Events, synchronicity, and recursive aspectorientation

1
Events, synchronicity, and recursive
aspect-orientation

• Nils Klarlund

2
Goal

• To lay a practical foundation for the solution of
  two problems fundamental to the programming of
  reactive systems
• Events v. synchronization
• Event abstraction

3
Were talking of pervasive problems

• Bedevil attempts to formulate declaratively
  temporal behavior of reactive programs
• Without such notations, building sophisticated
  concurrent system is very, very diffficult
• Example lack of undo and seek mechanisms in
• IVR (interactive voice response systems)

4
Part I. Introduction

• Two fundamental problems in the design of
  reactive systems

5
Events v. synchronization problem

• How
• events, which take place over time, and
• synchronization, which is instantaneous,
• are related is not well-understood

6
Rest of talk

• Part I. Introduction
• Part II. Big Picture
• Part III. Event woes
• Part IV. Solution Reaction trees
• Part VI. Towards a foundation for SMIL-like,
  reactive langauges

7
Part II. Big Picture

• Three kindred approaches to both problems
• StateCharts
• Aspect-oriented programming
• SMIL

8
Abstraction problem

• How to describe behavior in hierarchical manner
• Example
• Spoken dialogue system, where
• High level behavior deals
• Taking turns
• Defining possible inputs
• Low level behavior
• Speech recognizer time-outs
• Loading grammars

9
Abstraction solutions

• Idea lower level drives higher level
• Theory-inspired simplicity
• Hierarchical automata models (60s)
• Statecharts (David Harel)
• Whats done in practice messy world of
• Call-backs, event registration, listeners
• But also
• Aspect-oriented programming
• SMIL

10
Harels Statecharts

• Events are propositions
• Not consumed, but generated in a reaction
• On e as stimulus, least fixed point is e,f

gf
f
11
Advice of Aspect-Orientation

• Advice (Lisp CLOS, AspectJ, AspectC, etc.)
  expresses wrappers around existing functions
• Arguments can be changed or augmented
• Results can be changed
• Original function perhaps not called at all

12
Aspect-oriented programming

• An aspect is a cross-cutting module that
  defines variables, data types, and advice
• Advice consists of
• Declaration of a set of program points (e.g.
  function call sites)
• Code executing before or after or even wrapping
  around the original code
• Binding mechanisms allowing advice code to access
  actual parameters of function calls

13
Computing with advice

• Original program text not modified
• Easy to maintain code variants
• Easy to write logging information such as
• Before any call of methods Draw of class
  PaintObject, print the value of the size
  parameter
• Advice code is weaved with original code

14
SMIL

• SMIL (Synchronous Multimedia Language) tries to
  bridge the worlds
• Declarative and very convincing approach to
  managing the sequential and parallel activities
  of UI
• Does for the temporal dimension what HMTL does
  for the two dimensions of layout

15
SMIL basics

• In SMIL, you can say time containers I and J are
  to start at the same time
• time container interval
• We use thread
• Example two videos to be started together
• ltvideo srchead idI beginJ.begin/gt
• ...
• ltvideo srcside idJ beginI.begin/gt
• Sync arc from I to J and from J to I
  synchronizing start of video

16
Binding world of synchronization to programmatic
world of events

• Declarative notion inadequate in general
• External events myButton.click used to activate
  time containers
• Programmatic way to begin an element that is,
  way to go from push events into declarative world
• I.beginElement()forces I to begin
• And by synchrony J begins

17
More bindings between worlds

• Also, SMIL (Microsoft implementation) offers
• Programmatic inspection of declarative world
• I.isActive property (is interval I active or does
  thread I run?)
• Casting of causality in synchronization to events
• onbegin event fired when thread starts

18
Event/synchronization summary

• Events are instantaneous
• But they cause each other, indirectly, through
  effects of resumed threads (or they are caused by
  external stimuli)
• Thus a programmer has a clear picture of temporal
  progression in mind when understanding a reactive
  event-based program

19
Event/synchronization summary II

• But, synchronization is about doing things at the
  same time according to causal rules
• A rigorous pursuit of synchronization has lead to
  practical successes such as
• Esterelle (with a pure synchronous semantics)
• StateCharts (which often has a non-synchronous
  semantics, however)
• But significant semantic problems in general
• The problem is to reconcile events and
  instantaneous causality

20
Part III. Event woes

• SMIL
• Emacs
• Statecharts

21
Event woes I SMIL Example

• This example illustrates the naturalness of
  coupling intervals in SMIL
• And the difficulty of understanding casual
  dependencies as events
• The particular mechanism that breaks is time
  seek, a kind of temporal undo
• Link to example (only for IE 5.5 or 6)

22
The SMIL declaration

• ltSMILseq repeatCount"indefinite"gt
• ltbutton class"time" end"c.click" id"c"gt
• Click to launch!
• lt/buttongt
• ltSMILpar end"clip.click" id"example"gt
• ltspan class"time"gtLaunching!lt/spangt
• ltSMILvideo src"spaceshuttle.avi" id"clip"gt

