Customizing the Predictive Enterprise Browser
Dallas E. Sinnett Sales Engineer dsinnett_at_spss.com
[phone]
2
Customization

• Three options for thin-client customization
• Redeploying Predictive Enterprise Browser
• URL queries
• SPSS Tag Library

3
Option I Redeploying Predictive Enterprise
Browser

• Usage
• Minor modifications to Predictive Enterprise
  Browser
• Overriding default formatting, styles images
• Considerations
• Allows a single customization per server
• Requires basic HTML skills
• Is safer than manually swapping or editing
  deployed files

4
Quick Changes to PEB
C\Program Files\SPSSInc\Enterprise
Repository\components\peb\images
5
Or deploy a custom package
http//support.spss.com/Tech/.../Documentation/3.0
/CustomizingPEB.pdf (read the documentation 3
pages)
6
Example
7
Option II URL Queries

• Usage
• Placing repository content onto other web pages
• Accessing static objects or dynamic reports
• Considerations
• Easy means for embedding content elsewhere
• Provides control over design parameters
• Allows passing of parameters for dynamic reports
• Requires extra steps to obscure ID/PW values
• Requires basic HTML skills

8
Option II URL Queries

• Example

http//127.0.0.18080/peb/view/source_report.dbq?u
sernameadminpasswordspssproviderlocaldbuser_
Pubssadbpwd_Pubspasswordfragmenttrueoutputty
pehtml
9
Option III Java Tag Library

• Usage
• Placing repository content onto other web pages
• Enabling interactive reporting web pages
• Define source target variable parameters
• Sources are on-screen controls
• Targets are parameterized report objects
• Considerations
• Most powerful flexible customization option
• Allows passing of parameters for dynamic reports
• Requires intermediate to advanced JSP skills
• Support requires version 3.00.010

10
Something more elaborate - JSP
11
General Steps

• Create the pieces
• Reports
• Visualizations
• Pictures
• Documents
• Put them in the proper place
• Reports in the repository
• Images accessible to the web application
• Produce the JSP code
• Save to the web application
• View page in the browser

12
Setup Web Application Files

• WAR (Web Application aRchive) is a directory
  structure for Java web apps that contains XML
  files, tag libraries, resources and JSP files
• A WAR directory is setup for each web
  application.
• WAR file structure -
• The static HTML files and JSPs are generally
  stored in the top level directory.
• The Servlet and related Javatm technology class
  files must be stored in the WEB-INF/classes
  directory.
• Any auxiliary library JAR files must be stored in
  the WEB-INF/lib directory.
• The deployment descriptor is stored as a file
  named web.xml in the WEB-INF directory.

13
WAR Directory Notes

• Place all custom JSP pages in war directory
• jsp subdirectory contains system provided example
  JSP code
• resources subdirectory contain images to be
  displayed
• WEB-INF directory contains WEB.XML location of
  the tag directory.
• tlds subdirectory - A tag library is a file
  containing a list of custom tags to invoke custom
  actions in a JSP page..

14
SPSS Tag Library - credential
This tag provides a method for defining both a
data source login credential and a repository
login credential. The credential is referenced
by name for all reports and/or prompts defined on
the page.
15
SPSS Tag Library - report
This tag defines a report, DOM location,
activation and the source of any required
parameters (either prompts or other report
objects). The output type may be specified
however this may be overridden when this report
is the source for another reports parameters.
The appropriate rendering engine is chosen based
on the specified report definition and output
type. Tag Nesting This tag may include one
ltsourceLinkReport and/or multiple
ltsourceLinkPrompt tags.
16
SPSS Tag Library - report
17
SPSS Tag Library - report
18
SPSS Tag Library - documentation

• It is in the Predictive Enterprise Services
  documentation link on the support site.
• or
• http//support.spss.com/Tech/Products/Predictive2
  0Enterprise20Services/Documentation/3.0/TagLibRef
  erence.pdf

19
Processing Flow
20
Editing Report JSP HTML Section
Only sections of the JSP page that are usually
required to be edited for a new report are
discussed in the following slides.
21
Specifying Credentials (If not Provided, User is
prompted)
lt!--Begin Custom Edits Here--gt ltreporting-taglib
credential name"demo" provider"Native"
username"demo" password"user"
/gt ltreporting-taglibcredential name"SCSample80"
username"sa" password"password"
/gt ltreporting-taglibreport name"KPIProdProfit"
reportDefinitionURI"spsscr///?id7f0000014818f91
d0000011703e83ce38173" activate"ONLOAD"
outputType"text/html" repositoryCredentialName"d
emo" location"KPI01"gt lt/reporting-taglibreportgt
ltTABLE width"925" border"0" cellspacing"0"
cellpadding"0"gt ltTRgt ltTDgt ltiframe id"KPI01"
name"KPI01" scrolling"no" frameborder"0"
src"" height"260px" width"310px"gt lt/iframegt lt/T
Dgt lt/TRgt lt/TABLEgt lt!--End Custom Edits Here--gt

