Oracle%20Financial%20System

1

• Oracle Financial System
• Mary Ann Carr
• September 14, 2000

2
Financial Management Project

• The Financial Management Project (FMP) is a
  university-wide initiative to improve Carnegie
  Mellons financial systems and processes. FMP
  includes implementation of
• Integrated financial system (Oracle)
• Redesigned work processes
• Financial policies and consistent,
  university-wide procedures
• Comprehensive user education

3
Oracle Implementation Timeline

• May 1997 - Acquired Oracle Applications and
  development tools
• August 1997 - Beta Test Grants Management
• 1998 - 1999 - Project Implementation
• November 1999 - Big Bang Go-Live
• Today - System Stabilization and Upgrade
  Preparation
• - 300 Central and Campus Business Users
• - 600 Casual Users

4
FMP Deployment Requirements

• Support all major campus desktop platforms
• Achieve excellent performance on all platforms
• Implement a thin client
• Minimize software installation, distribution and
  maintenance
• Leverage existing infrastructure
• Mitigate any/all security risks

5
Oracle Applications Overview

• Core Financial Applications
• Self Service Web Applications
• Application Desktop Integrator Applications
• Budget Spreadsheet
• Feeder File Interface System
• CITRIX Application Server

6
Core Financial Applications - Overview

• Internet (Network) Computing Architecture
• Multi-Tier Tier Architecture
• Database Tier - DB, stored procedures,
  executables
• Application - web server, forms server
• Client - java-enabled web browser or applet
  viewer, forms client applet
• GUI Interface with Thin Client Implementation
• Java Applet connects to Oracles forms server,
  excepting initial signon HTML page

7
Multi-Tier Architecture
8
Self Service Web Applications

• Web-based Interface for Casual Users (travel
  expense reporting, pcard distributions)
• HTML and JavaScript
• Direct connection to an HTTP listener running
  Oracle Web Application Server
• Logic is executed through the Web Application
  Servers PL/SQL Cartridge, and Java servlets
• Database communication via JDBC

9
Application Desktop Integrator

• Excel-based interface and extension to Oracle
  application database
• Supports budget entry, journal entry, reporting,
  and analysis
• Communicates via SQLNet to database

10
Budget Spreadsheet

• Custom Excel-based budgeting tool
• Template files stored on file server
• Working budget files updated and stored locally
• Two possible transport mechanisms
• Budget inload functionality of ADI
• Web-based upload to interface tables

11
Feeder File Interface System

• Mechanism for uploading feeder files for import
  into Oracle GL and/or GM
• Validates and inloads feeder transactions
• Provides e-mail notification of process
  success/failure

12
CITRIX Application Server

• NT terminal server implementation to support
  UNIX, Macintosh and low-end PCs
• Access to Core Financials
• Access to ADI
• Possible file server for budget spreadsheet

13
System Configuration
14
Core Financial Applications Security

• Features
• Signed Java Applet guarantees its authenticity to
  the forms client and ensures that the forms
  server only accepts connections from certified
  forms clients (open TAR)
• All communication between the Forms client applet
  and forms server is encrypted using the RSA RC4
  40-bit standard form of encryption
• Application level security intact login
  id/password challenge/response
• Concerns
• Neither Web Browser (w/Java Plug-In, Jinitiator)
  nor Applet Viewer supports Secure Socket Layer
  transport (data encryption between the client and
  web server) at this timedesire for stronger
  encryption
• No certified Macintosh or Unix JVM as of 3/31/99
• Additional login/passworddesire to move to
  kerberos-based single sign-on

15
Self Service Web Applications Security

• Features
• Supports Secure Socket Layer transport (data
  encryption between the client and web server)
• Application level security intact login
  id/password challenge/response
• Concerns
• Additional login/passworddesire to move to
  kerberos-based single sign-on

16
Application Desktop Integrator Security

• Features
• Application level security intact encrypted
  login id/password challenge/response
• Ability to implement Oracles advanced networking
  option for stronger encryption
• Concerns
• Additional login/passworddesire to move to
  kerberos-based single sign-on.
• Physical security of local filestraining issue
• Excel is susceptible to viruses... train users to
  use anti-virus protection and to use caution when
  enabling embedded macros

17
Budget Spreadsheet Security

• Features
• Supports Secure Socket Layer transport (data
  encryption between the client and web server) via
  HTTPS to upload site
• Kerberos authentication of Andrew ID
• Concerns
• Physical security of local filestraining issue
• Excel is susceptible to viruses... train users to
  use anti-virus protection and to use caution when
  enabling embedded macros

18
Feeder File Interface Process Security

• Features
• Secure transfer options
• HTTPS - andrew authenticated and SSL encrypted,
  web-based upload
• SCP - encrypted transfer via public key
  encryption for unix to unix transfers
• Secured directory structure based on
  authenticated user id and limited access (only
  upload or download)
• Concerns
• Physical security of local files with hardcoded
  login/passwordtraining issue

19
CITRIX Application Server Security

• Features
• Standard NT account security (encrypted login)
• RSA RC5 add-on option
• Secured directory structure based on
  authenticated user id and limited access
• Supports all standard Oracle application security
  features
• Concerns
• Virus susceptibilityuse anti-virus protection
• Security holes in NTapply service paks and all
  patches

20
FMP Application Security
FMP Application Security

• Application Username/Password
• Custom responsibilities determine which forms,
  reports, functions, and data users can access
• Employee level set-ups determine approval
  relationships (workflow) and purchasing authority
• Secured value sets limit the range of data
  users can access by responsibility
• Customizations provide additional security to
  implement business rules, e.g. GM Award Security
  Extension

21
Additional Security Measures

• Fire wall (TIS) prevents direct connection to any
  administrative host
• Business Net isolates trusted user community
  (caveat need to verify on an on-going basis)
• SSH 1.2.26 for encrypted developer connections
• Reset Oracles default passwords for root
  accounts
• Audit user sessions (performance considerations)
