Sampling From a Moving Window Over Streaming Data

1
Sampling From a Moving Window Over Streaming Data

• Brian BabcockMayur DatarRajeev Motwani

Stanford University
Speaker
2
Continuous Data Streams

• Data streams arise in a number of applications
• IP packets in a network
• Call records (telecom)
• Cash register data (retail sales)
• Sensor networks
• Large volumes of data
• Online processing
• Data is read once and discarded
• Memory is limited

3
Why Moving Windows?

• Timeliness matters
• Old/obsolete data is not useful
• Scalability matters
• Querying the entire history may be impractical
• Solution restrict queries to a window of recent
  data
• As new data arrives, old data expires
• Addresses timeliness and scalability

4
Two Types of Windows

• Sequence-Based
• The most recent n elements from the data stream
• Assumes a (possibly implicit) sequence number for
  each element
• Timestamp-Based
• All elements from the data stream in the last m
  units of time (e.g. last 1 week)
• Assumes a (possibly implicit) arrival timestamp
  for each element
• Sequence-based is the focus for most of the talk

5
Sampling From a Data Stream

• Inputs
• Sample size k
• Window size n gtgt k (alternatively, time duration
  m)
• Stream of data elements that arrive online
• Output
• k elements chosen uniformly at random from the
  last n elements (alternatively, from all elements
  that have arrived in the last m time units)
• Goal
• maintain a data structure that can produce the
  desired output at any time upon request

6
A Simple, Unsatisfying Approach

• Choose a random subset Xx1, ,xk,
  X?0,1,,n-1
• The sample always consists of the non-expired
  elements whose indexes are equal to x1, ,xk
  (modulo n)
• Only uses O(k) memory
• Technically produces a uniform random sample of
  each window, but unsatisfying because the sample
  is highly periodic
• Unsuitable for many real applications,
  particularly those with periodicity in the data

7
Another Simple Approach Oversample

• As each element arrives remember it with
  probability p ck/n log n otherwise discard it
• Discard elements when they expire
• When asked to produce a sample, choose k elements
  at random from the set in memory
• Expected memory usage of O(k log n)
• Uses O(k log n) memory whp
• The algorithm can fail if less than k elements
  from a window are remembered however whp this
  will not happen

8
Reservoir Sampling

• Classic online algorithm due to Vitter (1985)
• Maintains a fixed-size uniform random sample
• Size of the data stream need not be known in
  advance
• Data structure reservoir of k data elements
• As the ith data element arrives
• Add it to the reservoir with probability p k/i,
  discarding a randomly chosen data element from
  the reservoir to make room
• Otherwise (with probability 1-p) discard it

9
Why It Doesnt Work With Moving Windows

• Suppose an element in the reservoir expires
• Need to replace it with a randomly-chosen element
  from the current window
• However, in the data stream model we have no
  access to past data
• Could store the entire window but this would
  require O(n) memory

10
Chain-Sample

• Include each new element in the sample with
  probability 1/min(i,n)
• As each element is added to the sample, choose
  the index of the element that will replace it
  when it expires
• When the ith element expires, the window will be
  (i1in), so choose the index from this range
• Once the element with that index arrives, store
  it and choose the index that will replace it in
  turn, building a chain of potential
  replacements
• When an element is chosen to be discarded from
  the sample, discard its chain as well

11
Example
3 5 1 4 6 2 8 5 2 3 5 4 2 2 5 0 9 8 4 6 7 3
12
Memory Usage of Chain-Sample

• Let T(x) denote the expected length of the chain
  from the element with index i when the most
  recent index is ix
• T(x)
• The expected length of each chain is less than
  T(n) ? e ? 2.718
• Expected memory usage is O(k)

13
Memory Usage of Chain-Sample

• Chain consists of hops with lengths 1n
• Chain of length ? j can be represented by
  partition of n into j ordered integer parts
• j-1 hops with sum less than n plus a remainder
• Each such partition has probability n-j
• Number of such partitions is (n) lt (ne/j)j
• Probability of any such partition is small
  O(n-c)when j O(k log n)
• Uses O(k log n) memory whp

j
14
Comparison of Algorithms
Algorithm Expected High-Probability
Periodic O(k) O(k)
Oversample O(k log n) O(k log n)
Chain-Sample O(k) O(k log n)

• Chain-sample is preferable to oversampling
• Better expected memory usage O(k) vs. O(k log
  n)
• Same high-probability memory bound of O(k log n)
• No chance of failure due to sample size shrinking
  below k

15
Timestamp-Based Windows

• Window at time t consists of all elements whose
  arrival timestamp is at least t t-m
• The number of elements in the window is not known
  in advance and may vary over time
• None of the previous algorithms will work
• All require windows with a constant, known number
  of elements

16
Priority-Sample

• We describe priority-sample for k1
• Assign each element a randomly-chosen priority
• The element with the highest priority is the
  sample
• An element is ineligible if there is another
  element with a later timestamp and higher
  priority
• Only store eligible, non-expired elements

17
Memory Usage of Priority-Sample

• Imagine that the elements were stored in a
  treap totally ordered by arrival timestamp and
  heap-ordered by priority
• The eligible elements would represent the right
  spine of the treap
• We only store the eligible elements
• Therefore expected memory usage is O(log n), or
  O(k log n) for samples of size k
• O(k log n) is also an upper bound (whp)

18
Conclusion

• Our contributions
• Introduced the problem of maintaining a sample
  over a moving window from a data stream
• Developed the Chain-Sample algorithm for this
  problem with sequence-based windows
• Developed the Priority-Sample algorithm for this
  problem with timestamp-based windows
• Future work
• What else can be computed in sublinear space over
  moving windows on data streams?
• For example The next talk!
