Respiratory Protection Devices

1
Respiratory Protection Devices

• Penn State
• Pesticide Education
• www.pested.psu.edu

2
Why wear a respirator?

• Protect your health
• Legal the label is the law

3
Respirable Health Hazards

• Many jobs
• expose people to

YOU THINK YOUR JOB STINKS?

• Mists
• Vapors
• Gases
• Molds
• Dust
• Fumes
• Smoke
• Aerosols

4
Normal Respiratory Anatomy
Modern Biology Holt Rinehart Winston
5
The Alveoli
The alveoli are where the oxygen from the air
enters your blood, and the carbon dioxide from
your body goes into the air. Here contaminants
in the air enter the bloodstream and are rapidly
transported throughout the entire body
6
Dust deposition in respiratory system
Andersen Samplers, Inc.
7
Health effects

• Acute inhalation effects
• may burn the entire respiratory tract and lead
  to pulmonary edema
• difficulty in breathing
• may enter blood stream very rapidly upon
  inhalation and have systemic effects

8
Health effects

• Chronic inhalation effects
• Repeated exposure leads to the formation of
  scar tissue.
• This destructs the walls of the alveoli sacs and
  decreases the area for air to be exchanged. Long
  term effects are definite.

9
Health effects
Progressive massive fibrosis 40-year-old miner
Healthy Tissue 90-year-old school teacher
Healthy Tissue
10
Legality

• You are legally required to follow all personal
  protective equipment instructions on the label.
• Pesticide labeling lists the minimum personal
  protective equipment you must wear while handling
  the pesticide.
• Often the labeling lists different requirements
  for different activities. Usually more
  requirements are needed for mixing and loading
  than for application.

11
(No Transcript)
12
Telone C17

• Handlers performing tasks with liquid contact
  potential must wear
• A half-face respirator with either an
  organic-vapor removing cartridge with a prefilter
  approved for pesticides (MSHA/NIOSH approval
  number prefix TC-23C) or canister approved for
  pesticides (MSHA/NIOSH approval number prefix
  TC-14G). See further regulatory requirements in
  the User Safety Requirements section on this label

13
Telone C17

• Handlers performing tasks with no liquid contact
  potential must wear
• A half-face respirator with either an
  organic-vapor removing cartridge with a prefilter
  approved for pesticides (MSHA/NIOSH approval
  number prefix TC-23C) or canister approved for
  pesticides (MSHA/NIOSH approval number prefix
  TC-14G).

14
Telone C17

• Handlers in treated area 1 to 5 days after
  application must wear
• A half-face respirator with either an
  organic-vapor removing cartridge with a prefilter
  approved for pesticides (MSHA/NIOSH approval
  number prefix TC-23C) or canister approved for
  pesticides (MSHA/NIOSH approval number prefix
  TC-14G).

15
Telone C17

• Handlers exposed to high airborne concentrations
  of this product, such as cleanup, following large
  spills and exposure to this product in poorly
  ventilated areas must wear
• Supplied air respirator with MSHA/NIOSH approval
  number prefix TC-19C for self-contained breathing
  apparatus (SCBA) with MSHA/NIOSH approval number
  prefix TC-13F. See further respirator
  requirements in the User Safety Requirements
  section on this label.

16
Telone C17 User Safety Requirements

• Respirator Requirements When a respirator is
  required for use with this product, the following
  criteria must be met
• Cartridges or canisters must be replaced daily or
  when odor or irritation from this product becomes
  apparent, whichever is sooner.

17
Telone C17 User Safety Requirements

• Respirator Requirements When a respirator is
  required for use with this product, the following
  criteria must be met
• Cartridges or canisters must be replaced daily or
  when odor or irritation from this product becomes
  apparent, whichever is sooner.
• Respirators must be fit-tested and fit-checked
  using a program that conforms to OSHAs
  requirements (in 29 CFR Part 1910.134).

18
Telone C17 User Safety Requirements

• Respirator Requirements When a respirator is
  required for use with this product, the following
  criteria must be met
• Cartridges or canisters must be replaced daily or
  when odor or irritation from this product becomes
  apparent, whichever is sooner.
• Respirators must be fit-tested and fit-checked
  using a program that conforms to OSHAs
  requirements (in 29 CFR Part 1910.134).
• Respirator users must be trained using a program
  that conforms to OSHAs requirements (in 29 CFR
  Part 1910.134).

