New Packet Sampling Technique for Robust Flow Measurements

1
New Packet Sampling Technique for Robust Flow
Measurements

• Shigeo Shioda
• Department of Architecture and Urban Science
• Graduate School of Engineering, Chiba University

2
Objectives of traffic measurements

• Short-term monitoring.
• Detecting high volume traffic patterns (denial of
  service attacks).
• Detecting unexpected or illegal packets.
• Investigating of origins.
• Long-term traffic engineering.
• Rerouting traffic.
• Upgrading selected links.

3
Per-flow-base traffic measurement (1)

• Just counting the number of packets or bytes is
  not sufficient per-flow-base traffic measurement
  is necessary.
• What is a flow?
• Informally, a set of packets consisting logical
  communication between application processes
  running on different hosts.
• Flow-level information could tell us who is now
  using the Internet.

4
Per-flow-base traffic measurement (2)

• Meaning of a flow.

Flow 1
Flow 2
5
Per-flow-base traffic measurement (3)

• How we could distinguish flows.
• Investigating headers of packets.
• Classifying packets based on IP addresses, port
  numbers, and protocol ID.

version
HL
TOS
Total Length
Identification
Flags
Fragment Offset
IP Header
TTL
Protocol-ID
Header Checksum
Source Address
Destination Address
Source Port
Destination Port
TCP Header
Sequence Number
Acknowledgement Number
6
Per-flow-base traffic measurement (4)

• Flow-measurement procedure.
• A Router maintains flow cache containing a flow
  record.
• When a packet is seen, a router updates counters
  of the corresponding entry in the flow cache.

Flow Cache
of packets
of bytes
Flow 1
0
0
1
1500
2
3000
2
0
1
3
1500
3000
0
4500
Flow 2
0
0
1
1500
Flow 3
Flow 1 packet
Flow 2 packet
Flow 3 packet
7
Problems of flow measurements

• Lack of scalability
• Due to the rapid increase of the todays line
  speed, the number of concurrent flows are
  increasing yearly.
• Updating per-flow counter on a per-packet basis
  is already impossible with todays line speed.
• The gap between DRAM speeds and link speeds is
  increasing.

8
Packet sampling

• Updating a flow cache only for sampled packets.
• Elephant flows would be detected even under the
  packet sampling.
• Although many tiny (and unimportant) flows would
  be missed under the packet sampling, it does not
  matter in terms of network management.
• Ciscos Sampled NetFlow.
• How to sample packets?

9
Fixed rate sampling

• Definition
• Choosing sampled packets at a fixed rate.
• For example, taking one in every N packets.
• Ciscos Sampled NetFlow uses the fixed rate
  sampling.

N 5
10
Shortcomings of the fixed rate sampling

• The size of memory holding the flow cache
  strongly depends on the traffic load.
• When DoS attacks are in progress, the memory
  would be rapidly consumed even if the sampling
  rate is low.
• However, low sampling rate would yield large
  error in traffic measurement under the normal
  load.
• Its a hard decision for network operators to set
  the static sampling rate.

11
Fixed period sampling

• Definition
• Choosing at most one packet to sample in every
  fixed-length period (called sampling window).
• For example, taking one in every tw second.
• Our solution.

Sampling Window
12
Properties of fixed period sampling

• The number of samplings during a second is
  bounded by 1/tw.
• The number of entries in the flow cache is also
  bounded.
• Sampling interval (tw) is easily determined based
  on the available memory or CPU for flow
  measurements.

13
Number of flow entrees
Number of Entries
Number of Entries
Indianapolis-Kansas City
U.S.-Japan link
Time s
Time s
N1000, tw10ms
14
Number of sampled packets
Number of Sampled Packets
Trace 1
Trace 2
Time s
N1000, tw10ms
15
Second Packet Sampling (1)

• An arbitrary packet can be chosen to sample
  during each sampling window.
• Which packets to be sampled?
• The simplest (and the most natural) rule the
  first packet sampling.
• Intuitively the first packet sampling rule seems
  to work well, but it is not true.
• We apply the second packet sampling.

