Interactive Query Processing

1
Interactive Query Processing

• Vijayshankar Raman
• Computer Science Division
• University of California at Berkeley

2
Motivation Nature of querying

• querying extracting information from data sets
• different techniques in different settings
• intrinsically slow
• significant user-system interaction
• info. seekers work iteratively, gradually
  refining requests based on feedback

3
Problems with traditional solutions

• mismatch between system functionality and mode of
  HCI
• black boxes
• do batch processing
• frustrating delays in iterative process

4
Interactive processing
query
process
exact answer

• HCI requirements
• users must get continual feedback on results of
  processing
• allow users to control processing based on prior
  feedback
• performance goals
• not to minimize time to give complete results
• give continually improving partial results
• adapt to dynamically specified performance goals

5
Context and Talk Outline

• query processing over structured data
• processing dataflow through
  pipelining operators
• outline of rest of talk
• support for dynamic user control in traditional
  query proc. architectures (static plans)
• architecture for giving more aggressive partial
  results
• policy for generating partial results
• client user interface
• impact of user actions on query execution
• other related issues
• interactive data cleaning (A-B-C)
• adaptive query processing

R
S
Q
6
Design goals in supporting user control

• make minimal change to system architecture
• must be independent of particular query
  processing algorithms
• no delay in processing

7
Online Reordering (Raman et al. 99,00)

• users perceive data being processed over time
• prioritize processing for interesting tuples
• interest based on user-specified preferences
• reorder dataflow so that interesting tuples go
  first
• encapsulate reordering as pipelined dataflow
  operator

8
Framework for Online Reordering
acddbadb...
abcdabc..
user interest

• want no delay in processing
• in general, reordering can only be best-effort
• typically process/consume slower than produce
• exploit throughput difference to reorder
• two aspects
• mechanism for best-effort reordering
• reordering policy

9
Juggle mechanism for reordering

• continually prefetch from input, spooling onto
  auxiliary side disk if needed
• juggle data between buffer and side disk, to keep
  buffer full of interesting items
• getNext chooses best item currently on buffer
• reordering policy determines what getNext
  returns, and enrich/spool decisions

10
Reordering policies
good permutation of items t1tn to t?1t?n
GOAL
QOF
time

• quality of feedback for a prefix t?1t?2t?k
• QOF(UP(t?1), UP(t?2), UP(t?k )), UP user
  preference
• determined by application
• goodness of reordering dQOF/dt
• implication for juggle mechanism
• process gets item from buffer that increases QOF
  the most
• juggle tries to maintain buffer with such items

11
One application of reordering

• online aggregation Hellerstein et. al 97,
  Hellerstein and Haas99
• for SQL aggregate queries, give gradually
  improving estimates
• with confidence intervals
• allow users to speed up estimate refinement for
  groups of interest
• prioritize for processing at a per-group
  granularity

SELECT AVG(gpa) FROM students GROUP BY college
12
Online Aggregation Screenshot
SELECT AVG(gpa) FROM students GROUP BY college
13
QOF in Online Aggregation

• avg weighted confidence interval
• preference acts as weight on confidence interval
• QOF ?? UPi / ?ni , ni number of tuples
  processed from group i
• process pulls items from group with max UPi /
  ni?ni
• desired ratio of group i tuples on buffer
  UPi2/3/? UPj2/3
• juggle tries to maintain this by enrich/spool

14
Other Quality of Feedback functions

• rate of processing (for a group) ? preference
• QOF ?? (ni - nUPi)2 (variance from ideal
  proportions)
• process pulls items from group with max (nUPi -
  ni )
• desired ratio of group i tuples in buffer UPi
• will see more complex QOF later

15
Results Reordering in Online Aggregation

• implemented in Informix UDO
• experiments with modified TPC-D queries
• questions
• how much throughput difference is needed for
  reordering
• can we reorder handle skewed data
• one stress test skew, minimal proc. cost
• index-only join
• 5 orderpriorities, zipf distribution

consume
SELECT AVG(o_totalprice), o_orderpriority FROM
order WHERE exists ( SELECT FROM lineitem
WHERE l_orderkey o_orderkey) GROUP BY
o_orderpriority
juggle
index
scan
process
16
Performance results
confidence interval
tuples processed
time
time

• 3 times faster for interesting groups
• 2 completion time overhead

17
Findings

• higher processing costs (index/hash join,
  subquery, ) make reordering easy
• at very low processing costs, juggle constrained
  bydensity of interesting tuples in source
• outlier groups hard to speed up
• better to use index on reordering column HHW
  97
• reordering becomes easier over time
• questions to answer
• where to place juggle
• are groups fixed statically