19
Telone C17 User Safety Requirements

• Respirator Requirements When a respirator is
  required for use with this product, the following
  criteria must be met
• Cartridges or canisters must be replaced daily or
  when odor or irritation from this product becomes
  apparent, whichever is sooner.
• Respirators must be fit-tested and fit-checked
  using a program that conforms to OSHAs
  requirements (in 29 CFR Part 1910.134).
• Respirator users must be trained using a program
  that conforms to OSHAs requirements (in 29 CFR
  Part 1910.134).
• Respirator users must be examined by a qualified
  medical practitioner to ensure physical ability
  to safely wear the style of respirator to be worn.

20
Respirators and Physical Fitness

• Medical evaluations
• are required for anyone
• wearing respirators.
• Breathing through a
• respirator is work for the
• body.
• Respirators can be
• hazardous to people
• with heart or lung
• problems.

21
Protect yourself
When used properly, respirators prevent the
inhalation of chemicals and dust and therefore,
offer the best protection.
22
How Respirators Work

• Air movement is
• controlled by
• rubber inhalation
• and exhalation
• valves.
• The adjustable
• straps are used to
• keep the respirator
• snug on the face.

straps
inhalation valves
Facepiece
exhalation valve
cartridge
valve cover
23
How Respirators Work
When you inhale, air is pulled through the
cartridge, where air contaminants are trapped.
OSHA
24
How Respirators Work
Air inhaled
Air inhaled
Air exhaled
25
Respirator Use

• Agricultural jobs where respirators are required
• Handling chemicals
• (pesticides, disinfectants)
• Nutrient management
• Cleaning grain bins
• Handling moldy hay or
• silage
• Working in dusty fields

26
Causes of Pesticide Inhalation

• Breathing vapors, dusts, and mists from handling
  pesticides
• Using fumigants and other highly toxic pesticides
• Inhaling mists and vapors from pesticide drift

27
Causes of Pesticide Inhalation

• Working in poorly ventilated spaces
• Using the wrong respirator/cartridge for
  the job
• Using a respirator that fits poorly
• Using cartridges that are spent

28
Typical Applicator Questions

• I must wear a respirator which type is best?
• Arent they all the same?
• Some look differentdoes size matter?
• Are there any significant differences?
• Do I really need a fancy one? Wont a paper dust
  mask work?

29
Types of Respirators

• Video by
• Dr. Dennis Murphy
• PSU Professor of Agricultural Engineering

30
(No Transcript)
31
Dust/Nuisance Mask

• Not an approved respirator
• No certification markings
• One strap poor seal
• Filters down to 10 microns
• Negative pressure

32
Particulate Respirator

• Approved NIOSH respirator
• Usually has certification markings
• 2 straps
• Filters down to 0.3 microns
• Negative pressure

33
Particulate Respirator Series Codes
34
Chemical Cartridge Respirators

• Approved NIOSH respirator
• Certification markings on cartridges
• 2 strong adjustable straps
• Filters down to 0.3 microns
• Negative pressure

35
Respiratory Cartridges
Respirator Cartridge Color Coding
Ammonia- green
Organic vapor (solvents) - black
Acid gas (sulfuric acid, for example) - white
Acid gas and organic vapor - yellow
Acid gas, ammonia, organic vapor - brown
Chlorine white yellow
36
Powered Air Purifiers

• Approved NIOSH respirator
• Certification markings on cartridges
• Entire head / neck area enclosed
• Filters down to 0.3 microns
• Positive pressure

37
Supplied Air Respirator (SAR)
An atmosphere-supplying respirator for which the
source of breathing air is not designed to be
carried by the user. Also called air-line
respirator.
OSHA
38
Self-Contained Breathing Apparatus (SCBA)
An atmosphere-supplying respirator for which the
breathing air source is designed to be carried
by the user.
OSHA
39
How to Put on and Fit Test a Respirator

• Video by
• Dr. Dennis Murphy
• PSU Professor of Agricultural Engineering

40
(No Transcript)
41
Respirator Maintenance

• Respirators must be
• cleaned, inspected
• and maintained
• regularly.
• Clean in warm soapy
• water.
• Allow to dry thoroughly
• before storing or using.

42
Storage

• protect from
• contamination
• dust
• sunlight
• extreme
• temperatures
• moisture

43
(No Transcript)
44
(No Transcript)
45
Storage
46
(No Transcript)
47
(No Transcript)
48
Selection of Respirators
Select an appropriate respirator based on the
respiratory hazards to which the worker is
exposed, the workplace, and user factors.
49
Selection of Respirators

• When selecting a respirator for a pesticide
• READ
• THE
• LABEL

50
Penn State Pesticide Education Program

• www.pested.psu.edu
