Skoll: A System for Distributed Continuous Quality Assurance

1
Skoll A System for Distributed Continuous
Quality Assurance

• Atif Memon Adam Porter
• University of Maryland
• atif,aporter_at_cs.umd.edu

2
Quality Assurance for Large-Scale Systems

• Modern systems increasingly complex
• Run on numerous platform, compiler library
  combinations
• Have 10s, 100s, even 1000s of configuration
  options
• Are evolved incrementally by geographically-distri
  buted teams
• Run atop of other frequently changing systems
• Have multi-faceted quality objectives
• How do you QA systems like this?

3
Distributed Continuous Quality Assurance

• QA processes conducted around-the-world,
  around-the-clock on powerful, virtual computing
  grids
• Grids can by made up of end-user machines,
  project-wide resources or dedicated computing
  clusters
• General Approach
• Divide QA processes into numerous tasks
• Intelligently distribute tasks to clients who
  then execute them
• Merge and analyze incremental results to
  efficiently complete desired QA process
• Expected benefits
• Massive parallelization allows more, better
  faster QA
• Improved access to resources/environs. not
  readily found in-house
• Carefully coordinated QA efforts enables more
  sophisticated analyses

4
Collaborators
Doug Schmidt Andy Gohkale
Alex Orso
Myra Cohen
Murali Haran, Alan Karr, Mike Last, Ashish
Sanil
Sandro Fouché, Alan Sussman, Cemal Yilmaz (now at
IBM TJ Watson) Il-Chul Yoon
5
Skoll DCQA Infrastructure Approach
Clients
See A. Porter, C. Yilmaz, A. Memon, A.
Nagarajan, D. C. Schmidt, and B. Natarajan,
Skoll A Process and Infrastructure for
Distributed Continuous Quality Assurance. IEEE
Transactions on Software Engineering. August
2007, 33(8), pp. 510-525.
6
Skoll DCQA Infrastructure Approach
Clients
1. Model
See A. Porter, C. Yilmaz, A. Memon, A.
Nagarajan, D. C. Schmidt, and B. Natarajan,
Skoll A Process and Infrastructure for
Distributed Continuous Quality Assurance. IEEE
Transactions on Software Engineering. August
2007, 33(8), pp. 510-525.
7
Skoll DCQA Infrastructure Approach
Clients
2. Reduce Model
See A. Porter, C. Yilmaz, A. Memon, A.
Nagarajan, D. C. Schmidt, and B. Natarajan,
Skoll A Process and Infrastructure for
Distributed Continuous Quality Assurance. IEEE
Transactions on Software Engineering. August
2007, 33(8), pp. 510-525.
8
Skoll DCQA Infrastructure Approach
Clients
3. Distribution
See A. Porter, C. Yilmaz, A. Memon, A.
Nagarajan, D. C. Schmidt, and B. Natarajan,
Skoll A Process and Infrastructure for
Distributed Continuous Quality Assurance. IEEE
Transactions on Software Engineering. August
2007, 33(8), pp. 510-525.
9
Skoll DCQA Infrastructure Approach
Clients
4. Feedback
See A. Porter, C. Yilmaz, A. Memon, A.
Nagarajan, D. C. Schmidt, and B. Natarajan,
Skoll A Process and Infrastructure for
Distributed Continuous Quality Assurance. IEEE
Transactions on Software Engineering. August
2007, 33(8), pp. 510-525.
10
Skoll DCQA Infrastructure Approach
Clients
5. Steering
See A. Porter, C. Yilmaz, A. Memon, A.
Nagarajan, D. C. Schmidt, and B. Natarajan,
Skoll A Process and Infrastructure for
Distributed Continuous Quality Assurance. IEEE
Transactions on Software Engineering. August
2007, 33(8), pp. 510-525.
11
The ACETAOCIAO (ATC) System

• ATC characteristics
• 2M line open-source CORBA implementation
• maintained by 40, geographically-distributed
  developers
• 20,000 users worldwide
• Product Line Architecture with 500 configuration
  options
• runs on dozens of OS and compiler combinations
• Continuously evolving 200 CVS commits per week
• Quality concerns include correctness, QoS,
  footprint, compilation time more

12
Define QA Space
Options Type Settings
Operating System compile-time Linux, Windows XP, .
TAO_HAS_MINIMUM_CORBA compile-time True, False
ORBCollocation runtime global, per-orb, no
ORBConnectionPurgingStrategy runtime lru, lfu, fifo, null
ACE_version component version v5.4.3, v5.4.4,
TAO_version component version v1.4.3, v1.4.4,
run(ORT/run_test.pl) test case True, False
Constraints Constraints Constraints
(TAO_HAS_AMI) ? (TAO_HAS_MINIMUM_CORBA) (TAO_HAS_AMI) ? (TAO_HAS_MINIMUM_CORBA) (TAO_HAS_AMI) ? (TAO_HAS_MINIMUM_CORBA)
run(ORT/run_test.pl) ?(TAO_HAS_MINIMUM_CORBA) run(ORT/run_test.pl) ?(TAO_HAS_MINIMUM_CORBA) run(ORT/run_test.pl) ?(TAO_HAS_MINIMUM_CORBA)
13
Nearest Neighbor Search
14
Nearest Neighbor Search
15
Nearest Neighbor Search
16
Nearest Neighbor Search
17
Fault Characterization

