Title: CS544 Computer Networks


1
CS544Computer Networks
  • Professor Mike Kain
  • Class 4 Slides
  • Winter 2008-2009

2
Tonights Topics
  • Review Class 3 major topics
  • Protocol analysis paper due at 1159pm
  • Submit to KP (tanetworks_at_cs.drexel.edu or through
    BlackBoard)
  • Be sure to include work breakdown and references
    as part of submission.
  • Protocol design paper due in 2 weeks Feb 11
    (can hand in early)
  • Midterm starts Sunday 2/1 (hopefully) -gt Sat 2/7.

3
Protocol Analysis
  • What did the paper show you?
  • Possibly many ways to solve a problem (e.g. file
    transfer)
  • Lots of tradeoffs during protocol design and
    implementation
  • Protocol inherits what the Internet looked like
    at the time and may not adapt as the Internet
    changes
  • Trust (node or application)
  • How the internet is connected
  • Security
  • Services / PDU
  • Developers had lots of common ideas (looked at
    the same protocols)

4
Discussion
  • So, what did you get out of the paper?

5
Major topics for tonight
  • PPP
  • Ethernet (IEEE 802.3)
  • Wireless (IEEE 802.11)
  • LLC (IEEE 802.2)
  • Bridges Switches
  • VLANs (IEEE 802.1q)
  • Review for midterm

6
Protocol Design Paper
  • Due in two weeks (February 11th)
  • Design a stateful protocol to solve a real-world
    problem.
  • Define
  • Service
  • Messages
  • DFA
  • Security
  • Extensibility

7
1st submission
  • Your groups first draft is due February 11th.
    It should cover all of the requirements
  • Well give comments on the design and give ideas
    for submission.
  • You will resubmit the design along with the
    implementation at the end of the semester (they
    should be equal).

8
Link Layer Major Duties
  • Breaking data into "frames (inbound and
    outbound)
  • Flow Control across the link
  • Acknowledgements
  • Error Detection and Retransmission
  • Sequencing (lost, duplicate)
  • Broadcasting (resolving access to the media)
  • Negotiation of service (QoS)
  • Shows some kind of link to upper layers.

9
Class 3 Major Topics
  • Sliding Window Protocol (SWP / ARQ)
  • Sequence Numbers (next to receive)
  • ACK / NAK
  • Timeouts
  • Checksum
  • Sending Window / Receiving Window
  • Pipelining / Piggybacking
  • Retransmission Strategy
  • Go Back N / Selective Repeat

10
Okay, so what can I do with this?
  • How the SWP operates is controlled by many
    factors
  • Reliability do I retransmit lost frames?
  • How fast do I slide my windows?
  • Do I ACK every PDU?
  • Do I wait for every PDU before sending up to
    higher layer?
  • Others? Can show many different QoS through SWP.

11
SWP/ARQ example
12
Shared Media
  • Concepts
  • Contention
  • Collision
  • Persistence
  • Carrier Sense
  • Collision Detection
  • Token

13
MAC tree
14
Examples of Random
  • ALOHA
  • Slotted ALOHA
  • CSMA
  • CSMA/CD
  • CSMA/CA

15
Examples of Scheduled
  • Token
  • Reservation
  • Polling
  • Examples of Static
  • FDMA
  • TDMA
  • CDMA

16
Point-to-Point Protocol (PPP)
  • RFC 1661, etc.
  • Provides framing over serial links
  • Shows evolution of protocol
  • Frame (RFC 1662)

17
PPP DFA (pg 331 Leon-Garcia)
18
Problems and opportunities
  • Cant have flag occur in data have to add extra
    bytes to make it special
  • Makes data packet variable in length depending on
    data
  • GFP (General Framing Procedure) goal is to make
    frame constant size so that it can be decoded
    easier (like ATM).
  • Seeing much more use because of cellular 3G
    networks reason for GFP due to constrained
    devices / power.

