RECORD SET DELIVERABLE REQUIREMENTS

1
RECORD SET DELIVERABLE REQUIREMENTS

• SMOOTH SAILING

2
WHAT ARE RECORD SET DOCUMENTS?

• VARIOUS MEDIA THAT REPRESENT THE DESIGN AND
  CONSTRUCTION PROGRESS OF A PARTICULAR PROJECT
• DOCUMENTS THAT MAY BE USED AS A BASIS FOR FUTURE
  CONSTRUCTION, AN AID IN SOLVING SITUATIONS
  PERTAINING TO WARRANTIES AND QUESTIONS OF
  METHODOLOGIES, LEGAL COMPLIANCES, AND A RESOURCE
  FOR HISTORICAL ARCHIVING
• THESE RECORD SUBMITTALS SIGNIFY THAT A PROJECT
  HAS BEEN SUBSTANTIALLY COMPLETED AND READY FOR
  FINANCIAL CLOSEOUT

YOU ARE A VITAL LINK AS A PARTNER WITH VANDERBILT
TO INSURE THAT THESE DOCUMENTS ARE SUBMITTED
SUCCESSFULLY.
3
WHAT DOCUMENTS DO I NEED TO SUBMIT?
4
WHAT FORMAT DO I USE TO SUCCESSFULLY SUBMIT
RECORD SET DOCUMENTS?

• PROJECT MANUALS OPERATION MAINTAINENCE
  MANUALS MUST BE IN A .PDF FORMAT HARD COPIES
  (CAMPUS SIDE ONLY)
• CAD FILES NEED TO BE IN AUTOCAD .DWG (ONLY FORMAT
  AVAILABLE FOR SUBMITTAL TO VANDERBILT UNIVERSITY
  MEDICAL SPACE AND FACILITIES PLANNING),
  MICROSTATION .DGN, OR AUTOCAD/MICROSTATION
  COMPATIBLE .DXF
• PLOT FILES FOR EACH CAD DRAWING SHALL BE IN
  EITHER HPGL/2 OR CAL FORMAT CONTAINING A FILE
  EXTENSION OF PLT, HPG, CAL, MIL, OR HPGL.
• HARDCOPY PRINTS OF PROJECT DRAWINGS. THE PRINT
  SIZE SHALL BE 18 X 24, NO MORE THAN 75 SHEETS
  PER BOUND BUNDLE, AND AT A SCALABLE REDUCTION
  THAT IS COMPATIBLE WITH AN ARCHITECTURAL OR
  ENGINEERING SCALE
• OPERATION MAINTAINANCE TRAINING SESSIONS ARE TO
  BE SUBMITTED IN DVD FORMAT

5
HOW SHOULD I NAME THESE DOCUMENTS?

• FOR COMMUNICATION, ARCHIVING AND SEARCH
  CAPABILITIES, IT IS EXTREMELY IMPORTANT THAT
  DOCUMENTS FOLLOW A STANDARDIZED NAMING CONVENTION

BLDG -ARCHITECT PROJECT - SPECIFIC INFO .
(FILE EXTENSION)
LETS SEE HOW THIS WORKS WITH EACH OF THE RECORD
SET DOCUMENTS
6
CAD FILE NAMING

• REMEMBER THE NAMING CONVENTION?

BLDG -ARCHITECT PROJECT - SPECIFIC INFO .
(FILE EXTENSION)
YOU WILL BE GIVEN A SHEET TODAY GIVING YOU THE
BUILDING NUMBERS, THE FIRM THAT YOU WORK FOR WILL
SUPPLY YOU WITH THE PROJECT NUMBER
SPECIFIC INFO PROJECT SECTION OR PHASE -
SHEET NOTE THAT THE SHEET SHOULD BE THE SAME
AS THE ARCHITECTURAL OR ENGINEERING SHEET THAT
YOU ARE DRAWING
FILE EXTENSION WILL BE .DWG, DGN OR DXF
7
YOUR CAD FOLDER SHOULD LOOK LIKE THIS
133 BUILDING (VANDERBILT UNIVERSITY
HOSPITAL) 20699 ARCHITECTS PROJECT A0.1,
A4.1, ECT ACTUAL DRAWING SHEET NUMBER .DWG
FILE EXTENSION
8
ONE LAST POINT ON CAD FILE NAMING CONVENTIONS

• IF THE PROJECT HAS A PHASE NUMBER,
• THAT NUMBER WILL BE INSERTED
• BEFORE THE SHEET NUMBER

133-20699-01-A0.1.DWG (THIS PROJECT HAS A PHASE
I)
133-20699-A0.1.DWG (THIS PROJECT DOES NOT HAVE
A PHASE
9
PLOT FILE NAMING

• REMEMBER THE NAMING CONVENTION?

BLDG -ARCHITECT PROJECT - SPECIFIC INFO .
(FILE EXTENSION)
YOU WILL BE GIVEN A SHEET TODAY GIVING YOU THE
BUILDING NUMBERS, THE FIRM THAT YOU WORK FOR WILL
SUPPLY YOU WITH THE PROJECT NUMBER
SPECIFIC INFO PROJECT SECTION OR PHASE -
SHEET NOTE THAT THE SHEET SHOULD BE THE SAME
AS THE ARCHITECTURAL OR ENGINEERING SHEET THAT
YOU ARE DRAWING
FILE EXTENSION WILL BE .PLT, HPG, .CAL, .MIL, OR
.HPGL
10
NOW FOR THE PDF FILES

• PROJECT OPERATION MANUALS ARE SUBMITTED IN .PDF
  FORMAT
• FILES ARE TO FOLLOWING THE NAMING CONVENTION OF
• BLDG -ARCHITECT PROJECT - SPECIFIC INFO .
  (FILE EXTENSION)

