CS 603 Mid-Semester Review

1
CS 603Mid-Semester Review

• March 4, 2002

2
One or Two Day Review?

• One day Skim material and Test Overview
• What to do with Wednesday?
• More on replication
• Start on distributed processes
• Two day Discuss material to date
• Wednesday
• Finish Review
• Work out sample question

3
Basics

• Why do we want distributed systems?
• Scaling
• Heterogeneity
• Geographic Distribution
• What is a distributed system?
• Transparency vs. Exposing Distribution
• Hardware Basics
• Communication Mechanisms

4
Basic Software Concepts

• Hiding vs. Exposing
• Distribution Distributed OS
• Location, but not distribution Middleware
• None Network OS
• Concurrency Primitives
• Semaphores
• Monitors
• Distributed System Models
• Client-Server
• Multi-Tier
• Peer to Peer

5
Communication Mechanisms

• Shared Memory
• Enforcement of single-system view
• Delayed consistency d-Common Storage
• Message Passing
• Reliability and its limits
• Stream-oriented Communications
• Remote Procedure Call
• Remote Method Invocation

6
RPC Example DCE

• Language / Platform Independent
• Implementation Issues
• Data Conversion
• Underlying Mechanisms
• Fault Tolerance Approaches

7
Java RMI

• Supports remote invocation of Java objects
• Key Java Object SerializationStream objects
  over the wire
• Language specific
• Advantages
• True object-orientation Objects as arguments
  and values
• Mobile behavior Returned objects can execute on
  caller
• Integrated security
• Built-in concurrency (through Java threads)
• Disadvantage Java only
• Implementation / Use
• Registry

8
SOAP

• Goal RPC protocol that works over wide area
  networks
• Interoperable
• Language independent
• Problem Firewalls
• Solution HTTP/XML
• Client side Ability to generate http calls and
  listen for response
• Server
• Listen for HTTP
• Bind to procedure
• Respond with HTTP
• SOAP message format and use mechanisms

9
Naming Requirements

• Disambiguate only
• Access resource given the name
• Build a name to find a resource
• Do humans need to use name?
• Static/Dynamic Resource
• Performance Requirements

10
Naming Approaches

• Scope
• Global vs. Hierarchical
• Unique ID vs. Non-Unique Description
• Namespaces
• URN, URI, URL
• Registries

11
Registry Example X.500

• Goal Global white pages
• Lookup anyone, anywhere
• Developed by Telecommunications Industry
• ISO standard directory for OSI networks
• Idea Distributed Directory
• Application uses Directory User Agent to access a
  Directory Access Point

12
Directory Information Base(X.501)

• Tree structure
• Root is entire directory
• Levels are groups
• Country
• Organization
• Individual
• Entry structure
• Unique name
• Build from tree
• Attributes Type/value pairs
• Schema enforces type rules
• Alias entries

13
X.500

• Directory Entry
• Organization level CNPurdue University, LWest
  Lafayette
• Person level CNChris Clifton, SNClifton,
  TITLEAssociate Professor
• Directory Operations
• Query, Modify
• Authorization / Access control
• To directory
• Directory as mechanism to implement for others

14
X.500 Distributed Directory

• Directory System Agent
• Referrals
• Replication
• Cache vs. Shadow copy
• Access control
• Modifications at Master only
• Consistency
• Each entry must be internally consistent
• DSA giving copy must identify as copy

15
X.500 Subsets

• LDAP
• X.500 without OSI
• Intended for use over IP
• Active Directory
• Microsofts answer to LDAP
• Extensible default naming schema
• Limited replication facilities

16
Clock Synchronization

• Definition All nodes agree on time
• What do we mean by time?
• What do we mean by agree?
• Lamport Definition Events
• Events partially ordered
• Clock counts the order

17
Event-based definition(Lamport 78)

• Define partial order of processes
• A ? B A happened before B Smallest relation
  such that
• If A and B in same process and A occurs first, A
  ? B
• If A is sending a message and B is receipt of a
  message, A ? B
• If A ? B and B ? C, then A ? C
• Clock C(x) is time x occurs
• C(x) Ci(x) where x running on node i.
• Clocks correct if ? a,b a?b ? C(a) lt C(b)

18
Lamport Clock Implementation

• Node i Increments Ci between any two successive
  events
• If event a is sending of a message m from i to j,
• m contains timestamp Tm Ci(a)
• Upon receiving m, set Cj current Cj and gt Tm
• Can now define total ordering. a ? b iff
• Ci(a) lt Cj(b)
• Ci(a) Cj(b) and Pi lt Pj

19
What if we want wall clock time?

• Ci must run at correct rate
• ? ? ltlt 1 such that dCi(t)/dt 1 lt ?
• Synchronized
• ? small e such that ? i,j Ci(t) Cj(t) lt e
• Assume transmission time between µ and µ?
• Algorithm Upon receiving message m,set Cj(t)
  max(Cj(t), Tmµ)
• Theorem Assume every t seconds a message with
  unpredictable delay ? is sent over every arc.
  Then ? t t0 td, e d(2?t ?)

