Symbolic Model Verifier: Introduction

1
Symbolic Model Verifier Introduction

• Chien-Liang Chen (???)

2
Useful Link

• CMU Model Checking homepage
• http//www.cs.cmu.edu/modelcheck/smv.html
• Cadence SMV
• http//www-cad.eecs.berkeley.edu/kenmcmil/smv
• NuSMV
• http//nusmv.irst.itc.it/

3
SMVSymbolic Model Verifier

• Ken McMillan, Symbolic Model Checking An
  Approach to State Explosion Problem, 1993.
• Finite-state Systems described in a specialized
  language
• Specifications given as CTL formulas
• Internal representation using BDDs
• Automatically verifies specification or produce
  counterexamples

4
SMVSymbolic Model Verifier
5
SMVSymbolic Model Verifier

• SMV is a program that verifies whether a logic
  model ? representing a systems behaviour
  satisfies temporal logic (CTL) formulate f
  representing desired properties of the system
• ? f
• In SMV, the logic model is a symbolic
  representation of the systems reachable state
  space.
• Developed to verify synchronous circuits
• Extended to verify asychronous circuits
• Successfully used to verify models of reactive
  software system

6
Reactive Systems

• System interacts with its environment, monitoring
  and responding to environmental events
• Computation may not terminate
• System behaviour changes over time, in reaction
  to history of inputs
• Complexity is due to concurrency and interactions
  among components
• Examples operating systems, embedded systems,
  process-control systems, financial trading
  systems, automated banking machines, etc.

7
Compared to Transformational Programs

• Program computes a function from inputs to
  outputs
• Complexity is in data transformations
• Examples compilers, filters, payroll systems,
  scientific computations

8
SMV Modelling

• Goal is to describe control and interaction.
  Hence, no complex data structures, not much data
  manipulation.
• SMV Language Communicating Finite State Machines
  (FSMs with variables and communication channels)
• System may consist of several modules
• Modules consist of several simple parallel
  assignments
• Model may also specify constraints on
  environments behaviour

9
SMV Modelling

• A system is described as a set of modules. Each
  module is a reactive system interacting with
  other modules and the systems environment.
• Each module has variables that it reacts to, and
  that it manipulates.
• In each module, there are variable declarations,
  variable assignments, and properties that we want
  to check.
• The main module is like a main program. In the
  simplest SMV descriptions, we use only the main
  module and no sub-modules.
• Modules can be parameterized, and the main module
  can create instances of modules to describe the
  system.

10
SMV Modelling

• Recall, that the SMV modelling notation is used
  to describe communicating finite state machines.
• It consists of a set of modules, with one main
  module.
• In each module there are
• variables declarations,
• variable initialization,
• assignments, and
• properties that we want to check.

11
Symbolic Model Verifier

• SMV language
• Module
• Module name
• VAR
• Variable declaration
• Boolean, Bounded Integer, Enumerated
• ASSIGN
• Initial and next value of variables
• DEFINE
• Macros
• TRANS
• Constraint on systems transition relation
• SPEC
• Property to check

12
Symbolic Model Verifier

• SMV language
• INIT
• The set of initial states of the model
• INVAR
• The set of all states of the model restrict to
  those that satisfy a Boolean expression under the
  INVAR keyword.

13
Data types and type declarations
14
Boolean, enumerated and subrange types
15
Arrays

• An array of signals is declared in the following
  way
• ltsignalgt array ltxgt..ltygt of lttypegt
• This declares a collection of signals of type
  lttypegt, with subscripts running from ltxgt to ltygt.
  For example, the declaration
• zip array 2..0 of boolean
• is equivalent to declaring.
• zip2 boolean
• zip1 boolean
• zip0 boolean

16
Multidimensional arrays

• Arrays of arrays can also be declared. For
  example,
• matrix array 0..1 of array 2..0 of boolean
• is equivalent to
• matrix0 array 2..0 of boolean
• matrix1 array 2..0 of boolean
• The boolean signals declared in this way are
• matrix00 matrix01 matrix02
• matrix10 matrix11 matrix12

17
Generic arrays

• Note that an array in SMV is not really a data
  type. It is simply a collection of signals with
  similar names. This means that it is possible to
  declare an array'' whose elements have
  different types, by simply declaring the elements
  individually. For example
• state0 ready, willing
• state1 ready, willing, able
• state2 ready, willing, able, exhausted

18
Structure

• A structure is a collection of signals that are
  referred to by symbolic names, rather than
  numeric subscripts. A structure declarion has
  this form
• foo struct
• c1 type1
• c2 type2
• ...
• cn typen
• where c1...cn are symbolic names. This
  declaration is exactly equivalent to the
  declarations
• foo.c1 type1
• foo.c2 type1
• ..
• foo.cn type1
• That is, like an array, a structure is simply a
  collection of signals with similar names.

