Toward Validation and Control of Network Models

1
Toward Validation and Control of Network Models

• Michael Mitzenmacher
• Harvard University

2
Internet Mathematics
Articles Related to This Talk
The Future of Power Law Research
A Brief History of Generative Models for Power
Law and Lognormal Distributions
3
Motivation General

• Network Science and Engineering is emerging as
  its own (sub)field.
• NSF cross-cutting area starting this year.
• Courses Cornell (Easley/Kleinberg), Kearns (U
  Penn), many others.
• For undergrads, not just grads!
• In popular culture books like Linked by
  Barabasi or Six Degrees by Watts.
• Other sciences Economics, biology, physics,
  ecology, linguistics, etc.
• What has been and what should be the research
  agenda?

4
My (Biased) View

• The 5 stages of networking research.
• Observe Gather data to demonstrate a behavior
  in a system. (Example power law behavior.)
• Interpret Explain the importance of this
  observation in the system context.
• Model Propose an underlying model for the
  observed behavior of the system.
• Validate Find data to validate (and if
  necessary specialize or modify) the model.
• Control Design ways to control and modify the
  underlying behavior of the system based on the
  model.

5
My (Biased) View

• In networks, we have spent a lot of time
  observing and interpreting behaviors.
• We are currently very active in modeling.
• Many, many possible models.
• Perhaps easiest to write papers about.
• We need to now put much more focus on validation
  and control.
• Have been moving in this direction.
• And these are specific areas where computer
  science has much to contribute!

6
Models

• After observation, the natural step is to
  explain/model the behavior.
• Outcome lots of modeling papers.
• And many models rediscovered.
• Example power laws
• Lots of history

7
History

• In 1990s, the abundance of observed power laws
  in networks surprised the community.
• Perhaps they shouldnt have power laws appear
  frequently throughout the sciences.
• Pareto income distribution, 1897
• Zipf-Auerbach city sizes, 1913/1940s
• Zipf-Estouf word frequency, 1916/1940s
• Lotka bibliometrics, 1926
• Yule species and genera, 1924.
• Mandelbrot economics/information theory, 1950s
• Observation/interpretation were/are key to
  initial understanding.
• My claim but now the mere existence of power
  laws should not be surprising, or necessarily
  even noteworthy.
• My (biased) opinion The bar should now be very
  high for observation/interpretation.

8
So Many Models

• Preferential Attachment
• Optimization (HOT)
• Monkeys typing randomly (scaling)
• Multiplicative processes
• Kronecker graphs
• Forest fire model (densification)

9
What Makes a Good Model

• New variations coming up all of the time.
• Question What makes a new network model
  sufficiently interesting to merit attention
  and/or publication?
• Strong connection to an observed process.
• Many models claim this, but few demonstrate it
  convincingly.
• Theory perspective significant new mathematical
  insight or sophistication.
• A matter of taste?
• My (biased) opinion the bar should start being
  raised on model papers.

10
Validation The Current Stage

• We now have so many models.
• It is important to know the right model, to
  extrapolate and control future behavior.
• Given a proposed underlying model, we need tools
  to help us validate it.
• We appear to be entering the validation stage of
  research. BUT the first steps have focused on
  invalidation rather than validation.

11
Examples Invalidation

• Lakhina, Byers, Crovella, Xie
• Show that observed power-law of Internet topology
  might be because of biases in traceroute
  sampling.
• Pedarsani, Figueiredo, Grossglauser
• Show that densification may also arise by
  sampling approaches, not necessarily intrinsic to
  network.
• Chen, Chang, Govindan, Jamin, Shenker, Willinger
• Show that Internet topology has characteristics
  that do not match preferential-attachment graphs.
• Suggest an alternative mechanism.
• But does this alternative match all
  characteristics, or are we still missing some?

