Bar Code Technology

1
Bar Code Technology
2
Successful Installation!

• ACL - Complete an Application Check List
• Take into consideration All Variables
• Get Exact Customer Samples!
• Test Samples after evaluating!
• Be Cautious of Competitive cross referencing

3
Bar Code Principles

• Element bar or space
• Barcount number of bars and spaces
• Start/Stop fixed patterns used to detect bar
  code

4
Bar Code Principles

• Resolution X module size width of the
  narrowest element in mm (mils in USA)
• Aspect Ratio bars height to symbols length
• Quiet Zone white margins (Overflow quiet
  zone time duration) Usually the Quiet Zone width
  must be 10 times X

5
Bar Code Principles
Stop pattern
Start pattern
Quiet Zone
Quiet Zone
123456
Scan Line
6
Bar Code Basics
Optical Symbologies
1 D - Codes
2 D - Codes
STACKED CODES
BAR CODES
MATRIX CODES
7
Bar Code Basics

• What is a one D code?
• It is a sequence of dark and light elements. The
  code can be considered like an alphabet where
  each character is composed by a specific sequence
  of BARS and SPACES.

8
Common Linear Symbologies

• EAN/UPC
• Code 39
• Interleaved 2 of 5
• Code 128

9
BAR CODE BASICS

• What is a stacked code?
• The terms stacked symbology or multi-row code are
  applied to those codes composed by stacked rows
  of one dimensional bar codes. Each row is
  independently decoded, but the complete
  information is obtained appending the single
  content of all individual rows.

10
BAR CODE BASICS

• What is a matrix code?
• The term matrix code applies to 2D symbologies
  composed by black elements positioned in specific
  locations of a matrix. Each element has the same
  dimension, and the relative position of all
  elements in the matrix determines the information
  content of the code.

11
BAR CODE BASICS

• What is a composite code?
• It is the combination of a linear and a stacked
  code. Typically, the linear code identify the
  item, and the stacked code contains additional
  relevant information (i.e. production date,
  expiration date, batch number, etc.).

12
BAR CODE BASICS
13
BAR CODE BASICS

• Why 2D codes?

• To reduce space

• To increase the quantity of information

14
SUITABLE APPLICATIONS FOR 2D CODES
there is lack of space
All applications in which
a lot of information is needed or there exist
need for portability of the code information
content
15
READING DIAGRAMS
Reading diagrams are mainly affected by code
resolution
NOT Readable
FIELD
Readable
SCANNER
D.O.F.Depth Of Field
16
PICKET FENCE

• Barcode moves parallel to the scan line

17
STEP LADDER

• Barcode moves perpendicular to the scan line

18
INSTALLATION READING ANGLES

• Unattended laser devices are able to decode
  moving labels at a variety of angles, however
  significant angular distortion reduces reading
  performances
• When mounting the Scanner take care the 3 angles
  are near to the following ideal values
• Pitch 0
• Skew 10 to 30
• Tilt 0

19
READING ANGLES PITCH

• Position the reader in order to minimise the
  Pitch angle value P
• Too High of Pitch results in possibleOut of
  Focus effect!!

20
READING ANGLES SKEW

• To avoid the direct reflection of the laser light
  emitted by the scanner, place the reader assuring
  at least 10 for the Skew angle, S

21
Reading Angles TILT

• Place the reader in order to get the minimum Tilt
  angle value T

22
RASTER OSCILLATING LASER PATTERNS
or oscillating mirror (not for DS2100/2200)

• In PICKET FENCE applications the use of a raster
  scanner ...

• widens the reading surface.
• When figuring out the number of effective scans,
  it must be
• considered the percentage of scans actually
  crossing the bar code

23
ACR Code Recunstruction

• When the TILT angle is too big and the laser beam
  doesnt cross the label from the begin to the
  end, you need to use USS devices having the
  "Advanced Code Reconstruction" mode

Partial scans
24
How ACR Works
Object Movement
Scan Line
100 GOOD READ !
REAL TIME DECODING
25
Laser Technology

• PROs
• Mature and Reliable
• Easy to use
• Lower Complexity
• Low maintenance
• Low Cost solutions
• Low Cost of Ownership

• CONs
• 1D reading only
• Omni-directional reading limitations
• Limited Analysis capability (i.e. No Read)
• Performance influenced by conditions

26
Vision Technology

• PROs
• Excellent Performance
• Naturally Omni-Directional
• Image Capturing
• 2D Code
• OCR-Videocoding
• Image Saving
• Quality Control Capability

• CONs
• Higher System Complexity
• Higher Cost

27
2D Codes symbologies

• Two-dimensional code information along the
  height (X-axis) as well as the length (Y-axis) of
  the symbol
• No vertical redundancy
• 2D Codes tolerates printing dropouts because of
• Error Correction Capability (ECC)
• Increase the effective density of the encoding
  more data in a smaller space
• Portable database (rather than just a database
  key) encode complete data files in an optically
  readable symbol and so
• extend the potential market for AUTO-ID
• There are two types of 2D codes in current use
• Multi-Row (Stacked) codes
• Matrix codes