16
First packet sampling and second packet sampling

• First packet sampling
• Second packet sampling

tw
2 tw
3 tw
4 tw
0
tw
2 tw
3 tw
4 tw
0
17
Second Packet Sampling (2)

• For example

Flow 1 packets arrive periodically
Flow 2 packets arrive according to a Poisson
process
We theoretically found that Under the first
packet sampling rule, 63.2 of sampled packets
are of flow 1. (strongly biased) Under the
second packet sampling rule, 49.7 of sampled
packets are of flow 1. (almost unbiased)
18
Flow level traffic estimation

• Sampling inevitably misses some information.
• Some inference techniques are required to know
  the statistics of flow level traffic from the
  sampled packets.
• Here, we focus on the flow rate estimation.

19
Flow rate estimation (1)

• Flow rate
• Informally, the rate at which a flow sends data.
• Formally, the ratio of the total bytes
  transferred to the flow duration.
• Flow rate is an index for identifying vital
  flows, which often have significant impact on
  network performance.
• Flow rate can be estimated from sampled packet
  streams.

20
Flow rate estimation (2)

• Real trace on a link between Indianapolis-Kansas
  City

tw10ms (0.15 packets were sampled)
tw1ms (1.5 packets were sampled)
Actual Flow Rate Mbps
Actual Flow Rate Mbps
Estimated Flow Rate Mbps
Estimated Flow Rate Mbps
21
Flow rate estimation (3)

• Real trace on a U.S. Japan link

tw10ms (1.5 packets were sampled)
tw1ms (13.4 packets were sampled)
Actual Flow Rate Mbps
Actual Flow Rate Mbps
Estimated Flow Rate Mbps
Estimated Flow Rate Mbps
22
Conclusion

• Sampling techniques are indispensable to todays
  traffic measurement in the Internet.
• Fixed period sampling could bypass problems of
  the existing sampling technique (fixed rate
  sampling).
• Fixed period sampling should be used together
  with the second packet sampling.
• Flow rate can be estimated well with the fixed
  period sampling.

23
Thank you.
24
Flow rate estimation under first packet sampling
Indianapolis-Kansas
U.S.-Japan link
Actual Flow Rate Mbps
Actual Flow Rate Mbps
Estimated Flow Rate Mbps
Estimated Flow Rate Mbps
N1000, tw10ms
25
Bayesian Estimates (2)

• tw1ms

Naive Estimator
Bayesian Estimator
Actual Flow Rate Mbps
Actual Flow Rate Mbps
Estimated Flow Rate Mbps
Estimated Flow Rate Mbps
26
Bayesian Estimates (1)

• tw10ms

Naive Estimator
Bayesian Estimator
Actual Flow Rate Mbps
Actual Flow Rate Mbps
Estimated Flow Rate Mbps
Estimated Flow Rate Mbps
27
Objectives of traffic measurements (2)

• QoS monitoring.
• Measurement of QoS properties.
• Validating service-level agreement.
• Usage-based accounting.
• Input to charge or billing.

28
Shortcomings of the fixed rate sampling

• Is there any sampling strategy which work even
  under massive DoS attacks?

350
300
250
Traffic
200
150
100
50
0
150
300
450
600
750
900
Time s
29
Existing solutions to the fixed rate sampling

• Sampling rate adaptation
• First, the sampling rate is initialized to the
  maximum rate, at which the processor can operate.
• Then, the sampling rate is dynamically adjusted
  based on the amount of consumed memory.
• Adaptive NetFlow.
• We propose another solution.

30
Fixed period sampling (2)

• Timeout transaction
• Under the sampling measurements, one could not
  exactly know the beginning and end of flows.
• (SYN or FIN packets may not be sampled.)
• Thus, flow entries that have not been seen during
  last N samplings are deleted from the flow cache.
• Due to timeout transaction, the flow cache keeps
  only flows, whose packets have been detected at
  least once during last N samplings.

31
Simulation experiments

• The accuracy of the flow-rate estimation was
  investigated using real traffic data.
• Two real traces (traffic data) were used .
• Trace1 Traffic data measured by PMA Project on a
  backbone link between Indianapolis - Kansas City.
• Trace 2 Traffic data measured by WIDE Project on
  a U.S. and Japan link published.

32
Flow rate estimation (2)

• Naïve estimation.
• Estimation based on the sampling frequency.
• Bayesian estimation.
• If we know the probability density function of
  the flow rate as prior information, we could
  apply Bayesian estimator to improve the
  estimation accuracy.