12
My (Biased) View

• Invalidation is an important part of the process!
  BUT it is inherently different than validating a
  model.
• Validating seems much harder.
• Indeed, it is arguable what constitutes a
  validation.
• Question what should it mean to say
  This model is consistent with observed data.

13
An Alternative View

• There is no right model.
• A model is the best until some other model comes
  along and proves better.
• Greedy refinement via invalidation in model
  space.
• Statistical techniques compare likelihood ratios
  for various models.
• My (biased) opinion this is one useful
  approach but not the end of the question.
• Need methods other than comparison for confirming
  validity of a model.

14
Time-Series/Trace Analysis

• Many models posit some sort of actions.
• New pages linking to pages in the Web.
• New routers joining the network.
• New files appearing in a file system.
• A validation approach gather traces and see if
  the traces suitably match the model.
• Trace gathering can be a challenging systems
  problem.
• Check model match requires using appropriate
  statistical techniques and tests.
• May lead to new, improved, better justified
  models.

15
Sampling and Trace Analysis

• Often, cannot record all actions.
• Internet is too big!
• Sampling
• Global snapshots of entire system at various
  times.
• Local record actions of sample agents in a
  system.
• Examples
• Snapshots of file systems full systems vs.
  actions of individual users.
• Router topology Internet maps vs. changes at
  subset of routers.
• Question how much/what kind of sampling is
  sufficient to validate a model appropriately?
• Does this differ among models?

16
To Control

• In many systems, intervention can impact the
  outcome.
• Maybe not for earthquakes, but for computer
  networks!
• Typical setting individual agents acting in
  their own selfish interest. Agents can be given
  incentives to change behavior.
• General problem given a good model, determine
  how to change system behavior to optimize a
  global performance function.
• Distributed algorithmic mechanism design.
• Mix of economics/game theory and computer science.

17
Possible Control Approaches

• Adding constraints local or global
• Example total space in a file system.
• Example preferential attachment but links
  limited by an underlying metric.
• Add incentives or costs
• Example charges for exceeding soft disk quotas.
• Example payments for certain AS level
  connections.
• Limiting information
• Impact decisions by not letting everyone have
  true view of the system.

18
My Related Work Hash Algorithms

• On the Internet, we need a measurement and
  monitoring infrastructure, for validation and
  control.
• Approximate is fine speed is key.
• Must be general, multi-purpose.
• Must allow data aggregation.
• Solution hash-based architecture.
• Eventual goal every router has a programmable
  hash engine.

19
Vision

• Three-pronged research data.
• Low Efficient hardware implementations of
  relevant algorithms and data structures.
• Medium New, improved data structures and
  algorithms for old and new applications.
• High Distributed infrastructure supporting
  monitoring and measurement schemes.

20
The High-Level Pitch

• Lots of hash-based schemes being designed for
  approximate measurement/monitoring tasks.
• But not built into the system to begin with.
• Want a flexible router architecture that allows
• New methods to be easily added.
• Distributed cooperation using such schemes.

21
What We Need
On-Chip Memory
Off-Chip Memory
CAM(s)
Memory
Hashing Computation Unit
Programming Language
Unit for Other Computation
Computation
Control System
Communication Architecture
Communication Control
22
Lots of Design Questions

• How much space for various memory levels? How to
  dynamically divide memory among competing
  applications?
• What hash functions should be included? Openness
  to new hash functions?
• What programming language and functionality?
• What communication infrastructure?
• Security?
• And so on

23
Which Hash Functions?

• Theorists
• Want analyzable hash functions.
• Dislike standard assumption of perfectly random
  hash functions.
• Hard to prove things about actual performance.
• Practitioners
• Want easy implementation, speed, small space.
• Want simple analysis (back-of-the-envelope).
• Will accept simulated results under right
  settings.

24
Why Do Weak Hash Functions Work So Well?

• In reality, assuming perfectly random hash
  functions seems to be the right thing to do.
• Easier to analyze.
• Real systems almost always work that way, even
  with weak hash functions!
• Can Theory explain strong performance of weak
  hash functions?

