Microsystems: The Power of SMALL

1
Microsystems The Power of SMALL

• Rosemary L. Smith
• MicroInstruments Systems Laboratory (MISL)
• Dept. Electrical Computer Engineering
• UCDavis

2
Microsystems

• What are they?
• Microfabricated Systems
• the integration of microfabricated sensors,
  actuators, and electronics on a common substrate
  or in a single package.
• a.k.a. MicroElectroMechanical Systems (MEMS)
• Optical MEMS
• RF MEMS
• BioMEMS

Biological System Microsystem brain microprocess
or eyes, ears, nose microsensors arms, legs,
fingers microactuators heart
circulation microfluidics lungs digestive
track power source vocal cords display
3
Why Microsystems?
Mechanical, optical, magnetic, chemical, and
electronic devices are manufactured using silicon
integrated circuit fabrication technology

• Paradigm shift new way of thinking!
• Batch Fabrication
• low-cost, small size, sophisticated electronics
  vacuum tubes to Pentium !
• Photolithographic patterning
• dimensional precision, reproducibile
• Millions of components High functionality.

4
IC Manufacturing Process
5
Photopatterning
photoresist spun on wafer
6

• Fabrication is independent of the complexity of
  the pattern.
• Mass production
• many chips per wafer
• many wafers per batch
• many batches per day

7
Microfabrication

• The Promise
• Improved manufacturing
• Batch fabrication
• Precise dimensional control
• Well established IC technology
• New types of sensors and structures
• New materials
• New structures, by micromachining
• New Sytems capabilities
• Integration
• Auto-reconfiguring
• Swarms
• Lower Cost
• Better Performance
• More Function per unit volume

Invest NOW !
8
Microelectronic Devices as Sensors
Resistors .Strain Capacitors
Displacement Diodes Optical Transistors
pH Circuits Temperature

• Proportional To Absolute Temperature (PTAT)
  circuit AD590
• R 1 µA/K , - 55 C ltTlt 150 C

9
Ion Selective Field Effect Transistor
MOSFET
Ion Selective Membrane
S. D. Collins, UCDavis
10
Micromachining

• Collection of technologies that create 3D
  microstructures on or within a substrate.
• Surface Micromachining
• Bulk Micromachining
• wet chemical etching
• dry plasma etching Reactive Ion Etching
• LIGA electroforming
• MicroMolding
• SU-8 Photocured epoxy

11
Surface Micromachining
Structural Layers Sacrificial Layers Etchant Polys
ilicon (Silicon) Silicon Dioxide HF Polymers Metal
s Metal Etches Metals Organics Solvents
Cantilever
Bridge
12
Multiple Levels gt Complex Structures
Multiple Structural Layers
Multiple Sacrificial Layers
Etch Sacrificial Layers
Anchored Joints
Substrate
Free Standing Joints
13
Surface Micromachines
http//mems.sandia.gov/scripts/images.asp
14
Bulk Micromachining

• Anisotropic Etching
• (Silicon in KOH)
• All crystal planes etch much faster than 111

(100)/(111) plane intersection 54.7o
15
Micromachined Sensors

• Pressure Sensor
• Thin Silicon Membrane deforms with pressure
• Piezoresistors change with strain induced by
  bending membrane
• Packaging requires sealing to maintain pressure
  differential

Photo of a packaged pressure sensor Motorola, Inc.
16
Accelerometer

• Accelerometer for automobile air bag
• Surface micromachined, capacitive sensor
• Sensor Electronics on same substrate smart

Analog Devices ADXL-50
17
Actuators
C. Keller MEMS Precision Instruments http//www.me
mspi.com
Micro light-bulb
Micro Switch
UCDavis
K. Petersen, IBM
18
Pump Flow Sensor

• Flow
• differential pressure across an integrated
  channel.
• Pump
• piezo-electric disk sitting on top of a thin,
  silicon membrane.
• Combined assembly
• measures 6.0x2.5x9 cm.

Flow Sensor
Piezo-electric Pump
B. Van der Schoot and M. Boillat University of
Neuchatel, Switzerland
19
Microthruster
UCDavis
20
Micromotors
MCNC Electrostatic Micromotor

• Motors, engines and turbines all have been made
  in and on silicon.

UCDavis
Nickel LIGA gear Sandia National Labs
Si Bulk micromachined Linear Synchronous Motor
21
Microfluidics

• Micro droplet manipulated by electrowetting of
  electrodes
• C. J. Kim, UCLA
• http//cjmems.seas.ucla.edu

• Fluid transport from needles to microchannel by
  capillary force
• E. Mukerjee, UCDavis

22
Micro Power Sources

• Micro Fuel Cell
• J. Morse, LLNL

Lawrence Livermore National Laboratories
http//www-eng.llnl.gov/explo_resear/mems_pg2.html
23
Surface Plasmon Resonance Microsystem
MicroInstruments Systems Laboratory, MISL
UCDavis
UCDavis

• A multi- layer, assembly of microfabricated
  components
• Mechanical Torsional Micromirror
• Optical GRIN Lens Optical Fiber
• Position Sensitive PhotoDiode
• Alumina Hybrid Electronic Substrate

Operation Polarized optical beam reflects off a
thin metal film. At the resonance angle, the
optical energy is completely converted into a
surface plasmon (zero reflection). The SPR angle
is a strong function of the surface dielectric.
http//www.ece.ucdavis.edu/misl/Homepage.htm
24
SPR Response
MicroInstruments Systems Laboratory, MISL
UCDavis
Response of SPR to avidin adsorption on a
biotynilated gold surface
25
Micro-ALPS?

• Number of sensors
• information
• Functions
• capability
• Lifetime
• Reduction in power
• redundancy

If MEMS can fly, then why shouldnt they swim?

• K. Pister, BSAC

http//robotics.eecs.berkeley.edu/pister/smartdus
t
