Title: Introducing the Heartland Corridor


1
The Heartland Corridor Virginia Economic
Developers Association Roanoke, VA September 29,
2006
2
(No Transcript)
3
Introducing the Heartland Corridor
  • The Heartland Corridor is a portfolio of
    intermodal based products designed significantly
    to improve mobility and increase freight capacity
    between the Mid-Atlantic and the Midwest, with
    benefits to regions of North Carolina and market
    opportunities for western Virginia and West
    Virginia.

4
Heartland Central Corridor
  • The core of the Heartland Corridor is the
    so-called Central Corridor component.
    Realization of the double-stack clearances helps
    justify related corridor projects, such as the
    rail relocation project to serve the APM
    Terminal/Craney Island and the mega-terminal at
    Rickenbacker, as well as making available
    opportunities for market access for western
    Virginia and West Virginia (via a Roanoke region
    and Prichard intermodal facilities).

5
The Heartland Corridor
664
NIT
CIMT(Proposed)
CIDMMA
Norfolk
APM
164
Portsmouth
PMT
264
664
264
464
CRMSRP Project (Median Rail)
6
Heartland Corridor Key Project Components
  • Central Corridor Double-Stack Project
  • Double-Stack Clearances Between Roanoke, VA
    through WV, to Columbus, OH
  • Expanded Intermodal Capacity
  • Columbus, OH Rickenbacker Airport
  • New Intermodal Terminals
  • Roanoke Region
  • Prichard, WV
  • Western Freeway Rail Corridor
  • Rail relocation project in Portsmouth, VA

7
(No Transcript)
8
Heartland received considerable federal funding
support.
9
Central Corridor Double-Stack Project The
current clearance envelope through western
Virginia and West Virginia only accommodates
railcars up to 191 multi-levels. No
double-stack cars can be accommodated in western
Virginia and West Virginia due to the height, as
well as the square profile of the conveyance.
10
Chicago
Cleveland
Harrisburg
Columbus
Prichard
Kenova
Roanoke
The Port of Virginia
11
Heartland Corridor Central Corridor Double-Stack
Project Scope
  • 28 Tunnels
  • 30,000 feet to be Cleared
  • Virginia, West Virginia and Kentucky
  • 24 Overhead Obstructions
  • Bracing Modifications, Fencing Modifications,
    Overhead Wire Removal, Miscellaneous Signal Work
  • West Virginia and Ohio

12
The project is similar to the clearance
improvements in Pennsylvania in 1993-1995.
13
  • The key funding mechanism for the clearances
    component of Heartland was Section 1301 of
    SAFETEA-LU
  • Projects of National and Regional Significance
  • We intentionally pursued a House strategy in the
    run-up to the surface transportation
    reauthorization

14
Status of the Clearances
  • Fully funded 151 million project
  • 95 million federal 9.8 million Virginia 0.8
    million Ohio the balance from Norfolk Southern
  • Federal Highways designated (by consensus of all
    parties) as sponsor agency
  • MOA signed by three States w/FHWA and MOA
    signed by NS w/FHWA effectuating the flow of
    funds for the project
  • The Project is a Go!
  • First order of business Completion of
    environmental document, expected Spring 2007
  • In the interim, construction design engineering
    allowed up to 70 completion

15
The new Columbus facility will be similar in
scope and design to the NS facility in Austell,
near Atlanta, GA.
16
The new facilities in Pritchard, WV and the
Roanoke region will be similar in scope and
design to Norfolk Southerns facility in
Cleveland, OH.
17
  • Each of these facilities, Rickenbacker, Roanoke
    Region and Prichard will be public/private
    partnerships.
  • A decision on Prichard by West Virginia remains
    pending in the future.

18
Port of Hampton Roads
Newport News Marine Terminal
NS Mainline
NS Drayage Sub-service
NIT Marine Terminal
Commonwealth RR (Current)
Commonwealth RR (Proposed)
Craney Island Marine Terminal (Proposed)
AP Moeller Marine Terminal (2007)
Commonwealth RR Marshalling Yard (Proposed)
Portsmouth Marine Terminal
NS Portlock
19
CRMSRP (Median Rail) Project
Project End
CRMSRP Project
APM Terminal
Suffolk
New Rte 17 Overpass Bridge
Portsmouth
CRMSRP Project
Existing Rail Tracks (To Be Abandoned)
Project Start
Chesapeake
20
Where we need to go
  • I applaud Virginia DRPT The Secretary
  • We need more balanced transportation in modal
    terms this means more rail, including in forms
    that facilitate highway mobility
  • We need more public/private
  • The public sector must grow comfortable with the
    notion of profit motivation and that individual
    companies or investors will be the partners on
    any given project

21
Any questions?
