Guanella Pass Spot Surfacing Evaluation

1
Guanella Pass Spot Surfacing Evaluation
2
Introductions
3
Presentation Agenda

• Goal and Purpose
• Background Information
• Environmental Path
• Environmental Considerations
• Question and Answers
• Open House

4
Goal Purpose of the Meeting

• Evaluation of a change in surface type
• Gravel and macadam sections
• Surfacing is not performing in some locations
• Public investment is in danger of being lost
• Seeking public input on the change in surface
  type

5
Purpose Need of the Guanella Pass Project

• Transportation Needs
• Accommodate anticipated traffic volumes
• Improve inadequate surface condition
• Improve safety
• Accommodate Forest local access

6
Purpose Need of the Guanella Pass Project

• Environmental Needs
• Reduce impacts to water resources
• Repair existing unvegetated slopes
• Maintain rural scenic character
• Maintenance Needs
• Roadway maintenance cost
• Drainage
• Dealing with untreated roadway surface conditions

7
Preferred Alternative Selection

• Alternative 6 was selected
• Used a lower design standard to allow for a
  slower design speed
• Closely followed the existing roadway as much as
  possible
• Consisted of three surfacing types

8
Progress to Date

• Phase 1 was completed in 2007
• Phase 2 construction is underway projected
  completion in October 2010
• Phase 3 design is underway currently programmed
  for construction starting in 2012

9
Development of an Outstanding Scenic Roadway

• Cooperation between public government
• Collaboration resulted in an outstanding roadway
• Workshops resulted in design enhancements
• Rockery walls
• Steel-backed timber guardrail
• Retaining wall facing

10
Development of an Outstanding Scenic Roadway
11
Development of an Outstanding Scenic Roadway
12
Development of an Outstanding Scenic Roadway
13
Development of an Outstanding Scenic Roadway
14
Design Enhancements to Benefit Wildlife

• The road design included special features for
  wildlife protection
• Additional gaps in guardrails
• Berms or boulders to facilitate crossing
• Wall height has been reduced.
• Improved aquatic habitat and fish passage

15
Wildlife Enhancements
16
Wildlife Enhancements
17
Recent Developments

• Roadway surface type in spot areas is not
  performing as anticipated
• Erosion and loss of vegetation
• Safety concerns from rutting, washboarding and
  premature failures
• Water quality concerns
• Potential loss of investment

18
Preparation of a Route Assessment

• Due to the problems that were being observed,
  CFLHD requested that an assessment of the route
  be performed
• Report is currently available on the website
• www.cflhd.gov/guanellapassroad

19
Findings of the Route Assessment

• Overall Purpose and Need objectives are being met
  (globally)
• Some objectives are not being met in spot areas
  (gravel and macadam sections)
• These problems are putting the overall investment
  at risk

20
Potholes and Rutting
21
Rutting
22
Loss of Macadam Surface
23
Loss of Macadam Surface
24
Loss of Macadam Surface
25
Safety

• Reducing the potential for a change to driver
  expectations (lane shoulder widths)
• Removal or mitigation of hazards
• Self regulating/self enforcing roadway
• Providing a uniform roadway surface

26
Soil Erosion Sedimentation
27
Surfacing Erosion
28
Soil Erosion Sedimentation
29
Vegetation Damage
30
Findings from the Route Assessment

• Degradation is expected to continue and worsen in
  some sections
• Leads to increased erosion, water quality
  problems, decreased safety and greatly increased
  maintenance needs/costs

31
Recommendations from the Route Assessment

• A permanent and sustainable surface in the gravel
  and macadam sections is needed

32
Proposed Changes

• Place an asphalt surface with a chip seal overlay
  on gravel and macadam sections
• A permanent and sustainable surface to address
  the deficiencies observed

33
Environmental Path

• Environmental Evaluation will guide the next step
  we will determine whether our proposed change
  will result in any new significant impacts

34
Environmental Issues Considerations

• Key Issues
• Rural and Scenic Character of the Roadway
• Traffic Analysis
• Impacts to Wildlife
• Water Quality
• Construction Impacts
• Others?

35
Rural and Scenic Character
36
Rural and Scenic Character
37
Rural and Scenic Character
38
Traffic Analysis

• Traffic Volumes
• Traffic Speeds
• Both overall speed and speeds at the Summit
• Travel Time

39
Travel Time to Metro Denver

40
Traffic Analysis Conclusions

• Traffic Volumes are not expected to change
• Traffic Speed increases will be barely
  perceptible
• Guanella Pass will not provide a shorter travel
  time to Denver

41
Wildlife Impacts

• Road footprint is not widened from that
  identified in Record Of Decision and Biological
  Opinion
• Special design considerations will remain in place

42
Water Quality

• Changing the surfacing type will reduce sediment
  coming off the road and will reduce erosion and
  vegetation concerns
• This will result in improvements to vegetation
  and water quality

43
Construction Impacts

• All disturbance resulting from the proposed
  action will occur on the existing roadway bench

44
Questions Comments

• Please provide comments to us today either
  verbally or in writing. You can also mail us
  your written comments by April 6, 2009
• Mark Meng, P.E.
• 12300 W. Dakota Ave.
• Suite 380
• Lakewood, CO 80228
• Mark.Meng_at_fhwa.dot.gov
