Title: Object Design Principles II


1
Object Design Principles II
  • Elizabeth Bigelow
  • School of Computer Science
  • Carnegie Mellon University

2
Exam
  • Will not contain Chapter 12 or Chapter 13
  • Will primarily test fluency
  • Some interpretation questions
  • Mostly modeling questions
  • Will be long

3
Packages and DeploymentDiagrams
  • Packages used to simplify diagrams
  • Dependencies are most common association between
    packagesused for analysis for where they can be
    reduced or where changes should be made
  • Many people use packages for components in
    deployment diagrams
  • Note that all contents should be within a node
    on a deployment diagram. Packages allow you to do
    this

4
Basic Design Questions
  • How can we measure connascence (or cohesion)?
  • What makes a class good in this respect
  • In order to answer this, well have to cover some
    more theory that looks abstruse at first glance
  • A little practice with the terminology and
    principles will show that it has practical basis
    and is intuitive (but not at first!)

5
Golden Rules of Object (or most any other design)
  • Minimize coupling
  • Increase cohesion

6
so what anyhow?
  • Increase in maintainability, understandability
  • robustness (I.e., avoiding crash burn)
  • general principles which allow you to decide how
    to set up a class hierarchy and eventually give
    trade-offs for component and class design
  • remember theoretically you can set up a
    hierarchy any way that you want and put
    operations wherever you want--but you lose the
    value of object languages and design if youre
    too random

7
Examples
  • Dogs and Owners
  • Which design is best and why?
  • Geometric Library
  • What could go wrong when you invoke operations?

8
Domains
  • Domain used slightly differently here--groups of
    classes
  • Foundation, Architecture, Business, Application

9
Foundation
  • useful across all businesses and architectures
  • (semantic,structural, fundamental)
  • Date,Time, Angle, Money
  • Stack, Queue, BinaryTree, Set
  • Integer, Boolean, Char
  • Dont do these at home!

10
Architecture
  • Classes valuable for one implementation
    architecture
  • Human-interface classes (Window, CommandButton)
  • Database-manipulation classes (Transaction,
    Backup)
  • Machine-communication classes (Port,
    RemoteMachine)

11
Business Classes
  • Useful for one industry or company
  • Relationship classes (AccountOwnership for bank,
    Patient Supervision for hospital nurse)
  • Role classes (Customer, Patient)
  • Attribute classes (properties of things--Balance,
    BodyTemperature)

12
Application
  • Classes valuable for one application
  • Event recognizer classes (event daemons,
    PatientTemperatureMonitor)
  • Event manager classes (carry out business
    policy--WarmHypothermicPatient)

13
Where do we get classes for each domain
  • Foundation -buy
  • Architectural--buy from vendors of hardware or
    software infrastructure--need tailoring for
    compatibility with foundation classes
  • Business--usually have to build changing a bit
    with movement to components
  • Application--almost always have to build

14
Encumbrance
  • Measure of how far a class sits above the
    fundamental domain
  • Encumbrance measures total ancillary machinery of
    a class (i.e.--other classes on which it must
    relying order to work
  • Direct class-reference set of a class C is the
    set of classes to which C refers directly

15
Encumbrance, Continued
  • If direct class reference set of C is C1, C2, C3,
    Indirect-class reference set of C is the union of
    the direct class-reference set of C and the
    indirect class reference sets of C1, C2, CN
  • Direct encumbrance of a class is the size of its
    direct class-reference set. The indirect
    encumbrance of a class is the size of its
    indirect class reference set

16
More Intuitively (-) )
C
C
C1
C2
C3
C1
C2
C3
Direct Class Reference Set Encumbrance 3
c21
c22
c11
c12
c31
c32
F1 F2 F3 F4 F5
Indirect Class Reference Set Encumbrance 13
17
Concrete Example
Rectangle 4
Point 3
Length 2
Boolean 0
Real 0
Numbers are indirect encumbrance
18
Use of encumbrance
  • Measure of class sophistication--how high the
    class is above the fundamental domain
  • Classes in higher domains have high indirect
    encumbrance and those in lower, low indirect
    encumbrance
  • Unexpected indirect encumbrance may indicate
    fault in class design--high indirect encumbrance
    in a low domain, there may be a fault in class
    cohesion
  • If class in high domain has low indirect
    encumbrance, probably designed from scratch
    rather than reusing intermediate classes from
    library

19
Law of Demeter
  • Strong law--variable can only be a variable
    defined in a class itself
  • Weak law --defines variable as being either a
    variable of the class or one it inherits from its
    superclass

20
Formal Law of Demeter
  • For an object obj of class C and for any
    operation op defined for obj, each target of a
    message within the implementation of op must be
    one of the following objects
  • the object itself
  • object referred to by an argument within ops
    signature
  • object referred to by a variable of obj
    (including any object within collections referred
    to by obj)
  • an object created by op
  • an object referred to by a global variable

21
So what?
  • Frees designer of Cs superclasses to redesign
    their internal implementation
  • Enhances understandability of C, because someone
    trying to understand the design of C isnt
    continually dragged into the implementation
    details of Cs superclasses or those of a
    completely unrelated class
  • Minimizes connascence across encapsulation
    boundaries

22
Class cohesion
  • Class cohesion is the measure of how well the
    features of the class (operatiions and
    attributes) belong together in a single class
  • Mixed-instance class cohesion has elements that
    are undefined for some objects instantianated
    from the class.
  • Mixed-domain class cohesion has element that
    refers to an extrinsic class belonging to a
    different domain.
  • Mixed-role cohesion has an element that refers to
    an extrinsic class belonging to the same domain
  • Try these concepts against the dog owner handouts

23
So?
  • Mixed-instance cohesion results in greatest
    design and maintenance problems
  • Mixed-role cohesion tends to result in fewest
    problems
  • Classes with no mixed-instance, mixed-domain, or
    mixed-role cohesion problems are the most
    reusable.
  • And, in real life, reusability is a prime reason
    that object orientation was adopted in the first
    place.