19
Arithmetic Operators
20
Comparison Operators
21
Boolean Operators

• The boolean operators are
• '', for logical and,
• '' for logical or,
• '' for logical not,
• '' for exclusive or ,
• -gt'' for implies, and
• lt-gt'' for if-and-only-if (exclusive nor).
• The boolean values are 0 (false) and 1 (true).

22
Signals and assignments

• A value of a signal is an infinite sequence of
  values of a given type. For example,
• 0101...
• is a sequence of type boolean (of course, it is
  also an integer sequence). Normally, we
  interpreted this sequence as being a seqeunce of
  values occurring over time, although this
  interpretation is not necessary.

23
Operations on signals

• An operator is applied to a signal value one
  element at a time. For example, the operator
  stands for logical not''. Thus if
• foo 0101...
• then
• foo 1010...
• That is, it is the result of applying logical
  not'' to each element of the sequence.
  Similarly, stands for logical and''. Thus, if
• foo 0101...
• and bar 0011...
• then
• foo bar 0001...

24
Assignments

• An assignment is of the form
• ltsignalgt ltexprgt
• where ltexprgt is an expression that combines other
  signals using operators like and . Unlike an
  assignent in a typical procedural'' language,
  this assignment means exactly what it says that
  ltsignalgt is equal to ltexprgt. So for example,
  suppose we make the assignment
• zip foo bar

25
Rules for assignments

• An SMV program amounts simply to a system of
  simultaneous equations, with a set of unkowns
  that are the declared signals. With an arbitrary
  set of equations, there is, of course, no
  guarantee that a solution exists, or that the
  solution is unique. Examples of systems that have
  no solutions are
• x x 1
• or
• next(x) x 1
• next(x) x - 1
• An example of a system with many solutions is
• x y
• y x

26
Rules for assignments

• The single assignment rule - each signal may be
  assigned only once.
• The circular dependency rule - a program may not
  have cycles'' in its dependency graph that are
  not broken by delays.

27
Nondeterministic assignments

• Non-determinism more than one outcome possible.
• Non-deterministic assignments
• x 1,2,3,4
• Undefined assignments
• A variable of undefined value may take on any
  value in its type. See examples next page. Note
  undefined assignments are not a good idea!

28
Undefined Assignments
29
Unit delay assignments - the next'' operator

• If x is a signal, then next(x) is, intuitively,
  the next'' value of x. More precisely, the i-th
  value of next(x) is equal to the (i1)st value of
  x. Thus, for example, if x 0,1,2,3,... Then
  next(x) 1,2,3,4,...
• For example, assuming x and y are boolean
  signals, next(x) y x
• We can determine this initial value by assigning
• init(x) 0
• In this case, if we had
• y 0101...
• we would get
• x 00110011...

30
Conditionals
31
Conditionals
32
Conditionals
33
Defaults

• The default'' construct provides a way of
  automatically filling in the cases where a signal
  is undefined with a default value. The syntax is

• default
• ltstmt1gt
• in
• ltstmt2gt
• The effect of this statement is to use the
  assignments in ltstmt1gt in any cases in ltstmt2gt
  where the given signal is unassigned.

34
Defaults
35
Complex conditionals - switch and case
36
Complex conditionals - switch and case
37
Complex conditionals - switch and case
38
Complex conditionals - switch and case
39
Basic for-loops

• For example,
• for(i 0 i lt 3 i i 1)
• xi i
• is in every way equivalent to
• x0 0
• x1 1
• x2 2
• The general form of the loop is
• for(var init cond var next)
• ltstmtgt

40
Kripke structure
MODULE main VAR state s0, s1, s2 ASSIGN
init(state) s0 next(state) case
states0 s1 states1 s2
states2 s2, s0 1 state
esac DEFINE p states0 q
states2 SPEC AG(p ? AFq) SPEC AG AF p
s0
p
s2
s1
q
? true
? false Counter example s0,s1,s2,s2,s2
Kripke structure
SMV code
41
Ready-Busy Example
MODULE main VAR request boolean task_done
boolean state ready, busy ASSIGN
Init(state) ready next(state) case
state ready request busy state busy
task_done ready 1 state esac
42
Modules

• Module declarations
• Instantiations
• Input and output declarations
• Instance hierarchies
• Structured data types
• Defined types

43
Module declarations
44
Instantiations
45
Input and output declarations
46
Instance hierarchies
47
Instance hierarchies
48
Structured data types
49
Structured data types
50
Defined types
51