THE SPECIFIC INFORMATION THAT IS NEEDED IN THE
NAMING CONVENTION IS OM FOR OPERATIONS MANUAL
OR PM FOR PROJECT MANUAL. IF YOU ARE GIVEN A
BUILDING NUMBER OF 133 AND A PROJECT NUMBER OF
20699, THEN YOUR FILE NAMES WILL LOOK LIKE THIS
FOR A PROJECT MANUAL PDF FILE 133-20699-PM.PDF
(1 MULTIPAGE PDF FILE)
FOR AN OPERATIONS MAINTAINENCE MANUAL PDF
FILE 133-20699-OM.PDF (1 MULTIPAGE PDF FILE) THE
OM PDF FILE WILL NEED TO BE BOOKMARKED BY CSI
DIVISION.
11
NAMING HARD COPY PRINTS

• THE NAMING CONVENTION APPLIES TO THE 18 X 24
  HARD COPY PRINTS OF ALL DRAWINGS SUBMITTED YOU
  WILL NEED TO ADD 2 BITS OF INFORMATION RECORD
  SET and COSC DATE.
• THE NAMING CONVENTION RECORD SET COSC DATE
  WILL NEED TO BE INCLUDED IN THE TITLE BLOCK

12
FINAL DETAILS BEFORE ASSEMBLING THE RECORD SET
DOCUMENTS

• ALL CAD WORK SHOULD BE DRAWN AT 11 IN MODEL
  SPACE
• ALL XREFS SHOULD BE BOUND
• INCLUDE SOURCE DRAWINGS, REFERENCE DRAWINGS, FONT
  LIBRARIES, CUSTOM LINE SYTLES/CODES
• ALL CAD FILES IN ONE FOLDER
• ALL PLOT FILES IN ONE FOLDER
• THE PROJECT MANUAL (PDF) IN ONE FOLDER
• THE OPERATION MAINTAINANCE MANUAL (PDF) IN ONE
  FOLDER
• CHECK WITH LEAD ARCHITECT TO SEE IF THERE WAS AN
  OM TRAINING VIDEO TO INCLUDE IN THE RECORD
  DOCUMENTS

13
BURN THE FOUR FOLDERS TO ONE CD
THE INFORMATION NEEDED ON THE CD LABLE IS
RECORD SET, COSC DATE, PROJECT NAME, OFFICIAL
PROJECT , DISK NUMER
14
LETS RECAP HOW MANY COPIES THAT I NEED TO
ASSEMBLE
15
RECORD SET REVIEW

• ONCE THE RECORD SET DOCUMENTS REACH VANDERBILT,
  THEY WILL BE REVIEWED TO INSURE THAT THEY COMPLY
  WITH THE STANDARDS THAT HAVE BEEN PRESENTED
  TODAY. THE REVIEW PROCESS IS A YES OR NO
  DECISION FOR EACH FILE CRITERIA, HARD COPY
  SUBMITTAL, AND CORRECT NUMBER OF DOCUMENTS
  RECEIVED. A SUCCESSFUL REVIEW BENEFITS YOU BY
• IMPARTING A SENSE OF JOB WELL DONE
• SAVING COSTLY REWORKS. THE SAVINGS ARE IN BOTH
  TIME AND MATERIAL
• RELEASES FINAL MONIES TO YOUR FIRM
• POTENTIALLY SETS A RECORD OF RELIABILITY FOR
  FUTURE PROJECT PARTNERSHIPS

16
QUESTIONS ANSWERS

• ARE ZIP FILES OK TO SUBMIT?....NO, EACH FOLDERS
  SHOULD STAND ON THEIR OWN.
• SHOULD THE PLOT-TYPE FILES BE PRODUCED IN MODEL
  OR PAPER SPACE?.....PAPER SPACE AND IN THE LAYOUT
  THAT YOU WOULD USE FOR REGULAR HARDCOPY PLOTTING.
• WHERE DO YOU PUT THE FONT AND CUSTOM LINE
  FILES?....THEY WILL GO IN THE DWG FOLDER.
• DOES EACH DIGITAL DRAWING AND HARDCOPY PRINT HAVE
  TO HAVE RECORD SET COSC DATE?......YES
• DO XREFS NEED TO FOLLOW THE NAMING
  CONVENTION?....YES, HOWEVER, INSTEAD OF A SHEET
  NUMBER THERE WILL BE A DESIGNATION ON THE ORDER
  OF XBASE, XBORDER, ECT. BE SURE AND BIND ALL
  XREFS TO THEIR ASSOCIATED DRAWINGS.

17
MUSHROOM THEORY OF MANAGEMENT

• A PERFECT EXAMPLE OF POOR MANAGEMENT WAS THE
  PHILOSOPHY OF KEEP YOUR PEOPLE IN THE DARK, FEED
  THEM MANURE AND HOPE THEY GROW.MUSHROOM
  MANAGEMENT
• TODAY, ALL OF US MADE THE EFFORT TO RAISE THE BAR
  OF STANDARDS, OF TASK AWARENESS AND, MOST
  IMPORTANTLY, PROFESSIONAL COMMUNICATION
• AS CADD PROFESSIONALS, OUR WORLD IS ONE OF
  DETAIL, DESIGN, CREATIVITY, SPEED AND ACCURACY.
  THIS PRESENTATION WAS CONCEIVED FOR THIS
  PROFESSIONAL NICHE FOR ,THROUGH US , A FINAL
  PRODUCT IS DELIVERED

THANK YOU