18
Outline

• motivation and context
• support for dynamic user control in traditional
  query proc. architectures
• architecture for giving more aggressive partial
  results
• policy for generating partial results
• user interface for displaying partial results
• impact on routing
• related work, work-in-progress, future work

19
Generating partial results

• traditional arch. also generate continual result
  tuples
• arises from continual dataflow thru pipelining
  operators
• much work on pipelining joins WA91, HH99,
  IFF99, UF00
• this is too rigid
• especially in distributed envirorments

Result Space
20
Context Query processing in Telegraph

• Telegraph adaptive dataflow system to query
  diverse, distributed sources
• much data available as services over Internet
• currently only accessible by browse/search/forms
• want to semi-automatically combine this data
• examples
• campaign finance information (fff.cs.berkeley.edu)

• multiple donor lists, home prices, census info.,
  crime ratings, maps, celebrity lists, legislative
  records
• restaurant information
• lists, reviews, addresses, maps, health
  inspection reports, nutrition information

21
More aggressive partial results

• complete results too rigid
• source latencies high, diverse
• dynamic source variations, delays
• query does not capture user desires
• want to process queries flexibly, giving results
  asap
• adapt dynamically to user preferences and source
  variations
• allow user feedback to refine partial results

22
Correctness of partial results

• must contain some essential columns
• group-by columns / sort-by columns
• full disjunction/outer-join semantics
• appropriate for many Internet data sources
• join semantics
• cannot give partial results without ensuring that
  match exists
• aggregates over-estimate, even with outer-join
  semantics
• update early, and compensate later

23
Dynamic query plans

• Eddy Avnur and Hellerstein 2000
• router for directing data thru modules
• dynamically chooses join and selection order
• all partial tuples generatable
• original routing policy optimize completion time

• our focus continual partial results, adaptation
  to user preferences

24
Eddy Routing
. . . modules
R
P
S
. . . inputs

• Eddy must decide
• what tuple to route next
• where to route it
• based on user preferences, and source properties
• need routing policy and a reordering mechanism
• eddy memory and module queues bounded

25
Prioritizing tuples
. . . modules
R
P
S
. . . inputs

• perform online reordering within Eddy
• all incoming tuples placed in reorderer
• when space available on queues to modules, Eddy
  takes tuple from reorderer and routes it to
  modules
• best-effort ? automatically reorder before slow
  modules

26
Routing and reordering policy
GOAL
QOF
time

• GOAL at any time, route to max. dQOF/dt
  benefit of sending tuple to module / cost
• cost estimate data rates to/from module
• benefit dependent on application and UI
• how partial results impact the UI
• user preferences

27
Outline

• motivation and context
• online reordering for user prioritization of
  partial results
• architecture for generating more aggressive
  partial results
• policy for generating partial results
• Telegraph UI displaying results and inferring
  preferences
• impact on routing
• experimental results
• related work/work-in-progress/future work

28
Telegraph UI

• screenshot

29
Telegraph UI

• partial results displayed on screen as they
  arrive
• values clustered into groups
• can roll-up or drill-down to see different
  granularities
• client has hash table mapping groups to values
• navigation
• vertical/horizontal scrolling
• column (un)hiding
• rollup/drilldown
• different columns visible at different drilldown
  levels

30
Getting user preferences (1)

• infer from navigation
• row/column scrolling, group drill down and rollup
• prioritize visible rows/columns
• query evolution
• subset one-size-fits-all queries
• future work query expansion
• explicit
• at the cell level -- need for some expensive
  sources
• can also have up/down buttons on columns

31
Getting user preferences (2)

• preferences
• col priorities
• ltpredicate, row priority, row-col prioritiesgt

• e.g. lt1, 1.0, nonegt, lt2, 1.7, nonegt,
  lt3, 1.3, maphighgt, lt8/33014, 1.0,
  nonegt, lt8/60610, 1.0, nonegt

32
Benefit of a partial result

• depends on user preferences
• benefit of updating a cell in output
• row priority x column weight x ? cell worthiness
• column weight max(col priority, row-col
  priority)
• incremental cell worthiness how much does one
  extra update add to the cells value ? quality
  of feedback
• enumerations -- 1
• aggregations -- change in confidence interval
• informing user about execution progress
• map cell worthiness to foreground color value

33
Benefit of Routing a Tuple

• route tuple according to expected benefit and
  cost
• benefit of sending a tuple t to a module M and
  forming set T ?cells c ?T benefit of updating c
• estimate fanout by sampling previous values --
  selectivity estimation

