Title: Advanced Measurement Techniques for Testing WiMAX PHY/RF


1
(No Transcript)
2
Advanced Measurement Techniques for Testing WiMAX
PHY/RF
3
About SeaSolve
  • SeaSolve Software Inc (SSI) is one of leading
    suppliers of real-time test and
  • measurement solutions for testing and
    analyzing the performance of IEEE
  • 802.15.4/ZigBee (WPAN), IEEE 802.11a/b/g
    (WLAN), IEEE 802.16-2004
  • (WiMAX) and IEEE 802.16e (Mobile WiMAX)
    transceivers.
  • SeaSolve is headquartered in San Jose, CA, USA.
  • National Instruments Alliance Member
  • WiMAX Forum Member company

4
Presentation Overview
  • Introduction to WiMAX
  • Characterizing WiMAX Transmitters
  • Basestations
  • CPEs
  • Characterizing WiMAX Receivers
  • Basestations
  • CPEs
  • Product Overview
  • Conclusion

5
Introduction to WiMAX
  • IEEE 802.16-2004 standard for fixed broadband
    wireless access (FBWA)
  • 256-carrier OFDM bandwidths 1.25 to 20 MHz
    carrier frequencies up to 11 GHz
  • High data rates with wireless metropolitan area
    coverage
  • Deployed in TDD, FDD, or H-FDD configurations
  • Base Stations (BS) and Subscriber Stations (SS)
    in PMP configuration
  • TDD BS and SS transmit at the same carrier
    frequency but at different time
  • FDD BS and SS transmit on different carrier
    frequencies at the same time
  • H-FDD BS and SS transmit at the same carrier
    frequency but one at a time

6
General WiMAX Frame
Downlink (DL) sub frame Preamble, Header and one
or more DL bursts and transmitted by BS
Uplink sub frame Slots for initial ranging, BW
request and data transmissions from various SSs.
7
WiMAX Networks
8
Characterizing WiMAX Transmitters
Base Station Subscriber Station
  • Visualize the data as channel
  • response, EVM/symbols, EVM/sub
  • carriers etc.
  • Neutralizes front end non idealities
  • from the IQ data
  • Dynamically detect CP used by Base
  • station from the Base station
  • Preamble
  • Analyze BS and SS transmission in
  • H-FDD and TDD modes
  • Configure RF Settings (Trigger, Span, Ref level
  • Acquisition length and Center frequency)

9
Characterizing WiMAX Receivers
Base Station Subscriber Station
  • Generate Real world WiMAX RF test
  • signals
  • Transmit TDD frame for BS SSs
  • All Measurements in one solution
  • Generate impaired RF/Baseband data
  • Transmit and Save the configured IQ
  • data with MAC information
  • Configure downlink and uplink bursts
  • profile
  • Configure RF Settings (Power level, Center
  • frequency and Bandwidth)

10
SET UP
Transmitter Test Set up
Receiver Test Set up
11
WiMAX Test and Measurement Solution set
SeaMAX-Fixed IQ Generator PRO IEEE 802.16 Base
Station and Subscriber Station Generator SeaMAX-
Fixed Analyzer PRO IEEE 802.16 Base Station and
Subscriber Station Analyzer SeaMAX-Mobile IQ
Generator PRO IEEE 802.16e Base Station and
Subscriber Station Generator SeaMAX-Mobile IQ
Analyzer PRO IEEE 802.16e Base Station and
Subscriber Station Analyzer
12
SeaSolves Wireless Solutions
  • WiLANTA LVSG11bg
  • 802.11 a/b/g PHY and MAC signal generation
  • WiLANTA LVSA11bg
  • 802.11 a/b/g PHY and MAC analysis
  • WiLANTA IQ Generator
  • IEEE 802.11 a/b/g PHY and MAC IQ signal files
    generator
  • WiPAN LVSG
  • IEEE 802.15.4 PHY and MAC signal generation
    (868/915/2450 MHz bands)
  • WiPAN LVSA
  • IEEE 802.15.4 PHY and MAC analysis
    (868/915/2450 MHz bands)
  • WiPAN LVCT
  • IEEE 802.15.4 PHY compliance testing
    (868/915/2450 MHz bands)

ZigBee Toolkit - IEEE 802.15.4 LabVIEW
API design and production test solution
13
SeaSolves IPs
IEEE 802.11 a/b/g PHY IP Cores
IEEE 802.11 MAC
Advanced Encryption Standard (AES)
Reed Solomon Decoder and Encoder
Viterbi Decoder
14
Summary
  • Solutions that address the need of WiMAX device
    manufacturers, system integrators, chipset
    manufacturers, test houses, researchers and
    universities.
  • SeaMAX-Fixed and Mobile Generator Benchmark
    the performance of IEEE

  • 802.16-2004 and 16e Base station
    and

  • Subscriber station receivers
  • SeaMAX-Fixed and Mobile Analyzer Perform
    drill-down analyses of 802.16-2004 and
    16e Base station and Subscriber station
    transmitters in TDD and H-FDD modes

15
Contact
Asia-Pacific office 3rd Floor, Vijay
Building 104, 1st Main Rd. 5th Block, Koramangala
Bangalore 560095 Ph. 91-80-4010 5200
Europe office 23, Vista Centre 50, Salisbury
Road Hounslow TW4 6JQ United Kingdom Ph 44(0)20
8538 0158 Fax 44(0)20 8538 0273
  • Headquarters
  • SeaSolve Software, Inc.
  • 1778 Technology Dr
  • San Jose, CA 95110
  • USA
  • Phone 408-437-9306
  • Fax 408-437-9320
  • sales_at_seasolve.com
  • support_at_seasolve.com
