Modules and Processes in SystemC

1
Modules and Processes in SystemC

• A Presentation by
• Najmeh Fakhraie
• Mozhgan Nazarian-Naeini
• Hardware-Software Codesign
• Spring 2006

SystemC
2
The Nightmares of Citation
SystemC
3
References

• An Introduction to SystemC 1.0 Bernard
  Niemann, Fraunhoffer Institute for Integrated
  Circuits
• SystemC Tutorial John Moondanos, Strategic CAD
  labs, Intel Corp. GSRC Visiting Fellow, UC
  Berkeley
• SystemC 2.0.1 Language Reference Manual
• SystemC Tutorial Anonymous Author
• Compositional Approach to SystemC Design
  Semantics of SystemC R.K Shyamasundar, IBM
  Research Lab
• Doulos SystemC Tutorial
• The NEW YORKER Cartoon Bank

SystemC
4
Modules in SystemC

• A module is the basic structural building block
  in SystemC. Modules may contain
• Ports
• Data Members
• Channel
• Processes
• Member functions not registered as processes
• Instances of other modules
• A new type of module is created by deriving from
  the container class sc_module
• Publicly deriving from class sc_module.
• Or alternatively, a module can be created with
  use of the SC_MODULE macro.

SystemC
5
Modules in SystemC

• An example for the former would be
• And an example for the latter

class my_module public sc_module ....
SC_MODULE(my_module) ....
SystemC
6
Module Constructor

• Every module can have a module constructor
• Accepts one argument which is the module name
• Will be thoroughly explained in the upcoming
  sections

7
Modules Instantiation

• Instantiation develops hierarchy through out the
  design
• Declaration
• SC_MODULE(ex2)
• . . .
• ex1 ex1_instance
• SC_CTOR(ex2) ex1_instance(ex1_anyname)
• //body

SystemC
8
Modules Instantiation

• Pointer
• SC_MODULE(ex2)
• . . .
• ex1 ex1_instance
• SC_CTOR(ex2)
• ex1_instance new ex1(ex1_anyname)
• //body

SystemC
9
Module Destructor

SC_MODULE(ex2) ex2() delete
ex1_instance
SystemC
10
Processes in SystemC

• An argument that begs the question
• Processes are small pieces of code that run
  concurrently with other processes.
• All high-level system level design (SLD) tools
  use an underlying model of a network of
  processes.
• Functionality is described in processes.
  Processes must be contained within a module.
• They are registered as processes with the SystemC
  kernel, using a process declaration in the module
  constructor.
• Processes accept no arguments and produce no
  output

SystemC
11
XOR Using Four NAND Gates
SystemC
12
Step One Modeling the NAND Gate

• A NAND Gate is a combination circuit. Its output
  is purely a function of its input.
• Use the simplest kind of SystemC process to model
  it SC_METHOD.
• SC_METHODs are simply C functions. Therefore,
  the SystemC class library must make them behave
  like processes, in particular
• The SystemC class library contains a simulation
  kernel a piece of code that models the passing
  of time, and calls functions to calculate their
  outputs whenever their inputs change.
• The function must be declared an SC_METHOD and
  made sensitive to its inputs.

SystemC
13
NAND Gate

include "systemc.h" SC_MODULE(nand2)
//declare nand2 sc_module sc_inltboolgt A,
B //input signal ports sc_outltboolgt
F //output signal ports void
do_nand2() //a C function
F.write( !(A.read() B.read()) )
SC_CTOR(nand2) SC_METHOD(do_nand2)
//register do_nand2 with kernel
sensitive ltlt A ltlt B //sensitivity
list
SystemC
14
What just happened?

