Title: Quality%20Control


1
Quality Control
  • Ross L. Fink

2
Quality Control
  • Quality control involves controlling the delivery
    processes to adhere to the specifications (or
    product design).

3
Quality Control Approaches
  • 100 Inspection
  • Acceptance Sampling
  • Statistical Process Control (SPC) or
    Control-Chart Method

4
Acceptance Sampling
Accept or Reject Entire Lot Based Upon Quality of
Sample
5
Statistical Process Control
  • Basic Approach
  • Take one sample of size 5 each hour
  • Measure quality characteristic
  • Plot measurement over time (sample number)

6
Run Chart
7
Distribution of Measurement on Control Chart
  • Since we are taking a mean, the Central Limit
    Theorem of the Sample Mean applies
  • Therefore, mean follows a normal distribution.
  • Three Sigma Limits

8
Plot of Mean
9
Theory of Control Charts
  • Purpose of control charts is to separate natural
    variability (common cause) from nonrandom
    variability (assignable cause).
  • In-control (common cause) versus out-of-control
    (assignable cause).

10
Types of Variability
11
X-bar Chart
12
Control Chart Rules
  • Simple Rules
  • One point above UCL
  • One point below LCL
  • Most organizations use more complex rules
  • e.g., seven consecutive points increasing

13
Constructing a Control Chart
  • Obs. 1 2 3
    4 5
  • Sample
  • 1 11.63 14.44 14.52 17.58 12.71
  • 2 13.30 16.21 15.04 16.09 14.19
  • 3 12.60 11.49 14.73 15.58 17.41
  • 4 13.68 13.49 13.24 16.98 16.23
  • 5 15.12 15.21 11.69 14.91 16.36
  • 6 15.70 16.09 16.78 15.48 14.56
  • 7 13.46 14.28 17.09 13.84 15.85
  • 8 14.22 13.90 14.47 15.18 19.31
  • 9 12.44 15.12 16.00 14.62 16.05
  • 10 14.04 14.88 19.26 14.37 16.35
  • 11 12.42 13.25 15.56 15.18 14.13
  • 12 15.65 12.94 16.16 15.98 18.67
  • 13 15.71 13.78 14.19 16.02 13.78
  • 14 14.80 12.17 16.00 12.93 12.34
  • 15 15.63 12.14 14.98 16.61 14.21
  • 16 10.13 15.43 17.09 17.72 18.72
  • 17 13.73 15.26 13.53 14.43 15.22

14
Find Sample Means and Ranges
  • Obs. 1 2 3
    4 5 Mean Range
  • Sample
  • 1 11.63 14.44 14.52 17.58 12.71 14.18 5.95
  • 2 13.30 16.21 15.04 16.09 14.19 14.96 2.93
  • 3 12.60 11.49 14.73 15.58 17.41 14.36 5.92
  • 4 13.68 13.49 13.24 16.98 16.23 14.72 3.75
  • 5 15.12 15.21 11.69 14.91 16.36 14.66 4.67
  • 6 15.70 16.09 16.78 15.48 14.56 15.72 2.22
  • 7 13.46 14.28 17.09 13.84 15.85 14.90 3.63
  • 8 14.22 13.90 14.47 15.18 19.31 15.42 5.39
  • 9 12.44 15.12 16.00 14.62 16.05 14.85 3.62
  • 10 14.04 14.88 19.26 14.37 16.35 15.78 5.22
  • 11 12.42 13.25 15.56 15.18 14.13 14.11 3.14
  • 12 15.65 12.94 16.16 15.98 18.67 15.88 5.72
  • 13 15.71 13.78 14.19 16.02 13.78 14.70 2.23
  • 14 14.80 12.17 16.00 12.93 12.34 13.65 3.83
  • 15 15.63 12.14 14.98 16.61 14.21 14.71 4.47
  • 16 10.13 15.43 17.09 17.72 18.72 15.82 8.59
  • 17 13.73 15.26 13.53 14.43 15.22 14.43 1.73

15
Calculate Grand Mean and Grand Range
16
Control Limits
17
Table
  • Factors for Computing Control Chart Limits
  • Sample Size Mean Factor Upper Range Lower Range
  • N A2 D4 D3
  • 2 1.880 3.268 0
  • 3 1.023 2.574 0
  • 4 .729 2.282 0
  • 5 .577 2.115 0
  • 6 .483 2.004 0
  • 7 .419 1.924 0.076
  • 8 .373 1.864 0.136
  • 9 .337 1.816 0.184
  • 10 .308 1.777 0.223

18
Control Limits
19
X-bar Chart
20
R Chart
21
In-Control v. Out-Of-Control
  • What are the implications of being in-control?
  • What are the implications of being
    out-of-control?