34
Granularity of Reordering/Routing

• reorder and route tuples at granularity of a
  group
• group ltbase relations, predicategt
• groups created and deleted dynamically, as user
  navigates in UI
• group predicate may be a subset of
  application-specified row predicate
• final row depends on values this tuple joins with

35
Partial results, no reordering

• Bush Contributors Income Crime
  Ratings

with partial results
without partial results
36
Partial results, no reordering

• Bush Contributors Income Crime
  Ratings

with partial results
total worthiness
without partial results
time(s)
37
Results with row-wise reordering

• scrolling AZ, AR, CA CO, CT, LA,KY,MA,MD,MI

100
Aggr. Updates
0
40
80
time
0.24
rel. error
0
groups
38
Prioritizing particular columns

• previous graph Income updates much faster than
  Crime Ratings
• can we prioritize Crime Ratings?
• increase number of threads to probe it
• if eddy sends na tuples to A, nb to B, per second
• na lt threadsa/latency(A), nb lt
  threadsb/latency(B)
• threadsa threadsb lt Number of Threads Per
  Query
• max. na ?worthiness(A) nb ?worthiness(B)
• more generally, optimize for multiple resources
• good citizenship
• costs

39
Outline

• motivation and context
• online reordering for user prioritization of
  partial results
• architecture for generating more aggressive
  partial results
• policy for generating partial results
• conclusions and future work

40
Related Work

• IR work
• ranked retrieval, relevance feedback
• search strategies, Berry Picking
• making operators pipelining (Ripple Join, XJoin,
  Tuqwila)
• precomputed summaries (OLAP, materialized views,
  AQUA)
• top N / fast-first query processing
• parachute queries, union queries
• adaptivity
• dynamic query plans
• mid-query reoptimization (KD98, IFF99)
• competition (DEC Rdb)

41
Summary

• query processor should care about how
  user/application uses results
• online reordering effective way of supporting
  dynamic user control
• give partial results as user wishes by embedding
  reordering within dynamically controlled dataflow
• system flexibility helpful
• hard to map these user-interaction needs
  intoconcrete algorithm performance goals
• wanted benchmarks based on user/application
  traces
• For more information
• http//telegraph.cs.berkeley.edu/,
  http//control.cs.berkeley.edu/

42
Future Work

• session-granularity query processing
• query evolution
• lazy evaluation user/client navigates through
  partial results
• closer dbms-application interaction
• reduced operator set querying
• execute query by appropriate routing through data
  sources and state modules

43
Lessons Learned

• query processor should care about how
  user/application uses results
• system flexibility helpful
• hard to map these user-interaction needs
  intoconcrete algorithm performance goals
• wanted benchmarks based on user/application
  traces
• For more information
• http//telegraph.cs.berkeley.edu/
• http//control.cs.berkeley.edu/

44
Granularity of Query Operators

• relational operators logical astractions
• encapsulate multiple physical effects
• inflexible in handling unexpected changes
• information hiding
• operator speeds
• resource consumption
• work sharing
• competitive access paths
• inflexible tuple routing
• suppose user asks for SQ tuples
• suppose there is a delay in P
• want to encapsulate at level of physical
  operators data sources, data structures

45
State Modules
SteMP
SteMQ
SteMS
SteMR
Eddy
?
Q
Q
R
S
P

• store state in separate State Modules (SteMs)
• SteM like an index supports builds and probes
• unifies caches, join state, rendezvous buffers
• Eddy routes tuples through SteMs and data sources
• gets results from sources, or probe/build into
  SteMs
• joins and data access performed in the process of
  routing

46
HCI Motivation Why Interactivity?

• Berry picking (Bates 90, 93)
• user studies
• decision support (Oday and Jeffries 93)
• relevance feedback (Koenemann and Belkin 96)

47
BACKUP Disk data layout during juggling

• performance goal
• favor early results optimize Phase 1, at expense
  of Phase 2
• spool sequential I/O, enrich random I/O
• reordering in Phase 2 much easier than in Phase 1
• enrich needs approx. index on side-disk
• have hash-index on tuples, according to user
  interest
• done at group granularity

48
BACKUP Other applications of reordering

• can add reorder to any dataflow
• will later discuss application for query systems
  that give aggressive partial results
• also useful in batch query processing
• sorting often used in query plans for performance
  gains
• can replace by best-effort reordering
• little performance hit, but plan is now
  pipelining
• will not discuss further in this talk
• spreadsheets