24
Class versus type
  • Type is the abstract or external view of a class
    (purpose of the class, class invariant,
    attributes, operations, operations preconditions
    and postconditions, definitions and signatures)
  • Class is the implementation of a type--there may
    be several implementations, each with its own
    internal design

25
Remember subtypes? Subclasses?
  • Subclass is distinct from subtype
  • If S is a true subtype of T, then S must conform
    to T (S can be provided where an object of type T
    is expected and correctness is preserved when
    accessor operation of the object is executed
  • If S is a subclass of T, doesnt automatically
    follow that S is a subtype of T
  • Any class can be made a structural subclass of
    another, but it wont necessarily make sense

26
Invariants, preconditions and postconditions again
  • Invariants are class level --limit state space.
    In the geometric library example, a polygon must
    have 3 or more vertices.
  • For each of the subtypes of of Polygon, for
    operations to work, precondition must define
    vertices and relationships to each other
  • Postconditions must maintain preconditions
    class invariant
  • So, you wont end up with the area of a circle
    from the polygon class or its subtypes

27
Principle of Type Conformance-
  • Helps avoid problems in class hierarchy
  • Type of each class should conform to the type of
    its superclass--this will allow us to
    effortlessly exploit polymorphism (can pass
    objects of a subclass in lieu of superclass)
  • How?

28
Contravariance and Covariance
  • Every operations precondition is no stronger
    than the corresponding operation in its
    superclass --principle of contravariance
    (strength goes in opposite direction from class
    invariant)
  • Every operations postcondition is at least as
    strong as the corresponding operation in the
    superclass (I.e., goes in same direction as class
    invariant. Operation postconditions get, if
    anything, stronger)
  • Gets entertaining when subclass overrides a
    superclasss operation with an operation of its
    own

29
Huh?
  • Bottom line--hierarchies which obey the
    contravariance and covariance principles will
    work others will likely crash.

30
Principle of Closed Behavior
  • Type conformance alone lets us design sound
    hierarchies, but it leads to sound design
    decisions only in read-only situations
  • When modifier operations are executed wealso need
    the principle of closed behavior--requires that
    the behavior inherited by a subclass from a
    superclass should respect the invariant of a
    subclass.
  • In practice may mean avoiding inheritance of
    certain operations or overriding them, reclassify
    if object as another type if acceptable to
    application

31
Example
  • Class Polygon -- operation move applied to
    subclass triangle -- OK
  • Class Polygon -- operation addVertex -- operation
    applied to triangle would make it a rectangle or
    trapezoid!
  • Your design must therefore take into
    consideration the greatest restrain on targets
    behavior (lowest class in hierarchy) or restrict
    polymorphism or check runtime class of target

32
So how does this relate to components
  • And how do ORBs enter into the soup?
  • Clearly an ORB influences component type if
    federate considered a component
  • How do the principles (connascence, type
    conformance, contravariance, covariance) apply at
    this level
  • Lets try to apply the principles to federate
    design and lower level components

33
Lightweight and Heavyweight components
  • Lightweight components utilize classes or
    components outside of component
  • Heavy weight components encapsulate everything
    necessary to do the job
  • Difference is in degree of encumbrance
  • Heavy weight components more reusable but harder
    to understand (also may carry unused code)
  • HLA components are someplace in between
  • What would ideal HLA compliant component be?

34
Similarities and differences among components and
objects a
  • components dont have to be designed or
    implemented in object-oriented style
  • different definitions--in some, executables only
    some exclude retention of state
  • different granularity than objects
  • may be quite large
  • most useful if same encapsulation and cohesion
    principles followed as for objects

35
Similarities, Difference, continued
  • clearly crucial to be able to predict what a
    component will do
  • therefore, component must be defined as if object
    (what it will do--definition, invariants,
    preconditions, postconditions) but overall
  • method helpful to allow analysis within
    encapsulated boundaries (very tricky, even if you
    develop in very principled manner)
  • for components to be composable, rules of
    composition and extension must be developed
  • TANSTAAFL -- trade offs will have to be made on
    complexity of interfaces (more complex to be more
    reusable because of standard interfaces)

36
Implications for Component Design
  • Rigorous application of design principles
  • Probably deserves at least a spiral devoted to
    extracting components from original design if not
    a well understood domain (ie, previously
    implemented)
  • CASE tools and design methods which have enough
    formality for mechanical analysis helpful
  • Run time analysis of implementations without
    components would be helpful to determine targets
    of opportunity
Write a Comment
User Comments (0)
About PowerShow.com
