Software Testing

1
Software Testing

• Sudipto Ghosh
• CS 406 Fall 99(Also used later)
• November 2, 1999

2
Learning Objectives

• Testing
• What is testing?
• Why test?
• How testing increase our confidence in program
  correctness?
• When to test?
• What to test?
• How to test?
• Different types of testing
• How to assess test adequacy?

3
Testing

• The act of checking if a part or product performs
  as expected.
• Why do we test?
• Check if there are any errors?
• Increase confidence in the correctness

4
Testing

• When should we test?
• Separate phase for testing? OR
• At the end of every phase? OR
• During each phase, simultaneously with all
  development and maintenance activities

5
What can be tested?

• All products generated during lifecycle
• Phase Product How to test?
• Specification Req. doc Scenario construction,
  simulations
• Design Design doc Simulations
• Implementation Modules Run against test cases
• Integration System Run against test cases
• Maintenance System Regression testing

6
Our focus

• Focus Testing programs
• Programs may be sub-systems or complete systems
• Programs are written in a programming language
• Explore techniques and tools for testing programs

7
Verification, Validation, Testing

• Verification
• Process of determining whether a phase has been
  correctly carried out
• Are we building the product right? (Boehm)
• Validation
• Intensive evaluation process that takes place
  just before the product is delivered to the
  client
• Are we building the right product? (Boehm)
• V V denotes testing
• (Verification mathematically prove program
  correctness)

8
Problems with formal verification

• Adequate mathematical training
• Economic viability of proofs
• Proving hard for non-trivial products
• Correctness of the prover itself
• Finding input, output specifications, loop
  invariants
• Wrong specifications

9
Terminology

• Program - Sort
• Collection of functions (C) or classes (Java)
• Specification
• Input p - array of n integers, ngt0
• Output q - array of n integers such that
• q0 ? q1 ? ? qn
• Elements in q are a permutation of elements in p,
  which are unchanged
• Description of requirements of a program

10
Tests

• Test input (Test case)
• A set of values given as input to a program
• Includes environment variables
• 2, 3, 6, 5, 4
• Test set
• A set of test cases
• 0, 9, 8, 7, 6, 5, 1, 3, 4, 5, 2, 1, 2,
  3

11
Oracle

• Function that determines whether or not the
  results of executing a program under test is as
  per the programs specifications

• Problems
• Correctness of Oracle
• Correctness of specs
• Generation of Oracle
• Need more formal
• specs

Software Under Test
output
Failure? Success?
Compare
Test Cases
Oracle
output
12
Correctness

• Program Correctness
• A program P is considered with respect to a
  specification S, if and only if
• For each valid input, the output of P is in
  accordance with the specification S
• What if the specifications are themselves
  incorrect?

13
Errors, defects, faults

• Often used interchangeably.
• Error
• Mistake made by programmer.
• Human action that results in the software
  containing a fault/defect.
• Defect / Fault
• Manifestation of the error in a program.
• Condition that causes the system to fail.
• Synonymous with bug

14
Failure

• Incorrect program behavior due to a fault in the
  program.
• Failure can be determined only with respect to a
  set of requirement specs.
• For failure to occur, the testing of the program
  should force the erroneous portion of the program
  to be executed.

15
Errors and failure
Error revealing inputs cause failures
Inputs
Program
Erroneous outputs indicate failures
Outputs
16
Debugging

• Suppose that a failure is detected during the
  testing of P.
• The process of finding and removing the cause of
  this failure is known as debugging.
• Testing usually leads to debugging.
• Testing and debugging usually happen in a cycle.

17
Test-debug cycle
Test
Yes
Failure?
No
Testing complete?
No
Yes
Debug
Done
18
Software quality

• Extent to which the product satisfies its
  specifications.
• Get the software to function correctly.
• SQA group is in charge of ensuring correctness.
• Testing
• Develop various standards to which the software
  must conform
• Establish monitoring procedures for assuring
  compliance with those standards

19
Nonexecution-Based Testing

• Person creating a product should not be the only
  one responsible for reviewing it.
• A document is is checked by a team of software
  professionals with a range of skills.
• Increases chances of finding a fault.
• Types of reviews
• Walkthroughs
• Inspections

20
Walkthroughs
TEAM
Rep from Specs team
Manager from Specs team
Client representative
Rep of team from next phase
Rep from SQA group

• Reviewer prepares two lists
• Items that the reviewer does not understand
• Items that the reviewer believes are incorrect

21
Managing walkthroughs

• Distribute material for walkthrough in advance.
• Includes senior technical staff.
• Chaired by the SQA representative.
• Task is to record fault for later correction
• Not much time to fix it during walkthrough
• Other individuals are trained to fix it better
• Cost of 1 team vs cost of 1 person
• Not all faults need to be fixed as not all
  faults flagged are incorrect

