MEETING THE WATER DEMANDS

1
MEETING THE WATER DEMANDS FOR THE KINGDOM OF
SAUDI ARABIA Major Investment Opportunities
in the 21st Century November 13-15, 2000
2
(No Transcript)
3
OBJECTIVES OF THE PRESENTATION

• AN OVERVIEW OF GLOBAL WATER SUPPLY AND DEMAND
• SUMMARY OF WATER SERVICES IN THE KINGDOM
• SCOPE OF SERVICES OF SALINE WATER CONVERSION
  CORPORATION (SWCC)
• A FUTURE OUTLOOK OF WATER SUPPLY AND DEMAND IN
  THE KINGDOM AND BUDGETARY CONSEQUENCES.
• CONCLUDING REMARKS

4
AN OVERVIEW OF GLOBAL WATER SUPPLY AND DEMAND
5
WORLD WATER SURVEY(1)

• WATER RESOURCES (100 )
  1,384,000,000(Km)3
• SWEET WATER (2.6 )
  36,000,000(Km)3
• SWEET WATER USABLE (0.24 )
  2,880,000(Km)3
• ANNUAL TOTAL PRECIPITATION (0.03 )
  423,000(Km)3
• ANNUAL RAIN ON THE
• CONTINENTS
  (0.007 ) 97,000(Km)3
• ANNUAL SWEET WATER
• CONSUMPTION
  (0.0002 ) 2,838(Km)3
• ANNUAL DRINKING WATER
• CONSUMPTION
  (0.000015 ) 201(Km)3
• or 0.2 of the continental
  precipitation.

(1) The UNO - Drinking- Water Decade (1980 - 1991)
6
GROWTH OF WORLD POPULATION (1)
(1) The UNO - Drinking- Water Decade (1980 - 1991)
7
Development of World Population
(1)
Inhabitants in million
(1) The UNO - Drinking- Water Decade (1980 - 1991)
8
Situation of Global Water Supply
(1)
In of supplied population
(1) The UNO - Drinking- Water Decade (1980 - 1991)
9
Situation of Global Waste Water Disposal
(1)
Population with sanitation in
(1) The UNO - Drinking- Water Decade (1980 - 1991)
10
Worldwide Cumulative Capacity of all land-based
desalting plants capable of producing 100
(m3/d)/unit or more fresh water vs. Contract year.
(1)
Contracted Capacity (m3/day)
Contract Year
(1) 2000 IDA Worldwide Desalting Plants Inventory
Report No. 16
11
SUMMARY OF WATER SERVICES IN THE KINGDOM
12
POTABLE WATER SOURCES IN THE KINGDOM
SURFACE WATER (LAKES, RIVERS, DAMS)
UNDERGROUND WATER
SEAWATER DESALINATION
13
AUTHORITIES RESPONSIBLE FOR WATER ACTIVITIES IN
THE KINGDOM OF SAUDI ARABIA
14
SCOPE OF SERVICES OF SALINE WATER CONVERSION
CORPORATION (SWCC)
15
HISTORICAL BACKGROUND OF SEAWATER DESALINATION
IN THE KINGDOM OF SAUDI ARABIA

• 1348H (1928G) ESTABLISHMENT OF THE FIRST TWO SEA
  WATER CONDENSERS AT JEDDAH BECAME KNOWN AS
  AL-KINDASA.
• 1385H (1965G) AN OFFICE HAD BEEN ESTABLISHED AT
  THE MINISTRY OF AGRICULTURE WATER FOR
  FEASIBILITY STUDY AND THE PREPARATORY STEPS FOR
  DESALINATION PLANTS CONSTRUCTION.
• 1389 H (1969G) OPERATING PHASE 1 OF AL-WAJH
  AND DUBA PLANTS.
• 1390 H (1970G) OPERATING JEDDAH PLANT PHASE 1.
• 1392 H(1972G) ASALINE WATER CONVERSION
  DEPUTYSHIP HAD BEEN ESTABLISHED AT THE MINISTRY
  OF AGRICULTURE AND WATER.
• 1393 H (1973G) OPERATING AL-KHOBAR PLANT (PHASE
  1).
• 1394H (1974G) ROYAL DECREE NO. M/49
  ESTABLISHING SALINE WATER CONVERSION
  CORPORATION AS AN INDEPENDENT GOVERNMENTAL
  ENTITY.
• 1394 H (1975G) OPERATING UMLUJ PLANT PHASE 1.
• 1398H (1978G) OPERATING JEDDAH PLANT PAHSE
  II (SWCC HAS TAKEN THE RESPONSIBILITY OF
  OPERATING AND MAINTAINING OF ITS PLANTS)
• 1399H (1979G) OPERATING FIVE PLANTS AT
  AL-WAJH, DUBA PHASE 1, JEDDAH PHASE III
  HAQL PHASE 1.

