From Multiagent Systems to Multiagent Societies

1
From Multiagent Systems to Multiagent Societies
Michael Berger
Based on 1) Multiagent Systems and Societies of
Agents / Michael N. Huhns and Larry M.
Stephens In Multiagent Systems A Modern
Approach to Distributed Artificial Intelligence
(Chapter 2) / Gerhard W. Weiss 2) Commitments
and Conventions The Foundation of Coordination
in Multi-Agent Systems / Nick R. Jennings
2
Overview

• Agent and Environment
• Communications
• Interactions
• Commitments and Conventions

3
Part IAgent and Environment
4
Agent - Definition

• An active object with the ability to perceive,
  reason and act.
• Has explicitly represented knowledge and a
  mechanism for operating on or drawing inferences
  from its knowledge.
• Has the ability to communicate.

5
Environment - Categories

• Knowable (Accessible)
• Predictable (Deterministic)
• Controllable
• Historical (non-Episodic)
• Telelogical
• Real-time (Dynamic)

6
Part IICommunications
7
Communications - Overview

• Motivation
• Meanings
• Speech Acts
• Message Types and Dialogue Roles
• Communication Protocols
• KQML
• KIF
• Ontologies

8
Motivation (I)

• Coordination - the extent to which agents avoid
  extraneous activity.
• Reducing resource contention
• avoiding livelock / deadlock
• maintaining safety conditions
• Coherence - how well the system behaves as a
  unit.
• Determining shared goals
• Pooling knowledge and evidence

?
9
Motivation (II)

• Coordination - not making things worse.
• Coherence - making things better.
• Communication enables the agents to coordinate
  their actions and behavior, resulting in systems
  that are more coherent.

10
Meanings (I)

• Communication - consists of
• Syntax - how the symbols of communication are
  structured.
• Semantics - what the symbols denote.
• Pragmatics - how the symbols are interpreted.
• Meaning Semantics Pragmatics

11
Meanings (II)

• Dimensions of meaning
• Descriptive vs. Prescriptive
• Speakers vs. Hearers vs. Societys Perspective
• Semantics vs. Pragmatics
• Contextuality
• Identity
• Cardinality

12
Speech Acts

• Speech act theory used as basis for analyzing
  human communication.
• Theory views human natural language as actions.
• Speech acts have three aspects
• Locution - the physical utterance by the speaker.
• Illocution - the intended meaning of the
  utterance by the speaker.
• Perlocution - the action that results from the
  locution.
• Performative - Speech acts that have the
  property that saying it makes it so (e.g.
  promise, report, tell, request, demand).

13
Message Types and Dialogue Roles

• Two basic message types
• Assertion
• Query
• Three dialogue roles
• Master (active)
• Sends queries (questions), receives assertions
  (answers), sends assertions (fact
  determinations).
• Slave (passive)
• Receives queries (questions), sends assertions
  (answers), receives assertions (fact
  determinations).
• Peer
• Master Slave

14
Communication Protocols

• Communication can be
• binary (single sender, single receiver)
• n-ary (single sender, many receivers)
• Messages sent using communication protocols are
  specified by a data structure, that contains the
  following fields
• Sender
• Receiver
• Encoding / Decoding functions
• Language of message
• Message content

15
Communicating Agents (I)
a is broken.
16
KQML

• KQML - Knowledge Query and Manipulation Language.
• Basic KQML performative defined by a structure
  that contains the following fields
• Sender
• Receiver
• Language
• Ontology
• Content
• More advanced performatives.
• Language used as wrapper for other languages -
  Domain independent!
• Forwarding and nesting possible.

17
Communicating Agents (II)
Je ne comprends pas
Sender Cowboy Receiver Shadow Language
English Content a is broken
Languages English, Spanish, Basque
Languages French
18
KIF

• KIF - Knowledge Interchange Format.
• Prefix version of first-order predicate calculus.
• Example or ((and (gt ?a 6) (gt b 5))) (lt c 7)
• Possible to encode knowledge about knowledge
  (second-order) and to describe procedures.