• SC_MODULE
• Hierarchy in SystemC is created by using a class
  sc_module. sc_module may be used directly, or may
  be hidden using the macro SC_MODULE. The
  example SC_MODULE above creates an sc_module
  class object called nand2.
• Ports
• SystemC numerous predefined ports such as
  sc_inltgt, sc_outltgt, sc_inoutltgt. The language also
  allows the definition of user defined ports
  through the use of the sc_portltgt class.

sc_portltsc_signal_in_ifltboolgt, 1gt clk
SystemC
15
The NAND Function

• do_nand2
• The function that does the work is declared. The
  input and output ports include methods read( )
  and write( ) to allow reading and writing to the
  ports. A and B are read, the NAND function is
  calculated and the result is written to F using
  the write( ) method.
• We could get away without writing the read( ) and
  write( ) methods by using operators F !( A
  B)

SystemC
16
Constructor for sc_module Instance nand2

• SystemC provides a shorthand way of writing the
  constructor using a macro SC_CTOR. This
  constructor does the following
• Create hierarchy (none in this case)
• Register functions as processes with the
  simulation kernel
• Declare sensitivity list for processes
• Accepts one argument only, which is the module
  name
• In this example, the constructor declares that
  do_nand2 is an SC_METHOD, and says that any event
  on ports A and B must make the kernel run the
  function (calculate a new value for F).

SystemC
17
XOR Gate

include "systemc.h" inclue "nand2.h" SC_MODULE(
xor2) sc_inltboolgt A, B sc_outltboolgt F
nand2 n1, n2, n3, n4 sc_signalltboolgt S1, S2,
S3 SC_CTOR(xor2) n1("N1"), n2("N2"),
n3("N3"), n4("N4") n1.A(A) n1.B(B)
n1.F(S1)
SystemC
18
XOR Gate (continued)

n2 ltlt A ltlt S1 ltlt S2 n3(S1) n3(B)
n3(S3) n4.A(S2) n4.B(S3)
n4.F(F)
SystemC
19
What just Happened II?

• Header Files
• Note the inclusion of nand2.h. This allows access
  to the module containing the NAND gate.
• Ports
• It is permitted to reuse the names A, B and F as
  this a different level of the hierarchy.
• Declaring Intermediate Wires
• They are declared using sc_signal. sc_signal is a
  class with a template parameter specifying the
  type of data the signal can hold bool in this
  example. It is a primitive, built-in channel with
  the SystemC library.

SystemC
20
XOR Constructor

• Must have four instances of nand2. After the
  port declarations, they are declared. And a label
  must be declared for each instance.
• The four labels, N1, N2, N3 and N4 are passed to
  the constructors of the instances of nand2 by
  using an initializer list on the constructor of
  xor2.
• Lastly, the ports are wired up. This can be done
  using parentheses () or ltlt and gtgt.
• Using ltlt and gtgt only allows the ports and
  signals to be listed by position (n2).
• Using () allows either by position (n3) or by
  name (n1 and n4).

SystemC
21
More on Modules

• They map functionality of HW/SW blocks
• The basic building block of every system
• Can contain a whole hierarchy of sub-modules and
  provide private variable/signals.
• Modules can interface to each other via
  ports/interfaces/channels
• Module functionality is achieved by means of
  processes

SystemC
22
Module Hierarchy

SystemC
23
Ports, Interfaces, Channels

• Data transmitted and held via channels
• Interfaces provide the operations that the
  channel provides
• Ports standardize interaction of modules with
  the external world
• At elaboration time, ports are BOUNDED to
  channels via interfaces

SystemC
24
Interfaces

• An interface consists of a set of operations
  (their prototype), not of their implementation
  which is a burden on the channels.
• There are two basic interfaces derived from
  sc_interface class
• sc_signal_in_ifltTgt
• provides a virtual functional read( ) returning
  a reference to T
• sc_signal_inout_ifltTgt
• provides a virtual functional write( ) taking a
  reference to T
• an out interface is identical to an inout
  interface

SystemC
25
Ports

• They provide communication functions to modules
• Derived from SystemC class sc_portltgt
• On the outside, they connect to channels by
  means of interfaces
• Typical channel (in RTL mode) sc_signal
• Specialized classes were derived sc_inltclass
  Tgt, sc_outltclass Tgt, sc_inoutltclassTgt, which are
  ports connected to N 1 interfaces of type
  sc_signal_in_ifltclass Tgt
• The interface sc_signal_in_ifltgt defines the
  restricted set of available messages that can be
  send to the port clk. For instance, the
  functions read() or default_event() are defined
  by this class.