• ltSMILanimate begin"10s"
• dur"5" to"true"
• attributeName"mute"/gt
• lt/SMILvideogt
• ltSMILseq begin"rewind.click" dur"0"
• onend"rewind(example)"/gt
• lt/SMILpargt
• lt/SMILseqgt

23
SMIL Example (continued)

• The problem occurs as follows
• Click on Click to launch!
• Let movie clip run for a few seconds
• Then click rewind
• The display now shows at the same time both
  subelements of the ltSMILseqgt element!!!
• This is not a problem with the IE implementation
  of SMIL, but a sign of deeper semantic trouble
  external events and declarative meaning do not
  mix well

24
Time seek and undo are hard

• Because how
• events, which take place over time, and
• synchronization, which is instantaneous,
• are related is not well-understood
• But creators would probably say SMIL is not a
  reactive language, it is a declarative notation
• Still SMIL is supposed to be used with scripting
• So we need to tie events and synchronous
  causality together
• Then, solving undo and seek semantics become
  rather simple

25
Event woes II Emacs

• An event (mouse click, key press) is an
  abstraction unit
• Namely, in keyboard macros
• Events are queued in unread-command-events
• A macro is a sequence of events
• A macro can be assigned to a key
• Thus, macros are definable in terms of macros

26
Queues examples of renegade thinking?

• Does execute-kbd-macro add events to front or to
  back of queue?
• Neither works in case of macro of macros!
• Analogy consider a programming language where
  yet-to-be-executed procedures are kept in a
  queue. One procedure at a time, from the front
  of the queue, is picked for execution
• Is this a good idea?
• For ShortTalk prototype written in 10,000 lines
  of Emacs Lisp
• Event model creates serious headaches

27
Event woes III Statecharts

• Events are propositions (an unusual point of
  view)
• Not consumed, but generated in a synchronous
  reaction
• On e as stimulus, least fixed point is e,f

gf
f
28
Mystery programs 1 and 2

• MP1
• I f
• J g f
• K f g

MP2 I Øg f J g f K f g
I
J
K
I
J
K

gf
gf
fg
Øgf
fg
f
29
Part IV. Solution reaction trees

• Causality
• Principle of no self-causation

30
Concepts towards an understanding

• An event is identified by a name
• A target is a block (thats where event appears)
• bE beginElement
• b begin
• event ? accept/receive/read/handle (pattern)
• event _at_ target ! emit/fire/raise/signal
  (statement)
• A handler is of form pattern statement
• Co-routine model one handler executed at a time

31
Modeling bE to b and sync arcs
Accept beginElement, then signal begin at I
bE? b!I
I
b_at_J? bE!I
When begin is signaled at J, signal beginElement
at I
b_at_I? bE!J
bE? b!J
J
32
Cyclic dependencies lead to cyclic behaviors
33
Co-events happen when?
I

• Augment I and J with isActive variable
• We expect true and true to be printed
• History for bE signaled at I
• event b at I(execute handler now? no!)
• co-event b_at_I at J (observation)
• bE at J
• b at J
• So, co-event must be handled before execution of
  handler for b

bE? b!I I.isActive true b_at_J? bE!I b?
print(J.isActive)
J
bE? b!J J.isActive true b_at_I? bE!J! b?
print(I.isActive)
34
Temporal ordering of co-events

• bE? b!I I.isActive true
• b_at_J-? bE!I
• b? print(J.isActive)

35
The reaction tree

• The root is an empty node (document node)
• It holds the external event or injected event
• After an event is handled,
• the signaled events are appended as children in
  left-to-right order with time
• each child is accompanied by its pre-events,
  which are siblings inserted in front of it
• When an event has executed
• its post-events are inserted after it as
  siblings, and
• the next node in pre-order traversal is selected
  for handling

36
Example of tree growth
Goal when b!I and b!J are handled, both isActive
variables are true
When event node p is handled, the already handled
nodes are the ones before p in document order
(preorder)
37
When to be able to handle?

• A guard of true() is always enabled?
• Goes against idea of event consumption
• So, tie this predicate to an event!
• Which one?
• The external event
• Not every event!

38
Reify reaction tree
39
Node matching XSLT/XPath

• Convention a pattern is now that of XSLT
• Examples
• / the root, but never
  signaled/handled
• e the event named e
• / any external event
• /click the external event click
• ///click any mouse click that was synthesized

40
Use filters

• /not(//g)
• an external event, but only if g has not been
  signaled so far
• ///enot(ancestorf) and not(ancestorg
• any e, when not external and when not indirectly
  caused by f or g

41
Mystery Program Solutions
MP2 I /not(//g)_at_MP2 ? f J g f!MP2
K f g!MP2

• MP1
• I /_at_MP1 -? f !MP1
• J g f !MP1
• K f g !MP1

I
J
K
I
J
K

/f
g/f
f/g
Øg/f
g/f
f/g
42
Mystery Program 1
e!MP1

• Let us inject e at location MP1
• This event is never handled
• There is no handler!
• Still f is generated as expected

