Infrared Application

1
Infrared Application

• HASUL KIM

2
Introduction

• General information for the infrared wave
• Thermography
• Infrared Imagery
• Commercial application
• -gas detection method
• Military application
  -counter-measurement
• Conclusion

3
Blackbody Radiation

• Theoretical ideal IR radiator
• Emissivity (Celsius degree)
• polished aluminum 5(100)
• snow 85(-10)
• human skin 98 (32)

4
Characteristics of infrared

• It is invisible since its wavelength is longer
  than visible light. It has nothing to do with
  brightness or darkness of visible light
• It is emitted naturally from any object of which
  temperature is absolute zero(0K) or higher.
  Therefore, it can be applied to any field
• It has a characteristic of heating an object.
  Therefore, it is sometimes called "heat wave".
• It is a kind of light (electromagnetic wave) It
  can be transmitted through vacuum.
• There is a correlation between infrared energy
  and temperature of an object. Therefore, it can
  be used to measure the temperature of an object

5
IR transmission

• Major transmission window
• Near, mid, far-infrared ranges

6
Infrared Thermography

• Definition
• Infrared thermography is equipment or method,
  which detects infrared energy emitted from
  object, converts it to temperature, and displays
  image of temperature distribution.

http//www.x20.org/thermal/
7
Characteristics of infrared thermography
equipment

• It captures as a temperature distribution on a
  surface and it can display as a visible
  information.
• Temperature can be measured from a distance
  without contacting an object.
• Temperature can be measured in real time.

8
Merits of infrared thermography equipment

• Relative comparison of distribution of surface
  temperature can be made over a wide area.
• Temperature can be measured easily for a moving
  object or an object which is dangerous to get
  close to.
• Temperature of small object can be measured
  without confusing the temperature.
• Temperature of an object with drastic temperature
  change or a phenomenon during a short period of
  time can be measured.

http//www.avio.co.jp/english/products/tvs/what_th
ermo/index.htm
9
Principle of measurement by infrared thermography
equipment
http//www.avio.co.jp/english/products/tvs/what_th
ermo/index.htm
10
Image Format of Infrared Thermography

• Arrangement of detector and image data of
  Infrared Thermography

http//www.avio.co.jp/english/products/tvs/what_th
ermo/index.htm
11
Temperature distribution image data

• Temperature distribution
• -matrix of pixels (number of detector for
  example, 320 horizontal X 240 vertical pixels)
• - thermal image data can be transferred to
  PC.
• - the data can be calculated and utilized
  freely.
• - thermal image data is colored up pixel by
  pixel based on temperature

12
Infrared Imagery

• Thermal infrared (IR) imagery is imagery that
  shows heat.
• -It is often in the form of a grayscale picture
  whose scales (shades of gray) indicate the
  differences in temperature and emissivity of
  objects in the image.
• -Objects in the image that look lighter are
  colder and those that look darker are warmer.

13
http//www.meto.gov.uk/satpics/disk_eur.html
Example of IR imagery

• This image is updated every 6 hours and comes
  from a satellite positioned 36,000 kilometer
  above the Equator.
• The infrared image shows cold areas in white and
  warm areas in black, and the cool clouds can be
  seen clearly against the darker oceans and land.

14
Application of the IR (gas detection)

• Strong absorption band beyond 5 micron such as a
  pollutant NOx,Sox
• InSb/InAlSb LED
• Detector similar structure to LED

15
Application of the IR
16
Military application

• Primary and secondary mirrors focus energy
  through a reticule onto an IR sensing cell.
• A spinning reticule pattern rotates around the
  optical axis of the seeker

• Diagram of IR-guided missile

http//www.deastore.com/pdf/artech/1580536867.pdf
17
IR seeker

• A spinning reticule pattern rotates around the
  optical axis of the seeker.
• Seek can sense the direction to the target from
  the timing of the square wave portion of
  waveform.

http//www.deastore.com/pdf/artech/1580536867.pdf
18
Infrared countermeasures (1)

• Principal countermeasure against an IR-guided
  missile has been a high temperature flare ejected
  from an aircraft to break the lock of current
  types of missile.
• Missile will home on the flare.
• Flare radiates significantly more IR energy

http//www.deastore.com/pdf/artech/1580536867.pdf
19
Infrared countermeasures (2)

• IR jammer generate IR signal which attack the
  guidance signals passed to the sensor in
  IR-guided weapons.
• IR laser generates a modulated high level jamming
  signals.

http//www.deastore.com/pdf/artech/1580536867.pdf
20
Conclusion

• We can use an infrared image and detector for an
  civilian and military application.
• Let do more research to make better device !

21
Reference

• http//www.deastore.com/pdf/artech/1580536867.pdf

http//www.avio.co.jp/english/products/tvs/what_th
ermo/index.htm
http//www.meto.gov.uk/satpics/disk_eur.html
http//www.x20.org/thermal/
