Title: ITU Structure


1
ITU Structure Study Groups
  • Masatoshi Ohishi
  • NAOJ

2
(No Transcript)
3
(No Transcript)
4
(No Transcript)
5
Members of the ITU
  • Member States (189)
  • Sector Members such as private companies (more
    than 600)
  • Regional Groups
  • International Organizations such as IUCAF

6
Structure of the ITU-R
7
(No Transcript)
8
Regional Groups
  • CEPT Europe
  • CITEL North and South America
  • APT Asia-Pacific region
  • Arab group
  • ? They prepare common proposals for
  • WRC agenda items.

9
RA frequency groups
  • IUCAF IAU URSI COSPAR
  • Europe -- CRAF
  • Committee for Radio Astronomy Frequencies
  • US -- CORF
  • Committee on Radio Frequencies
  • AP region -- RAFCAP

10
Regions 1, 2 3
11
(No Transcript)
12
(No Transcript)
13
Radio Astronomy Service
  • 1.58 radio astronomy service  A service
    involving the use of radio astronomy.
  • Historically RAS was restricted to ground-
  • based one. Now RAS includes space-based
    observations.

14
Radio Astronomy in ITU
Footnote of Radio Regulation
  • 1.13 radio astronomy  Astronomy based on the
    reception of radio waves of cosmic origin.
  • 1.5 radio waves or hertzian waves  Electromagnet
    ic waves of frequencies arbitrarily lower than
    3 000 GHz, propagated in space without artificial
    guide.

15
RAS ? radiocommunication
  • 1.3 telecommunication   Any transmission,
    emission or reception of signs, signals,
    writings, images and sounds or intelligence of
    any nature by wire, radio, optical or other
    electromagnetic systems (CS).
  • 1.138 emission  Radiation produced, or the
    production of radiation, by a radio transmitting
    station.
  • 1.137 radiation  The outward flow of energy from
    any source in the form of radio waves.
  • 1.6 radiocommunication  Telecommunication by
    means of radio waves (CS) (CV).

16
RAS ? radiocommunication
  • 1.7 terrestrial radiocommunication  Any
    radiocommunication other than space
    radiocommunication or radio astronomy.
  • 1.8 space radiocommunication  Any
    radiocommunication involving the use of one or
    more space stations or the use of one or more
    reflecting satellites or other objects in space.

17
RAS as radiocommunication
  • 4.6 For the purpose of resolving cases of harmful
    interference, the radio astronomy service shall
    be treated as a radiocommunication service.
    However, protection from services in other bands
    shall be afforded the radio astronomy service
    only to the extent that such services are
    afforded protection from each other.

18
(No Transcript)
19
WRC
  • World Radiocommunication Conference
  • New allocations, new regulations, etc., are
    discussed and adopted based on national and
    regional proposals.
  • Study Groups, Working Parties consider technical
    aspects of agenda items for WRCs.

20
Study Cycle (3 years)
  • CPM report

Agenda Items
WRC Admins.
Adopt Radio Regulations
CPM Experts
Study Groups
Exchange info
Assign AIs
Draft CPM report
WPs, TGs
21
Study Groups
  • drafting Technical bases for Radiocommunication
    Conferences
  • developing Draft Recommendations
  • compiling Handbooks

22
Study Groups
  • SG 1Spectrum Management
  • SG 3Radio Wave Propagation
  • SG 4Fixed-Satellite Service
  • SG 6Broadcasting Service
  • SG 7Science Services
  • SG 8Mobile, radiodetermination, amateur
  • and related satellite services
  • SG 9Fixed Services
  • SC Special Committee

23
Working Parties
  • Study Groups are organized into Working Parties
    and Task Groups
  • Deal with specific aspects of Study Group work
  • Issues related with multiple SGs
  • ? Joint WPs, Joint TGs

24
SG 1
  • WP 1A Spectrum engineering techniques
  • WP 1B Spectrum management methodologies
  • WP 1C Spectrum monitoring
  • TG 1/7 Protection of passive service bands
    from unwanted emissions
  • JTG 1-6-8-9 Multimedia applications (Resolution
    737 (WRC-2000))