20
Clock SynchronizationLimits

• Best Possible Delay Uncertainty
• Actually e(1 1/n)
• Synchronization with Faults
• Faulty clock
• Communication Failure
• Malicious processor
• Worst case Can only synchronize if lt 1/3
  processors faulty
• Better if clocks can be authenticated

21
Real example NTP

• I doubt you need to review this...

22
Process Synchronization

• Problem Shared Resources
• Model as sequential or parallel process
• Assumes global state!
• Alternative Mutual Exclusion when Needed
• Coordinator approach
• Token Passing
• Timestamp

23
Mutual Exclusion

• Requirements
• Does it guarantee mutual exclusion?
• Does it prevent starvation?
• Is it fair?
• Does it scale?
• Does it handle failures?

24
CS 603Mid-Semester Review

• March 6, 2002

25
Mutual ExclusionColored Ticket Algorithm

• Goals
• Decentralized
• Fair
• Fault tolerant
• Space Efficient
• Idea Numbered Tickets
• Next number gets resource
• Problem Unbounded Space
• Solution Reissue blocks

26
Multi-ResourceMutual Exclusion

• New Problem Deadlock
• Processes using all resources
• Each needs additional resource to proceed
• Dining Philosophers Problem
• Coordinated vs. truly distributed solutions
• Problems with deterministic solutions
• Probabilistic solution Lehman Rabin
• Starvation / fairness properties

27
Distributed Transactions

• ACID properties
• Issues
• Commit Protocols
• Fault Tolerance
• Why is this enough?
• Failure Models and Limitations
• Mechanisms
• Two-phase commit
• Three-phase commit

28
Two-Phase Commit(Lamport 76, Gray 79)

• Central coordinator initiates protocol
• Phase 1
• Coordinator asks if participants can commit
• Participants respond yes/no
• Phase 2
• If all votes yes, coordinator sends Commit
• Participants respond when done
• Blocks on failure
• Participants must replace coordinator
• If participant and coordinator fail, wait for
  recovery
• While blocked, transaction must remain Isolated
• Prevents other transactions from completing

29
Transaction Model

• Transaction Model
• Global Transaction State
• Reachable State Graph
• Local states potentially concurrent if a
  reachable global state contains both local states
• Concurrency set C(s) is all states potentially
  concurrent with s
• Sender set S(s) local states t t sends m and
  s can receive m
• Failure Model
• Site failure assumed when expected message not
  received in time
• Independent Recovery

30
Problems with 2-PC

• Blocking on failure
• 3-PC as solution
• Theorems on recovery limits
• Independent recovery No two-site failure
• Non-independent recovery
• Anything short of total failure okay
• Recovery protocol for total failure

31
3PC assuming timeout on receipt of message
Coordinator
Participant
q1
q2
start xact/ no
start xact/ yes
xact request/ start xact
abort/ -
w1
w2
no/ abort
yes/ pre-commit
pre-commit/ ack
p1
p2
ack/commit
commit/ -
32
Termination Protocol

• If participant times out in w2 or p2
• Elect new Coordinator
• If coordinator alive, would have
  committed/aborted
• New coordinator requests state of all processes.
  Termination rules
• If any aborted, broadcast abort
• If any committed, broadcast commit
• If all w2, broadcast abort
• If any p2, send pre-commit and enter state p1
• Complete failure protocol

33
Test Basics

• Mechanics Open book/notes
• No electronic aids
• Two questions
• Each multi-part
• Will include scoring suggestions
• Underlying question Do you understand the
  material?
• No need to regurgitate best in literature
  answer
• Reasonable self-designed solution fine
• Key Do you really understand your answer
• Can you build CORRECT distributed systems?

34
Sample QuestionClock Synchronization

• Develop synchronization protocol for a four
  processor system with fully-connected processors.

• Linear envelope of real time
• Bounded difference between clocks on correct
  processors.
• Time set to 0 when the protocol begins (but not
  synchronized).
• Assume
• Clocks don't drift
• Messages take between time 0 and e
• At most one faulty processor
• No authentication

• Discuss the correctness of your algorithm,
  including the types of faults handled.
• Scoring
• Protocol Up to five points
• Argument for correctness 2 points
• requires believable proof sketch for full 2
  points
• Faults supported / not supported 1-3 points
• 3 points requires proof sketch that it handles
  supported faults and examples showing failure
  with unsupported fault types.
