Characterizing doseresponse model uncertainty using model averaging

1
Characterizing dose-response model uncertainty
using model averaging

• Matthew W. Wheeler
• NIOSH
• MWheeler_at_cdc.gov

The findings and conclusions in this report are
those of the authors and do not necessarily
represent the views of the National Institute for
Occupational Safety and Health
2
Acknowledgements

• A. John Bailer
• Miami University/NIOSH

3
Outline

• Introduction/Motivation.
• Model Averaging 101.
• Validation Simulation Study.
• MA Software for dichotomous response.
• Low Dose Extrapolations.
• Conclusions/Future research.

4
Introduction/Motivation

• Model choice is frequently often a point of
  contention among risk assessors/risk managers.
• Frequently multiple models describe the data
  equivalently.
• Two models estimates of risk, especially at the
  lower bound, can differ dramatically.
• Model uncertainty is inherent in most risk
  estimation, though practically ignored in most
  situations.

5
Introduction/Motivation (cont)

• Consider the problem of estimating a benchmark
  dose (BMD) from dichotomous dose response data.
• Here we seek to estimate the BMD from a
  plausible model, given experimental data.
• In these experiments
• Animals are exposed to some potential hazard.
• The adverse response is assumed to be distributed
  binomially.
• Risk (i.e, probability of adverse response) is
  estimated using regression modeling.
• Multiple dose-response models can be used to
  estimate risk.

6
Common Dose-Response Models Used

• logistic model
  (1)
• log-logistic model
  (2)
• gamma
  (3)
• multistage
  (4)
• probit
  (5)

7
Common Dose-Response Models Used

• log-probit
  (6)
• quantal-linear
  (7)
• quantal-quadratic
  (8)
• Weibull (9)
• where G(a) gamma function evaluated at a, for
  ?(x) CDF N(0,1) and pi ? when di0 for models
  (2) and (7).

8
Benchmark dose estimation

• BMD is the dose associated with the a specified
  increase in response relative to the control
  response (BMR) e.g.,
• dose d such that BMRpd- p0/1- p0 or
• BMR pd- p0
• The BMR is commonly set at values of 1, 5, 10.
• BMDL 100(1-a) lower confidence limit on the
  BMD.
• NOTE As pd is dependent on a model thus the BMD
  is model dependent!!

9
Typical Risk Estimation Process

• Given data (in absence of mechanistic
  information), a typical analyst will
• Estimate the regression coefficients for models
  (1)-(9).
• Estimate the BMD/BMDL given the model.
• Pick the best model.

10
Example of this

• Consider TiO2 lung tumor data which has been
  combined from the studies of Heinrich et al.
  (1995) Muhle et al. (1991) and Lee et al. (1985).
• Here the benchmark dose (BMD) as well as its
  lower bound (BMDL) are estimated at BMRs of 10
  and 1.

11
All fits were obtained using the US EPAs
BMDS Calculated using the number of parameters
vs. the number of non-bounded parameters.
12
(No Transcript)
13
Model Choice

• If we pick best AIC the quantal-quadratic model
  BMD estimates would be chosen.
• If we pick the best Pearson ?2 test statistic
  the 3-degree multistage model would be chosen.
• All of the models are reasonable based on these
  statistics.

14
Model Choice (cont)

• Estimates are reasonably similar at the 10
  estimate.
• Estimates vary by a factor of 5 for the 1
  estimate.
• If a BMR of 0.1 is used (results not shown) the
  Ti02 BMD/BMDL estimates differ by a factor of 35.

• This heterogeneity in model estimates exists even
  though the model fit statistics are very similar.

• Model uncertainty results when any one of the
  above models is chosen.

15
Model Averaging

• A better way would be to find an adequate way to
  combine all estimates, and thus describe/account
  for model uncertainty.
• Model Averaging (MA) is one such method that may
  satisfactorily account for model uncertainty.
• Instead of focusing on a single model it allows
  researchers to focus on plausible behavior.

16
Model Averaging (cont.)

• We can think of any model contributing
  information (including possible bias) to an
  analysis.
• Picking any one model ignores other plausible
  information, and possibly introduces bias into
  the analysis.
• Model averaging is a method that attempts to
  synthesize all of the information available.

