Aerial Video Surveillance and Exploitation

1
Aerial Video Surveillance and Exploitation

• Roland Miezianko
• CIS 750 - Video Processing and Mining
• Prof. Latecki

2
Agenda

• Aerial Surveillance Comparisons
• Technical Challenges and the Mission
• Framework Ideas for Video Surveillance
• Alignment and Change Detection
• Mosaicing
• Tracking Moving Objects
• Geo-location
• Enhanced Visualization
• Image Mosaics

3
Types of Aerial Surveillance

• Using film and framing cameras
• Hi-resolution still images
• Examined by human or machine
• Video captures dynamic events
• Used to detect and geo-locate moving objects in
  real-time
• Follow detected motion
• Constantly monitor a site

4
Technical Challenges, 1

• Video cameras have lower resolution than framing
  cameras
• Video uses telephoto lens to get high resolution
  to identify objects
• Telephoto lens - Narrow field of view
• Provides soda straw view of the scene 2

5
Technical Challenges, 2

• Camera must scan the region of interest to get
  the full-picture
• Objects of interest move in and out of the field
  of view
• Difficulty in perceiving object relative locations

6
Technical Challenges, 3

• Challenge in manually tracking an object due to
  cameras small field of view
• Video contains much more data then film frames
  Storage is expensive

7
The Mission

• The new aerial surveillance systems must provide
  a framework for spatio-temporal aerial video
  analysis

8
Video AnalysisFramework, 1

• Frame-to-Frame alignment and decomposition of
  video frames into motion layers
• Mosaicing static background layers to form
  panoramas as compact representations of the
  static scene

9
Video AnalysisFramework, 2

• Detecting and tracking independently moving
  objects in the presents of background clutter
• Geo-locating the video and tracked objects by
  registering it to controlled reference imagery
  digital terrain maps and models

10
Video AnalysisFramework, 3

• Enhanced visualization of the video by
  re-projecting and merging it with reference
  imagery, terrain, and maps to provide a larger
  context

11
Alignment and Change Detection, 1

• Displacement of pixels between video frames may
  occur due to the following
• Motion of the video sensor
• Independent motion of objects in the field of
  view
• Motion of the source of illumination

12
Alignment and Change Detection, 2

• Global motion estimation
• Displacement of pixels due to the motion of the
  sensor is computed
• Alignment of Video Frames
• Pyramid-Processing
• Lock into the motion of background scene
• Warp images into common coordinate frame

13
Alignment and Change Detection, 3

• Moving objects are detected by aligning video
  frames and detecting pixels with poor correlation
  across the temporal domain

14
MosAICING, 1

• Images are accumulated into the mosaic as the
  camera pans
• Construction of a 2D mosaic requires computation
  of alignment parameters that relate all of the
  images in the collection to a common world
  coordinate system

15
MosAICING, 2

• Transformation parameters are used to warp the
  images into the mosaic coordinate system
• Warped images are then combined to form a mosaic
• To avoid seams, warped frames are merged in the
  Laplacian pyramid domain

16
MosAICING, example
17
MosAICING, example
18
Tracking Moving Objects, 1

• Scene analysis includes operations that interpret
  the source video in terms of objects and
  activities in the scene
• Moving objects are detected and tracked over the
  cluttered scene

19
Tracking Moving Objects, 2

• State of each moving object is represented by
  its
• Motion
• Appearance
• Shape
• The state is updated at each instant of time
  using Expectation-Maximization (EM) algorithm

20
Tracking Moving Objects, example
21
Geo-location

• Video Surveillance system must also determine the
  geodetic coordinates of objects within the
  cameras field of view
• More precise geo-locations can be estimated by
  aligning video frames to calibrated reference
  images

22
Enhanced Visualization

• Challenging aspect of aerial video surveillance
  is formatting video imagery for effective
  presentation to an operator
• The soda straw view makes direct observation
  tedious and disorienting

23
Mosaic-Based Display

• Display de-couples the observers display from
  the camera
• Operator may scroll or zoom to examine one region
  of the mosaic even as the camera is updating
  another region of the mosaic

24
Elements of Mosaic Display
camera
Pyramid merge
warp
merge
ED
Estimate displacement
Update window
Operators display
Image accumulating memory
25
Camera Input
26
Mosaic Generation, 1
27
Mosaic Generation, 2
28
Psuedo codes of main algorithm 5
read(base_image) read(unregistered_image)
base_imageexpand(base_image) confirm three
pairs of matched points between base_image and
unregistered_imagecalculate initial matrix
MApply Levenberg-Marquardt minimization to
update MM inverse(M)Resample and apply
blending function to render the mosaics
29
Homogeneous Coordinates
Using homogeneous coordinates, we can describe
the class of 2D planar projective transformations
using matrix multiplication 4
30
Rigid Transformation
The same hierarchy of transformations exists in
3D. Rigid (Euclidean) transformation where R is a
3 3 orthonormal rotation matrix and t is a 3D
translation vector.
31
Viewing Matrix
The 34 viewing matrix
projects 3D points through the origin onto a 2D
projection plane a distance f along the z axis.
32
Combined Equations
The combined equations projecting a 3D world
coordinate p (x, y, z, w) onto a 2D screen
location u (x', y', w') can thus be written as
where P is a 3 4 camera matrix. This equation
is valid even if the camera calibration
parameters and/or the camera orientation are
unknown.
33
Local Image Registration, 1

• How do we compute the transformations relating
  the various scene pieces so that we can paste
  them together?
• We could manually identify four or more
  corresponding points between the two views
• Manual approaches are too tedious to be useful

34
Local Image Registration, 2

• This has the advantages of not requiring any
  easily identifiable feature points and of being
  statistically optimal, that is, giving the
  maximum likelihood estimate once we are in the
  vicinity of the true solution.

Rewrite our 2D transformations
35
Minimizes Intensity Errors
Technique minimizes the sum of the squared
intensity errors. Over all corresponding pairs of
pixels i inside both images I(x, y) and I(x,
y). Pixels that are mapped outside image
boundaries do not contribute.
36
Minimization
To perform the minimization, we use the
Levenberg-Marquardt iterative nonlinear
minimization algorithm. This algorithm requires
computation of the partial derivatives of ei with
respect to the unknown motion parameters m 0 ...
m 7 .
37
Complete Registration Algorithm Step 1 4
38
Complete Registration Algorithm Steps 2-4
39
Bryce Canyon Mosaic
40
Wall Frame, example
41
Conclusion

• The techniques presented here automatically
  register video frames into 2D and partial 3D
  scene models.
• Video mosaics and related techniques will enable
  an even more exciting range of interactive
  computer graphics, telepresence, and virtual
  reality applications.

42
References
1 Automatic Panoramic Image Construction
Yap-Peng Tan, Sanjeev R. Kulkarni and Peter J.
Ramadge Princeton University, Department of
Electrical Engineering
2 Chapter 2 by Rakesh Kumar Aerial Video
Survelliance and Exploitation
3 A Multiresolution Spline With Application to
Image Mosaics PETER J. BURT and EDWARD H.
ADELSON RCA David Sarnoff Research Center
43
References
4 Richard Szeliski. Video mosaics for virtual
environments. IEEE Computer Graphics and
Applications, 16(2)22--30, March 1996
5 Jingbin Wang, Boston University
CS580Advanced Graphics Project 1 Image Mosaics