22
Managing walkthroughs (contd.)

• Two ways of doing walkthroughs
• Participant driven
• Present lists of unclear items and incorrect
  items
• Rep from specs team responds to each query
• Document driven
• Person responsible for document walks the
  participants through the document
• Reviewers interrupt with prepared comments or
  comments triggered by the presentation
• Interactive process
• Not to be used for the evaluation of participants

23
Inspections

• Proposed by Fagan for testing
• designs
• code
• An inspection goes beyond a walkthrough
• Five formal stages
• Stage 1 - Overview
• Overview document (specs/design/code/ plan) to be
  prepared by person responsible for producing the
  product.
• Document is distributed to participants.

24
Inspections (contd.)

• Stage 2 - Preparation
• Understand the document in detail.
• List of fault types found in inspections ranked
  by frequency used for concentrating efforts.
• Stage 3 - Inspection
• Walk through the document and ensure that
• Each item is covered
• Every branch is taken at least once
• Find faults and document them (dont correct)
• Leader (moderator) produces a written report

25
Inspections (contd.)

• Stage 4 - Rework
• Resolve all faults and problems
• Stage 5 - Follow-up
• Moderator must ensure that every issue has been
  resolved in some way
• Team
• Moderator-manager, leader of inspection team
• Designer - team responsible for current phase
• Implementer - team responsible for next phase
• Tester - preferably from SQA team

26
What to look for in inspections

• Is each item in a specs doc adequately and
  correctly addressed?
• Do actual and formal parameters match?
• Error handling mechanisms identified?
• Design compatible with hardware resources?
• What about with software resources?

27
What to record in inspections

• Record fault statistics
• Categorize by severity, fault type
• Compare faults with average faults in same
  stage of development
• Find disproportionate in some modules, then
  begin checking other modules
• Too many faults gt redesign the module
• Information on fault types will help in code
  inspection in the same module

28
Pros and cons of inspection

• High number of faults found even before testing
  (design and code inspections)
• Higher programmer productivity, less time on
  module testing
• Fewer faults found in product that was inspected
  before
• If faults are detected early in the process there
  is a huge savings
• What if walkthroughs are used for performance
  appraisal?

29
Comparison of inspection and walkthroughs

• Inspection
• Checklist used to find faults
• Five step process
• Formalized procedure in each step
• Longer time

• Walkthrough
• No checklist used
• Two step process
• No formalized procedure in the steps
• Shorter time

30
Strengths and weaknesses of reviews

• Effective way of detecting faults
• Faults detected early in development
• Effectiveness reduced if software process is
  inadequate
• Large scale software hard to review if it
  consists of smaller largely independent units
  (OO)
• Need access to complete, updated documents from
  previous phase

31
Testing and code inspection

• Code inspection is generally considered
  complimentary to testing
• Neither is more important than the other
• One is not likely to replace testing by code
  inspection or by formal verification

32
Program testing

• Testing is a demonstration that faults are not
  present.
• Program testing can be an effective way to show
  the presence of bugs, but it is hopelessly
  inadequate for showing their absence. - Dijkstra

33
Execution-based testing

• Execution-based testing is a process of inferring
  certain behavioral properties of a product,
  based, in part, on the results of executing the
  product in a known environment with selected
  inputs.
• Depends on environment and inputs
• How well do we know the environment?
• How much control do we have over test inputs?
• Real time systems

34
Utility

• Extent to which a users needs are met when a
  correct product is used under conditions
  permitted by its specs.
• How easy is the product to use?
• Does it perform useful functions?
• Is it cost-effective?

35
Reliability

• Probability of failure-free operation of a
  product for a given time duration
• How often does the product fail?
• mean time between failures
• How bad are the effects?
• How long does it take to repair it?
• mean time to repair
• Failure behavior controlled by
• Number of faults
• Operational profile of execution

36
Robustness

• How well does the product behave with
• range of operating conditions
• possibility of unacceptable results with valid
  input?
• possibility of unacceptable results with invalid
  input?
• Should not crash even when not used under
  permissible conditions

37
Performance

• To what extent does the product meet its
  requirements with regard to
• response time
• space requirements
• What if there are too many clients/ processes,
  etc...

38
Levels of testing

• Unit testing
• Integration testing
• System testing
• Acceptance testing

39
Test plan

• Test unit specification
• Features to be tested
• Approach for testing
• Test deliverables
• Schedule
• Personnel allocation

40
References

• Textbook
• Scach - Classical and Object-Oriented Software
  Engineering
• Other books
• Beizer - Software Testing Techniques
• Beizer - Black-Box Testing Techniques for
  Functional Testing of Software and Systems
• Marick - The Craft of Software Testing
• Myers - The Art of Software Testing