25
SG 3
  • WP 3J Propagation fundamentals
  • WP 3K Point-to-area propagation
  • WP 3L Ionospheric propagation
  • WP 3M Point-to-point and Earth- space
    propagation

26
SG 4
  • WP 4A Efficient orbit / spectrum utilization
  • WP 4B Systems, performance, availability and
    maintenance of FSS, Satellite news gathering
    (SNG) and outside broadcast via satellite
  • JWP 4-9S Frequency sharing, between the FSS
    and the FS
  • JTG 4-7-8 Sharing in the band 13.75 14 GHz
    (Resolution 733 (WRC-2000))
  • JTG 4-7-8-9 5 GHz band allocations (Resolution
    736 (WRC-2000))

27
SG 6 (WPs)
  • WP 6A Programme assembling and
    formatting
  • WP 6E Terrestrial delivery
  • WP 6M Interactive and
  • multimedia broadcasting
  • WP 6P Content production / postproduction
  • WP 6Q Performance assessment
  • and quality control
  • WP 6R Recording for production, archival
  • and play-out film for
    television
  • WP 6S Satellite delivery

28
SG 6 (TGs)
  • TG 6/6 Recommendation for a digital
    broadcasting standard below 30 MHz
  • TG 6/7 Planning parameters for digital
    broadcasting at frequencies below 30 MHz
  • TG 6/8 Preparation for the Regional
    Radiocommunication Conference
  • 2004 (RRC-04)
  • TG 6/9 Digital cinema

29
SG 7
  • WP 7A Time signals and frequency standard
    emissions
  • WP 7B Space radio systems
  • WP 7C Earth-exploration satellite
  • systems and meteorological elements
  • WP 7D Radioastronomy
  • WP 7E Inter-service sharing and compatibility

30
SG 8
  • WP 8A Land mobile service excluding
    IMT- 2000
  • WP 8B Maritime mobile service including
    Global Maritime Distress and Safety System
    (GDMSS) aeronautical mobile service and
  • radiodetermination service
  • WP 8D All mobile-satellite services
  • and radiodetermination-satellite service
  • WP 8F IMT-2000 and systems beyond IMT- 2000
  • JRG 8A-9B Wireless access systems

31
SG 9
  • WP 9A Performance and availability,
    interference objectives and analysis, effects of
    propagation and terminology
  • WP 9B Radio-frequency channel arrangements,
    radio system characteristics, interconnection,
    maintenance and various applications
  • WP 9C Systems below 30 MHz (HF and others)
  • WP 9D Sharing with other services (except
    for the FSS)
  • JRG 6S-9D Frequency sharing between the FS and
    BSS (sound)

32
(No Transcript)
33
Documents
  • Input Documents from Member States, Sector
    Members and International Organizations, etc.
    (White)
  • Liaison Statements from other WPs, TGs, etc.
    (White)
  • Output Documents (Yellow)
  • Administrative Documents (Green/Blue)

34
Contributions from Member States, etc.
Liaison Statements From other Groups
Chairmans Report
Consider input Documents
WPs, TGs, SGs, etc.
Contributions To Parent SG Such as DNRs
Liaison Statements To other Groups
Documents carried on ?Chairmans report
35
ITU Web page
  • http//www.itu.int/ top page
  • http//www.itu.int/ITU-R/
  • Submitted documents appear on the Web.
  • You need a TIES account to download
  • files.

36
Recommendations
  • The ITU-R Recommendations provide a body of
    technical, operational and regulatory /
    procedural information that has been agreed upon
    by the participating administrations.