16
HISTORICAL BACKGROUND OF SEAWATER DESALINATION
IN THE KINGDOM OF SAUDI ARABIA

• 1401 H (1981G) OPERATING YANBU PLANT PHASE 1
  JEDDAH PHASE IV.
• 1402 H (1982G) OPERATING THREE PLANTS AT
  AL-JUBAIL PHASE 1, RABIGH PHASE 1 AL-KHOBAR
  PHASE II AND THE TRAINING CENTER AT JUBAIL.
• 1403 H (1983G) OPERATING AL-BIRK PLANT PHASE
  1, AL-JUBAIL PLANT PHASE II.
• 1407H (1986G) OPERATING AL-WAJH PLANT FIRST
  EXTENSION, AL-KHAFJI AND UMLUJ PLANTS PHASE
  II.
• 1409H (1989G) OPERATING FIVE PLANTS AT DUBA
  PHASE III, AL-WAJH SECOND EXTENSION, JEDDAH
  R.O. PHASE 1, SHOAIBA PHASE 1 AND SHUGAIG
  PHASE 1.
• 1410 H (1990G) OPERATING OF HAQL PLANT PHASE
  II AND FARASAN PLANT FIRST EXTENSION.
• 1413 H (1993G) OPERATING OF AL-WAJH THIRD
  EXTENSION.
• 1414 H (1994G) OPERATING JEDDAH R.O. PLANT
  PHASE II RABIGH FIRST EXTENSION.
• 1419 H (1999G) OPERATING YANBU PHASE II (MSF
  R.O.).
• 1421 H (2000G) PARTIAL COMMISSIONING OF
  AL-KHOBAR (PHASE III), SHOAIBA (PHASE II).