19
Communicating Agents (III)
Sender Cowboy Receiver Shadow Language
KIF Ontology Computers Content broken(a)
bad(message)
Languages English, Spanish, Basque, KIF
Languages French, KIF
Ontologies Computers, Politics, Sports
Ontologies Fashion, Politics, Weather
20
Ontologies

• Ontology - specification of objects, concepts and
  relationships in an area of interest (domain).
• Concepts represented in first-order logic as
  unary predicates. Relationships represented by
  n-ary predicates.
• Note predicates refer to classes of objects, not
  instances of objects.
• except instanceof
• All agents share the same ontology - i.e. all
  agents use and understand the same vocabulary!

21
Communicating Agents (IV)
Sender Cowboy Receiver Shadow Language
KIF Ontology Computers Content broken(a)
need_fixing(a)
Computer Ontology instanceof(a,
disk) instanceof(X, disk) AND
broken(X) gt need_fixing(X)
Languages English, Spanish, Basque, KIF
Languages French, KIF
Ontologies Computers, Politics, Sports
Ontologies Fashion, Politics, Weather, Computers
22
Part IIIInteractions
23
Interactions - Overview

• Motivation
• Negotiation
• Market Mechanisms
• Contract Net
• Truth Maintenance Systems
• Blackboard Systems

24
Motivation

• Communication is a necessary condition for
  coordination and coherence, but not a sufficient
  one.
• It would help if agents could
• Determine shared goals
• Avoid unnecessary conflicts
• Pool knowledge and evidence

25
Negotiation

• Negotiation - a process by which a joint decision
  is reached by two or more agents, each trying to
  reach an individual goal.
• Main steps
• One of the agents communicates its initial
  position.
• While no agreement is reached, each agent makes a
  proposal in its turn. These may include
• Concessions.
• New alternatives.
• Ends with agreement or disagreement.
• Mechanisms for negotiation may be
• Environment-centered
• Agent-centered

26
Negotiation MechanismsEnvironment-Centered

• Environment designer.
• How can the rules of the environment be designed
  so that the agents will interact productively and
  fairly?
• A negotiation mechanism would ideally have the
  following attributes
• Efficiency
• Stability
• Simplicity
• Distribution
• Symmetry

27
Negotiation MechanismsAgent-Centered

• Agent designer.
• Given an environment, what is the best strategy
  for my agent to follow?
• Large part of the negotiation mechanisms assume
  that agents are economically rational.
• For example, a negotiation protocol that contains
  the following terms
• Deal
• Utility
• Negotiation set

28
Market Mechanisms (I)

• Everything of interest to the agents described in
  terms of prices.
• Two types of agents
• Consumers
• Producers
• Markets of goods are interconnected.

29
Market Mechanisms (II)

• Big market will usually reach a competitive
  equilibrium
• Consumers bid to maximize utility, subject to
  their budget constraints.
• Producers bid to maximize profits, subject to
  their technological capability.
• Net demand is zero for all goods.

30
Contract Net (I)

• Interaction protocol for cooperative problem
  solving.
• Modeled on the contracting mechanism used by
  businesses.
• For any assignment, agents are divided ad-hoc
  into managers and contractors.

31
Contract Net (II)

• Managers
• Announce a task that needs to be performed.
• Receive and evaluate bids from potential
  contractors.
• Award a contract to a suitable contractor.
• Receive and synthesize results.
• Contractors
• Receive task announcements.
• Evaluate their own capability to respond.
• Respond (decline / bid).
• Perform the task if bid is accepted by manager.
• Report tasks results.