37
Production of Recs.
Working Party Task Group
Study based on contributions
APPROVE
Study Group
ADOPT
Administration
New Rec
VOTE
38
How to Name Recs
  • Recommendation ITU-R RA.769-1

RARadio Astronomy
769 sequential number
-1 Revision number
39
(No Transcript)
40
RA series
  • RA.314 Preferred frequency bands for radio
    astronomical measurements
  • RA.479 Protection of frequencies for
    radioastronomical measurements in the shielded
    zone of the Moon
  • RA.517 Protection of the radioastronomy service
    from transmitters in adjacent bands
  • RA.611 Protection of the radioastronomy service
    from spurious emissions
  • RA.769 Protection criteria used for
    radioastronomical measurements
  • RA.1031 Protection of the radioastronomy service
    in frequency bands shared with other services
  • RA.1237 Protection of the radio astronomy service
    from unwanted emissions resulting from
    applications of wideband digital modulation
  • RA.1272 Protection of radio astronomy
    measurements above 60 GHz from ground based
    interference
  • RA.1417 A radio-quiet zone in the vicinity of the
    L2 Sun-Earth Lagrange point
  • RA.1513 Levels of data loss to radio astronomy
    observations and percentage-of-time criteria
    resulting from degradation by interference for
    frequency bands allocated to the radio astronomy
    on a primary basis

41
Current Frequency Allocations
  • 9 kHz 275 GHz
  • lt 9 kHz
  • 5.53 Administrations authorizing the use of
    frequencies below 9 kHz shall ensure that no
    harmful interference is caused thereby to the
    services to which the bands above 9 kHz are
    allocated.
  • 5.54 Administrations conducting scientific
    research using frequencies below 9 kHz are urged
    to advise other administrations that may be
    concerned in order that such research may be
    afforded all practicable protection from harmful
    interference.

42
Secondary
Primary alloc.
direction
footnotes
RAS
43
Primary Secondary Services
a) services the names of which are printed in
capitals (example FIXED) these are called
primary services b) services the names of
which are printed in normal characters
(example Mobile) these are called secondary
services. Stations of a secondary service
a) shall not cause harmful interference to
stations of primary services to which frequencies
are already assigned or to which frequencies may
be assigned at a later date b) cannot claim
protection from harmful interference from
stations of a primary service to which
frequencies are already assigned or may be
assigned at a later date c) can claim
protection, however, from harmful interference
from stations of the same or other secondary
service(s) to which frequencies may be assigned
at a later date.
44
Allocation gt 275 GHz
  • No allocation at present
  • (only footnote 5.565)
  • Provisional Agenda Item for WRC-2006

45
(No Transcript)
46
  • 5.565 The frequency band 275-1000 GHz may be used
    by administrations for experimentation with, and
    development of, various active and passive
    services. In this band a need has been identified
    for the following spectral line measurements for
    passive services
  • radio astronomy service 275-323 GHz,
    327-371 GHz, 388-424 GHz, 426-442 GHz,
    453-510 GHz, 623-711 GHz, 795-909 GHz and 926-945
    GHz
  • Earth exploration-satellite service (passive)
    and space research service (passive) 275-277
    GHz, 294-306 GHz, 316-334 GHz, 342-349 GHz,
    363-365 GHz, 371-389 GHz, 416-434 GHz,
    442-444 GHz, 496-506 GHz, 546-568 GHz,
    624-629 GHz, 634-654 GHz, 659-661 GHz,
    684-692 GHz, 730-732 GHz, 851-853 GHz and
    951-956 GHz.
  • Future research in this largely unexplored
    spectral region may yield additional spectral
    lines and continuum bands of interest to the
    passive services. Administrations are urged to
    take all practicable steps to protect these
    passive services from harmful interference until
    the date when the allocation Table is established
    in the above-mentioned frequency
    band.     (WRC-2000)

47
RA bands defined in ITU
  • Frequency usages are regulated in ITU
  • RA bands ? rights to be protected

48
Where are RA bands ?
Frequency Bands(MHz) Frequency Bands(GHz)
13.360 - 13.410 25.550 - 25.670 37.5 - 38.25 73 - 74.6 150.05 - 153 322 - 328.6 406.1 - 410 608 - 614 1 400 - 1 427 (HI) 1 610.6 - 1 613.8 (OH) 1 660 - 1 670 (OH) 2 655 - 2 700 4 800 - 5 000 (H2CO) 10.6 - 10.7 14.47 14.50 (H2CO)0 15.35 - 15.40 22.21- 22.50 (H2O) 23.6 - 24.0 (NH3) 31.3 - 31.80 42.5 - 43.5 (SiO) 76 - 116 123 - 158.5 164 - 16700 200 - 231.500 241 - 275
49
New RA bands above 71 GHz
50
Shared RA bands
  • In many RA bands, other services are
  • also allocated.
  • INTERFERENCE !?
  • It is necessary to coordinate between
  • RAS and other services.