19
So, how do these MACs look?
  • Ethernet (IEEE 802.3)
  • Originally defined for a bus topology
  • Defined as a 1-persistent CSMA/CD with Binary
    Exponential Backoff for collision resolution
  • BEB maintain a counter of frame collisions, and
    backoff a random number between 0 and 2N-1
    slots for contenting again

20
Ethernet (continued)
  • So, for 1 collision, back off 0 or 1 slots
    what is a slot?
  • Time that it takes signal to get from one end of
    the cable and back.
  • For collisions 1-9, (0-gt2n-1), for 10, maxxed at
    (0-gt1023 slot times)
  • So, what does this do for persistence?

21
Ethernet PDU format
22
Ethernet Physical Layers
  • 10Base5 (Thick Coax) bus
  • 10Base2 (Thin Coax) bus
  • 10BaseT (Twisted Pair gt CAT5) star
  • 10BaseF point-to-point
  • collision domain group of stations to which a
    collision affects.
  • How do we go faster?

23
Faster Ethernet
  • 100BaseT (IEEE 802.3u)
  • 1000BaseT (IEEE 802.3z)
  • 10Gigabit Ethernet (IEEE 802.3ae) pairs with
    SONET
  • How do we go faster?

24
Other IEEE protocols
  • Token Bus (IEEE 802.4)
  • Token Ring (IEEE 802.5)
  • Actually a ring made acknowledgements easy!
  • FDDI (ANSI) two rings
  • A/C bits in trailer

25
Wireless (IEEE 802.11)
  • Wireless removes wires from the computer, but
    makes it more complex due to
  • Mobile can leave and enter range of signal
    easily
  • Signals more susceptible to interference and
    dissipation than wired
  • Devices are usually running on batteries (power
    limited)
  • hidden terminal problem

26
Wireless topologies
  • Each station connected to an ACCESS POINT
    (AP/WAP)
  • APs grouped into DS (Distribution System)
  • When each station powers on, it creates an
    association with the closest AP (could be
    cleartext or encrypted)

27
802.11 PDU
28
Sending in 802.11 (DCF)
  • Try to send if medium busy calculate a random
    backoff time.
  • When to send?
  • SIFS for ACK frames, CTS frames, segmented data
    or AP control frames
  • PIFS for priority access
  • DIFS for regular data and management
  • short, medium, and long

29
Sending in 802.11 (DCF) cont.
  • Can also use RTS/CTS when they feel there is a
    hidden terminal.
  • Stations can also set NAV field to tell others
    how long they are transmitting.

30
New technologies
  • Broadband (IEEE 802.16)
  • WiMax
  • HSPA / EVDO
  • 3G

31
LLC (IEEE 802.2)
  • A basic sliding window protocol between SAPs
    (SSAP DSAP) provides a class of service
  • COS1 unacked connectionless
  • COS2 acked connectionless
  • COS3 acked connection-oriented

32
Bridges Switches
  • Bridge a device at the Data Link layer which
    connects one or two different MAC types.
  • Deals with speed, acknowledgements, media
    contention, etc.
  • Can learn which stations are on which sides of
    them.
  • For example 802.3 vs 802.11

33
Switches
  • Switches MAC level devices which operate in the
    center of the star to put the MAC frame down the
    right wire.

34
VLANs
  • Switches allow grouping of Ethernet connections
    into virtual LANs to minimize collision domain
    (if any) mostly speed
  • Either by port (in the device) device on only
    one VLAN
  • Or Tagged (after SSAP) with VLAN id tag device
    can be on multiple VLANs (IEEE 802.1q)

35
Link Layer Authentication
  • When the link layer greets, it may ask the other
    side for credentials
  • 802.2 (LLC)
  • 802.1 (middle protocols, including
    authentication)
  • 802.x (MACs)
  • CHAP, RADIUS, NAC, 802.1x.
  • May include other information such as anti-virus
    signature date, firewall status, etc.
  • Shows even more sublayering possible.

36
The midterm
  • What to expect?
  • Master concepts and be able to use examples to
    illustrate concepts
  • Major concepts (nothing small).
  • 6 questions in essay form
  • Nothing that can be googled.
  • You have 4 hours from the time that you check out
    the exam in BlackBoard to submit your answers.
  • Can submit a separate doc/pdf rather than type
    into Blackboard.

37
Review
  • Class 1
  • Class 2
  • Class 3
  • Class 4

38
Next week
  • MIDTERM! Due by Saturday February 7th!
  • No class February 4th
  • Protocol Design due February 11th.