• We used machine learning techniques
  (classification trees) to model option setting
  patterns that predict test failures

18
Applications Feasibility Studies

• Compatibility testing of component-based systems
• Configuration-level fault characterization
• Test case generation input space exploration

19
Compatibility Testing of Comp-Based Systems

• Goal
• Given a component-based system, identify
  components their specific versions that fail to
  build
• Solution Approach
• Sample the configuration space, efficiently test
  this sample identify subspaces in which
  compilation installation fails
• Initial focus on building installing
  components. Later work will add functional and
  performance testing

See I. Yoon, A. Sussman, A. Memon A. Porter,
Direct-Dependency-based Software Compatibility
Testing. International Conference on Automated
Software Engineering, Nov. 2007 (to appear).
20
The InterComm (IC) Framework

• Middleware for coupling large scientific
  simulations
• Built from up to 14 other components (e.g., PVM,
  MPI, GCC, OS)
• Each comp can have several actively maintained
  versions
• There are complex constraints between components,
  e.g.,
• Requires GCC version 2.96 or later
• When configured with multiple GNU compilers, all
  must have the same version number
• When configured with multiple comps that use MPI,
  all must use the same implementation version
• http//www.cs.umd.edu/projects/hpsl/chaos/Research
  Areas/ic
• Developers need help to
• Identify working/broken configurations
• Broaden working set (to increase potential user
  base)
• Rationally manage support activities

21
Annotated Comp. Dependency Graph

• ACDG (CDG, Ann)
• CDG DAG capturing inter-comp deps
• Ann comp. versions constraints
• Constraints for each cfg, e.g.,
• ver (gf) x ? ver (gcr) x
• ver (gf) 4.1.1 ? ver (gmp) 4.0
• Can generate cfgs from ACDG
• 3552 total cfgs. Takes up to 10,700 CPU hrs to
  build all

22
Improving Test Execution

• Cfgs often share common build subsequences. This
  build effort should be reusable across cfgs
• Combine all cfgs into a data structure called a
  prefix tree
• Execute implied test plan across grid by (1)
  assigning subpaths to clients, (2) building each
  subcfg in a VM caching the VMs to enable reuse
• Example with 8 machines each able to cache up
  to 8 VMs exhaustive testing takes up to 355 hours

23
Direct-Dependency (DD) Coverage

• Hypothesis A comps build process is most likely
  to be affected by the comps on which it directly
  depends
• A directly depends on B iff there is a path (in
  CDG) from A to B containing no comp nodes
• Sampling approach
• Identify all DDs between every pair of components
• Identify all valid instantiations of these DDs
  (ver. combs that violate no constraints)
• Select a (small) set of cfgs that cover all valid
  instantiations of the DDs

24
Executing the DD Coverage Test Suite

• DD test suite much smaller than exhaustive
• 211 cfgs with 649 comps vs 3552 cfgs with 9919
  comps
• For IC, no loss of test eff. (same build failures
  exposed)
• Speedups achieved using 8 machines w/ 8 VM cache
• Actual case 2.54 (18 vs 43 hrs)
• Best case 14.69 (52 vs 355 hrs)

25
Summary

• Infrastructure in place working
• Complete client/server implementation using
  VMware
• Simulator for large scale tests on limited
  resources
• Initial results promising, but lots of work
  remains
• Ongoing activities
• Alternative algorithms test execution policies
• More theoretical study of sampling test exec
  approaches
• Apply to more software systems

26
Configuration-Level Fault Characterization

• Goal
• Help developers localize configuration-related
  faults
• Current Solution Approach
• Use covering arrays to sample the cfg space to
  test for subspaces in which (1) compilation fails
  or (2) reg. tests fail
• Build models that characterize the configuration
  options and specific settings that define the
  failing subspace

See C. Yilmaz, M. Cohen, A. Porter, Covering
Arrays for Efficient Fault Characterization in
Complex Configuration Spaces, ISSTA04, TSE v32
(1)
27
Covering Arrays

• Compute test schedule from t-way covering arrays
• a set of configurations in which all ordered
  t-tuples of option settings appear at least once
• 2-way covering array example

Configurations Configurations Configurations Configurations Configurations Configurations Configurations Configurations Configurations Configurations
C1 C2 C3 C4 C5 C6 C7 C8 C9
O1 0 0 0 1 1 1 2 2 2
O2 0 1 2 0 1 2 0 1 2
O3 0 1 2 1 2 0 2 0 1
28
Limitations

• Must choose the strength covering array before
  computing it
• No way to know, a priori, what the right value is
• Our experience suggests failures patterns can
  change over time
• Choose too high
• Run more tests than necessary
• Testing might not finish before next release
• Non-uniform sample negatively affects
  classification performance
• Choose too low
• Non-uniform sample negatively affects
  classification techniques
• Must repeat process at higher strength

29
Incremental Covering Arrays

• Start with traditional covering array(s) of low
  strength (usually 2)
• Execute test schedule classify observed
  failures
• If resources allow or classification performance
  requires
• Increment strength
• Build new covering array using previously run
  array(s) as seeds

See S. Fouche, M. Cohen and A. Porter. Towards
Incremental Adaptive Covering Arrays, ESEC/FSE
2007, (to appear)
30
Incremental Covering Arrays (cont.)