• Outline section contains tags from SPSS tag
  library.
• First credential is for PES logon (parameter in
  repositoryCredentialName SPSS tag). Will be
  accessed at execution in next section by name
  demo
• Second credential is for database access

22
Referencing PES Object URI for the Report To
Execute
lt!--Begin Custom Edits Here--gt ltreporting-taglib
credential name"demo" provider"Native"
username"demo" password"user"
/gt ltreporting-taglibcredential name"SCSample80"
username"sa" password"password"
/gt ltreporting-taglibreport name"KPIProdProfit"
reportDefinitionURI"spsscr///?id7f0000014818f91
d0000011703e83ce38173" activate"ONLOAD"
outputType"text/html" repositoryCredentialName"d
emo" location"KPI01"gt lt/reporting-taglibreportgt
ltTABLE width"925" border"0" cellspacing"0"
cellpadding"0"gt ltTRgt ltTDgt ltiframe id"KPI01"
name"KPI01" scrolling"no" frameborder"0"
src"" height"260px" width"310px"gt lt/iframegt lt/T
Dgt lt/TRgt lt/TABLEgt lt!--End Custom Edits Here--gt
Outline section uses reporting tags from the SPSS
library. Unique Object URI id must be entered
23
Obtaining Object URI

• Logon to PES Content Explorer
• Select Report
• Right Click

• Copy Paste Object URI to JSP page

24
Setting up Internal Reference Nameto Link Report
to Page Layout Section
lt!--Begin Custom Edits Here--gt ltreporting-taglib
credential name"demo" provider"Native"
username"demo" password"user"
/gt ltreporting-taglibcredential name"SCSample80"
username"sa" password"password"
/gt ltreporting-taglibreport name"KPIProdProfit"
reportDefinitionURI"spsscr///?id7f0000014818f91
d0000011703e83ce38173" activate"ONLOAD"
outputType"text/html" repositoryCredentialName"d
emo" location"KPI01"gt lt/reporting-taglibreportgt
ltTABLE width"925" border"0" cellspacing"0"
cellpadding"0"gt ltTRgt ltTDgt ltiframe id"KPI01"
name"KPI01" scrolling"no" frameborder"0"
src"" height"260px" width"310px"gt lt/iframegt lt/T
Dgt lt/TRgt lt/TABLEgt lt!--End Custom Edits Here--gt
Outline section contains reporting tag from SPSS
tag library. KPI01 is an user assigned name to be
used in Table layout section.
25
HTML Layout
lt!--Begin Custom Edits Here--gt ltreporting-taglibc
redential name"demo" provider"Native"
username"demo" password"user"
/gt ltreporting-taglibcredential name"SCSample80"
username"sa" password"password"
/gt ltreporting-taglibreport name"KPIProdProfit"
reportDefinitionURI"spsscr///?id7f0000014818f91
d0000011703e83ce38173" activate"ONLOAD"
outputType"text/html" repositoryCredentialName"d
emo" location"KPI01"gt lt/reporting-taglibreportgt
ltTABLE width"925" border"0" cellspacing"0"
cellpadding"0"gt ltTRgt ltTDgt ltiframe id"KPI01"
name"KPI01" scrolling"no" frameborder"0"
src"" height"260px" width"310px"gt lt/iframegt lt/T
Dgt lt/TRgt lt/TABLEgt lt!--End Custom Edits Here--gt
This section is used to place report output on a
page. For this report, Table HTML tag is used to
allow multiple report graphs to place on a page
(only one report is created in this example)
26
For Example
27
Link Reports Tags Passing Values to Another
Report
28
SPSS Tag Library - sourceLinkReport
This tag will identify the source report and
variables that will be used to satisfy this
reports defined parameters. Tag Nesting This tag
will contain 1..n ltsourceLinkVariable tags that
will identify the source column and the target
parameter names.
29
SPSS Tag Library - sourceLinkReport
30
SPSS Tag Library - sourceLinkVariable
This tag will define the source column and the
target parameter.
31
Example sourceLinkReport, sourceLinkVariable
ltreporting-taglibreport name"QTD Sales Rep
Summary" reportDefinitionURI"spsscr///?id7f00
0001d6485ae800000116f95839e681b5"
activate"ONDEMAND" outputType"text/html"
repositoryCredentialName"demo"
location"SalesRep"gt
ltreporting-taglibsourceLinkReport
sourceReportName"QTD Sales Summary Chart" gt
ltreporting-taglibsourceLinkVariable
columnName"Country"
targetNameParameter"COUNTRYDESC"gt
lt/reporting-taglibsourceLinkVariablegt
lt/reporting-taglibsourceLinkReportgt lt/reporti
ng-taglibreportgt
32
Summary Steps for Creating Interactive Reports

• Create a new Web application if needed.
• Save any new images into resource subdirectories.
• Create Reports/queries and publish to PES.
• Embedded HTML
• Update any references to images
• Update on-click Query URIs
• Create JSP file and save to Web application
• Edit userids / passwords if needed.
• Edit each dashboard report URI.
• Edit HTML for layout changes if necessary.

33
