Title: Web Security


1
Web Security
  • Ben Johnston
  • bjohnston_at_thoughtworks.com

2
Overview
  • About ThoughtWorks
  • What is security?
  • Threats and threat modelling
  • Secure technologies
  • Web software vulnerabilities
  • Development process

3
ThoughtWorks
http//www.thoughtworks.com
4
About ThoughtWorks
  • Specialists in high technical risk custom
    software development and application integration
  • Leaders in Agile software development
    methodologies, Patterns and Open Source software
  • Offices in U.S., Oz, U.K., Canada, India and
    China
  • 600 staff globally, 60 staff locally
  • Equal opportunity employer
  • Graduate boot camp

5
What is security?
6
Security defined
  • Prevention of unauthorised actions
  • Detection of authorisation failures and
    unauthorised actions
  • Reaction to authorisation failures and
    unauthorised actions

7
Unauthorised actions
  • Damage or access to equipment
  • Disclosure of or access to confidential data
  • Tampering with private data
  • Destruction of data
  • Data spoofing
  • Identity theft
  • Execution of malicious code
  • Denial of service
  • Covering of tracks

8
The defenders dilemma
  • Every point must be strongly defended
  • Attacker only needs to find one weak point to
    succeed
  • Only known threats can be defended against
  • Attackers can probe for undiscovered
    vulnerabilities
  • Defenders can never sleep
  • Attackers can strike at leisure
  • No such thing as perfect security!

9
Threats and threat modelling
10
Threats
  • Physical
  • Network
  • Environment (OS, app server, web server, db
    server)
  • Application
  • Social

11
Threat categories
  • STRIDE categorises effects of threats
  • Spoofing identity
  • Tampering with data
  • Repudiation
  • Information disclosure
  • Denial of service
  • Elevation of privilege

12
Spoofing Techniques
  • Web spoofing
  • False copy of the WWW
  • Not as difficult as it may sound!
  • TCP spoofing
  • IP packets have forged return addresses
  • DNS spoofing
  • Forged information about machine name , IP
    address correspondence
  • Man-in-the-middle attacks

13
Whole-web spoofing
14
Assessing risk
  • DREAD risk calculation
  • Damage potential
  • Reproducibility
  • Exploitability
  • Affected users
  • Discoverability

15
Threat modelling
  • Analyse data flows
  • Construct threat trees using STRIDE (example)
  • Assess threat priorities using DREAD
  • Design mitigation

16
Security technologies
17
Using cryptography
  • Dont write your own crypto algorithms
  • Random number generation algorithms
  • Dont use linear congruence functions. E.g. CRT
    rand()
  • Can use approved algorithms from FIPS 140-1
    standard
  • Crypto depends on secret keys
  • Dont pass secret data around
  • Key management is typically the biggest
    vulnerability

18
Protecting secret data
  • Memory and file data is not secure
  • Never hard code secret strings
  • Random valued strings dont help
  • Secret algorithms for recovering secrets can be
    debugged!
  • Dont store secret keys unless you really have
    to!
  • Hash passwords into verifiers
  • Use salted hashing to improve protection against
    dictionary based attacks
  • PKCS 5 computationally expensive hashing
    algorithms

19
Ciphers
  • Symmetric ciphers use same key to encrypt/decrypt
  • Typically used to encrypt large amounts of data
    due to speed
  • Most symmetric ciphers (DES, RC4) require brute
    force attacks
  • RSA is an asymmetric cipher
  • Does not require a shared secret
  • Typically used to encrypt small amounts of data
  • Attackers must use a different technique call
    factoring
  • Key sizes are not equivalent
  • 70 bit symmetric key size ? 947 bit RSA modulus
    size
  • Choose appropriate key length
  • DES keys are 56 bit short term
  • Password strength measure effective bit size
    (entropy)
  • Bit size pwdLength log2(number of valid pwd
    characters)

20
Technologies
  • Digital certificates
  • Bind a public key to an identity that holds the
    private key
  • Mostly based on X.509v3 standard
  • Issued by a certification authority that verifies
    identity out of band
  • Public Key Infrastructure (PKI)
  • Comprises laws, policies, standards and software
  • Regulates or manipulates certificates and public
    and private keys
  • Secure Sockets Layer (SSL) / Transport Layer
    Security (TLS)
  • Use digital certificates and short term keys to
    encrypt connections
  • Firewalls
  • Prevents unauthorised network access by limiting
    port access
  • Provides packet filtering services

21
Web software vulnerabilities
22
Open Web Application Security Project (OWASP)
  • Top ten most critical web application security
    vulnerabilities 2004
  • Unvalidated input
  • Broken access control
  • Broken authentication and session management
  • Cross site scripting (XSS) flaws
  • Buffer overflows
  • Injection flaws
  • Improper error handling
  • Insecure storage
  • Denial of service
  • Insecure configuration management

23
Unvalidated input
  • HTTP requests can be arbitrarily altered
  • URL, querystring, headers, cookies, form fields,
    hidden fields
  • Telnet example
  • Common input tampering attacks
  • Cross site scripting (XSS)
  • Buffer overflows
  • SQL injection
  • Hidden field manipulation
  • Forced browsing
  • Path traversal