• Multiple CAs at each level of t
• Use t1 as a seed for the first t1-way array
  (t11)
• To create the ith t-way array (ti), create a seed
  of size t-11 using non-seeded cfgs from t-1i
• If seed lt t-11 complete seed with cfgs from
  t11

31
MySQL Case Study

• Project background
• Widely-used, 2M line open-source database
  project
• Cont. evolving maint. by geographically-distribu
  ted developers
• Dozens of cfg opts runs on dozens of
  OS/compiler combos
• Case study using release 5.0.24
• Used 13 cfg opts with 2-12 settings each (gt 110k
  unique cfgs)
• 460 tests/per config across a grid of 50 machines

• Executed 50M tests total using 25 CPU years

32
Results

• Built 3 trad and incr covering arrays for 2 ? t ?
  4
• Traditional sizes 108, 324, 870
• Incremental sizes 113, 336 (223), 932 (596)
• Incr appr exposed classified the same failures
  as trad appr
• Costs depend on t failures patterns
• Failures at level t Inc gt Trad (4-9)
• Failures at level lt t Inc lt Trad (65-87)
• Failures at level gt t Inc lt Trad (28-38)

33
Summary

• New application driving infrastructure
  improvements
• Initial results encouraging
• Applied process to a configuration space with
  over 110K cfgs
• Found many test failures corresponding to real
  bugs
• Incremental approach more flexible than
  traditional approach. Appears to offer
  substantial savings in best case, while incurring
  minimal cost in worst case
• Ongoing extensions
• MySQL continuous build process
• Community involvement starting
• Want to volunteer? Go to http//www.cs.umd.edu

34
GUI Test Case Executable By A Robot

• JFCUnit
• Other interactions
• Exponential with length
• Capture/replay
• Tedious
• Test common sequences
• Bad Idea
• Model-based techniques
• GUITAR
• guitar.cs.umd.edu

35
Modeling The Event-Interaction Space
Sampling

• Event flow graph (EFG)
• Nodes all GUI events
• Starting events
• Edges Follows
• relationship
• Reverse Engineering
• Obtained Automatically

• Test case generation
• Cover all edges

See Atif M. Memon and Qing Xie, Studying the
Fault-Detection Effectiveness of GUI Test Cases
for Rapidly Evolving Software. IEEE Transactions
on Software Engineering, vol. 31, no. 10, 2005,
pp. 884-896.
36
Lets See How It Works!

• Point to the CVS head
• Push the button
• Read error report
• What happens
• Gets code from CVS head
• Builds
• Reverse engineers the event-flow graph
• Generates test cases to cover all the edges
• 2-way covering
• Runs them
• SourceForge.net
• Four applications

37
Digging Deeper!

• Intuition
• Non-interacting events (e.g., Save, Find)
• Interacting events (e.g., Copy, Paste)
• Key Idea
• Identify interacting events
• Mark the
• EFG edges
• (Annotated graph)
• Generate
• 3-way, 4-way, covering
• test cases for interacting
• events only

EFG
38
Identifying Interacting Events

• High-level overview of approach
• Observe how events execute on the GUI
• Events interact if they influence one anothers
  execution
• Execute event e2 execute event sequence lte1, e2gt
• Did e1 influence e2s execution?
• If YES, then they must be tested further
  annotate the lte1, e2gt edge in graph
• Use feedback
• Generate seed suite
• 2-way covering test cases
• Run test cases
• Need to obtain sets of GUI states
• Collect GUI run-time states as feedback
• Analyze feedback and obtain interacting event
  sets
• Generate new test cases
• 3-way, 4-way, covering test cases

39
Did We Do Better?

• Compare feedback-based approach to 2-way coverage

40
Summary

• Manually developed test cases
• JFCUnit, Capture/replay
• Can be deployed and executed by a robot
• Too many interactions to test
• Exponential
• The GUITAR Approach
• Develop a model of all possible interactions
• Use abstraction techniques to sample the model
• Develop adequacy criteria
• Generate an initial test suite Develop an
  Execute tests collect feedback annotate
  model generate tests cycle
• Feasibility study results

41
Future Work

• Need volunteers for MySQL Build Farm Project
• http//skoll.cs.umd.edu
• Looking for more example systems (help!)
• Continue improving Skoll system
• New problem classes
• Performance and robustness optimization
• Improved use of test data
• Test case ROI analysis
• Configuration advice
• Cost-aware testing (e.g., minimize power,
  network, disk)
• Use source code analysis to further reduce state
  spaces
• Extend test generation technology outside GUI
  applications
• QA for distributed systems

42
The End