1
5
6
9
2
3
4
7
8
32
Truth Maintenance System (I)

• Truth Maintenance System (TMS) - ensures the
  integrity of an agents knowledge, and keeps the
  knowledge base
• Stable
• Each datum that has a valid justification is
  believed.
• Each datum that lacks a valid justification and
  which is not in initial belief set is
  disbelieved.
• Well-founded
• Permits no set of its beliefs to be mutually
  dependent.
• Logically consistent
• No datum is both believed and disbelieved.
• Every datum is either believed or disbelieved.
• No data and its negation are both believed or
  disbelieved.

33
TMS Graph
U(OUT)
T(EXTERNAL)
_
Agent 2

P(IN)
T(INTERNAL)
_
_
Q(OUT)
R(IN)
S(OUT)

_
Agent 1
34
Truth Maintenance System (II)

• Every datum is labeled either
• IN (in initial belief set).
• INTERNAL (IN because of local justification).
• EXTERNAL (IN because another agent asserts it).
• OUT (disbelieved).
• When justification is added or removed, the TMS
  is invoked
• Some data unlabeled, including the newly
  justified datum and its consequences in all
  agents.
• New Labeling introduced for all unlabeled data.
• If any affected agent fails to label, backtrack
  occurs.
• Principal of TMS changes Affect as few agents as
  possible and as few beliefs as possible.

35
TMS - Example (I)
U(OUT)
T(EXTERNAL)
_
Agent 2

P(IN)
T(INTERNAL)
_
_
Q(OUT)
R(IN)
S(OUT)

_
Agent 1
36
TMS - Example (II)
U(OUT)
T(EXTERNAL)
_
Agent 2

P(IN)
T(INTERNAL)

_
_
Q(OUT)
R(IN)
S(OUT)

_
Agent 1
37
TMS - Example (III)
U(OUT)
T(EXTERNAL)
_
Agent 2

P
T(INTERNAL)

_
_
Q
R(IN)
S(OUT)

_
Agent 1
38
TMS - Example (IV)
U
T
_
Agent 2

P
T

_
_
Q
R(IN)
S(OUT)

_
Agent 1
39
TMS - Example (V)
U
T
_
Agent 2

P
T

_
_
Q
R
S

_
Agent 1
40
TMS - Example (VI)
U(IN)
T(OUT)
_
Agent 2

P(OUT)
T(OUT)

_
_
Q(OUT)
R(OUT)
S(IN)

_
Agent 1
41
Blackboard Systems (I)

• Akin to the following metaphor
• A group of specialists working together on
  solving a problem.
• A common blackboard allows every specialist to
  report (write down) his sub-task results.
• Every specialist may be assisted in his work by
  information reported on the blackboard.
• Every specialist is called a knowledge source
  (KS).

42
Blackboard Systems (II)

• Characteristics of blackboard systems
• Independence of expertise.
• Diversity in problem-solving techniques.
• Flexible representation of blackboard
  information.
• Common interaction language.
• Event-based activation.
• Need for control.
• Incremental solution generation.

43
Part IVCommitments and Conventions
44
Distributed Goal Search Model

• Goals solution expressed as AND/OR graph (which
  is directed and a-cyclic).
• High-level goals are root nodes.
• Primitive goals are leaf nodes.
• Graph also contains resources needed for solving
  primitive goals.
• Dependencies may exist between different goals or
  between a goal and its resource.
• Strong vs. weak
• Uni-directional vs. bi-directional
• Note that dependencies from resources to goals
  may be solved by adding more instances of the
  resource.

45
Distributed Goal Search Graph
Agent1
Agent2
G1
G2
G11
G12
G1k
G1,2m
G2p
G2t

.
G11,1
G11,2
G1m,1
G2m,2
G2p,1
G2p,2
G1m,1,1
G1m,1,2
G2p,1,1
G2p,1,2
G2p,2,2

• Goals

46
Interactions among Agents for Distributed Goal
Search

• Defining the goal graph.
• Assigning particular regions of the graphs to
  different agents.
• Controlling decisions about which areas of the
  graph to explore.
• Traversing the graph.
• Ensuring that successful traversal of the graph
  is reported.

