Paint Project CEN3031

1
Paint Project CEN3031

• Presented by the Web Junkies

2
Overview

• Group Introduction
• Individual Contribution
• Program Requirements
• Design/Structure
• Requirement Implementation
• Requirements In Progress
• Summary

3
Web Junkies

• Gulam Vayda
• Christian Boldan
• Chris Walker

4
Individual Contributions

• Gulam Vayda
• Proposed Requirements 5, 10-12
• Project Manager (involved in all phases of
  project)
• Class Structure/Documentation
• Christian Boldan
• Proposed Requirements 1-4
• Lead Coder/Tester
• Chris Walker
• Proposed Requirements 6-9
• Maintained Group Website and Presentation
• Class Structure/Documentation

5
Requirements 1-4

• The system shall have an icon that gives the user
  the ability to open the paint program by
  double-clicking on the icon.
• The system shall, when executed, open a window
  with a title bar. Inside the window, the
  dimension shall be fixed at 800 by 600 pixels.
• The system shall contain a white canvas inside
  the window with a dimension of 600 by 600 pixels.
• The system shall contain a panel of buttons on
  the left hand side of the window with a dimension
  of 200 by 600 pixels, which will represent all
  the drawing functions that the user can use as
  well as all the color options available for each
  function.

6
Requirements 5-8

• The system shall limit the user to the following
  color selection for each drawing function white,
  black, red, yellow, blue, green, orange, and
  purple.
• The system shall contain four drawing functions,
  the first of which is the Pen, allowing the
  user to draw a 2-pixel-wide, freeform line.
• The system shall have a second drawing function,
  the Brush, allowing the user to draw an
  8-pixel-wide, freeform line.
• The system shall have a third drawing function,
  the Paintroller, allowing the user to draw a
  16-pixel wide, freeform line.

7
Requirements 9-12

• The system shall have a fourth and final drawing
  function, the Paintcan, allowing the user to
  change an area of one color to another color.
• The system shall contain a menu bar directly
  below the title bar (which is not a part of the
  800 by 600 pixel window).
• The system shall have two options of the menu
  bar, the first of which is the Clear Canvas
  option, allowing the user to make the entire
  canvas white.
• The system shall have a second and final menu
  option, Close, allowing (perhaps redundantly)
  the user to close the window and program.

8
Design / Class Structure
Canvas
Action Listener
MouseInputListener
JFrame
Paint menuBar JMenuBar fileMenu
JMenu clearCanvas JMenuItem closeApp
JMenuItem black yellow JButton pen
JRadioButton brush JRadioButton paintroller
JRadioButton paintcan JRadioButton toolPanel
JPanel colorPanel JPanel buttonPanel
JPanel aWindow JFrame --------------------------
----- paint(Graphics g) void
MyMouseHandler -------------------------- mouseC
licked(MouseEvent e) void mouseDragged(MouseEven
t e) void
JPanel
JRadioButton
MyButtonHandler -------------------------- actio
nPerformed(ActionEvent e) void
JButton
JMenuBar
JMenu
JMenuItem
9
Implementation
10
Implementation
11
Requirement 9 The Paintcan

• Requirement Definition
• Drawing function that fills in an area of one
  color with another color
• Possible Implementation
• When clicked on the canvas, a method looks for
  all pixels of the same color surrounding the
  pixel clicked and changes it to the color
  selected (perhaps using some methods in Canvas
  class)

12
Summary

• Web Junkies Work Distribution
• Requirements 1-12 and Design
• 11 Requirements Implemented
• 1 Requirement Yet To Be Done!