25
Recent Work

• A new explanation (joint work with Salil Vadhan)
• Choosing a hash function from a pairwise
  independent family is enough if data has
  sufficient entropy.
• Randomness of hash function and data combine.
• Behavior matches truly random hash function with
  high probability.
• Techniques based on theory of randomness
  extraction.
• Extensions of Leftover Hash Lemma.

26
What Functionality?

• Hash tables should be a basic primitive.
• Best hash tables cuckoo hashing.
• Worst case constant lookup time.
• Simple to build, design.
• How can we make them even better?
• Move cuckoo hashing from theory to practice!

27
Cuckoo Hashing Pagh,Rodler

• Basic scheme each element gets two possible
  locations.
• To insert x, check both locations for x. If one
  is empty, insert.
• If both are full, x kicks out an old element y.
  Then y moves to its other location.
• If that location is full, y kicks out z, and so
  on, until an empty slot is found.

28
Cuckoo Hashing Examples
A
B
C
E
D
29
Cuckoo Hashing Examples
A
B
C
F
E
D
30
Cuckoo Hashing Examples
A
B
F
C
E
D
31
Cuckoo Hashing Examples
A
B
F
C
G
E
D
32
Cuckoo Hashing Examples
E
G
B
F
C
A
D
33
Cuckoo Hashing Examples
A
B
C
G
E
D
F
34
Cuckoo Hashing Failures

• Bad case 1 inserted element runs into cycles.
• Bad case 2 inserted element has very long path
  before insertion completes.
• Could be on a long cycle.
• Bad cases occur with small probability when load
  is sufficiently low, but not low enough
• Theoretical solution re-hash everything if a
  failure occurs.
• For 2 choices, load less than 50, n elements
  gives failure rate of Q(1/n) maximum insert time
  O(log n).
• Better space utilization and rate for more
  choices, more elements per bucket.

35
Recent Work A CAM-Stash

• Use a CAM (Content Addressable Memory) to stash
  away elements that would cause failure.
• Joint with Kirsch/Wieder.
• Intuition if failures were independent,
  probability that s elements cause failures goes
  to Q(1/ns).
• Failures not independent, but nearly so.
• A stash holding a constant number of elements
  greatly reduces failure probability.
• Implemented as a CAM in hardware, or a cache line
  in hardware/software.
• Lookup requires also looking at stash.

36
Modeling Economic Principles

• Joint work with Corbo, Jain, Parkes.
• Exploration what models make sense for AS
  connectivity.
• Extending approach of Chang, Jamin, Mao,
  Willinger.
• Entering nodes link according to business model,
  utility function.
• Nodes revise their links based on new entrants.
• Like the forest fire model.
• Future considerations how to validate such
  models.

37
Conclusion My (Biased) View

• There are 5 stages of networking research.
• Observe Gather data to demonstrate power law
  behavior in a system.
• Interpret Explain the import of this
  observation in the system context.
• Model Propose an underlying model for the
  observed behavior of the system.
• Validate Find data to validate (and if
  necessary specialize or modify) the model.
• Control Design ways to control and modify the
  underlying behavior of the system based on the
  model.
• We need to focus on validation and control.
• Lots of open research problems.

38
A Chance for Collaboration

• The observe/interpret stages of research are
  dominated by systems modeling dominated by
  theory.
• And need new insights, from statistics, control
  theory, economics!!!
• Validation and control require a strong
  theoretical foundation.
• Need universal ideas and methods that span
  different types of systems.
• Need understanding of underlying mathematical
  models.
• But also a large systems buy-in.
• Getting/analyzing/understanding data.
• Find avenues for real impact.
• Good area for future systems/theory/others
  collaboration and interaction.

39
More About Me

• Website www .eecs.harvard.edu/michaelm
• Links to papers
• Link to book
• Link to blog mybiasedcoin
• mybiasedcoin.blogspot.com