24
Protection against malicious input
  • Dont attempt to filter malicious input
  • Accept well formed input and reject anything else
  • Perform validation on the server
  • Client side validation is easily subverted
  • HTTP requests can be entered via Telnet session!
  • Centralise validation routines
  • Validation guidelines
  • Data type, allowed character set, min and max
    length
  • Can be null?, is required?
  • Numeric range, specific legal values
    (enumeration)
  • Specific patterns (Regular expressions)

25
Broken Access Control (Authorisation)
  • Authorisation is difficult to implement correctly
  • Separation of concerns is important in design
  • Principle of least privilege applies
  • Create an access control matrix
  • Users/roles vs functions
  • Ensure default deployment is secure
  • Specific issues
  • Insecure IDs
  • Forced browsing past access control checks
  • Client side caching

26
Broken authentication and session management
  • Correctly implementing authentication and session
    management is difficult
  • Flaws commonly found in credential management
  • Password change, Forgot my password, Remember my
    password, Account update
  • Authorisation
  • Strong passwords
  • Encrypted logins
  • Always POST authentication data, never cache it
  • Beware walk by attacks
  • Re-authenticate ALL admin functions
  • HTTP is stateless - sessions tokens provide
    state
  • Attackers can assume identity is session token
    compromised

27
Cross site scripting (XSS) flaws
  • Attacker uses web app to send malicious code to a
    different user
  • Attacks might be stored in web server, database,
    message forum, visitor log, comment field,
  • Victims can be lured via email reflected
    attacks
  • Potential consequences
  • Account compromise
  • Disclosure of users files
  • Installation of Trojan horse programs
  • Re-direction
  • Modification of content
  • Many free tools available to hackers

28
Protection against XSS flaws
  • Validate input!
  • Positive validation, NOT negative
  • HTML encode user supplied output
  • lt ? lt ( ? 40 ? 35
  • gt ? gt ) ? 41 ? 38

29
Buffer overflows
  • Attacker causes stack or heap corruption with
    carefully prepared input
  • Attacker can cause arbitrary code to be executed
  • Protection
  • Validate input!
  • Managed environments JVM, CLR
  • Principle of least privilege Apache, IIS 6

30
Injection attacks
  • OS Command injection
  • Web servers that call external services
  • SQL Injection
  • Constructing queries from user input
  • Quote the input?
  • Use stored procedures?
  • SQL injection remedies
  • Never connect as sysadmin!
  • Use parameterised SQL queries

31
Improper error handling
  • Exception conditions reported to user
  • Stack traces
  • Database dumps
  • Error codes
  • Fail-open
  • Protection
  • Error handling policy
  • Handle all possible errors gracefully
  • Log errors with sufficient details to indicate
    possible flaws

32
Denial of service
  • Application failure
  • Code quality issues check input!
  • CPU starvation
  • Profile application under load
  • Dont optimise prematurely!
  • Memory starvation
  • Dont assume memory is limitless
  • Dont allocate memory until its needed
  • Resource starvation
  • Allocation policy change behaviour under attack
  • Network bandwidth attacks
  • Dont respond to improper requests

33
Development process
34
What should you do about security?
  • Educate the team about security issues
  • Design continuously and consciously for security
  • Amortize the cost across all feature development
  • Factor threat modeling into design decisions
  • Test for security preferably automated tests
  • Identify a security expert for the project

35
Security - engineering practices and development
process
  • Adopt a process that reduces cost of change
  • Continuously refine the process through
    retrospectives
  • Document shared knowledge in a Wiki
  • Engineering practices
  • Test Driven Development
  • Continuous Integration
  • Simple Design
  • Coding standards
  • Pair Programming

36
Security principles in software development
  • Learn from your mistakes
  • Minimize your attack surface
  • Use defense in depth
  • Use least privilege
  • Use secure defaults
  • Assume external systems are insecure
  • Expect failure
  • Fail securely
  • Dont mix code and data
  • Fix security issues correctly

37
Features of secure software
  • Enables minimal functionality by default
  • Allows least privilege
  • Determine appropriate access control for
    resources
  • Configurable security features via admin tools
  • Provides audit logging
  • Provides security documentation

38
References
  • Writing Secure Code, 2nd Edition
  • Michael Howard David LeBlanc
  • Open Web Application Security Project
  • http//www.owasp.org
  • Web Spoofing
  • http//bau2.uibk.ac.at/matic/spoofing.htm
  • The Honeynet project
  • http//www.honeynet.org

39
Please fill out the survey
40
ThoughtWorks contacts
  • Follow-up from presentation
  • Ben Johnston (bjohnston_at_thoughtworks.com)
  • Recruitment
  • Amanda Keleher (akeleher_at_thoughtworks.com)
  • Commercial
  • Natalie Phillips (nphillips_at_thoughtworks.com)
  • John Sullivan (jsullivan_at_thoughtworks.com)
