Magnetic fields and CMB

1
Eduardo Battaner, Estrella Florido, Ana Guijarro,
Africa Castillo Universidad de Granada
2

• Reviews
• Grasso and Rubinstein (2001)
• Giovannini (2004)
• Distortion of Planck spectrum (Jedamzik,
  Katalinic and Olinto, 2000
• Faraday rotation (Kosowsky and Loeb, 1996)
• Shift in the position of Doppler peak (Adams,
  Danielson, Grasso and Rubinstein, 1996)
• Increase of amount of anisotropy (Giovannini,
  1999)
• Depolarization (Harari et al, 1997)

3
Magnetogenesis

• B created
• After Recombination
• By turbulence in the radiation dominated epoch.
• In cosmological phase transitions.
• At Inflation. (assumed here)
• The radiation dominated era is highly
  resistive. Only large magnetic coherence cells
  can survive, mainly super-horizon cells.

4
Pre-recombination magnetic fields

• 10-8-10-9 G (comoving) fields affect the
  formation of the large structure, introducing
  filaments at any large scale.
• AA papers
• Magnetic fields and large scale structure in a
  hot universe
• I. General equations
• II. Magnetic fields and filamentary structure.
• III. The polyhedric network.
• IV. The egg-carton universe.
• The fractal octohedron network of the large scale
  structure.
• Following these papers CMB must be affected by B,
  too.

5
Radiation dominated era

• The mathematical procedure requires GR.
• Non-linear effects are not important. d is very
  small.
• From Annihilation to Equality.
• Energy-momentum tensor takes into account the
  magnetic contribution.
• This magnetic contribution acts anisotropically.
• ltBgt0, in agreement with the Cosmological
  Principle, but ltB2gt is not vanishing. It is
  ordered at coherence cells.

6
Mean magnetic fields

• In the synchronous gauge

7
...where

• Equation of state

Equation of state
8
Perturbed quantities

• Probably the mean magnetic energy density is
  negligible in the Universe as a whole.
• Therefore, the expansion and the cooling rates of
  the Universe are unaffected by magnetic fields.
• However magnetic effects can be important at
  scales where isotropy does not hold.
• i.e. magnetic fields may play a role in producing
  the large scale of the Universe.
• Magnetic fields may play a role in CMB
  anisotropies and its interpretation.

9

• The model does not include dark energy (yet)
• The model stops at Equality (transition between
  radiation and matter dominated eras).
• It is an step towards a future more detailed
  model.
• To follow a single structure (instead of
  considering a spectrum of primordial magnetic
  structures).

10
linear perturbations
radiative
11
EM quantities

• As the mean quantities vanish, perturbed
  quantities are

12
Perturbed Equations

• Perturbations of general relativistic
• Maxwell equations
• Fluid equations of motion-energy
• Einstein field equations
• Not all equations are independent.

13
Perturbed Maxwell equations
This reminds the frozen-in conditions, but rather
it shows that the magnetic pattern remains the
same. The strength is just reduced by the effect
of expansion. The original pattern is conserved!
14
More Maxwell...
Macroscopic neutrality
Calculation of electrical current
15
Perturbed equation of motion-energy

• From

i-component
Observe the Anisotropic action
0-component
16
Perturbed Einstein Field Equation
17
More field equations
18
Energy density perturbations

• Let us define

19
...some algebra

• Define present-day or comoving quantities

Probably, B0 does not coincide with B
at Present!
constant
It would coincide If only the expansion could
modify it
20
...after miraculous algebra

• From 17 equations, we obtain for the density
  contrast

t is a time variable
Elliptic Linear Second order Differential eq.,
with Variables Coeff.
21
Formation of CMB anisotropies

• Pre-existing magnetic configurations determine
  the evolution of radiation inhomogeneities.
• For very large t, i.e. for very large structures

22
Primordial B

• If comoving magnetic strength is larger than
  about 0.01 microgauss, it should have had an
  important influence in CMB.
• If it is much larger the formation of galaxies
  would have begun too early and anisotropies in
  CMB would have been produced too early.
• If it is much lower, we meet the classical
  theory, without magnetic fields.
• If X is of order unity, we find equipartition,
  which is difficult to assume.

