GRAPHS AND GRAPH TRAVERSALS 9/26/2000

1
GRAPHS AND GRAPH TRAVERSALS 9/26/2000
COMP 6/4030 ALGORITHMS
2
Graphs - Traversals

• Task visit all nodes of a (connected) graph G,
  starting from a given node.
• Equivalent formulation of this task Find a
  spanning tree T of graph G starting from a given
  node.
• Definition
• Spanning Tree T of G(V,E)
• T is a tree that contains all vertices of G
  T(VT,ET)
• VTV ET lt E.

3

• Figure 1
• Figure 2

4
Two Main Algorithms

• Depth-First Search (DFS)
• Continue exploration along a path as long as one
  can continue by adding edges one by one, until on
  reaches a node already discovered. Then,
  backtrack and start a new path.
• Breadth-First Search (BFS)
• Starting from a node, go in all possible
  directions to nodes 1 edge away. Then, go one
  step from each of the newly discovered nodes and
  repeat until there are no new nodes to discover.

5

• Figure 3 (DFS diagram)
• Figure 4 (BFS diagram)

6
The N-Queens Problem

• Figure 5

7

• Choose initial vertex (root of DFS tree). Label
  it O and push incident edges onto stack. Set
  counter c1
• Repeat until (stack empty). Take edge xy on top
  of stack and explore
• if y has no label yet
• assign it label c increment c
• push all incident edges yz on
  stack
• make xy a tree-edge
• else
• just pop xy off stack (a
  back-edge, going to ancestores,
  ends of tree-edges)



8
Analysis

• Invariant Top stack vertex x always has a no.
  already. No back-edge can go to a non ancestor
  (else would have been explored earlier from
  another direction, would be a tree edge).
• O( E V )
• Because
• o Each edge is stacked once at most in
  each direction
• o Each vertex requires a constant amount
  of processing.

9
Depth_First Search (DFS). Example

• Figure 6

10
Algorithm 4.2.1 Depth-First Search

• Input a connected graph G and a starting vertex
  v
• Output a depth-first spanning tree T and a
  standard vertex- labeling of G
• Initialize tree T as vertex v
• Initialize the set of frontier edges for tree T
  as empty
• Set dfnumber(v) 0
• Initialize label counter I 1
• While tree T does not yet span G
• Update the set of frontier edges for T.
• Let e be a frontier edge for T whose labeled

11
Algorithm 4.2.1 contd

• endpoints has the largest possible
  dfnumber.
• Let w be the unlabeled endpoint of edge e.
• Add edge e (and vertex w) to tree T.
• Set dfnumber(w) i.
• i i 1.
• Return tree T with its dfnumbers.
• Notation For the standard vertex-labeling
  generated during the depth-first search, the
  integer-label assigned to a vertex w is denoted
  df number (w).

12
Algorithm 4.2.2 Depth-First Search (Stack
Implementation)

• Input a connected graph G and a starting vertex
  v
• Output a depth-first spanning tree T and a
  standard vertex- labeling of G
• Initialize tree T as vertex v
• Initialize the set of frontier edges for tree T
  as empty
• Set dfnumber(v) 0
• Initialize label counter I 1
• While tree T does not yet span G
• Push onto the stack every frontier edges
• whose labeled endpoint has df number i -
  1.
• Pop the top edge from the stack and call
  it e

13
Algorithm 4.2.2 contd

• While edge e is not a frontier edge
• Pop next edge from the stack and call it
  e
• Let w be the unlabeled endpoint of e
• Add edge e (and vertex w) to tree T
• Set df number(w) I
• I I 1
• Return tree T with its dfnumbers.

14
Algorithm 7.3 DFS Skeleton

• Input Array adjVertices of adjacency lists that
  represent a directed graph G (V,E), as
  described in Section 7.2.3, and n, the number of
  vertices. The array is defined for indexes 1.n.
  Other parameters are as needed bye the
  application.
• Output Return value depends on the application.
  Return type can vary int is just an example
• Remarks This skeleton is also adequate for some
  undirected graph problems that ignore nontree
  edges, but see algorithm 7.8. Color meanings are
  white undiscovered, gray active, black
  finished.

15

• Int dfsSweep(IntList adjVertices, int n, )
• int ans
• Allocate color arrya and initialize to white
• For each vertex v of G, in some order
• if (colorv white)
• int vAns dfs(adjVertices, color, v,
  )
• (Process vAns)
• //Continue loop
• return ans

16

• Int dfs(IntList adjVertices, int color, int
  v, )
• int w
• intList remAdj
• int ans
• colorv gray
• Preorder processing of vertix v
• remAdj adjVerticesv
• while (remAdj ! nil)
• w first(remAdj)
• if (colorw white)
• Exploratory processing for tree edge
  vw

17

• int wAns dfs(adjVertices, color, w,
  )
• Backtrack processing for tree edge vw, using
  wAns
• else
• Checking (I.e., processing ) for nontree edge
  vw
• remAdj rest(remAdj)
• Postorder processing of vertex v, including final
  computation
• colorv black
• return ans

18
Algorithm 4.2.3 Breadth-First Search

• Input a connected graph G and a starting vertex
  v
• Output a breadth-first spanning tree T and a
  standard vertex- labeling of G
• Initialize tree T as vertex v
• Initialize the set of frontier edges for tree T
  as empty
• Write label counter i 1
• Initialize label counter i 1
• While tree T does not yet span G
• Update the set of frontier edges for T.
• Let e be a frontier edge for T whose labeled
  (contd)

19
Algorithm 4.2.3 contd

• endpoints has the largest possible
  dfnumber.
• Let w be the unlabeled endpoint of edge e.
• Add edge e (and vertex w) to tree T.
• Write label I on vertex w.
• i i 1.
• Return tree T with its dfnumbers.

20
Algorithm 4.2.4 Breadth-First Search (queue
Implementation)

• Input a connected graph G
• Output a breadth-first spanning tree T and a
  standard vertex- labeling of G
• Initialize tree T as vertex v
• Initialize the set of frontier edges for tree T
  as empty
• Write label 0 on vertex v
• Initialize label counter i 1
• While tree T does not yet span G
• Enqueue (to the back of queue) every frontier
  edge
• whose labeled endpoint is i - 1.
• Dequeue an edge from the front of queue and
  call it e

21
Algorithm 4.2.4 contd

• While edge e is not a frontier edge
• Dequeue next edge and call it e
• Let w be the unlabeled endpoint of e
• Add edge e (and vertex w) to tree T
• Write label I on vertex w
• i i 1
• Return tree T with its dfnumbers.
• Notation Whereas the stack (Last-In-First-Out)
  is the appropriate data structure to store the
  frontier edges in a DFS, the queue
  (First-In-First-Out) is most appropriate for the
  BFS, since the frontier edges that arise earliest
  are given the highest priority.

22
Example 7.7 Breadth-first Search

• Lets see how breadth-first search works,
  starting from vertex A in the same graph as we
  used in Example 7.6. Instead of Terry the
  tourist, a busload of tourists start walking at A
  in the left diagram. They spread out and explore
  in all directions permitted by edges leaving A,
  looking for bargains. (We still think of edges
  as one-way bridges, but now they are one-way for
  walking, as well as traffic.)
• Figure 8