17
Model Averaging (cont)

• Kang et al. (Regulatory Toxicology and
  Pharmacology, 2000) and Bailer et al. (Risk
  Analysis,2005) proposed model averaging for risk
  assessment.
• They used an Average-BMD methodology. (i.e.,
  the calculated statistics were averaged, not the
  corresponding dose response curve)
• Averaged-BMD MA is not described here, but its
  performance is often poor (Wheeler Bailer,
  Environmental and Ecological Statistics, (2009))

18
Average-Model MA

• Instead of averaging statistics we could average
  models.
• Given the fits of models (1)-(9) a MA procedure
• Calculates the dose-response based upon a
  weighted average of dose-responses Raftery et al.
  (1997), Buckland et al. (1997), with the MA
  dose-response curve estimated as
• Weights are formed as
• Where IiAIC, IiKIC , or IiBIC. Other weights
  are possible.

19
(No Transcript)
20
Average-Model MA Benchmark Dose

• Given this Average-model, the benchmark dose is
  then computed by finding the dose that satisfies
  the equation
• BMR pMA(d)i- p MA(0)/1- p MA(0).
• The BMDL is computed through a parametric
  bootstrap. Here the 5th percentile of the
  bootstrap distribution is used to compute the 95
  lower tailed confidence limit estimate on the
  BMD.

21
Average-Model vs. Average-Dose

• This is substantially different from the
  average-dose method.
• Average-Dose
• Model Fits ? Individual BMD estimation ? BMD MA
  estimate
• Average-Model
• Model Fits ? MA Model Estimate ? MA-BMD
  estimation

22
TiO2 Analysis Revisited
23
Validation Study

• MA seems like a good idea, however we need to
  know if it works well in practice.
• A simulation study was conducted to investigate
  the behavior of MA.

24
Validation Study

• 54 true model conditions, using models (1) (9)
  were used in the simulation.
• Full study described in Wheeler and Bailer (Risk
  Analysis, 2007)

25
Validation Study (Cont)

• The simulation proceeded by generating
  hypothetical toxicology experiments with response
  probability p(d).
• With p(d) specified by one a parameterization of
  one of the models (1)-(9).
• These experiments consisted of 4 dose group
  design with doses of 0, 0.25, 0.50, and 1.0. As
  well as a 6 dose group design (not reported)
• n50 for all dose groups.
• 2000 experiments were generated per true
  dose-response curve.
• Bias as well as coverage i.e., Pr(BMDL
  BMDtrue) was estimated.
• Coverage is reported here.

26
Validation Study (Cont)

• In each experiment the average-model BMD as
  well as the BMDL was estimated.
• BMRs of 1 and 10 were used to estimate the BMD.
• Two model spaces for averaging were considered.
• One space consisted of three flexible models the
  multistage, Weibull and the log-probit model.
• The second space had seven models that added the
  probit, logistic, quantal-linear, and
  quantal-quadratic to the three model space.
• The simulation took approximately 1 CPU year of
  computation.

27
Coverage BMR 10
28
Coverage BMR 1
29
Coverage (Summary)

• Nominal coverage is reached for most simulation
  conditions.
• MA fails to reach nominal coverage in the
  quantal-linear and similar cases.

30
Quantal-Linear Problems

• It is important to understand why the BMD is
  mischaracterized in the quantal linear case.
• We study this through investigating the sampling
  distribution.
• Here we can see the skewed sampling distribution,
  at low doses, might be the culprit

31
Sampling distribution for the quantal-linear
model
32
Average fit for 3-model MA models
33
Quantal Linear Bias

• The flexibility of the models combined with the
  sampling distribution introduces bias into the
  estimation of the dose-response curve.
• The bias carries through in BMD estimation.
• This also may be the cause of the conservative
  behavior (i.e. coverage gt 99) seen in the
  quantal-quadratic case.

34
Final notes on the Quantal Linear model

• Improved coverage can be obtained using BCa
  bootstrap intervals.
• Other results suggest that MA is superior to
  picking the best model.
• The results show MA is not a panacea, it is
  however a step in the right direction.