51
Adjacent to RA bands
  • In many cases, there are satellite services
  • (FSS, MSS, BSS, etc) in downlink !!
  • RA can not avoid interference
  • by choosing sites.

52
Iridium Satellites

  • Max hold

  • 1 min

  • IF output

  • 5dB/div

  • 1450-1950

  • MHz

53
Observed Interference at CRL
54
Interference by GSOs
21cm obs. at Bonn
GSOs
55
Radio Frequency Interference
  • Radio contaminations by artificial
  • transmission (Telecomm., Radar, etc.)
  • Serious Problem for low-frequency
  • RA observations
  • RFI will occur in higher frequencies

56
Necessary bandwidth
  • 1.152 necessary bandwidth  For a given class of
    emission, the width of the frequency band which
    is just sufficient to ensure the transmission of
    information at the rate and with the quality
    required under specified conditions.

57
Unwanted emissions
  • 1.144 out-of-band emission  Emission on a
    frequency or frequencies immediately outside the
    necessary bandwidth which results from the
    modulation process, but excluding spurious
    emissions.
  • 1.145 spurious emission  Emission on a frequency
    or frequencies which are outside the necessary
    bandwidth and the level of which may be reduced
    without affecting the corresponding transmission
    of information. Spurious emissions include
    harmonic emissions, parasitic emissions,
    intermodulation products and frequency conversion
    products, but exclude out-of-band emissions.
  • 1.146 unwanted emissions  Consist of spurious
    emissions and out-of-band emissions.

58
Appendix to Article 3
  • For the purpose of setting limits, all emissions,
    including harmonic emissions, intermodulation
    products, frequency conversion products and
    parasitic emissions, which fall at frequencies
    separated from the centre frequency of the
    emission by  250, or more, of the necessary
    bandwidth of the emission will generally be
    considered as spurious emissions.

59
Necessary bandwidth
?f
2.0 x ?f
2.0 x ?f
Spurious emission
Spurious emission
OOB
OOB
frequency
60
Roadmap of Communication
61
HAPS Issue
  • High Altitude Platform Stations
  • Airships at 20 km altitude
  • For Broadband communication
  • US 47 GHz region
  • Japan 31 GHz region

62
(No Transcript)
63
HDFS at 43GHz
  • High Density Fixed Service?broadband
    communication
  • Includes the SiO band (42.5-43.5GHz)
  • It may degrade pointing accuracy.
  • Since 2000, we are collaborating to
  • avoid interference to the RAS band.

64
Other RFI?s
  • BS around 608 614 MHz in Europe
  • ? New RFI? for Urmuqi and GMRT
  • MSS near 1.4 GHz (HI) band
  • RNSS near 5 GHz (H2CO) band
  • Internet access from aircrafts (Boeing)
  • near 14.5 GHz (H2CO) band

65
Space Solar Power Satellite
  • Generation of Electricity in Orbit
  • Up to 10 GW ? Rectenna 10kmx10km
  • Microwave Power transfer _at_ 2.45 GHz
  • ? Interference at 5 GHz (H2CO band)
  • 40 dB higher than interference level detrimental
    to the RAS

66
RFI ? IRFI ? OFI
  • Similar Problems might occur in IR/Optical
    Astronomy

67
Above 10 THz issue
68
Optical Communication
  • Laser Communications gt 10 THz
  • has been studied
  • ? Probable Problems in NEAR FUTURE

69
(No Transcript)
Write a Comment
User Comments (0)
About PowerShow.com