SystemC
26
Channels

• SystemCs communication medium
• This feature of SystemC differentiates it from
  other HDLs such as Verilog
• Provides abstraction at the interface level of
  components and thus achieves greater design
  modeling flexibilities
• By definition, modules are interconnected via
  channels and ports.
• In turn, channels and ports communication via a
  common interface
• Implementation of interfaces functions

SystemC
27
Channels

• Communication among modules and among processes
  within a module
• Any channel must
• be derived from sc_channel class
• be derived from one or more classes derived from
  sc_interface
• provide implementations for all pure virtual
  functions defined in its parents interfaces

SystemC
28
Fifo Example

SystemC
29
FIFO Declaration of Interfaces

class write_if public sc_interface public
virtual void write(char) 0 virtual void
reset() 0 class read_if public
sc_interface public virtual void
read(char) 0 virtual int num_available()
0
SystemC
30
FIFO Declaration of Channel

void write(char c) if (fifo_full())
wait(read_event) data ltyou calculategt c
num_elements write_event.notify() void
read(char c) if (fifo_empty())
wait(write_event) c datafirst
--num_elements first ...
read_event.notify()
class fifo public sc_channel, public
write_if, public read_if private int
max_elements10 char datamax_elements
int num_elements, first sc_event
write_event, read_event bool
fifo_empty() bool fifo_full()
public fifo() num_elements(0),
first(0)
SystemC
31
FIFO Declaration of Channel
void reset() num_elements first
0 int num_available() return
num_elements // end of class
declarations

SystemC
32
FIFO Producer Consumer
SC_MODULE(producer) public
sc_portltwrite_ifgt out SC_CTOR(producer)
SC_THREAD(main) void main()
char c while (true)
out.write(c) if() out.reset()

SC_MODULE(consumer) public
sc_portltread_ifgt in SC_CTOR(consumer)
SC_THREAD(main) void main()
char c while (true)
in.read(c) coutltlt in.num_available()

SystemC
33
FIFO Completed

SC_MODULE(top) public fifo afifo
producer pproducer consumer pconsumer
SC_CTOR(top) pproducernew
producer(Producer) pproducer-gtout(afifo)
pconsumernew consumer(Consumer)
pconsumer-gtin(afifo)
SystemC
34
More on Processes

• They provide module functionality
• Implemented as member functions of the module
  and declared to be SystemC process in SC_CTOR
• Three kinds of process available
• SC_METHOD
• SC_THREAD
• SC_CTHREAD
• These macros are needed because a member
  function is not necessarily a process. The macros
  operate specifics registrations with the
  scheduler
• All these processes in the design run
  concurrently
• Code inside of each process is sequential

SystemC
35
SC_METHOD

• Sensitive to any changes on input ports (i.e.,
  it is sensitive to a set of signals, on its
  sensitivity list. It can be sensitive to any
  change on a signal e.g., the positive or
  negative edge of a Boolean signal).
• Usually used to model purely combinational logic
  (i.e., NORs, NANDs, MUX)
• Cannot be suspended. All the function code is
  executed every time the SC_METHOD is invoked
  (whenever any of the inputs it is sensitive to
  change).
• Instructions are executed in order.
• Does not remember internal state among
  invocations (unless explicitly kept in member
  variables)

SystemC
36
Defining the Sensitivity List of a Process

• sensitive with the ( ) operator
• Takes a single port or signal as argument
• sensitive(sig1) sensitive(sig2)
  sensitive(sig3)
• sensitive with the stream notation
• Takes an arbitrary number of arguments
• sensitive ltlt sig1 ltlt sig2 ltlt sig3
• sensitive_pos with either ( ) or ltlt operator
• Defines sensitivity to positive edge of Boolean
  signal or clock
• sensitive_pos ltlt clk
• sensitive_neg with either ( ) or ltlt operator
• Defines sensitivity to negative edge of Boolean
  signal or clock
• sensitive_neg ltlt clk

