NPS: A Non-interfering Web Prefetching System

1
NPS A Non-interfering Web Prefetching System

• Ravi Kokku, Praveen Yalagandula,
• Arun Venkataramani, Mike Dahlin
• Laboratory for Advanced Systems Research
• Department of Computer Sciences
• University of Texas at Austin

2
Summary of the Talk

• Prefetching should be done aggressively, but
  safely
• ? Safe Non-interference with demand
  requests
• Contributions
• A self-tuning architecture for web prefetching
• Aggressive when abundant spare resources
• Safe when scarce resources
• NPS A prototype prefetching system
• Immediately deployable

3
Outline

• Prefetch aggressively as well as safely
• Motivation
• Challenges/principles
• NPS system design
• Conclusion

4
What is Web Prefetching?

• Speculatively fetch data that will be accessed in
  the future
• Typical prefetch mechanism PM96, MC98, CZ01

Client
Server
Demand Requests
Responses Hint Lists
Prefetch Requests
Prefetch Responses
5
Why Web Prefetching?

• Benefits GA93, GS95, PM96, KLM97, CB98, D99,
  FCL99, KD99, VYKSD01,
• Reduces response times seen by users
• Improves service availability
• Encouraging trends
• Numerous web applications getting deployed
• News, banking, shopping, e-mail
• Technology is improving rapidly
• ? capacities and ? prices of disks and networks

Prefetch Aggressively
6
Why doesnt everyone prefetch?

• Extra resources on servers, network and clients
• Interference with demand requests
• Two types of interference
• Self-Interference Applications hurt themselves
• Cross-Interference Applications hurt others
• Interference at various components
• Servers Demand requests queued behind prefetch
• Networks Demand packets queued or dropped
• Clients Caches polluted by displacing more
  useful data

7
Example Server Interference

• Common load vs. response curve
• Constant-rate prefetching reduces server capacity

0.7
Pfrate5
0.6
0.5
0.4
Pfrate1
Avg. Demand Response Time (s)
Demand
0.3
0.2
0.1
0
100
200
300
400
500
600
700
800
Demand Connection Rate (conns/sec)
Prefetch Aggressively, BUT SAFELY
8
Outline

• Prefetch aggressively as well as safely
• Motivation
• Challenges/principles
• Self-tuning
• Decoupling prediction from resource management
• End-to-end resource management
• NPS system design
• Conclusion

9
Goal 1 Self-tuning System

• Proposed solutions use magic numbers
• Prefetch thresholds D99, PM96, VYKSD01,
• Rate limiting MC98, CB98
• Limitations of manual tuning
• Difficult to determine good thresholds
• Good thresholds depend on spare resources
• Good threshold varies over time
• Sharp performance penalty when mistuned
• Principle 1 Self-tuning
• Prefetch according to spare resources
• Benefit Simplifies application design

10
Goal 2 Separation of Concerns

• Prefetching has two components
• Prediction What all objects are beneficial to
  prefetch?
• Resource management How many can we actually
  prefetch?
• Traditional techniques do not differentiate
• Prefetch if prob(access) gt 25
• Prefetch only top 10 important URLs
• Wrong Way! We lose the flexibility to adapt
• Principle 2 Decouple prediction from resource
  management
• Prediction Application identifies all useful
  objects
• In the decreasing order of importance
• Resource management Uses Principle 1
• Aggressive when abundant resources
• Safe when no resources

11
Goal 3 Deployability

• Ideal resource management vs. deployability
• Servers
• Ideal OS scheduling of CPU, Memory, Disk
• Problem Complexity N-Tier systems, Databases,

• Networks
• Ideal Use differentiated services/ router
  prioritization
• Problems Every router should support it
• Clients
• Ideal OS scheduling, transparent informed
  prefetching
• Problem Millions of deployed browsers
• Principle 3 End-to-end resource management
• Server External monitoring and control
• Network TCP-Nice
• Client Javascript tricks