49
BACKUP Estimators for rowPriority, incremental
worthiness

• easy, unless output row depends on new values
• currently use average of all possible rows
• could estimate a distribution instead

50
BACKUP Interactive query processing with
non-pipelining operators

• basic techniques independent of pipelined
  operators.
• reordering --- can be used in general query
  plans, although effectiveness may be hindered by
  blocking operators
• State Modules applicable in general -- helps with
  adaptivity
• much work on making plan operators pipelining --
  ripple join, xjoin, tuqwila
• reordering itself can be used to avoid blocking
  sorts in some cases

51
Query processing using SteMs (1)

• SteM operations -- works like index on a table
• build(tuple) add tuple to SteM
• probe(tuple) find all matches among build values
• bounce back tuple if all matches not found and
  probe tuple not cached elsewhere
• performing joins by routing through SteMs
• index joins
• regular synchronous index joins easy -- have no
  state
• over distributed sources, lookups cached by
  building into SteM
• separating cache allows Eddy to distinguish
  access cost
• asynchronous index joins GW00
• helps for high-throughput Internet sources
• SteM acts as rendezvous buffer for pending probe
  results

52
Query processing using SteMs (2)

• performing joins by routing through SteMs (contd)

• doubly pipelined hash join
• use two SteMs, one on each source
• can also do extensions (e.g. Tuqwila IFF99),
  and even non-pipelined joins, using appropriate
  SteMs
• thus can simulate any static query plan by
  appropriate routing

SteMS
SteMR
R probe
S probe
R bld.
S bld.
Eddy
R
S
53
Query processing using SteMs (3)

• how to do this in general?
• dont want Eddy to be a super-join
• want it to route as per user desires and source
  properties, independent of any join algorithm
• routing constraint
• each tuple must have a non-zero probability of
  being sent to every appropriate module
• can avoid repeated looping by marking tuples
• Theorem any routing that satisfies above
  constraint will produce all query results and
  terminate
• could get duplicates
• prune at application, or
• enforce atomicity in tuple routing

54
Benefits of SteMs

• adaptivity
• join algorithm and access path selection are
  determined by eddy routing
• hence Eddy can dynamically choose these based on
  source properties
• in fact, Eddy can do hybrid join algorithms
• adapt to dynamic delays, etc.
• work sharing -- for query evolution, competition
• better information to the Eddy
• speeds, memory consumption

55
BACKUP Lazy Evaluation

• User navigates thru partial results
• can see only a few at a time
• exploit to delay processing
• do on demand on the region user currently
  navigating over
• things to delay
• expensive source lookups (e.g. map)
• joins (e.g. )
• any other formatting etc.

56
Backup giving probabilistic results

• view partial result as somethng that throws
  light on outer-join space
• positive result probabilistic
• negative result deterministic
• benefit of positive result
• weighted sum of cells it is likely to show
  penalty for false result
• repudiation of earlier false results
• benefit of negative result
• direct benefit unlikely
• repudiation of earlier false results
• complications
• many tuples may contribute to single output tuple
  -- aggregation

57
Probabilistic partial results

• partial result gt may not apply all filters
• still want to show result probabilistically
• filters ill-specified
• data on Internet often inconsistent
• show all partial results full disjunction
  (Galindo-Legaria 94)
• positive and negative results

Output Space
Outer Join Space
58
What does user see?

• user navigates thru partial results
• with complete row partial results
• can either explore these results in detail
  (sort/scroll along columns as in spreadsheet)
• compute approx. aggregates on them in online
  fashion
• errors shrinking as more results come in
• with probabilistic, incomplete results?
• easy if primary key in partial result
• what to show otherwise?

59
Quantifying benefit of partial results

• partial result sheds light on outer-join space
• positive result probabilistic
• negative result deterministic
• benefit of positive result
• weighted sum of cells it is likely to show
• penalty for false result ?
• repudiation of earlier false results ?
• benefit of negative result
• direct benefit unlikely
• repudiation of earlier false results ?

60
Why probabilistic results are good

• data on Internet is often inconsistent
• hence even exact processing cannot give perfect
  answers
• people are used to sloppy answers
• can allow negations in expert interfaces only

61
Data growth vs. Computer Speedup

• Moores Law -- of transistors/chip doubles
  every 18 months (1965)
• data growth

Source J. Porter, Disk/Trend, Inc.
(http//www.disktrend.com/pdf/portrpkg.pdf)
62
Disk Appetite, contd.

• Greg Papadopoulos, CTO Sun
• Disk sales doubling every 9 months
• similar results from Winter VLDB survey
• time to process all your data doubles every 18
  months!