35
(No Transcript)
36
Model Averaging Software

• Implementation of Average Model MA is
  difficult.
• The simulation code has been repackaged to allow
  users to implement dichotomous dose-response
  model averaging.
• This is done in a simple MS Windows command
  prompt program.

37

• The software should be available shortly online.
  At the Journal of Statistical Softwares web
  site. (http//www.jstatsoft.org/)
• Implementation is described in Wheeler and Bailer
  (Journal of Statistical Software, In Press/(2008))

38
MA Low Dose Extrapolations

• Because model averaging accounts for model
  uncertainty, many are curious about MA and the
  use of low dose extrapolations.
• Specifically people want to know if it is still
  best practice to calculate the BMDL at the point
  of departure using MA (usually specified at a BMR
  of 10), and then do a linear extrapolation?

39
Low Dose Extrapolations

• The answer is yes and no.
• This is because at low doses the MA procedure is
  performing its own linear extrapolation.
• Thus if you dont, it will.
• As an example consider the Ti02 data above.
• We look at the extra risk curve using
• A linear low dose extrapolation, using the
  linearized multistage mode, with an excess risk
  of 10 being the point of departure.
• MA lower bound estimate.
• MA estimated extra risk curve.

40
(No Transcript)
41
Low Dose Extrapolations

• The MA lower bound estimate is approximately
  linear at doses below 0.1.
• The estimated risk, given a dose, is not
  substantially different (i.e., an order of
  magnitude) from the linearized multistage model
  estimate of risk.
• Other examples (with smaller sample sizes) show
  even less departure from the linearized
  multistage low dose linear extrapolation.

42
Linear Extrapolations

• Consider a fixed response of 20, 20, 20, 50,
  90, at doses of 0, 0.5, 1, 2 and 4.
• Further consider experiments having n 10, 20,
  50 and 100, given the above response.
• Thus we have the same response, all we do is
  increase the sample size. We ask the question how
  does MA respond?

43
Estimated MA Dose Response
Estimated MA 95 Lower Bound
44
Low Dose Extrapolations

• At low doses model averaging is essentially
  performing a linear extrapolation.
• The only difference is that it is essentially
  picking the point of departure, which is often
  very close to the standard 10.
• It is going to be different from the standard
  approach.
• The difference is not an order of magnitude,
  which is often suggested by non-linear dose
  response curves.

45
Conclusions

• Simulation Results Software Linearization
  study implies dichotomous based model averaging
  can be used reliably in ones own research.
• Though we have tested the software, and fixed
  many bugs, it is still a use at your own risk
  program.

46

• As mentioned before model averaging is not a
  panacea.
• As such it does not
• Relieve scientists from using their expert
  judgment.
• Remove the need for adequate individual model fit
  diagnostics.
• Remove all model uncertainty from the analysis.

47

• It does
• Reframe the debate of model choice.
• Produces relatively stable central estimates
  often independent of a given model being included
  in the average.

48
Selected References

• Raftery, A. E. (1995). Bayesian model selection
  in social research. Sociological Methodology,
  25, 111-163.
• Hoeting, J.A., Madigan, D., Raftery, A.E.,
  Volinsky, C.T. (1999) Bayesian model averaging
  a tutorial. Statistical Science, 14, 382-417.
• Buckland, S.T., Burnham, K. P., Augustin, N.
  H., (1997). Model Selection An Integral Part of
  Inference. Biometrics, 53, 603-618.
• Kang, S.H., Kodell, R.L., Chen, J.J. (2000)
  Incorporating Model Uncertainties along with Data
  Uncertainties in Microbial Risk Assessment.
  Regulatory Toxicology and Pharmacology, 32,
  68-72.
• Bailer, A.J., Noble R.B. and Wheeler, M. (2005)
  Model uncertainty and risk
• estimation for quantal responses. Risk Analysis,
  25,291-299.
• Wheeler, M. W., Bailer, A.J., (2007).
  Properties of model-averaged BMDLs A study of
  model averaging in dichotomous risk estimation.
  Risk Analysis 27, 659670
• Wheeler, M. W., Bailer, A.J. (2008). Model
  Averaging Software for Dichotomous Dose Response
  Risk estimation. Journal of Statistical Software
  (Accepted)