MP1 I /_at_MP1-? f !MP1 J g f !MP1 K
f g !MP1
43
Mystery Program 2
e!MP2

• Let us inject e at location MP2
• Post-event generates f

MP2 I /not(//g)_at_MP2? f J g f!MP2
K f g!MP2
44
Namespace for event values

• Events, of course, are not atomic, but are trees
• So reaction tree is tree of trees!
• Use namespace notation with
• ReaxEvt for top element of an event
• ReaxEvtPre top element of pre-event
• ReaxEvtPost for top element of post-event

45
Example of namespace use

• ltReaxEvte locid1gt
• ltReaxEvtPref atid3 locid4/gt
• ltnamegtAnnalt/namegt
• ltReaxEvtPrefgt
• ltReaxEvtf locid3gt
• ltnamegtAnnalt/namegt
• ltReaxEvtfgt
• ltperson gendermalegt
• ltnamegtBoblt/namegt
• lt/persongt
• ltReaxEvte/gt

46
XML for locations as well

• Broadcast for event signals
• Observe several places for co-events
• So, program syntax itself should be XML
• Then, we can write
• // any location
• id(helperProc)// any location within
  helperProc
• .. for the block above

47
Modeling exceptions

• try S throw e throw f
• catch e Se f Sf
• becomes
• init_at_I!
• Iinit S e! break
• f! break
• e Se exit
• f Sf exit

48
Related work

• Esterel
• UML Statecharts
• As in our approach, one event is presented at a
  time. If several transitions are enabled, then
  either they are in different threads or the
  deepest one takes precedence
• By default all events are broadcast
• Varro 2002 A Formal Semantics of UML
  Statecharts by Model Transitions
• Uses a hierarchy of queues

49
Part VI. Towards a foundation for SMIL-like,
reactive langauges
50
UI issues and undo seek

• In principle, we can now with confidence explain
  a SMIL-like language
• With declarative synchronization and temporal
  features
• Based on one event model comprises
• Reified causality
• Principle of no self-causation
• And, we can augment this notation with undo and
  seek as built-in mechanisms

51
Time seek and undo

• Add to ReaX
• Notion of module
• Checkpoints to identify unit tasks that are to be
  undone
• Ways of categorizing events as
• Undoable
• With or without specific undo event
• Various roll-back characteristics of modules
• Not undoable
• Notion of real time and module that allow time
  seek
• See my Web-site for more details

52
Appendix. ReaX overview

• Syntax
• Semantics

53
ReaX expressions

• LocE XPath expression with
• context node node of innermost block containing
  expression
• EvtE XPath expression with
• context node current event being handled
• E EvtE or XSLT-like tree fragment
• In XPath event()refers to current event

54
ReaX syntax I

• Stmt while EvtE do Stmts
• if EvtE then Stmts else Stmts var
  E
• EvtNnm_at_LocE ! ( lt gt )
• break
• exit
• Handlrs
• Decls
• Stmts Stmt

Exit handler
Exit handlers block
55
ReaX syntax II

• Decls
• (var VarNvm ( E)?) Stmts
• Handlrs
• (EvtNmeEvtE?
• EvtNme_at_locE EvtE? -?)
• Stmts)

56
Run-time model

• The run status of a thread is none, waiting, or
  executing
• When status is waiting or executing, the thread
  has a program counter
• Between reactions all thread statuses are none or
  waiting
• Co-routine model at most one thread is executing
  at a time
• If a thread is waiting, then its parent is, too

57
The reaction

• Add(e_at_l at p)
• Append pre-events of e_at_l as children of p
• Append e_at_l
• Process(e_at_l at p)
• If there is a handler eEvtE Stmts at l with
  thread of l waiting at l and with EvtE evaluating
  to true, then execute Stmts as a subthread
• For each e_at_L that is signaled, Add(e_at_L at p)
• Append post-events as siblings of p
• Process(event at next node) in pre-order
  traversal
• Pre-events and post-events are processed
  similarly
• No additional pre- and post-events added

58
Statement execution

• Simple do the obvious, advancing the PC of the
  thread, until a handlers block in encountered
  then stop
• This is where the thread waits
• A subthreads run status is (still) none
• If break or end of thread is encountered, then
  stop
• The threads run status becomes none (parent
  thread still waiting)
• If exit is encountered
• Make run status none for this thread and all
  siblings
• Continue execution of parent thread after parent
  block

59
Add co-events for e_at_l

• For each
• e _at_ locE EvtE- Stmts
• at location lt such that
• locE evaluated at lt contains l
• EvtE evaluates to true
• add e _at_ l _at_ lt to set of co-events
• Order co-events according to document order on lt
  (or use static priority declarations)

60
Termination property

• If every while loop terminates, then the ReaX
  semantics guarantee termination of a reaction
• Proof
• Königs Lemma states that a finitely branching
  tree is infinite only if it has an infinite path
• Termination of while loops imply that the
  reaction tree is finitely branching
• Principle of no self-causation implies no
  infinite paths

61
Exceptions through transformations,

• try S throw e throw f
• catch e Se f Sf
• becomes
• init_at_I!
• Iinit S e! break
• f! break
• e Se exit
• f Sf exit
