Energy Conservation and Efficiency

1
Energy Conservation and Efficiency

• Where Does the Wasted Energy Go?

2
Heat and Thermal Energy

• All matter is made of atoms/molecules, which move
  around randomly
• Thermal Energy The energy stored in the
  individual motion of atoms or molecules
• Heat The thermal energy transferred from one
  place to another

3
E mc2

• Albert Einstein showed that mass can be converted
  into energy and visa versa
• The total amount of energy (in Joules) contained
  in m kg of mass is
• E m x c2
• Where c is the speed of light (3 x 108 m/s)

4
The Law of Conservation

• The total mass and energy of the universe never
  changes (I.e. it is conserved)
• Mass Energy Constant
• We extract energy by converting a tiny amount of
  mass into energy
• In practice, the amount of mass converted to
  energy is always small!

5
Example

• A gallon of gasoline (about 3.3 kg) can produce
  1.3 x 108 Joules of energy
• How much mass is converted to energy?
• Answer m E/c2 1.3 x 108/9 x 1016
• 1 x 10-9 kg
• Where does the rest of the mass go?

6
The Approximate Law of Conservation

• In most situations, the amount of mass converted
  to energy is tiny
• In practice, then
• 1.) The total amount of energy is conserved
• 2.) The total amount of mass is conserved
• Energy and mass are conserved separately!

7
Example Conservation of Mass
Smoke, gas, soot
Fuel, Air
Total Mass In Total Mass Out
8
Example Conservation of Energy
Chemical Energy in Fuel
Heat, Electricity
Total Energy In Total Energy Out
9
Stored Energy

• Energy can be stored in a system if it enters but
  doesnt leave
• Energy In Energy Out Energy Stored
• (English) What goes in must either stay in or
  come out
• Energy can never be created or destroyed, only
  wasted!

10
Example Solar House

• Energy in sun heats the house through windows
• Energy out heat leaks out through walls and
  windows
• Energy stored heat is stored in walls and floors

11
Energy Efficiency

• Not all energy in a system can be converted into
  useful work (2nd law of thermodynamics)

12
Example

• A fossil fuel plant releases 6 x 108 J of energy
  from burning oil in one day. It produces 2 x 108
  J of electricity. What is the efficiency?
• Answer efficiency
• (2 x 108)/(6 x 108)x100
• 30

13
Power and Efficiency

• Power input and output can also be used to
  calculate efficiency in exactly the same way

14
Where Does it Go?
Answer The wasted energy goes into heating the
lake and combustion gases
15
Some Typical Efficiencies
16
Overall Efficiency

• The overall efficiency of a multiple-step energy
  conversion is the product of the individual
  efficiencies

17
Friction and Heat

• Friction is the principal means of energy loss in
  many machines
• Friction energy losses produce heat

18
Automobile Efficiency

• Thermal Efficiency percentage of chemical energy
  in gasoline converted into work (moving the
  pistons)--typically 38
• Mechanical Efficiency percentage of engine work
  used to move vehicle--typically 50
• Overall Efficiency (0.38)(0.5)x100
• 19

19
Where Does it Go?

• Most of the engine work creates heat (engine
  friction)
• Most of the remaining energy is used to overcome
  air and rolling resistance
• Maximum fuel efficiency at 40 mph!

20
Automobiles Then and Now