17
HAQL
AL-KHAFJI
DUBA
ALZULFI
ALMAGMAAH
AL-JUBAIL
HODATSIDAIR
AL-WAJH
BRAIDAH
AL-KHOBAR
ALHISI
UMM LAJJ
ALGHAT
ALMADINA
SHGRA
YANBU MADINAH
RIYADH
RABIGH
MAKKAH
AZIZIA
JEDDAH
TAIF
SHOAIBA
AL-BIRK
ABHA
KHAMIS MUSHAIT
SHUQAIQ
FARASAN
18
HAQL R.O. PLANT PHASE II 3,784 m3/d
ALWAJH (MSF)PHASEII 473 m3/d ALWAJH(MED)TR1
825 m3/d ALWAJH (MED)TR2 1032 m3/d
ALWAJH (MSF)TR3 473 m3/d
DUBA R.O. PLANT PHASEIII 3,784 m3/d
UMMLUJJ R.O. PLANT PHASE II 3,784 m3/d
YANBU-MADINAH PLANTS PHASE I MSF 94,625
m3/d 250 MW PHASEII MSF 120,096 m3/d 35
MW PHASE II R.O. 106,904 m3/d
RABIGH MSF PHASE1 1204 m3/d RABIGH MSF TR1
774 m3/d
AZIZIA MED PLANT 3,870 m3/d
JEDDAH MSF PLANTS PHASE II
37,916 m3/d 71 MW PHASE III
75,987 m3/d 200 MW PHASE IV 190,555
m3/d 500 MW JEDDAH R.O.-1 48,848
m3/d JEDDAH R.O.-2 48,848 m3/d
ALSHOAIBA MSF PLANT PHASE I 191,780 m3/d
157 MW
ALSHOAIBA MSF PLANT PHASE II 390,909 m3/d
340 MW
AL-BIRK R.O. PLANT PHASE I 1,952 m3/d
SHUQAIQ MSF PLANT PHASE I 83,432 m3/d 62 MW
FARASAN MSF PH.I 430 m3/d FARASAN MSF TR1
1075 m3/d
19
AL-KHAFJI MSF PLANT PHASE II 19,682 m3/d
AL-JUBAIL MSF PLANTS PHASE I 118,447 m3/d
238 MW PHASEII 815,185 m3/d 762 MW
AL-JUBAIL R.O PLANT 78,182 m3/d
AL-KHOBAR MSF PLANT PHASE II 191,780 m3/d
500 MW
AL-KHOBAR MSF PLANT PHASE III 240,800 m3/d
311 MW
20
SWCC DESALINATION POWER PLANTS
21
(No Transcript)
22
Development in SWCC Installed Water
Capacities(Includes Decommissioned Plants)
Cumulative Contracted Capacity (m3/day)
Contract Year
23
Development in SWCC Installed Electric Power
Capacities (Includes Decommissioned Plants)
Cumulative Contracted Capacity (MW)
Contract Year
24
Annual Desalinated Water Exported by SWCC Plants
(from 1981 to 1999)
Million Cubic Meter Per Year
25
Annual Electric Energy Exported by SWCC Plants
(from 1981 to 1999)
Million Megawatt Hour
26
Years of Training Operation Maintenance
Graduates 2507
O M Graduates Number
27
Years of Training Engineers Graduates 263
Engineers Graduates Number
28
O M MANPOWER
29
PERCENTAGE BREAKDOWN OF THE AVERAGE WATER COST
OF SWCC PLANTS

• CAPITAL COST 37.3

• LABOUR
  22.1
• ENERGY
  32.5
• MAINTENANCE 6

• CHEMICALS
  2.1

30
WATER ELECTRIC ENERGY PRODUCTION COST (1998)
31
(No Transcript)
32
(No Transcript)
33
A FUTURE OUTLOOK OF WATER SUPPLY DEMANDIN THE
KINGDOM AND BUDGETARY CONSEQUENCES
34
FORECASTED POPULATION GROWTH IN THE KINGDOM OF
SAUDI ARABIA
35
Decommissioning of the Existing SWCC Desalination
Plants (from 2000 to 2020)
(m3/day)
36
(No Transcript)
37
ASSUMPTIONS USED TO ESTIMATE FUTURE BUDGETS

• Desalinated seawater accounts for 50 of water
  supply.
• New plant size has been taken as 60 MIGD to meet
  the water demand with corresponding power of 360
  MW (16 ratio).
• Plants construction starts 5 years ahead of
  required production date.
• Construction expenditure is over 5 years (10,
  20, 35, 25 and 10 each year consecutively).

38
(No Transcript)
39
(No Transcript)
40
(No Transcript)
41
CONCLUDING REMARKS
42
CONCLUDING REMARKS

• CONSOLIDATE THE WATER SERVICES
• PROVIDE MANAGEMENT FLEXIBILITY.
• INVEST IN EXISTING INFRASTRUCTURE
• REHABILITATE DESALINATION PLANTS
• REDUCE DISTRIBUTION NETWORK LEAKAGES
• OTHERS
• CONSERVE
• PUPLIC CAMPAIGNS
• LEGISLATION
• ALTERNATIVES
• TARIFF
• REUSE (RECYCLE)
• RESEARCH DEVELOPMENT
• STUDY PRIVATE SECTOR INVOLVEMENT

43
See our SWCC site www.swcc.gov.sa
Water Means Life
THANK YOU FOR YOUR ATTENTION
