IPC Interprocess Communication

1
IPC Interprocess Communication

• Chapter 28

2
Whats IPC?

• Interprocess communication is used to transfer
  data from one process to another. This can be
  between parent/child, two unrelated processes on
  the same machine, on the LAN or over the
  internet. We will focus mainly on communicating
  data between parent child processes.

3
Family Talk

• In the last lecture (chapter 27), we said the
  parent process passes all of its data to the
  child on a fork() call because the child is a
  duplicate of the parent. Once the fork has
  occurred though, there is no longer a link
  between the parent and child, so theres no
  built-in way to pass data.
• There are a five ways to pass data once the fork
  has occurred. Each method below becomes
  progressively harder to accomplish as you go down
  the list.
• Environment variables
• Pipes
• Signals
• Sockets
• Shared Memory

4
Environment Variables

• The easiest way to pass data is through
  environment variables. Each process has the
  ability to set (setenv()) get (getenv())
  variables.
• The disadvantage is that the processes
  communicating with environment variables must be
  run from the same shell login.
• You also cannot block one process to wait for the
  other process when using environment variables.

5
Pipes

• A pipe is a unidirectional communication link
  between two or more porcesses, which resembles an
  ordinary file from the process perspective.
  Processes can write data into one end of a pipe
  for others to read. Pipes do not work across a
  network.
• Pipes are generally implemented as sockets, but
  much of the complexity is hidden from the
  programmer.
• There are some important differences between a
  pipe and an ordinary file.
• A pipe is a fixed size buffer. Once the buffer
  is full, any attempt to write to the buffer will
  cause the process to block, waiting for data to
  be removed from the pipe.
• Reading from a pipe is destructive the data is
  removed from the pipe. Reading from an empty
  pipe will block until data is written into the
  pipe.
• EOF only occurs when the last process with write
  access to the pipe closes it.
• There are two types of pipes, named and unnamed.
• Unnamed pipes can only be used to connect parent
  child.
• Named pipes can be used to connect unrelated
  processes.

6
Unnamed Pipes

• int pipe( int fd2 )
• returns 0 on success, -1 on failure
• This function creates a pipe, and two associated
  file descriptors. The first descriptor, fd0 is
  used for reading from the pipe, and fd1 is used
  for writing.
• The pipe() function is called before a fork so
  that the child inherits copies of the file
  descriptors.
• Normally, one process is designated as the
  reader and the other only writes to the pipe.
  Hence, each process would close one of the
  descriptors immediately after the fork().

7

• include ltstdio.hgt
• include ltstring.hgt
• include ltunistd.hgt
• define BUFF_SIZE 40
• int main(int argc,char argv)
• int fd2
• char buffBUFF_SIZE1
• if ( pipe(fd) 0 )
• if ( fork() ! 0 )
• / Parent reader /
• close(fd1)
• / Read message from parent /

8
Another Pipe

• File popen( char command, char mode)
• returns a pointer to the opened stream, or NULL
  on error.
• The popen() function executes the specified
  command, and establishes a pipe connection to
  either its standard input (if mode is r) or
  its standard output (if mode is w).
• You could use this to run another program such as
  ls which would get a directory listing for your
  program without displaying it to the user.
• Files opened with popen() must be closed with
  pclose() not fclose()

9
Named Pipes

• Named pipes can be used to connect unrelated
  process running on the same computer. They are
  referenced as a special file which can be opened
  by name just like an ordinary file.
• int mknod(char path, mode_t mode, int dev)
• Returns 0 on success, -1 on failure.
• The dev argument is ignored for pipes.
• int mkfifo(char path, mode_t mode)
• Returns 0 on success, -1 on failure.
• An easier way to make a named pipe, calls mknod()
  for you.
• The mode argument specifies only the file
  permissions, since the file type is always a
  pipe.
• Once created, the pipe can be opened with open()
  or fopen() just like a normal file.
• It must be closed explicitly and removed with
  remove() or unlink().

10
Signals

• You can communicate to your processes with
  signals like kill, terminate (TERM), hang up
  (HUP), interrupt (CTRL C), etc. In order to
  deal with these signals in a custom manner
  (instead of just dieing on ctrlc for instance)
  you need to specify handlers for each of the
  signals you want to catch.
• Signals are asynchronous, meaning that they can
  arrive at any moment and not at any specified
  point.
• Signal handling, sockets and shared memory(in the
  next slides) are complex, and beyond the scope of
  this course, so I will not go into detail. You
  do need to know that they exist.

11
Sockets

• Sockets in C are just like those you dealt with
  in Client/Server programming. They allow you to
  send data either from one process to another on
  the same machine, or between processes on
  different machines across a network.
• The general premise is to
• create two sockets, A and B
• connect the sockets
• Set socket A to listen for connection requests
• Send a connection request from B to A
• Have A accept the connection request
• send/receive data
• Socket functions definitions are provided in
  ltsys/socket.hgt

12
Shared Memory

• Shared memory is an alternative form of IPC that
  does not involve file descriptors. Shared memory
  objects are blocks of memory which can be
  accessed directly by more than one process.
• For related processes, you would need just to
  create the shared memory object before calling
  fork() so that access is inherited by the child.
• Shared memory objects are created by shmget() and
  are mapped into the process address space using
  shmat(). Releasing shared memory is done by
  shmdt().
• Since shared memory isnt owned by any one
  process, it isnt freed when any one process
  exits. It must be explicitly freed from within
  your program using shmctl().
