NN4ZZ Tilt Plate Project

1
NN4ZZ Tilt Plate Project

• June 2007 -- V7

2
Goals

• Free standing, tilt-over tower
• Gain antenna for 20-10M
• Antenna height 70-80 feet
• Convenient operation
• Antenna maintenance from
• the ground, no ladders or climbing

3
Tower and Antennaselection

• U.S. Towers MA-850
• Steppir 4 el yagi
• The next few slides show the tower construction
  and steppir specs

4
U S Tower MA 850
5
MA-850 foundation

• 7 x 7 x 7 -- 13.5 yrds
• 4,000 psi fiberglass

6
Tiltover base

7
Motorized winches
8
Steppir 4 element

• Monobander on 20-10
• Control from the shack
• Tracks transceiver

9
Steppir Specifications
10
Problem / Solution / Strategy

• Problem - How to lower an antenna with a 32 foot
  boom and 36 ft elements to ground level.
• Solution - Develop a method to tilt the antenna
  so it can be lowered to ground level for all
  maintenance
• Strategy - Keep it simple, make it sturdy
• Over engineer the design. If its worth doing,
  its worth over-doing

11
Tiltplate 1 2 - Two versions

• The first design (tiltplate1) has been in service
  since April 2004.
• I decided to build another one for my second
  tower. A new design (tiltplate2) was created
  with direct rotator mounting.
• The power point is divided into sections to
  highlight both designs
• Both versions work equally well

12
Tiltplate 1 2 - Common Components

• Steppir 4 element 20-10 meter yagi,
• U S Tower MA 850, 85 foot tubular crankup tower
  with motorized winches.
• Same bearings, shaft, etc used for both designs.

• Aluminum plate material is the same, just cut
  differently

13
Tiltplate 1Mast mounted plate design.Major
Components

• Yaesu G-2800 DXA rotor
• Aluminum plates hinged on an aluminum shaft. Use
  of pillow bearings to provide tilting capability

14
G-2800 DXA
15
Tiltplate diagram

16
Design Notes

• Uses gravity to hold boom plate in place. Boom
  plate is held about 5 degrees off vertical. The
  boom is rotated to compensate for the offset and
  to keep antenna elements parallel to the ground
• No latch - allows boom plate to tilt in high wind
• Supports a dynamic loads of 3,000 pounds on
  bearings, shaft.
• Boom plate is kept close to the rotor to minimize
  offset load

17
Tiltplate Materials

• Stainless steel clamps, McMaster Carr part
  29535T11 (for 1 diam shaft) pg 1446
• ½ inch aluminum plate 18 x 12, McMaster Carr
  89155 k29
• Severe duty pillow block bearings, McMaster Carr
  6494K14
• 1 inch diameter aluminum shaft, McMaster Carr
  5911k36

18
Aluminum Shaft
19
Bearings
20
U bolts for shaft
21
Tiltplate
22
Building the Steppir
23
Fully Assembled(Tower tilts to the left and
toward viewer. Elements are parallel to the
tower)
24
Closeup of Tiltplate

25

26
Tiltplate 2Rotator direct mounting
design.Major Components

• Same basic concept. Same materials used for
  construction.
• Also using a Yaesu G-2800 DXA rotor
• Mast plate directly mounted to the rotor instead
  of using a mast
• Fewer parts (no mast or mast clamps)

27
G-2800 DXA
28
TiltPlate 2
29
Tiltplate 2

• Direct mount to rotator
• Eliminates the possibility of mast slippage
• Same basic tiltplate design
• Fewer parts (no mast or mast clamps)
• Cleaner look

30
Tiltplate 2 installed
31
Tiltplate 2 - view from below
32
Tiltplate 2 tower at 70 degrees
33
The Wind

• Most frequent question is does it bang around in
  the wind? Answer No does not move at all
  expect in high winds over 30 MPH
• Wind from the ends has no effect
• Wind from the boom plate adds to down force
• Wind from mast plate is mostly blocked
• Designed to gently lift in very heavy wind

34
Tiltplate performance

• No surprises
• Highest wind gust so far, 52 MPH on July 4, 2004
• Smooth tilting operation, no problems in over 3
  years of operation
• Costs about 400, most expensive item is the
  aluminum plate.

35
Completed project

36
For More Information

• Web page www.nn4zz.com
• Email al_at_nn4zzk.com
• Opening slide, the wave Page, AZ
• Dish Antennas, the Very Large Array in Socorro,
  NM