12
Outline

• Prefetch Aggressively as well as safely
• Motivation
• Principles for a prefetching system
• Self-tuning
• Decoupling prediction from resource management
• End-to-end resource management
• NPS prototype design
• Prefetching mechanism
• External monitoring
• TCP-Nice
• Evaluation
• Conclusion

13
Prefetch Mechanism
Fileset
Hint Server
Server m/c
1. Munger adds Javascript to html pages
2. Client fetches html page
3. Javascript on html page fetches hint list
4. Javascript on html page prefetches objects
14
End-to-end Monitoring and Control
while(1) getHint( ) prefetchHint( )
GET http//repObj.html
200 OK
if (budgetLeft) send(hints) else
send(return later)

• Principle Low response times ? server not loaded
• Periodic probing for response times
• Estimation of spare resources (budget) at server
  AIMD
• Distribution of budget
• Control the number. of clients allowed to prefetch

15
Monitor Evaluation (1)
0.7
Manual tuning, Pfrate5
0.6
0.5
Manual tuning, Pfrate1
No-Prefetching
0.4
Avg Demand Response Time(sec)
0.3
Monitor
0.2
0.1
0
0
100
200
300
400
500
600
700
800
Demand Connection Rate (conns/sec)

• End-to-end monitoring makes prefetching safe

16
Monitor Evaluation (2)
No-Prefetching
80
60
Bandwidth (Mbps)
40
Demand pfrate1
20
Prefetch
pfrate1
0
0
100
200
300
400
500
600
700
800
Demand Connection Rate (conns/sec)

• Manual tuning is too damaging at high load

17
Monitor Evaluation (2)
No-Prefetching
80
PrefetchMonitor
DemandMonitor
60
Bandwidth (Mbps)
40
Demand pfrate1
20
Prefetch
pfrate1
0
0
100
200
300
400
500
600
700
800
Demand Connection Rate (conns/sec)

• Manual tuning too timid or too damaging
• End-to-end monitoring is both aggressive and safe

18
Network Resource Management

• Demand and prefetch on separate connections
• Why is this required?
• HTTP/1.1 persistent connections
• In-order delivery of TCP
• So prefetch affects demand
• How to ensure separation?
• Prefetching on a separate server port
• How to use the prefetched objects?
• Javascript tricks In the paper

19
Network Resource Management

• Prefetch connections use TCP Nice
• TCP Nice
• A mechanism for background transfers
• End-to-end TCP congestion control
• Monitors RTTs and backs-off when congestion
• Previous study OSDI 2002
• Provably bounds self- and cross-interference
• Utilizes significant spare network capacity
• Server-side deployable

20
End-to-end Evaluation

• Measure avg. response times for demand reqs.
• Compare with No-Prefetching and Hand-tuned
• Experimental setup

Network Cable modem, Abilene
Fileset
Client httperf
Trace IBM server
HintSvr PPM predict
21
Prefetching with Abundant Resources

• Both Hand-tuned and NPS give benefits
• Note Hand-tuned is tuned to the best

22
Tuning the No-Avoidance Case

• Hand-tuning takes effort
• NPS is self-tuning

23
Prefetching with Scarce Resources

• Hand-tuned damages by 2-8x
• NPS causes little damage to demand

24
Conclusions

• Prefetch aggressively, but safely
• Contributions
• A prefetching architecture
• Self-tuning
• Decouples prediction from resource management
• Deployable few modifications to existing
  infrastructure
• Benefits
• Substantial improvements with abundant resources
• No damage with scarce resources
• NPS prototype
• http//www.cs.utexas.edu/rkoku/RESEARCH/N
  PS/

25
Thanks
26
Prefetching with Abundant Resources

• Both Hand-tuned and NPS give benefits
• Note Hand-tuned is tuned to the best

27
Client Resource Management

• Resources CPU, memory and disk caches
• Heuristics to control cache pollution
• Limit the space prefetch objects take
• Short expiration time for prefetched objects
• Mechanism to avoid CPU interference
• Start prefetching after all demand done
• Handles self-interference more common case
• What about cross-interference?
• Client modifications might be necessary