28
Matrix Symbologies (1/2)

• Matrix symbologies differ in terms of
• way input data is converted in binary pattern
• way pattern is placed on the greed
• grid size (number of cells)
• finder pattern
• Maximum data capacity
• up to 7089 numeric characters or 4296
  alphanumeric characters using Structure Append
  capability
• The most used Matrix codes are
• Data Matrix family
• QR Code
• Aztec Code
• Maxicode

29
Data Matrix ECC200 benefits

• Large amount of data
• High level of security
• High reading rate
• Low requirement for contrast
• Any printing technique
• Direct marking (silk screen printing, laser
  etching, etc.)
• Reduction of costs by using smaller labels
• Amount of data and size of the code are
  dynamically variable

30
Laser vs. Camera Comparison

• Camera/Vision Technology is Future Oriented
  Solution
• Benefits in Many Applications
• Image offers much more information
• Image Acquisition is creating New Functions that
  will modify the Logistic Process (VDC,
  Image Storage, )
• Higher performance thanks to future chips.
• Laser Technology is Best Performance/Price Ratio
• Excellent Performance in Many Applications
• Reliable Technology
• Easy to use
• Very low cost of ownership

31
Main Application Areas
DIRECT MARKING

• INK-JET
• LASER MARKING
• DOT PEENING

32
Main Application Areas
DOCUMENT HANDLING

• HYBRID MAIL
• POSTAL
• AUTOMATIC BILLING

33
Extended Applications
READING OF LOW QUALITY CODES

• LOW CODE/BACKGROUND CONTRAST
• REDUCED HEIGHT BAR CODE
• UNEVEN CODE SURFACE
• REFLECTIONS

CRITICAL FOR LASER SCANNERS
34
Camera Illumination

• Proper illumination offers
• The ability to effectively read various part
  marking methods, i.e. dot peening, ink jet, laser
  etching, Dot Matrix codes
• High effectiveness in low quality and low
  contrast DPM codes

35
Complimentary Platforms

• Offer to the clients what they need
• Vision
• Laser
• Vision Laser
• Vision Laser Complementary Platforms

36
INDUSTRIES APPLICATIONS
37
Connectivity Options

• Serial Connectivity
• Ethernet and Ethernet/IP
• DeviceNet
• Profibus
• ID Net

38
ID-NET BENEFITS
39
ID-NET is

• is a further interface beside Main and Aux
• is basically a 485 Half-Duplex (2wiresRef)
• uses the enhanced Mux32 Sw Protocol
• is a dedicated high-speed channel for scanner
  interconnection

40
ID-NET is COST SAVING !

• Master scanner performs Data Collection while
  reading barcodes.

NO MX4000 REQUIRED !
Main
Aux
41
ID-NET is SIMPLE LAYOUTS!

• Topology 1 Single station multiple
  scannersID-NET supports up to 16 devicesin M/S
  Synchronized layout
• Topology 2 Multiple station single
  scannersID-NET supports up to 32 devicesin M/S
  Multidata layout

COMMON CONNECTION SCHEMES !
42
ID-NET is EASE OF CONFIGURATION !

TOTAL CLUSTER MANAGEMENT FROM THE MASTER !
Aux
43
ID-NET is EASE OF REPLACEMENT !
Master
AUTOMATIC SCANNER REPLACEMENT !
Slave
Slave
Main
Aux
C-BOX 150
C-BOX 100
C-BOX 100
STORAGE OF MASTER 9 x SLAVE CFGs !
44
ID-NET is STANDARDIZATION !
ALL NEW PRODUCTS EQUIPPED WITH ID-NET !
45
Product Range
Systems
Products
Laser
Vision
46
Price / Performance
TRANSPORTATION LOGISTIC
MANUFACTURING
OEM
8000 Series
6000 Series
PRICE
PERFORMANCE/FEATURES
4000 Series
2000 Series
1000 Series
READING DISTANCE / DOF
47
Matrix 400 Industrial 2D compact imager
Excellent Performance
Automotive
Flexibility
Versatility
Ease of Setup
Electronics
Distribution Retail
Industrial Strength
Ease of Use
Medical Pharmaceutical
Food beverage
48
Successful Installation!

• ACL - Complete an Application Check List
• Take into consideration All Variables
• Get Exact Customer Samples!
• Test Samples after evaluating!
• Be Cautious of Competitive cross referencing

49
Datalogic Automation Services

• Datalogic Automation offers the following range
  of services on its USS product line
• Warranty extension
• Maintenance Agreement
• DL_at_Work

Thank You for your Attendance and
Attention. John Pessina Key Account
Manager Datalogic Automation