23
Integration

• A primordial B configuration must be given as an
  input.
• The simplest configuration is a gaussian magnetic
  field flux tube

24
General integration

• Simultaneous over-relaxation method with
  Chebyshev acceleration.
• As initial time condition we have considered
  either
• Homogeneity (d(t0)0)
• or
• Isocurvature (d(t0)-X)
• Except at the beginning, both provide similar
  results.

25
Large scale tube fluxes

• In this case
• the integration is no longer elliptic,
• it can be treated analytically,
• more prediction ability.
• They are unaffected by dissipative effects.
• They are unaffected by resistive effects.
• They produce CMB anisotropies and density
  inhomogeneities unaffected by later non linear
  effects

26
(No Transcript)
27
History

• Primordial magnetic flux tubes gives filamentary
  photon estructures. (DMbaryons)
• They are still observable at Recombination (CMB).
• Matter falls into the photon potential wells.
• After photon decoupling matter filamentary
  structures remain.

28
...more history

• Large structures are unmodified by post
  Recombination non linear effects, damping...
• Small scale non-linear effects amplify and
  distort magnetic fields from B0 10-8 G to 10-6
  G observed today.
• No galactic dynamo amplification is required.

29
Why filaments?

• They are natural coherence cells.
• They are found in many astrophysical systems.
• The large scale structure is rich in filaments.
• First example is Coma-A1367 supercluster.
• gt100 Mpc long, 10 Mpc in diameter.
• B has been measured in this supercluster (0.3-0.6
  mG in extracluster region)
• Is there a gt600 Mpc filament connecting Draco and
  Tucana?

30
(No Transcript)
31
B and CMB

• B created at Inflation could have observable
  consequences in the last scattered surface.
• It could be difficult to identify filaments in
  maps.
• For instance, it would depend on the relative
  size and orientations of the structures in the
  LSS.
• But the interpretation of the power spectrum
  should be reconsidered. Also the polarization
  power spectrum.
• Filaments of magnetic origin with a component
  perpendicular to the LSS would produce FR. A
  correlation between FR and DT2 is therefore
  expected.

32
Speculations

• Because of

Magnetic field lines either are straight lines
(in contradiction with the Cosmological
Principle) or form loops.
33
And speculations...

• Assume there is a network of filaments.
• Many workers (Broadhurst, Tully, Einasto...)
  find that, even at scales larger than 100 Mpc.
• Tully A 3-dimension chess board
• Of course we are not proposing that the Universe
  is a pure crystal, but rather an imperfect
  network, like a foam lattice.
• The simplest network would consist in polyhedra.
• Assume that these filaments are fossil structures
  of previous magnetic field tubes.
• As a zero-order a crystalographic approach is not
  unreasonable.

34
...and more speculations...

• Filaments arranged to form polyhedra defined by
  their edges.
• Edges are made of superclusters.
• Edges have formed by primordial magnetic tubes.
  Then, the edges have a direction and form
  loops.
• What is the basic polyhedra of the lattice?

35
...Following speculations...

• Magnetism imposes restrictions on the basic
  polyhedra.
• If all edges, all vertexes and faces are
  equivalent.
• Nature cannot solve puzzles
• The loops must close in a face. This is the
  simplest.
• The basic polyhedron must be the octahedron.

36
The egg-carton Universe

• Octahedra contacting at their vertexes.
• Other possibilities are too complicated.

37
A model Universe
38
(No Transcript)
39
(No Transcript)
40
(No Transcript)
41
Identification

• Most important superclusters reasonably fit the
  egg-carton lattice.
• Most voids fit this lattice too.
• There would be two kinds of voids intra- and
  inter-octahedra.

42
If magnetic energy density is negligible

• As always, however...

43
For a Robertson-Walker metric
44
(No Transcript)