47
Commitment - Definition

• A pledge from one agent to another agent (or
  itself) to undertake a specified course of action.

48
Commitments

• Practical reasoning agents employ intentions for
  choosing a course of action - a kind of
  self-commitment.
• In computational problems, different agents
  commit themselves to solving different sub-goals
  of a larger goal.
• Agents may inform other agents of the sub-goals
  to which they are self-committed. In stronger
  terms, they may commit to other agents about
  solving these sub-goals.

49
Motivation for Conventions (I)

• Agents do not have complete knowledge of the
  goals and intentions of other agents.
• Infeasible to have all agents re-contemplate
  about the goals of other agents in every step
• Limited computation power
• Limited communication bandwidth
• Infeasible to have one agent or database keep all
  information about all agents
• Bottleneck
• Single point of failure

50
Motivation for Conventions (II)

• If circumstances changed, an agent might be
  working sub-optimally until he asks about it.
• Another agent solves a goal
• Another agent commits itself to a goal
• Another agent drops his commitment to a goal
• Another agent discovers that a goal is no longer
  attainable
• We still would like to keep a distributed system
  of agents...

51
(No Transcript)
52
Convention - Definition

• A pre-determined description, common to all
  agents in the system, of the course of action to
  be taken by an agent, given a specific
  circumstance or occurrence.

53
Minimum Convention for Joint Commitments

• Formalism by Cohen and Levesque.
• BASIC SOCIAL CONVENTION
• REASONS FOR ACTION
• STATUS OF COMMITMENT TO SHARED GOAL CHANGES
• STATUS OF COMMITMENT TO REACHING SHARED GOAL IN
  PRESENT TEAM CONTEXT CHANGES
• STATUS OF COMMITMENT OF A TEAM MEMBER TO SHARED
  GOAL CHANGES
• ACTIONS
• R1 IF STATUS OR COMMITMENT TO SHARED GOAL
  CHANGES OR
• STATUS OF COMMITMENT IN PRESENT TEAM CONTEXT
  CHANGES
• THEN INFORM ALL OTHER TEAM MEMBERS OF CHANGE
• R2 IF STATUS OF COMMITMENT OF A TEAM MEMBER TO
  SHARED GOAL CHANGES
• THEN DETERMINE WHETHER JOINT COMMITMENT STILL
  VIABLE

54
Convention for Limited-Bandwidth Environments

• LIMITED-BANDWIDTH CONVENTION
• REASONS FOR ACTION
• COMMITMENT SATISFIED
• COMMITMENT UNATTAINABLE
• MOTIVATION FOR COMMITMENT NO LONGER PRESENT
• ACTIONS
• R1 IF COMMITMENT SATISFIED OR
• COMMITMENT UNATTAINABLE OR
• MOTIVATION FOR COMMITMENT NO LONGER PRESENT
• THEN DROP COMMITMENT
• R2 IF COMMITMENT SATISFIED
• THEN INFORM ALL AGENTS WORKING ON RELATED GOALS
• R3 IF COMMITMENT DROPPED BECAUSE UNATTAINABLE
  OR
• MOTIVATION NOT PRESENT
• THEN INFORM ALL AGENTS WORKING ON STRONGLY
  RELATED GOALS
• R4 IF COMMITMENT DROPPED BECAUSE UNATTAINABLE
  OR
• MOTIVATION NOT PRESENT AND COMMUNICATION
  RESOURCES NOT OVERBURDENED
• THEN INFORM ALL AGENTS WORKING ON WEAKLY
  RELATED GOALS