SystemC
37
SC_THREAD

• Still has a sensitivity list and may be
  sensitive to any change on a signal.
• It is reactivated whenever any of the inputs it
  is sensitive to changes. Once it is reactivated
• Instructions are executed infinitely fast (in
  terms of internal simulation time) until the next
  occurrence of a wait( ) statement.
• Instructions are executed in order.
• The next time the process is reactivated, the
  execution will continue after the wait( )
  statement.
• wait( ) suspends execution of the process until
  the process is invoked again

SystemC
38
SC_THREAD

• Akin to a Verilog initial block
• Executes only once during simulation and then
  suspends
• Designers commonly use an infinite loop inside
  an SC_THREAD to prevent it from ever exiting
  before the end of the simulation
• Adds the ability to be suspended to SC_METHOD
  processes by means of wait() calls (and
  derivatives)
• Remembers its internal state among invocations
  (i.e., execution resumes from where it was left)
• Very useful for clocked systems, memory
  elements, multi-cycle behavior

SystemC
39
An Example of SC_THREAD

void do_count() while(true)
if(reset) value 0 else if (count)
value q.write(value)
wait()
SystemC
40
Thread Processes wait( ) Function

• wait( ) may be used in both SC_THREAD and
  SC_CTHREAD processes but not in SC_METHOD process
  block
• wait( ) suspends execution of the process until
  the process is invoked again
• wait(ltpos_intgt) may be used to wait for a
  certain number of cycles (SC_CTHREAD only)
• In Synchronous process (SC_CTHREAD)
• Statements before the wait( ) are executed in
  one cycle
• Statements after the wait( ) executed in the
  next cycle
• In Asynchronous process (SC_THREAD)
• Statements before the wait( ) are executed in
  the last event
• Statements after the wait( ) are executed in the
  next event

SystemC
41
Another Example

SC_MODULE(my_module) sc_inltboolgt id
sc_inltboolgt clock sc_inltsc_uintlt3gt gt in_a
sc_inltsc_uintlt3gt gt in_b sc_outltsc_uintlt3gt gt
out_c void my_thread() SC_CTOR(my_module)
SC_THREAD(my_thread) sensitive ltlt
clock.pos()
//my_module.cpp void my_module my_thread()
while(true) if (id.read())
out_c.write(in_a.read()) else
out_c.write(in_b.read()) wait()
SystemC
42
SC_CTHREAD

• Will be deprecated in future releases
• Almost identical to SC_THREAD, but implements
  clocked threads
• Sensitive only to one edge of one and only one
  clock
• It is not triggered if inputs other than the
  clock change
• Models the behavior of unregistered inputs and
  registered outputs
• Useful for high level simulations, where the
  clock is used as the only synchronization device
• Adds wait_until( ) and watching( ) semantics for
  easy deployment

SystemC
43
SC_CTHREAD

• Once invoked
• The statements execute until a wait( ) statement
  is encountered.
• At the wait( ) statement, the process execution
  is suspended
• At the next execution, process execution starts
  from the statement after the wait( ) statement
• Local variables defined in the process function
  are saved each time the process is suspended

SystemC
44
Counter in SystemC

SystemC
45
Counter in SystemC
SC_MODULE(countsub) sc_inltdoublegt in1
sc_inltdoublegt in2 sc_outltdoublegt sum
sc_outltdoublegt diff sc_inltboolgt clk void
addsub() //Constructor SC_CTOR(addsub)
//Declare addsub as SC_METHOD
SC_METHOD(addsub) dont_intialize()
//make it sensitive to positive clock
sensitive_pos ltlt clk

//Definition of addsub method void
countsubaddsub() double a double b a
in1.read() b in2.read()
sum.write(ab) diff.write(a-b)
SystemC
46
The End

SystemC
