust and part of the upper mantle
  • Behaves rigidly
  • Forms plates

13
Tectonic plates
Large plates (61) North American, South
American, Eurasian, African, Australian,
Antarctic Pacific Small plates (2 6) Arabian,
Indian Scotia, Caribbean, Nazca, Cocos, Juan de
Fuca, Philippine Sea
Contain continental lithosphere Purely oceanic
14
J. Tuzo Wilson
  • Proposed hotspot hypothesis in 1963, in support
    of Hess seafloor spreading model
  • Had difficulty getting this work published!

15
J. Tuzo Wilson
  • Proposed transform plate boundary hypothesis in
    1965 to explain linear fracture zones in oceans
  • Realized that motion on an oceanic transform
    fault is opposite to apparent offset of ridges

16
The Wilson Cycle
1. Continental breakup (rifting) 2. Opening of
ocean basin 3. Subduction zones form 4. Ocean
basin closes 5. Continents collide and form high
mountains 6. Crust thins by erosion
17
Types of plate boundaries