55
Convention in Nearly Open Environments (I)

• JOINT RESPONSIBILITY SOCIAL CONVENTION
• INHERIT BASIC SOCIAL CONVENTION
• REASONS FOR ACTION
• SHARED GOAL IS MET
• SHARED GOAL WILL NEVER BE MET
• MOTIVATION FOR SHARED GOAL IS NO LONGER PRESENT
• AGREED PLAN WILL NOT ACHIEVE DESIRED RESULTS
• AGREED PLAN CANNOT BE EXECUTED
• AGREED PLAN HAS NOT BEEN EXECUTED PROPERLY
• ACTIONS
• R1 IF SHARED GOAL IS MET OR
• SHARED GOAL WILL NEVER BE MET OR
• MOTIVATION FOR SHARED GOAL IS NO LONGER
  PRESENT
• THEN DROP COMMITMENT TO SHARED GOAL TO AGREED
  PLAN
• R2 IF AGREED PLAN WILL NOT ACHIEVE DESIRED
  RESULTS OR
• AGREED PLAN CANNOT BE EXECUTED OR
• AGREED PLAN HAS NOT BEEN EXECUTED PROPERLY
• THEN DROP COMMITMENT TO AGREED PLAN
• R3 IF DROP JOINT COMMITMENT TO AGREED PLAN AND

56
Convention in Nearly Open Environments (II)

• R4 IF DROPPED COMMITMENT TO AGREED PLAN AND
• CANNOT RE-PLAN USING SAME AGENTS AND
• CAN DEVELOP NEW PLAN USING DIFFERENT TEAM
• THEN DROP COMMITMENT TO EXISTING TEAM COMMIT
  TO NEW TEAM
• R5 IF CANNOT DEVELOP NEW COMMON PLAN
• THEN DROP COMMITMENT TO SHARED GOAL TO AGREED
  PLAN

57
Possible Trends in Conventions

• The harsher the environment, the more rules are
  needed to determine the agents action.
• The harsher the environment, the more frequent
  are situations in which the agent stops and
  reconsiders objectives.
• Similar to the spectrum between bold agents and
  cautious agents (Kinny and Georgeff).

58
Example for Benefits of Conventions
Agent1
Agent2
G1
G2
G11
G12
G1k
G1,2m
G2p
G2t

.
G11,1
G11,2
G1m,1
G2m,2
G2p,1
G2p,2
G1m,1,1
G1m,1,2
G2p,1,1
G2p,1,2
G2p,2,2

• Goals

Strong dependencies
Weak dependendcies
59
Agents without Honor
G1,21
Agent 1 G11,1 Agent 2 G21,2 Agent 1 reneges
G11,1
G21,2
G1,21
Agent 1 G11,1 Agent 2 G2p Agent 1 reneges
G11,1
G21,2
G2m
Agent 1 G1k Agent 2 G2m Agent 1 reneges
G1k
G2m,1
G2m
Agent 1 G1k Agent 2 G2m Agent 1 reneges
G1k
G2m,1
G2m,2
G2m
G1k
Agent 1 G1k,2 Agent 2 G2m Agent 2 reneges
G1k,2
G2m,1
G1k,1
60
Benefits of Conventions

• Provides a degree of predictability to counteract
  the uncertainty caused by the distribution of
  control.
• Mitigates the effect of commitments reneged.
• Flexible - can sometimes be made at different
  levels and thus have varied time horizons.
• The lower the level, the higher the accuracy of
  information and the larger are the required
  computation and communication bandwidth
• Lower levels dont always provide a significant
  contribution
• Lower levels might cause more constraints

61
Conventions vs. Conventions

• Humans also have conventions.
• Not obligatory.
• Others dont always expect adherence to them.
• Agent conventions are actually rules rather than
  conventions.

62
The Dawn of Society

• In a System of agents/humans acting without
  conventions, they cannot expect anything from
  their peers.
• Pre-determined rules/conventions act as common
  denominator for all units.
• Conventions that are adhered to, allow the system
  to act more coherently without extra effort from
  particular units.
• The whole is larger than the sum of its parts.
• Thus a system turns into a society.
• Human societies always have unwritten rules.
• Agent conventions also called social rules.

63
Thank You
